HomeTheater Speakers 23
SKS-HT540 7.1-Channel Home Theater Speaker System
SKF-540F 2-Way Bass Reflex Front Speakers
• 5˝ OMF diaphragm woofer x 2 • 1˝ balanced-dome, floating tweeter • Frequency response:
55 Hz–50 kHz • Magnetically shielded • Impedance: 8 ohms • Max. input power: 130 W
• Dimensions (WHD): 6 3/16˝ x 17 1/16˝ x 7 7/8˝ • Weight: 8.4 lbs.
SKC-540C 2-Way Bass Reflex Center Speaker
• 5˝ OMF diaphragm woofer x 2 • 1˝ balanced-dome, floating tweeter • Frequency response:
55 Hz–50 kHz • Magnetically shielded • Impedance: 8 ohms • Max. input power: 130 W
• Dimensions (WHD): 17 1/16˝ x 6 3/16˝ x 7 7/8˝ • Weight: 8.4 lbs.
SKM-540S/SKB-540 2-Way Bass Reflex Surround/Surround Back Speakers
• 3 1/8˝ cone woofer • 3/4˝ ceramic tweeter • Frequency response:60 Hz–20 kHz • Impedance:
8 ohms • Max. input power:130W • Dimensions (WHD):6 7/8˝ x 10 7/16˝ x 4˝ •Weight: 3.1 lbs.
SKW-540 Bass Reflex Powered Subwoofer
• Built-in 230W amplifier • Auto-standby/On circuitry • Output level control • 10˝ cone
woofer • Frequency response:25 Hz–150 Hz • Dimensions (WHD): 10 13/16˝ x 18 5/8˝ x 16 7/8˝
• Weight: 25.4 lbs.
SKS-HT240 6.1-Channel Home Theater Speaker System
SKF-240F 2-Way Bass Reflex Front Speakers
• 3 1/8˝ cone woofer x 2 • 1˝ balanced-dome tweeter • Rigid aluminum cabinet • Frequency
response: 55 Hz–35 kHz • Magnetically shielded • Impedance: 8 ohms • Max. input power:
100W • Dimensions (WHD): 5 1/8˝ x 19 11/16˝ x 3 9/16˝ • Weight: 5.5 lbs.
SKC-240C 2-Way Bass Reflex Center Speaker
• 3 1/8˝ cone woofer x 2 • 1˝ balanced-dome tweeter • Rigid aluminum cabinet • Frequency
response: 65 Hz–35 kHz • Magnetically shielded • Impedance: 8 ohms • Max. input power:
100W • Dimensions (WHD): 17 5/16˝ x 5 1/8˝ x 3 9/16˝ • Weight: 5.1 lbs.
SKM-240S/SKB-240 2-Way Bass Reflex Surround/Surround Back Speakers
• 3 1/8˝ cone woofer • 1˝ balanced-dome tweeter • Rigid aluminum cabinet • Frequency
response: 65 Hz–35 kHz • Magnetically shielded • Impedance: 8 ohms • Max. input power:
100W • Dimensions (WHD): 5 1/8˝ x 13 3/8˝ x 3 9/16˝ • Weight: 3.5 lbs.
SKW-240 Bass Reflex Powered Subwoofer
• Built-in 150W amplifier • Auto-standby/On circuitry • 8˝ cone woofer • Frequency response:
27 Hz–150 Hz • Dimensions (WHD): 10 13/16˝ x 20 3/8˝ x 16 3/16˝ • Weight: 30.9 lbs.
SKW-204 Bass Reflex Powered Subwoofer
• Built-in 230W amplifier • Auto-standby/On circuitry • 10˝ cone woofer • Continuously
variable crossover (50 Hz–200 Hz) • Phase switch (0° or 180°) • Line level inputs • Impedance:
100 k-ohms • Frequency response: 25 Hz–150 Hz • Dimensions (WHD): 10 13/16˝ x 18 5/8˝ x
16 7/8˝ • Weight: 26.0 lbs.
SKS-HT750 7.1-Channel Home Theater Speaker System
SKF-750F 2-Way Acoustic-Suspension Front Speakers
• 3 1/8˝ cone woofer x 2 • 1˝ balanced-dome tweeter • Magnetically shielded • Impedance:
8 ohms • Frequency response: 60 Hz–50 kHz • Max. input power: 110 W • Dimensions
(WHD): 5 1/2˝ x 14˝ x 3 11/16˝ •Weight: 4.0 lbs.
SKC-750C 2-Way Acoustic-Suspension Center Speaker
• 3 1/8˝ cone woofer x 2 • 1˝ balanced-dome tweeter • Magnetically shielded • Impedance:
8 ohms • Frequency response: 60 Hz–50 kHz • Max. input power: 110 W • Dimensions
(WHD): 14˝ x 5 1/2˝ x 3 11/16˝ • Weight: 4.0 lbs.
SKM-750S/SKB-750 2-Way Acoustic-Suspension Surround/Surround Back Speakers
• 3 1/8˝ cone woofer • 1˝ balanced-dome tweeter • Magnetically shielded • Impedance:
8 ohms • Frequency response: 60 Hz–50 kHz • Max. input power: 110 W • Dimensions
(WHD): 5 1/2˝ x 14˝ x 3 11/16˝ • Weight: 2.9 lbs.
Note:All speakers feature color-coded,push-type speaker terminals, speaker cables, and rubber spacers.The
center speaker has a base for horizontal mounting.
SKW-750 Bass Reflex Powered Subwoofer
• Built-in 230W amplifier • Auto-standby/On circuitry • Output level control • 10˝ cone
woofer • Frequency response:25 Hz–150 Hz • Dimensions (WHD): 10 13/16˝ x 19 15/16˝ x
16 3/16˝ •Weight: 24.7 lbs.
AS-240(S/B)Speaker Stand
• Hidden cable management • Durable anodized aluminum finish • Dimensions (WHD):10 5/8˝ x
43˝ x 10 5/8˝ • Weight: 11.7 lbs.
AS-140 Speaker Stand
• Hidden cable management • Steel construction • Dimensions (WHD): 10 5/8˝ x 35 3/16˝ x
10 5/8˝ (270 x 894 x 270 mm) •Weight: 6.0 lbs.(2.7 kg)
