ONEUW ONE160x User manual

Thank you for purchasing an ONEUW product!
We have created this innovative underwater strobe by interpreting
your requests and suggestions with the highest technological
expression and an extreme attention to quality.
Please read this user guide carefully before using your ONE160x
underwater strobe. Only in this way you will be able to use it to its full
potential in absolute safety for yourself and for others.
For any clarification or additional information please do not hesitate to
contact us.
We are confident that this tool will become for you a faithful
companion in your photographic path and a valuable aid in achieving
the greatest satisfactions.
We give you a light for underwater photography "state of the art", it is
now up to you with your imagination to realize the most beautiful
images.
Light becomes emotion, enjoy it.
2018-12_04_EN

CONTENTS
IMPORTANT INFORMATION
1.0 CE Mark - Safety notes .......................................................... 1
1.1 CE Mark ................................................................................... 1
1.2 Warnings and caution .............................................................. 1
1.3 Warnings and informations in the chapters ............................ 3
BASIC INFORMATION
2.0 Key features overview .......................................................... 4
3.0 Available versions ................................................................. 6
3.1 Nikon - Flash exposure modes ................................................. 6
3.2 Canon - Flash exposure modes ................................................ 7
3.3 Version identification .............................................................. 7
3.4 Firmware upgrade ................................................................... 7
4.0 Strobe parts and controls ...................................................... 8
GETTING STARTED - POWER SUPPLY MANAGMENT
5.0 Power supply managment .................................................. 10
5.1 Battery compartment opening .............................................. 10
5.2 Battery compartment closing ................................................ 10
5.3 Battery pack installing and removing .................................... 11
5.4 Battery pack recharging ......................................................... 11
5.5 Battery pack state of charge check ........................................ 12
5.6 Air transport .......................................................................... 13
6.0 Strobe switching on/off ...................................................... 14
CONTROLS FUNCTIONS - DISPLAY INDICATIONS
7.0 Lever selectors function ...................................................... 15
7.1 MAIN lever selector - Pilot light ............................................. 15
7.2 MAIN lever selector - TTL mode ............................................ 15
7.3 INPUT lever selector - Input mode ........................................ 15
7.4 Storing operating parameters ............................................... 16
I

CONTENTS
8.0 Rotary control switch function ............................................ 17
9.0 Display indications .............................................................. 18
9.1 Inverted display mode - Check flash ...................................... 20
9.2 Power output reading ........................................................... 20
FLASH EXPOSURE MODES - ADVANCED OPERATIONS
10.0 Flash exposure modes ......................................................... 21
10.1 i-E-TTL - film-TTL auto mode .................................................. 21
10.2 s-TTL auto mode .................................................................... 22
10.3 Manual mode ........................................................................ 23
11.0 Rear-curtain sync ................................................................ 25
11.1 Rear-curtain sync Nikon cameras .......................................... 25
11.2 Rear-curtain sync Canon cameras ......................................... 25
12.0 Pilot light ............................................................................ 26
12.1 Pilot light manual switching on/off ....................................... 26
12.2 Autofocus assistence mode ................................................... 26
CONNECTION - SYNCHRO CABLES - FIBER OPTIC
13.0 Connectors - Synchro cables ................................................ 27
13.1 Synchro cable socket ............................................................. 27
13.2 Synchro cables ....................................................................... 27
13.3 Fiber-optic cable socket ......................................................... 28
13.4 Fiber-optic cables .................................................................. 28
SINGLE-STROBE AND MULTI-STROBE SET-UP
14.0 Single-Strobe and Multi-Strobe set-up ................................ 29
14.1 Nikon cameras ....................................................................... 29
14.2 Setting the ONE160's SLAVE mode ........................................ 30
14.3 Nikon connection wiring ........................................................ 31
14.4 Canon cameras ...................................................................... 33
14.5 Canon connection wiring ....................................................... 34
II

CONTENTS
PROBLEMS AND ERROR INDICATIONS - MAINTENANCE
15.0 Problem and error indications ............................................. 36
15.1 Overheating protection ......................................................... 36
15.2 Battery pack excessive discharge protection ......................... 37
16.0 Overpressure safety valve ................................................... 38
17.0 Maintenance ....................................................................... 40
ACCESSORIES - SPECIFICATION
18.0 Accessories ......................................................................... 41
18.1 Standard accessories ............................................................. 41
18.2 Optional accessories .............................................................. 41
19.0 Specification ....................................................................... 42
REFERENCE INFORMATION - SUPPLEMENT
20.0 Warranty terms .................................................................. 43
21.0 Environmental protection - Information on disposal ........... 44
21.1 Electrical and electronic equipment disposal ........................ 44
21.2 Battery disposal ..................................................................... 45
22.0 General information - Notices ............................................. 46
22.1 Trade mark® information ...................................................... 47
23.0 Annotations ........................................................................ 48
III

IMPORTANT INFORMATION
1.0 Safety Notes
1.1 CE Mark
The ONE160x strobe has been developed
and manufactured with safety standards
in accordance with applicable CE
Directives.
1.2 Warnings and caution
• Use the product for its intended purpose
– underwater photography –
following the modes and instructions given by this user guide.
• Do not attempt to disassemble the strobe under any circumstances.
High voltages that can cause fatal electric shocks are present in the
electronic components of it. Any tampering with the flash will void
the warranty. All inspections and repairs must be carried out at
ONEUW’s premises or authorized service centers.
• Never short-circuit the terminals of the battery packs and do not
attempt, for any reason, to disassemble them.
1

IMPORTANT INFORMATION
• Do not leave the strobe in overheated environments such as car
interiors in summer or boat engine compartments. Do not expose
the strobe in summer directly to the sun for prolonged periods,
overheating can damage the unit and create dangerous situations.
• To recharge the battery packs, use only the specific battery charger
supplied with the strobe, following the appropriate instructions for
use (chapter 5.4). Recharge the battery packs in cool rooms and
avoid overheating when using them.
• If the strobe is flooding turn it off immediately and for your safety
do not use it until reconditioning to technically efficient condition.
Send the unit to our plant or authorized service centers for
inspection. Carefully read the instructions given in this manual in
the relevant chapter (16.0)
• Strictly follow the instructions on how to connect the strobe.
Camera model, wiring mode, single or dual units, interface with
strobes of other brands, are all parameters that should be carefully
checked for compatibility. The strobe and the units connected may
be seriously damaged due to improper connections. Carefully read
the instructions given in this manual in the relevant chapter (14.0).
• Do not fire the strobe directly into the lens of a digital camera, the
camera sensor may become damaged.
• Do not fire the strobe directly into the eyes of someone, and do not
look at the emission of lightning flash, it could cause retinal injury.
2

IMPORTANT INFORMATION
1.3 Warnings and informations in the chapters
The following chapters contain further notes in the form of "danger
warnings" or "technical information notes".
The type of annotation is easily recognizable by the icon that precedes
it as indicated below.
This icon indicates warnings concerning potentially dangerous
situations that could result in property damage or personal injury.
i This icon indicates warnings that allow you to deepen your
technical knowledge of the equipment and its correct use.
3

BASIC INFORMATION
2.0 Key features overview
ONE160x is a professional underwater strobe with maximum energy of
157 Ws (J) and Guide Number 20 (ISO100-1m-full power). The beam
angle is 130° (GN16).
The body of strobe is machined from a solid block of anticorodal
aluminium, protected by a hard anodizing treatment with nanotech
quartz coating.
The depth rating is 200 m.
The strobe control is entrusted to a pair of powerful CPU that manage,
one the digital communication between the camera and the strobe, i-
TTL protocol by Nikon and E-TTL protocol by Canon, and the other the
power circuits in order to optimize the performances of the unit in
every situation, in addition to operational safety and battery life.
The possibility of firmware upgrade allows us to guarantee, within
hardware limits, the future compatibility with the new digital cameras.
Two large lever selectors, a multifunction rotary control switch and a
wide control display allows us every function to be setted and
monitored.
The left MAIN lever selector operates the control of the pilot light and
the TTL flash light reading mode. The 7-PL-TTL control lamps indicate
the flash readiness, the switching on of the pilot light and the selection
of the TTL mode respectively.
4

BASIC INFORMATION
The right INPUT lever selector allows us to select input and connection
mode that we intend to use: synchro cable socket, fiber-optic cable
socket, optical receiver on parabolic reflector for slave mode. The
control lamps indicate the selected SYN-OPT-SLV input.
The rotary control switch adjusts power output in manual mode or
exposure compensation in TTL mode. The selected energy level or
exposure compensation are clearly visible in the center section of the
wide display.
The lighting element is a professional and oversized circular flash lamp,
with a slightly warm coating, mounted on parabolic reflector with
dome port.
The strobe is equipped with a LED coaxial pilot light with two power
levels that can be selected manually or automatically with focusing.
Power is supplied by a removable NiMH battery pack rechargeable by
the dedicated desktop battery charger. More than 250 flashes at full
power are ensured with recharge times ranging from 0.1 to 1.8
seconds.
5

BASIC INFORMATION
3.0 Available versions
The ONE160x digital strobe is available for Nikon and Canon cameras.
The choice of version is carried out in purchase moment.
Depending on the version, the digital communication software
between camera and strobe, managed by the first CPU, is compatible
with Nikon's i-TTL or Canon's E-TTLII protocols.
In both version, Nikon and Canon, the TTL auto flash exposure mode is
available when in use are digital cameras connected to the strobe by a
synchro cable correctly wired according to the specific i-TTL or E-TTL
protocol (chapter 14.0). Are also supported auxiliary functions such as
AF assist illuminator by pilot light and rear-curtain synchronization.
In addition to the i-E-TTL protocols managed with synchro cable, the s-
TTL auto flash exposure mode is also available. This auto flash
exposure mode is the same for both version.
3.1 Nikon - Flash exposure modes
§ i-TTL auto flash exposure mode - digital camera connected to
strobe via synchro cable (wiring in according to the specific
protocol - chapter 14.1)
§ film-TTL auto flash exposure mode - film camera (or digital camera
with converter) connected to strobe via synchro cable
§ s-TTL auto flash exposure mode - strobe connected via fiber-
optic cable
§ manual manual flash exposure mode - strobe connected via
synchro cable, fiber-optic cable or by optical slave receiver
6

BASIC INFORMATION
3.2 Canon - Flash exposure modes
§ E-TTLII auto flash exposure mode - digital camera connected to
strobe via synchro cable (wiring in according to the specific
protocol - chapter 14.2)
§ film-TTL auto flash exposure mode - film camera (or digital camera
with converter) connected to strobe via synchro cable
§ s-TTL auto flash exposure mode - strobe connected via fiber-
optic cable
§ manual manual flash exposure mode - strobe connected via
synchro cable, fiber-optic cable or by optical slave receiver
3.3 Version identification
When you switch on the strobe, as first information, the release
number of firmware is showed on display. If nothing is visualized on
display in addition to the number, the strobe firmware is for Nikon
cameras. If the visualized number is preceded by the _underscore
symbol, the strobe firmware is for Canon cameras.
3.4 Firmware upgrade
The unit's firmware is upgradable for future functionality. The upgrade
has to be carried out at ONEUW's premises. It is also possible to
change the firmware from Nikon to Canon, or vice versa, with the
complete replacement of the operating software.
7

BASIC INFORMATION
4.0 Strobe parts and controls
8

BASIC INFORMATION
9

GETTING STARTED - POWER SUPPLY MANAGMENT
5.0 Power supply managment
Power is supplied by a removable NiMH battery pack made with the
best professional high-energy cells from Panasonic. More than 250
flashes at full power are ensured with fully-charged battery pack. The
recharge times, electronically managed by CPU, ranging from 0.1 to 1.8
seconds. The removable battery pack is located inside the strobe in a
waterproof battery compartment which you may access by special
closing cap.
i The power circuits to optimize performances in every situation are
managed by a dedicated CPU. In this way the battery pack voltage
and current are contantly monitored and adjusted to guarante the
best performance and to avoid overload currents or cells excessive
discharge.
5.1 Battery compartment opening
Rotate the closing cap selector by pressing the release button
counterclockwise to the open position (selector dot at the open
padlock symbol). When this position is reached, there will be a click
that will keep the selector in place. It will then be possible, with
adequate traction, to pull out the closing cap.
5.2 Battery compartment closing
Before inserting the cap into the battery compartment, make sure that
it is in the open position. Place the cap and push it all the way into the
slot. Turn the cap selector, in a clockwise direction, to the close
position (selector dot corresponding to the close padlock symbol). In
this position the release button will return to the initial state activating
the safety lock.
10

GETTING STARTED - POWER SUPPLY MANAGMENT
5.3 Battery pack installing and removing
The battery pack inserting in a univocal way, due its semi-circle shape,
the side to be inserted is the one that shows the positive + and -
negative power pins.
The battery pack is easily inserted or removed thanks to the tilting
metal handle placed in the front.
5.4 Battery pack recharging
The battery pack must be charged using only the the included specific
battery charger. Insert the AC power plug of the charger into the
power outlet (check that the electrical voltage of the appliance
corresponds with that of your electric network). When the device
indicator light vill be green it's ready to charge. Connect the DC cable
connector of the charger to the power connector of the battery pack.
When the battery pack is charcing the device indicator light turns red.
When the recharge of battery pack is completed, after a maximum of
90 min, the charger indicator light turns green.
11

GETTING STARTED - POWER SUPPLY MANAGMENT
i The battery compartment is full watertigh. In the event of water
seeping due a wrong battery cap compatment positioning, the
inside of strobe body, where the electronic is installed, will be not
flooded. If the power pins into the battery compartment are
oxidized they have to replaced. The repair must be carried out at
ONEUW’s premises or authorized service centers.
Do not charge the battery pack when it is placed in battery
compartment - remove and charge it in a cool and ventilated place
to avoid overheating.
Do not insert the battery pack into the strobe compartment after
charging if they are still hot.
Do not handle the battery packs or battery charger with wet hands.
Do not remove the battery pack from battery compartment when
strobe is turn on.
5.5 Battery pack state of charge check
The battery charge status is shown every time at unit turn on/off. The
three-level charge indication is displayed by a series of horizontal
segments, as shown in the following page. The data is to be considered
as indicative and depends on external factors such as temperature, age
of the batteries and their wear. For a correct battery charge indication
in shut-down step, before turn-off the strobe wait for about 20-30
seconds without flashing.
12

GETTING STARTED - POWER SUPPLY MANAGMENT
i To improve the capacity and duration of battery packs some full
discharge-charge cycles are recommended every three months.
i Do not discharge the battery pack by flashing. Use the pilot light
only. The unit automatically switches off when the battery is
discharged.
i Do not recharge an already charged battery pack, you may
damage it.
5.6 Air transport
Nickel Metal Hydride batteries are not subject to air transport
restrictions as indicated in the IATA International Air Transport
Association specific declaration “Guidance on the air transport of
Batteries, nickel-metal hydride UN3496 - ” V.2 August 2016“ estratta
dal testo “Dangerous Goods Regulations (DGR) 57th edition 2015”.
Alway travel with the minimum battery pack charge level. In this
way any dangerous situation that may arise will be less critical and
of lower intensity and duration.
13

GETTING STARTED - POWER SUPPLY MANAGMENT
6.0 Strobe switching on/off
The strobe is switched on and off by pressing the MAIN and INPUT
lever selector simultaneously.
Turning on the unit is indicated by the visual indications on the display
and by a single beeping sound after which the lever selectors can be
released.
When the strobe is switched on, the following information are showed
on the display:
-Firmware release number and strobe version
-Battery charge status
Together with this information, all the indicator lights on the display,
MAIN section on the left and INPUT section on the right, light up at the
same time for a check.
The strobe is switched off by pressing the MAIN and INPUT lever
selectors simultaneously for a few seconds. A first beeping sound is
emitted after one second and keeping the pressure on the lever
selectors a second acoustic signal will warn that the lever selectors can
be released. The strobe will turn off after displaying the battery charge
status on the display.
i The left and right lever selectors, operated either individually or
together, give different commands depending on the operating
time that we can classify as short (one pulse) or long (one or more
seconds depending on the command).
14

CONTROLS FUNCTIONS - DISPLAY INDICATIONS
7.0 Lever selectors function
Using the lever selectors, we set the operating parameters of the flash.
The red MAIN left lever selector operates the control of the pilot light
and the TTL auto flash exposure mode.
The black INPUT right lever selector selects the active input of the flash.
7.1 MAIN lever selector - Pilot light
Pressing it for a short time the pilot light switches on sequentially at
50%, then at 100% output power and finally turns off it. The pilot light
switch on is signaled by the light up of the PL indicator light and by a
single beeping sound after which the MAIN control selector can be
released.
7.2 MAIN lever selector - TTL mode
Pressing for a long time, it allows the change from manual mode to TTL
mode, both with synchro cable connection and with optical fiber. The
activation of the TTL auto flash exposure mode is signaled by the light
up of the TTL indicator light. At this action will be released immediately
a first beeping sound and after about a couple of seconds will be issued
a further one. At this second warning you can release the control lever.
7.3 INPUT lever selector - Input mode
Pressing it for a short time selects input and connection mode that we
intend to use: synchro cable socket, fiber-optic cable socket, optical
receiver on parabolic reflector for slave mode. The selected input is
signaled by the light up of the respective indicator light SYN-OPT-SLV
and by a single beeping sound after which the INPUT control selector
can be released.
15
