OPERATIONS OPERATIONS
The AUTO Mode :
1. Press "MODE" button to cyclically step through the COOL, FAN,
DRY & AUTO modes and stop when AUTO mode is selected.
2. AUTO mode symbol can be seen on the remote display when you
select the AUTO mode.
3. In AUTO mode, the fan speed can be changed by pressing
FAN button.
4. In AUTO mode, the unit automatically runs at preset temp.
LIGHT Operation:
You can ON/OFF the LED DISPLAY on indoor unit by press “ LIGHT “ button on remote
control.
CLOCK Setting:
Press the “CLOCK” button on remote to set the real time clock, clock time will blink on
remote display. Press “+ ” or “-” keys to set the desired time. press again after setting to
confirm the change.
TIMER Operation:
You can program your split AC to switch itself ON or OFF at particular time.
Maximum set time is 24 hrs, with 1 min increment.
ON TIMER:
When the AC is "OFF" (in standby), press "TIMER ON" Button on remote to use this
feature as the ON TIMER. (make sure that MCB switch is "ON”
The "TIMER ON" symbol seen on the remote display.
For EXAMPLE:
Suppose you want to switch ON the AC at 08:00.
Press "TIMER ON" button, when AC is in OFF condition.
Press “+ ” or “-” buttons to set 08:00 to switch on AC. Press again
“TIMER ON” after setting the time to confirm Timer ON.
Display on Remote will show "TIMER ON”.
TIMER OFF FUNCTION:
When the AC is "ON", press "TIMER OFF" Button on remote to use this feature as
the OFF TIMER. The "TIMER OFF" symbol seen on the remote display.
For EXAMPLE:
Suppose you want to switch OFF the AC after 08:30. Press "TIMER OFF" button, when AC
is in ON condition.
OPER
TIMER ON
AUTO
OPER
Your split AC operates in one of four modes, COOL-DRY-FAN-AUTO. The modes button
cyclically chooses between the four operating modes.
The COOL mode:
In the cool mode, the compressor is in operation and your AC functions in the standard
operating mode, cooling your room to the desired set temp.
1. Press "MODE" button to cyclically step through the COOL, FAN,
DRY & AUTO modes and stop when cool mode is selected.
2. Cool mode symbol can be seen on the LCD panel when you select
the cool mode.
In this mode, you can change the temp. settings by pressing "+"
and "-” temp. buttons.
You can change the fan speed setting by pressing FAN button.
3. If the Room temp. is more than the set temp., then the compressor &
outdoor FAN will remain ON and perform the Cooling operation.
If the room temp. achieves the temp. less than set temp., then the
Compressor & Outdoor FAN will remain OFF.
The DRY Mode:
In the DRY mode, your AC reduces the humidity within the room faster.
1. Press "MODE" button to cyclically step through the COOL, FAN,
DRY & AUTO modes and stop when DRY mode is selected.
2. DRY mode symbol can be seen on the LCD panel when you
select the DRY mode.
3. Indoor FAN will run at low speed.
4. Temperature can be changed.
The FAN Mode:
1. Press "MODE" button to cyclically step through the COOL, FAN,
DRY & AUTO modes and stop when FAN mode is selected.
2. FAN mode symbol can be seen on the LCD panel when
you select the FAN mode.
3. In FAN mode, only Indoor FAN will run at set speed and
Compressor & Outdoor Fan will remain off.
4. In this mode, you can change the Indoor FAN Speed.
OPER
OPER
OPER
