Onkyo HT-S894(B) User manual

HT-S894
SERVICE MANUAL
SERVICE MANUAL
5.1-CH HOMETHEATER SYSTEM
Black model
MODEL HT-S894(B)
Ref. No. 3976
082006
120V AC, 60HzB MDD
- - - HT-R640 (AV Receiver) - - -
- - - - - - - - - - - - HTP-640 (5.1-channel Speaker Package) - - - - - - - - - - - -
- - - DV-SP404 (DVD Player) - - -
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK ON THE
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.

HT-S894
PACKING PROCEDURE-1
RECEIVER SECTION
A631
A601
(L & R)
A605
A631
A655
A655
A603
A821
A822
A823
A824
A825
A826
A801
A802
A803
A804
A805
A811
A813
<R>
Front side
Right side
marking
Front side
marking
Left side
marking
Front side
marking
<L>

HT-S894
PACKING PROCEDURE-2
SPEAKER SECTION
BOTTOM
SURROUND-R
SURROUND-L
FRONT-R
FRONT-L
CENTER
TOP
FRONT
CENTER
SP01 : INNER
SP02 : OUTER
SP04
SP03
SP10
SP04
SP04
SP04
SP05
(Top)
SP06
(Center)
SP07
(Bottom)
SP10
SKM-640S(L)
SKM-640S(R)
SKF-640F(R)
SKF-640F(L)
SKC-640C
SKW-540
Front side

HT-S894
PACKING PROCEDURE-3
OVERALL
HT-S894(B)
HT-S894(B)
HT-S894
DV-SP404E
DV-S P404
DV-SP404
BOTTOM
L = 15 ft.
(22# 4.5 m)
(Red / Black)
L = 30 ft.
(22# 9 m)
(Blue / Black)
L = 10 ft.
(22# 3 m)
(Green / Black)
SP13
SP13
L = 10 ft.
(3 m)
(Black / RCA)
L = 30 ft.
(22# 9 m)
(Gray / Black)
SP16
L = 15 ft.
(22# 4.5 m)
(White / Black)
SP18
20 pcs (1set)
SP12
SP11
SP14
SP15
SP04
SP08
SP08
SP09
SP09
SP19
(SP19a)
Front side
Refer to "PACKING
PROCEDURE-2"
Refer to "PACKING
PROCEDURE-1"
"DV-SP404"

1/1 PAGE
HT-S894
PACKING PROCEDURE PARTS LIS
T
RECEIVER SECTION
(
HT-R640
)
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PACKING A601 PAD (L & R / 1set) 1 29092339
PACKING A603 POLY BAG POLY BAG (850 x 650) 1 29100034-1A
PACKING A605 POLY BAG 350 x 250 1 29100097-1B
PACKING A631 TAPE NITTO NO.29 (Yellow) (1) 29110149
PACKING A655 LABEL (DES), 2sheets 1 29364543
PACKING A801 INS MANUAL En (HT-R640) 1 29344250
PACKING A802 INS MANUAL U9 (RC647/649/650/651) 1 29344188B
PACKING A803 INST SHEET En (XM RADIO) 1 29355602
PACKING A804 SHEET (SETUP) 1 29096036
PACKING A805 INST SHEET ERRATA (SP) 1 29355562
PACKING A811 WRNTY CARD (ONKYO) 1 29365102A
PACKING A813 HANDBILL (DS-A2) US 1 29380145
PACKING A821 REMO CON RC-668M 1 24140668
PACKING A822 BATTERY R6/AA (UM-3) 2 3010194
PACKING A822 or BATTERY R6/AA (UM-3) (2) 3010054
PACKING A823 ANT COIL NMA-3057 1 232140
PACKING A824 FM ANT AS Type W 1 292191
PACKING A825 CORD AS HDMI 1.5M 1 2010449
PACKING A826 TRM (WRENCH) 1 25060468
SPEAKER SECTION
(
HTP-640
)
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PACKING SP01 MIRAMAT SHEET L1950 x W550 x T0.5 (FOR SKW) 1 715-220011-00
PACKING SP02 PE BAG L1000 x W720 x T0.025 (FOR SKW) 1 700-820013-11
PACKING SP03 POLY BAG 300 x 100 (FOR AC CORD) 1 700-210001-11
PACKING SP04 TAPE NITTO NO.29 (Yellow) (1) 29110149
PACKING SP05 POLYFOAM TOP (TOP) 1 720-TS894T-00
PACKING SP06 POLYFOAM CENTER (CENTER) 1 720-TS894C-00
PACKING SP07 POLYFOAM BOTTOM (BOTTOM) 1 720-TS894B-00
PACKING SP08 POLYFOAM DUMMY-T (DUMMY) 2 720-TS894A-00
PACKING SP09 POLYFOAM DUMMY (DUMMY) 2 720-TS894D-00
PACKING SP10 PE BAG L440 x W320 x T0.025 (SKF/SKC/SKM) 5 700-820012-11
PACKING SP11 CARTON BOX HT-S894 (B) MDD 1 730-1S894B-10
PACKING SP12 MIRAMAT SHEET L535 x W490 (Between Receiver and SP) 1 715-220007-00
PACKING SP13 PP TAPE W50 (1) 29110071 or
PACKING SP13 or PP TAPE W48 OPP TAPE (1) 29110148 or
PACKING SP13 or PP TAPE NITTO 3703 SUPER W50L100 (1) 29110176
PACKING SP14 POLY BAG 350 x 250 1 29100097-1B
PACKING SP15 INS MANUAL En (HTP-640) (29344293) 1 640-HTS640-00
PACKING SP16 CABLE SET SP CABLE / RCA CABLE / POLY BAG 1 319-HTS894-00
PACKING SP18 LEG CUSHION PORON 1t x D7 x 20pcs / 1set 1 441-850100-01
PACKING SP19 STAND --- 1 D243-P64001B-10
PACKING (SP19a) CUSHION PORON 1t x 85 x 8 (For STAND) 2 442-801102-00
