OneTouch®UltraEasy™
Owner’s Booklet
i
Symbols
Caution symbol: See instructions for use.
Serial number symbol
LOT
Lot Number
IVD
In Vitro Diagnostic Medical Device
Sterilized by irradiation
Expiration Date
DCO_06397001C_OTUE_OB_GB.qxd 4/13/07 3:17 PM Page i

ii
DCO_06397001C_OTUE_OB_GB.qxd 4/13/07 3:17 PM Page ii

iii
Welcome to the OneTouch®family!
We know how difficult it can be to understand and manage diabetes.
The right products and services can help make life with diabetes just a
little bit easier. At LifeScan, our priority is to ensure that you have the right
blood glucose meter to meet your needs.
That’s why we design products like the OneTouch®UltraEasy™Blood
Glucose Monitoring System. The OneTouch®UltraEasy™Meter makes it
simple to get a test result and review past results. This owner’s booklet
will help you learn how to use your meter properly. Please read it carefully.
As you get started, you may have questions and we are always here to
help. You can reach our Customer Care Freephone at 0800 121200(UK),
1800 535676 (Ireland). You can also obtain information at
www.LifeScan.co.uk.
DCO_06397001C_OTUE_OB_GB.qxd 4/13/07 3:17 PM Page iii

iv
• Getting to know your
OneTouch®UltraEasy™
Blood Glucose Meter and
Test Strips
• Turning your meter on and off
• Setting up your meter
NOTE: Before testing, read this
owner’s booklet carefully.
Table of contents
Setting up pg. 2
your system
Starting the test process pg. 7
Insert a test strip
Check the code on the test
strip vial before inserting the
strip. Make sure the three
contact bars are facing you.
Push the strip in as far as it
will go. Do not bend the strip.
The meter will turn on, show
a start-up test screen, and
then a code number. The first
time you use the meter, the
screen will display “––”
instead of a number.
Match the code displayed
on the meter with the code
on the test strip vial
If the code on the meter does
not match the code on the
vial, press ▲or ▼to change
the code. If the flashing blood
drop icon
R
appears on the
display before you are ready,
remove the strip and re-start
the test process.
The meter is ready for testing
when the flashing blood drop
icon
R
appears.
DCO_06397001C_OTUE_OB_GB.qxd 4/13/07 3:17 PM Page iv

Getting a blood sample pg. 10
Prepare the OneTouch
®
Lancing Device
Remove the blue cap and put
a new lancet in the lancing
device. Twist off the protective
disk. Replace the cap and
cock the lancing device.
Get a drop of blood
Hold the OneTouch®Lancing
Device firmly against your
finger. Press the release button.
Gently squeeze and/or
massage your fingertip until
a round drop of blood of at
least one microlitre ( actual
size) forms on your fingertip.
v
DCO_06397001C_OTUE_OB_GB.qxd 4/13/07 3:17 PM Page v

Applying blood and reading results pg. 22
Touch and hold the drop
of blood to the narrow
channel in the top edge of
the test strip
Blood will be drawn into the
strip. Keep holding the drop of
blood to the top edge of the
strip until the confirmation
window is full.
The meter will begin to count
down from 5 to 1. Then, your
blood glucose level appears
on the display along with the
unit of measure, and the date
and time of the test.
If the test results are
lower than, higher than,
or not what you expect,
see pages 24–25.
vi
DCO_06397001C_OTUE_OB_GB.qxd 4/13/07 3:17 PM Page vi

vii
Reviewing past results pg. 27
Caring for your system pg. 33
Control solution testing pg. 28
Detailed information about your system pg. 43
Index pg. 47
Understanding error and other messages pg. 37
DCO_06397001C_OTUE_OB_GB.qxd 4/13/07 3:17 PM Page vii

viii
Before you begin
Before using this product to test your blood glucose, carefully read this booklet and the
inserts that come with the OneTouch
®
Ultra
®
Test Strips and OneTouch
®
Ultra
®
Control
Solution. Take note of warnings and cautions throughout this booklet, which are identified
with
æ
. Many people find it helpful to practice the test with control solution before testing
with blood for the first time. See pages 28–32 in the Control solution testing section.
Intended use
The OneTouch
®
UltraEasy™ Blood Glucose Monitoring System is intended to be used for the
quantitative measurement of glucose (sugar) in fresh capillary whole blood. The
OneTouch
®
UltraEasy
™
System is intended for use outside the body (in vitro diagnostic use)
by people with diabetes at home and by healthcare professionals in a clinical setting as an
aid to monitor the effectiveness of diabetes control. It should not be used for the diagnosis
of diabetes or for testing newborns.
Test principle
Glucose in the blood sample mixes with special chemicals in the test strip and a small
electric current is produced. The strength of this current changes with the amount of glucose
in the blood sample. Your meter measures the current, calculates your blood glucose level,
displays the result, and stores it in its memory.
DCO_06397001C_OTUE_OB_GB.qxd 4/13/07 3:17 PM Page viii

The OneTouch®UltraEasy™Blood Glucose Monitoring System
To test with the OneTouch®UltraEasy™System,
you will need the following:
a. OneTouch®UltraEasy™Meter (battery included)
b. OneTouch®Ultra®Control Solution
c. OneTouch®Lancing Device
If another type of lancing device was
included, see the separate instructions that
came with that lancing device.
d. OneTouch®AST™Clear Cap
e. OneTouch®UltraSoft®Sterile Lancets
f. Carrying Case
g. You will also need OneTouch®Ultra®Test Strips.
Some kits do not include strips.
Strips are sold separately.
Documents in your kit include this
owner’s booklet, a quick reference guide,
a control solution insert and a warranty
registration card.
If any items are missing from your kit,
call Customer Care.
æ
WARNING: Keep the meter and testing
supplies away from young children. Small
items such as the battery door, battery, test
strips, lancets, protective disks on the
lancets and control solution vial cap are
choking hazards.
a
e
gb
f
1
d
c
DCO_06397001C_OTUE_OB_GB.qxd 4/13/07 3:17 PM Page 1

2
TEST STRIP
Edge to
apply sample
Confirmation
window
Contact bars
Insert into
test port
Getting to know your OneTouch®UltraEasy™Blood Glucose Meter and test strips
Setting up your system
FRONT
BACK Battery door
Meter battery
Up and down buttons
Turns the meter on or off
Select or change information
Test port
Insert test strip
here to turn meter
on for testing
mmol/L is the pre-set unit of measure
Display
with battery door
open
DCO_06397001C_OTUE_OB_GB.qxd 4/13/07 3:17 PM Page 2

Turning your meter on
To perform a test, insert a test strip as far as it will
go. The display will turn on and the meter will briefly
perform system checks. Or, to change the time and
date, start with the meter off, then press and
hold ▼for five seconds until the start-up test screen
appears. After the test screen, the pre-set time and
date will appear on the display. Or, if you want to
turn the meter on to review past results, start with
the meter off, then press and release ▼.
Every time you turn your meter on, a start-up test
screen will appear for two seconds. All segments of the display should appear briefly on
the test screen to tell you that the meter is working properly. To check that all display
segments are working, as soon as the start-up test screen appears, press and hold ▲ to
keep the test screen display on. Release ▲to proceed to the next step.
If the meter does not power on, try changing the meter battery. See pages 35–36.
Turning your meter off
There are several ways to turn your meter off:
• Press and hold ▼for two seconds, when reviewing past results.
• Your meter will turn off by itself if left alone for two minutes.
• Before or after completing a test, remove the test strip.
3
Setting up your system
æ CAUTION: If any information
is missing from the start-up test
screen, there may be a problem
with the meter. Call Customer
Care.
DCO_06397001C_OTUE_OB_GB.qxd 4/13/07 3:17 PM Page 3

4
Setting up your system
Setting the time and date
Your OneTouch®UltraEasy™Meter comes with the time, date and unit of measure
pre-set. Before using your meter for the first time or if you change the meter battery, you
should check and update the time and date. Make sure you complete steps 1 to 6 below
to ensure your desired settings are saved.
Step 1
Turn the meter on, see page 3
After the test screen, the pre-set time and date will
appear on the display for five seconds.
The hour will now start flashing.
NOTE: If a setting does not need to be updated, simply wait five seconds. The meter
display will automatically advance to the next setting.
æ
WARNING: If your display shows mg/dL rather than mmol/L, contact Customer Care.
You cannot change the unit of measure. Use of the wrong unit of measure may cause you
to misinterpret your blood glucose level, and may lead to incorrect treatment.
DCO_06397001C_OTUE_OB_GB.qxd 4/13/07 3:18 PM Page 4

Step 2
Set the hour
With the hour flashing on the display, press and release ▲or ▼to go forward or backward
one hour. To move faster, hold the ▲or ▼buttons down. When the correct hour appears
on the display, wait five seconds. Your entry will be saved and you will move to the next
setting.
The minutes will now start flashing.
Step 3
Set the minutes
Press ▲or ▼to change the minutes. When you have
the correct minutes on the display, wait five seconds
to move to the next setting.
The year (last two digits only), month and day appear
on the display and the year flashes.
Step 4
Set the year
Press ▲or ▼to change the year. When you have the
correct year on the display, wait five seconds to move to the next setting.
The month will now start flashing.
5
Setting up your system
DCO_06397001C_OTUE_OB_GB.qxd 4/13/07 3:18 PM Page 5

6
Setting up your system
Step 5
Set the month
Press ▲or ▼to change the month. When you have
the correct month on the display, wait five seconds to
move to the next setting.
The day will now start flashing.
Step 6
Set the day
Press ▲or ▼to change the day. When you have the
correct day on the display, wait five seconds to move
to the next screen.
Your time and date settings will be displayed for five
seconds. After the five seconds, the settings will be
saved and the meter will then turn off.
If you want to adjust your settings, press ▲or ▼
while the time and date are still on the display. You
will be returned to the first set-up screen where you
can begin with the hour.
DCO_06397001C_OTUE_OB_GB.qxd 4/13/07 3:18 PM Page 6

7
Starting the test process
Have these things ready when you test your blood glucose level:
• OneTouch®UltraEasy™Meter
• OneTouch®Ultra®Test Strips
• Lancing device
• Sterile lancets with protective disks
• OneTouch®Ultra®Control Solution
NOTE:
• Use only OneTouch®Ultra®Test Strips with your OneTouch®UltraEasy™Meter.
• Make sure your meter and test strips are about the same temperature before you test.
• Testing must be done within the operating temperature range (6–44°C). For the most accu-
rate results, try to test as close to room temperature (20–25°C) as you can.
• You can perform a blood glucose test while your OneTouch®UltraEasy™
Meter is inside its case.
Step 1
Check the code on the test strip vial before inserting the strip
Code numbers are used to calibrate your meter with the test strips you are
using to obtain accurate test results. You must code the meter before using it for the first
time and then every time you change to another vial of test strips.
æCAUTION: If you cannot test due to a problem with
your testing supplies, contact your healthcare
professional or LifeScan Customer Care. Failure to test
could delay treatment decisions and lead to a serious
medical condition.
DCO_06397001C_OTUE_OB_GB.qxd 4/13/07 3:18 PM Page 7

After the start-up test screen appears, the meter will
display the code from your last test. If a constant and
a flashing “––” appear instead of a code number, such
as when you are first using the meter, follow the
instructions on the next page to change to a numerical code.
8
Starting the test process
æCAUTION: OneTouch®Ultra®Test Strips are for single use only. Never
re-use a strip that had either blood or control solution applied to it.
Step 2
Insert a test strip to turn on the meter
Start with the meter off. If you have turned the meter on to change
settings or review past results, turn it off. Remove a test strip from its
vial. With clean, dry hands, you may touch the test strip anywhere
on its surface. Do not bend, cut or modify the test strips in any way.
Use each test strip immediately after removing it from the vial.
Hold the meter as shown and insert the test strip into the test port.
Make sure the three contact bars are facing you. Push the strip in
as far as it will go. Do not bend the strip.
æ CAUTION: The test strip vial contains drying agents that are harmful if inhaled or
swallowed and may cause skin or eye irritation.
DCO_06397001C_OTUE_OB_GB.qxd 4/13/07 3:18 PM Page 8

Step 3
Match the code on the meter with the code on the test strip
vial
If the code on the meter does not match the code on the test strip
vial, press ▲or ▼to match the code number on the test strip vial.
The new code number will flash on the display for three seconds,
and then stay constant for three seconds. The display will advance
to the screen with the flashing blood drop icon
R
.
If the codes already match, wait three seconds. The
display will advance to the screen with the flashing
blood drop icon
R
.
The meter is now ready to perform a blood glucose test.
NOTE:
• If the screen with the flashing blood drop
icon
R
appears before you are sure the codes
match, remove the test strip, wait until the meter turns off, then re-start from step 1, see
page 7.
• If you press ▲by mistake so that the control solution test symbol CtL appears on the
display, press ▲
again to change it back to the screen with the flashing blood drop icon
R
.
9
Starting the test process
æCAUTION: Matching the code on the meter and the code on the test strip vial is essential to
obtain accurate results. Each time you test, check to make sure the code numbers match.
DCO_06397001C_OTUE_OB_GB.qxd 4/13/07 3:18 PM Page 9

10
Getting a blood sample
Overview of the OneTouch®Lancing Device
NOTE: If you do not
have a OneTouch®
Lancing Device,
please refer to the
instructions that
came with your
lancing device.
OneTouch®UltraSoft®Sterile Lancet
Blue cap* (for fingertip sampling)
Depth indicator
*The blue cap and OneTouch®AST™Clear Cap are also used for depth adjustment.
Cocking control
Release button
OneTouch®AST™Clear Cap*
(for alternate site sampling)
Lancet point
Protective disk
æCAUTION: To reduce the chance of infection:
• Make sure to wash the puncture site with soap and water
before sampling.
• Never share a lancet or a lancing device with anyone.
• Always use a new, sterile lancet—lancets are for single use only.
• Keep your meter and lancing device clean. See page 34.
DCO_06397001C_OTUE_OB_GB.qxd 4/13/07 3:18 PM Page 10

11
Getting a blood sample
Choosing the right sampling site at the right time
The OneTouch® UltraEasy™Meter allows you to sample blood from your fingertip,
forearm or palm. Forearm and palm sampling is also referred to as “alternate site
testing” (AST). At times, results obtained at the forearm or palm may be different
from a fingertip measurement. Talk to your healthcare professional before you
begin using your forearm or palm for sampling.
If you are testing:
Routinely before meals
Prior to or more than two hours after:
• a meal
• a rapid-acting insulin injection or insulin pump bolus
• exercise
When your blood glucose is changing rapidly, such as:
• within two hours after a meal
• within two hours after a rapid-acting
insulin injection or insulin pump bolus, or
• during or within two hours after exercise
When you are concerned about the possibility of
hypoglycaemia (low blood sugar)
Fingertip
Fingertip,
forearm, or
palm
Use blood
sample from your:
DCO_06397001C_OTUE_OB_GB.qxd 4/13/07 3:18 PM Page 11

12
Getting a blood sample
æCAUTION: Do not test on your forearm or palm when:
• You think your blood glucose is rapidly falling, such as within two hours of
exercise or a rapid-acting insulin injection or insulin pump bolus. Testing with a
fingertip sample may identify hypoglycaemia or an insulin reaction sooner than
testing with a forearm or palm sample.
• It has been less than two hours after a meal, a rapid-acting insulin injection or
insulin pump bolus, physical exercise, or you think your glucose level is changing
rapidly.
• You are concerned about the possibility of hypoglycaemia or an insulin reaction,
such as when driving a car. This is especially important if you suffer from
hypoglycaemia unawareness (lack of symptoms to indicate an insulin reaction).
Remember: Consult with your healthcare professional before using your forearm or
palm for testing.
DCO_06397001C_OTUE_OB_GB.qxd 4/13/07 3:18 PM Page 12
