HT-R592

North American, Brazilian and Taiwanese models ---> “DIMMER”

Asian models ---> “RT/PTY/TP”

RC-863M

AV RECEIVER

Black model

MODEL HT-R592(B)

Ref. No. 4438

032013

120V AC, 60HzB MDF

Black model for HT-S5600

120V AC, 60Hz

220-240V AC, 50/60Hz

B MDC, B MDS

B MMK, B MMQ

HT-R592

SERVICE PROCEDURE

O1.00/13119AL

D1.00/13125aLA

M1.00/13302ALU MMPU

(Main Microprocessor)

DSP

HDMI/Video Microprocessor

Version displayed

only for 3 seconds.

e.g.

M1.00/13302ALU Version of MMPU displayed only for 3 seconds.

e.g.

-

(TONE)

-

(TONE)

-

(TONE)

+(TONE)

1. Replacing the fuses

2. Safety check out

This symbol located near the fuse indicates that the

fuse used is slow operating type, For continued protection against

fire hazard, replace with same type fuse, For fuse rating, refer to

the marking adjacent to the symbol.

Ce symbole indique que le fusible utilise est e lent.

Pour une protection permanente, n'utiliser que des fusibles de meme

type. Ce demier est indique la qu le present symbol est apposre.

Press ON/STANDBY button while pressing down VCR/DVR button when the unit is POWER ON, then

the FL displays "CLEAR", and turn to STAND-BY.

Remove power cord from power line.

(U.S.A. model only)

After correcting the original service problem, perform the following safety check before releasing the unit to the customer.

Leakage current Check

Measure the leakage current to a known earth ground (water pipe or conduct etc.) by connecting a leakage current

tester between the earth ground and exposed metal parts of the unit (input/output ground terminals,

screw heads or metal overlays etc.).

Plug the power supply cord directly into a 120Vac 60Hz wall socket and turn ON/STANDBY button on.

Any current measured must not exceed 0.5mA.

3. To initialize the unit

F6401, F6402

F6401, F6402 or

F901

F901 or

F901

F901 or

R9001

10A-UL/T-233

10A-T/UL-ST2

8A-UL/T-233

8A-T/UL-ST2

4A-SE-EAK

4A-SE-TL250V

5A-UL-125V

252330GR

252333GR

252329GR

252261GR

252077GR

252277GR

252385T

<MDC, MDS, MDF>

<MMK, MMQ>

!

FUSE

REF NO. PART NAME DESCRIPTION PART NO. REMARKS

[Notes]

<MDC> : 120V,Canadian model

<MDF> : 120V,Taiwanese model

<MDS> : 120V,Brazilian model

<MMK> : 220/230-240V, Korean model

<MMQ> : 220/230-240V,Hong kong model

4. To check version of each Firmware

a. Push STANDBY/ON key while pushing down DISPLAY key to display MMPU(Main Microprocessor) version.

b. In display version, + (TONE) key and - (TONE) key are pushed to display another F/W version.

HT-R592/ 2295

DEBUG MODE-1

AUDIO DEBUG MODE-1/3

To set in Debug mode

1. Press and hold down DISPLAY button, then press ON/STANDBY button.

D1.00/13125aLA

M1.00/13302ALU

AUDIO dubug mode

4D48K1N 0FFPo0

e.g.

The version number of microprocessor is displayed

only for 3 seconds.

The version number of DSP is displayed

only for 3 seconds.

The operations of DSP and DIR etc are able to checked by the information displayed on FL in this debug mode.

This information will help to analysing digital audio no sound trouble.

Exit

e.g.

2. Press + (TONE) button while the version number of microprocessor is displayed.

3. Press DISPLAY button while the version number of DSP is displayed.

4. Press DISPLAY button.

Contents of Display

Number of digits -->

FL Display (e.g.)

Number of

digits

Contents State

1 DIR INPUT LOCK/UNLOCK E:UNLOCK

:LOCK

2 DIR INPUT RX

0:None

1:COAX1

2:COAX2

3:OPT1

4:OPT2

5:FRONT

8:HDMI1

9:HDMI2

3 DIR/ADC,FIX MODE D:Digital(SPDIF)

A:Analog

M:AnalogMultich

p:PCM FIXED

d:DTS FIXED

4-6 Sampling Freq,Emphasis 32K: 32 kHz w/o Emphasis

44K: 44.1kHz w/o Emphasis

48K: 48 kHz w/o Emphasis

64K: 64 kHz

88K: 88.2kHz

96K: 96 kHz

176:176.4kHz

192:192 kHz

32e: 32 kHz w Emphasis

44e: 44.1kHz w Emphasis

48e: 48 kHz w Emphasis

7 DIR DETECT TYPE 0:Analog

1:PCM

2:Not PCM

3:Data

4:DTS CD(Not used)

5:Multich

6:Not Decided

8 CODEC CLOCK MODE N:Normal

U:Up Sampling

H:High Sampling(Double Rate)

D:Down Smapling

Q:Quad Rate

10 DSP PORT bit0:NIC

bit1:DEC

bit2:BUSY

bit3:EXEC WAIT

Refer to "NIC DEC SPI Busy Ecec wait"

in DEBUG MODE-2

11-12 DSP SEQUENCE 00-FE:NotFree

2D:Mute Control

FF:Free

Refer to "DSP Sequence" in

DEBUG MODE-3

13 DSP DETECT FORMAT P:PCM(Analog)

D:Dolby Digital

d:DTS

A:AAC

d:DTS

A:AAC

S:DSD

p:DolbyDigital+

T:TrueHD

H:DTSHD High Resolution

M:DTSHD MaterAudio

?:UNKNOWN

14 DSP DECODE OK o:OK

x:NG

15 Mute 1:Selector

2:Effector

4:DSP

8:DIR

4 D 4 8 K 1 N 0 F F P o 0

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

DEBUG MODE-2

AUDIO DEBUG MODE-2/3

HT-R592/ 2295

NIC/DEC/SPI Busy/Exec wait

0

Stable state

Internal state Inferred state

1NIC

2DEC

3NIC+DEC

9Exec wait + NIC

8Exec wait

If you stop at these numbers, please check the DSP Sequence.

If the stop remains "1" is indicated, it is possible that there is an abnormality in

the connection between the microcomputer and the NIC.

4SPI Busy

5SPI Busy + NIC

6SPI Busy + DEC

7SPI Busy + NIC + DEC

FExec wait + SPI Busy

+ NIC + Dec

EExec wait + SPI Busy

+ DEC

DExec wait + SPI Busy

+ NIC

CExec wait + SPI Busy

BExec wait + NIC+DEC

AExec wait + DEC

Display

contents

Please check if the input signal Dolby / DTS / AAC / PCM from Coax or OPT.

If the stop remains “2” is indicated, it is possible that there is an abnormality

in the connection between the DIR and the DSP.

There is a case of "2" for the state to stop or pause playback equipment.

And it is normal.

If the stop in these numbers, it is possible that there is an abnormality in

the connection between the DSP and the microcomputer.

If the stop remains "3" is indicated, it is possible that there is an abnormality in

the connection between the microcomputer and the NIC.

DEBUG MODE-3

AUDIO DEBUG MODE-3/3

HT-R592/ 2295

DSP Sequence

Possible Causes

Display

contents Inferred state

Stop at "03"

is indicated.

Stop at "05"

is indicated.

Stop at "08"

is indicated.

Stop at

"09 - 0C"

is indicated.

Stop at "17"

is indicated.

Have not been able to communicate

between the microcontroller and

the DSP.

Have not been able to write from

the boot loader of the DSP.

While running the boot loader of DSP,

the main program is not running.

Main program of DSP is not working

properly.

There is a possibility that the power is

turned off during the S / PDIF Update.

1.There is a problem with the connection between the FlashROM and

the DSP, and the SDRAM.

2.Power is not supplied to the DSP.

3.Operation clock is not input to the DSP.

4.Reset port of the DSP is not connected.

5.There is a problem with the line of communication between the

microcontroller and DSP.

6.DSP is broken or Microcomputer.

7.Program has not been successfully written to the Flash ROM. Or the

program is not written.

8.Communication port (such as DIR) other devices are connected to t

he SPI mode is broken short. Terminals are short-circuited.

1.Program is not written correctly to Flash ROM.

2.DSPSDO line of microcomputer is interrupted somewhere.

3.There is a problem with the FlashROM (or SDRAM) of DSP.

4.DSP is broken or Microcomputer.

5.Upper address bus of Flash ROM is not connected properly.

1.SDRAM is broken or Flash ROM.

2.Upper address bus of Flash ROM is not connected properly.

3.Program is not written correctly to Flash ROM.

4.There is a possibility that the power is turned off during

the S / PDIF Update.

1.SDRAM is broken or Flash ROM.

2.Upper address bus of Flash ROM is not connected properly.

3.Program is not written correctly to Flash ROM.

4.There is a possibility that the power is turned off during

the S / PDIF Update.

Solution :

Hold down the VCR/ DVR when the power is turned on, press the

On/Standby key. (Clear)

When out of the state of S / PDIF Update, please press the

On/Standby key.

Stop at

"22-24"

is indicated.

Stop at

"30-33"

is indicated.

Stop at

"26-2F"

is indicated.

Stop at "FF"

is indicated.

Main program of DSP is not working

properly.

main program of DSP is not working

properly.

The audio signal is not input.

main program of DSP is not working

properly.

The audio signal is not input.

DSP settings has failed.

The DSP is functioning properly.

1.SDRAM(or Flash ROM) is broken.

2.Upper address bus of Flash ROM is not connected properly.

3.Program is not written correctly to Flash ROM.

4.Operation clock to the DSP is not a predetermined value.

1.SDRAM(or Flash ROM) is broken.

2.Upper address bus of Flash ROM is not connected properly.

3.Program is not written correctly to Flash ROM.

4.Operation clock to the DSP is not a predetermined value.

5.Audio clock to the DSP is not a predetermined value.

1.SDRAM(or Flash ROM) is broken.

2.Upper address bus of Flash ROM is not connected properly.

3.Program is not written correctly to Flash ROM.

1.SDRAM(or Flash ROM) is broken.

2.Upper address bus of Flash ROM is not connected properly.

3.Program is not written correctly to Flash ROM.

All settings are completed, DSP has started normal operation.

Stop at “21”, to return to the

previous display after a while.

Format display indicator flashes.

There is no sound even though it is

the display of "FF".

Refer to

“NIC/DEC/SPI Busy/Exec wait” in DEBUG MODE-2

HT-R592/ 2295

DEBUG MODE-4

HDMI DEBUG MODE-1/4

HDMI-related operations can be checked to some extent by displaying HDMI debug mode.

To enter this mode

Hold down DISPLAY button for 3 seconds. Information display will last for about 8 seconds.

Input resolution

Output resolution

List of standard resolution

4 8 0 i / 6 0

4 8 0 p / 6 0

1 0 8 0 i / 6 0

7 2 0 p / 6 0

1 0 8 0 p / 6 0

2 4 0 p / 6 0

# 4 8 0 i / 6 0

# 4 8 0 p / 6 0

# 2 4 0 p / 6 0

5 7 6 i / 5 0

5 7 6 p / 5 0

1 0 8 0 i / 5 0

7 2 0 p / 5 0

1 0 8 0 p / 5 0

2 8 8 p / 5 0

# 5 7 6 i / 5 0

# 5 7 6 p / 5 0

# 2 8 8 p / 5 0

1 0 8 0 p / 2 4

1 0 8 0 p / 2 5

1 0 8 0 p / 3 0

V G A

1 0 8 0 i 1 0 0

7 2 0 p 1 0 0

5 7 6 p 1 0 0

5 7 6 i 1 0 0

1 0 8 0 i 1 2 0

7 2 0 p 1 2 0

4 8 0 p 1 2 0

4 8 0 i 1 2 0

5 7 6 p 2 0 0

5 7 6 i 2 0 0

4 8 0 p / 6 0

4 8 0 p 2 4 0

4 8 0 i 2 4 0

* 4 8 0 p / 6 0

* 5 7 6 p / 5 0

7 2 0 p / 2 4

7 2 0 p / 2 5

7 2 0 p / 3 0

1 0 8 0 i / 6 0 →

1 0 8 0 i / 6 0

Display of Input Resolution

DVI input signal

VGA input signal

No input

“I” and “P” will be capitalized.

Display the ” ” in column 1

4 8 0 I / 6 0 →

4 8 0 P / 6 0 →

* V G A →

U n k n o w n →

Resolution display method

HT-R592/ 2295

DEBUG MODE-5

HDMI DEBUG MODE-2/4

i / p will be

capitalized.

Display the ” ”

in column 5

Display the ” ”

in column 14

Display the ” # ”

in column 14

Display the ” x ”

in column 14

Display the ” ”

in column 4

4K Upscaling

Display of Output resolution

Display of Input resolution

If the three-digit numbers

are refrate

List of resolution

Resolution Error

EDID_READ_NG

Dislay of Output Resolution

For a video processor

DVI input signal

VGA input signal

RSEN is OFF

EDID_READ is NG

Resolution Error

No output

(Signal output destination

can not be found.)

Hot-plug of Sink equipment

can not be detected.

Via VSP

VSP skip

→1 0 8 0 i / 6 0

1 0 8 0 i / 6 0

4 8 0 I / 6 0

4 8 0 P / 6 0

* 4 8 0

p

/ 6 0

4 8 0 p / 6 0 *

4 8 0 p / 6 0

#

4 8 0 p / 6 0

x

- - - - -

O F F

1 0 8 0 i / 6 0 →

* * * * x * * * * p / * *

* * *

3 8 4 0 x 2 1 6 0 p / 3 0

3 8 4 0 x 2 1 6 0 p / 2 5

3 8 4 0 x 2 1 6 0 p / 2 4

4 0 9 6 x 2 1 6 0 p / 2 4

3 8 4 0 x 2 1 6 0 p / 3 0 x

3 8 4 0 x 2 1 6 0 p / 3 0 #

→

3D Display

Display the ” ”

in column 14

Display the ” # ”

in column 9

Display the ” x ”

in column 13

3D format

INPUT/OUTPUT

Resolution display

Status Display

RSEN OFF

EDID READ NG

Resolution Error

1 0 8 0

p

/ 2 4

(

3 D

)

H D M I 4 4 4 3 6 b i t

F r a m e P a c k i n g

I N

:

O U T

:

1 0 8 0

p

/ 2 4 ( 3 D ) *

H D M I 4 4 4 # 3 6 b i t

1 0 8 0

p

/ 2 4

(

3 D

)x

HT-R592/ 2295

DEBUG MODE-6

HDMI DEBUG MODE-3/4

INPUT/ OUTPUT

Status

Input Mode

Input Color

Deep Color

HDMI input

DVI input

No input

RGB

422

444

24bit

30bit

36bit

3D format

Frame Packing

Side-by-Side(Full)

Side by Side(Harf)

Field alternative

Line alternative

L+depth

unknown

Top and Bottom

L+depth + graphics

H D M I 4 4 4 3 6 b i t

D V I 4 4 4 3 6 b i t

- - - 4 4 4 3 6 b i t

H D M I R G B 3 6 b i t

H D M I 4 2 2 3 6 b i t

H D M I 4 4 4 3 6 b i t

H D M I R G B 2 6 b i t

H D M I R G B 3 0 b i t

H D M I R G B 3 6 b i t

F r a m e P a c k i n g

F a l t e r n a t i v e

L a l t e r n a t i v e

S i d e b y S i d e ( F )

L + d e p t h

L + d e p t h g r a p h i c

S i d e b y S i d e ( H )

T o p - a n d - B o t t o m

U N K N O W N

I N

: * *

O U T

: * *

HT-R592/ 2295

DEBUG MODE-7

HDMI DEBUG MODE-4/4

Input Resolution

Output Resolution

PC Resolution

Display of Input resolution

Display of Output resolution

INPUT/ OUTPUT

DVI input

HDMI input

No input

Three-digit numbers

are Referat

Display uppercase P/I

Display lowercase p/i

Horizontal resolution Vertical resolution Referat

DVI output

HDMI output

Display”-----”

Three-digit numbers

are Referat

EDID READ NG

Resolution through

Display uppercase P/I

Display lowercase p/i

Display the ” # ” in

column 13

Display the ” x ” in

column 13

1 0 2 4 x 7 6 8 p / 6 0 →

1 0 2 4 x 7 6 8 p / 6 0

* * * * x * * * * p / * *

→

1 0 2 4 x 7 6 8 P / 6 0

→

1 0 2 4 x 7 6 8 p / 6 0

→

1 0 2 4 x 7 6 8 P 1 2 0

→

U N K N O W N

* * * * x * * * *

p

/ * *

1 0 2 4 x 7 6 8 P / 6 0

1 0 2 4 x 7 6 8 p / 6 0

→- - - - -

1 0 2 4 x 7 6 8 P 1 2 0

1 0 2 4 x 7 6 8 P / 6 0 #

1 0 2 4 x 7 6 8 P / 6 0

x

I N

:

* O U T

:

*

HT-R592/ 2295

DEBUG MODE-8

SERVICE INFORMATION MODE

Displaying Service information

This service information display system is helpful in analyze the status when the unit goes into Protect mode and is powered off.

Pay attention that the status will change if a button is pushed.

0 1 : 2 3 1 0 h

e.g.

1. Press twice the ON/ STANDBY key while pressing the DISPLAY key.

Listening Mode Code List

- 8 0 F 2 7 D D

e.g.

Power off Cause

T : Thermal Protect

V : Voltage Protect

I : Current Protect

- : Other

Temperature

: xx F or xx C

Volume Level Listenning Mode

---> Refer to the code list below.

Time after Power on

xx : xx

Time after Initialize

xx hour

M1.00/13302ALU The version of main microprocessor is

displayed only for 3 seconds.

e.g.

C_LM_LAST01

C_LM_PURE02

C_LM_DIRECT03

C_LM_STEREO04

C_LM_MONO05

C_LM_SURR20

C_LM_THX_MUSIC50

C_LM_THX_GAME70

C_LM_THX_CINEMA90

C_LM_THX_U2GAMEA0

C_LM_THX_U2MUSICA8

C_LM_THX_U2CINEMAB0

C_LM_ASCF4

C_LM_FLASHF5

C_LM_DEBUGMODEF6

C_LM_FLASH2F7

C_LM_FLASH3F8

C_LM_FLASH4F9

C_LM_FLASH_CHECKFA

C_LM_RPG0D

C_LM_ACTION0E

C_LM_ROCKBAND0F

C_LM_SPORTS10

3. Press SETUP button again. The following information are displayed.

2. Press SETUP button within 3 seconds above.

C_LM_AUDYSSEYD0

C_LM_DTSSS48

C_LM_ORCHESTRA06

C_LM_UNPLUGGED07

C_LM_STUDIOMIX08

C_LM_TVLOGIC09

C_LM_ALLCHST0A

C_LM_FULLMONO0B

C_LM_TD0C

C_LM_TESTTONEF1

C_LM_TESTTHRF2

C_LM_TESTAUTOF3

4. Press ON/STANDBY button to exit the display of service information.

(Ref.: Press RETURN button to initialize the data in the service information.)

ProtectData CLR

Normal display

Information Displayed (Record this Information)

TX-NR525/HT-R592/HT-RC550

OPERATION CHECK-1

1.OPERATION CHECK(1/2)

1-1. OPERATIONS OF VOLTAGE-DETECTION PROTECTORS.

See “OPERATION CHECK-3,-5” for TEST MODE operation.

NOTE: Don't connect load nor short speaker terminals.

a. Change the state to "TEST-4-21".

b. It tests by being automatic in order of TEST 4-21(FL+) → 22(FR-) → 23(C+) → 24(SL-) → 25(SR+) → ( 26(SBL-)

→ 27(SBR+) ). If TEST 4-27(TX-NR525/HT-RC550 are 4-25) is OK, it becomes the display of "TEST-4-35".

c. It will complete, if displayed on FL TUBE as "TEST 4-35".

1-2. OPERATIONS OF CURRENT-DETECTION PROTECTORS

See “OPERATION CHECK-3,-5” for TEST MODE operation.

a. Change the state to "TEST-4-35".

Even if you connect 3-ohm load for every channel of L, R, C, SL, SR, SBL and SBRch, a relay should not cut off.

If 1-ohm load is connected for every channel of L, R, C, SL, SR,SBL and SBRch, a relay should hold the state of ON.

1-3. CONFIRMATION OF RDS (RADIO DATA SYSTEM) OPERATION (Applied to MM*/MP* type )

a. Input 98MHz,30dBμ signal modurated with RDS data.

b. When a PS information is received, the name of the station "RDS TEST" shall be displayed within 2 seconds instead

of the frequency.

1-4. CONFIRMATION OF HEAD PHONE OPERATION.

Confirm the Listening Mode is automatically switched to "STEREO" mode when headphones plug is inserted into

the PHONES jack.

1-5. COMFIRMATION OF FRONT USB

See “OPERATION CHECK-3,-4” for TEST MODE operation.

a. Connect ipod to AVR USB port.

b. When set to TEST 3-09, confirm that the display of AVR change "connecting" to "Push [MODE] b ..." or "Playlist" after

few seconds.

The following iPod models can be used for inspection.(The above-mentioned operation is not done excluding the

following items.)

iPod classic, 3G nano, 4G nano, 5G nano

1-8. CONFIRMATION OF OUTPUT SENSER AND THERMAL SENSOR

See “OPERATION CHECK-3,-5” for TEST MODE operation.

a. Set the TEST MODE to "TEST 4-36" and "TEST 4-37".

After light "FM STEREO" on FL display ,

the relays RL641/642 is OFF and "FM STEREO"is off .(TEST 4-37 is only for HT-R592)

b. Push ON/Standby button 2 times while pushing down DISPLAY button to display CPU Debug PROGRAM version.

Push TONE button while displaying CPU PROGRAM version to display value of temparature sensor.

Confirm outside temperature ±20C is displayed immediately after energizing.

Note that the error margin is caused by the rise of the temperature of the heat sink when time passes.

FL Display

000 034 F:x S:H

Amplifier power

supply voltage condition

H: High-B

L: Low-B

Temparature

of thermal sensor

Voltage

of VOLH port

FAN condition

x: Stop

L: Low speed

M: Mid speed

H: High speed

1-6. COMFIRMATION OF REAR USB(Applied to TX-NR525/HT-RC550)

See “OPERATION CHECK-3,-4” for TEST MODE operation.

a. Connect USB-Storage to AVR USB port.

b. When set to TEST 3-10, confirm that the display of AVR change device name.

1-7. COMFIRMATION OF NETWORK(Only TX-NR525/HT-RC550)

See “OPERATION CHECK-3,-4” for TEST MODE operation.

a. Connect the receiver to the router.

b. When set to TEST3-18 confirm that the display of AVR change IP adress.

*Please wait for about 1 minute after turning on the power supply of the set when you use TEST 3-18.

e.g.

TX-NR525/HT-R592/HT-RC550

OPERATION CHECK-2

1.OPERATION CHECK(2/2)

Monitor out

A

B

C

D

E

1-9. CONFIRMATION OF OSD(ON SCREEN DISPLAY) OPERATION

a. When SETUP(HT-R592) or HOME(TX-NR525/HT-RC550) button is pushed, confirm that setup menu

is displayed in HDMI Out.

b. Confirm that specified operations for ENTER(with 4-cursor) buttons are made.

1-10. CONFIRMATION OF HDMI AUDIO OPERATION.

See “OPERATION CHECK-3,-6” for TEST MODE operation.

a. CONFIRMATION OF HDMI I2S SIGNAL

1. Input the one of these signals below from HDMI1 terminal.

DTS-HD MasterAudio 7.1ch

Dolby TrueHD 7.1ch

2. Change the state to TEST 6-00. Confirm the signal is output from L/R,SW/C,SL/SR,SBL/SBR.

3. When TEST 6-08, confirm the sound(HDMI1 input) outputs from the TV.

b. CONFIRMATION OF HDMI SPDIF SIGNAL

4. SPDIF signal is input from HDMI terminal.

5. When TEST 6-06, confirm the sound(HDMI IN1) outputs from the speaker.

6. When TEST 6-07, confirm the sound(BD/DVD analog input) outputs from the TV.(VIDEO is Blue back.)

c. CONFIRMATION OF HDMI DSD SIGNAL.

7. When TEST 6-10,11,12, confirm the sound of DSD 5.1ch input HDMI IN 3, output from the speaker.

1-11. VIDEO FUNCTION CHECK

See “OPERATION CHECK-3,-6” for TEST MODE operation.

a. Confirm Video output signal as shown Table 2, while Video signal are input as shown Table 1.

NOTE 1: Confirm the HDMI path at 1080p signal.

Table 1

Input

BD/DVD

VCR/DVR

CBL/SAT

GAME

AUX

Composite Video

A

B

C

D

E

Component

IN1

---

IN2

---

F

---

G

---

HDMI

IN1

IN2

IN3

IN4

---

H

I

J

K

---

Test mode

5-05(BD/DVD)

5-06(VCR/DVR)

5-07(CBL/SAT)

5-08(GAME)

5-10(AUX)

Composite Video

VCR out

A

---

C

D

E

Component

OUT

F

---

G

---

HDMI

OUR

H

I

J

K

---

Table 2

b. OPERATIONS OF VIDEO SIGNAL-DETECTION

1. Confirm "RDS" light up on FL TUBE when component video signal is input in "TEST 5-00".

Confirm "RDS" turn off on FL TUBE when component video signal isn't input in "TEST 5-00",too.

2. Confirm "FM STEREO" light up on FL TUBE when component video signal is input in "TEST 5-00".

Confirm "FM STEREO" turn off on FL TUBE when component video signal isn't input in "TEST 5-00",too.

1-12. MISCELLANEOUS

a. Confirm all input and output terminals operate normally.

b. Please confirm LED and FL displaying by the FL TEST mode. And confirm the destination setting.

---> See to “OPERATION CHECK-3”.

c. Change the state to KEY TEST under TEST MODE to confirm each key operation.

---> See to“OPERATION CHECK-3”.

d. Confirm the version of each firmware.

---> See to “SERVICE PROCEDURE-2”.

e. Confirm the firmware combination check.

---> See to “OPERATION CHECK-3”.

Applied to HT-R592

Applied to TX-NR525/HT-RC550.

Table 1

Input

BD/DVD

IN2

CBL/SAT

GAME

PC

AUX

Composite Video

A

---

B

C

D

E

Component

IN1

---

IN2

---

F

---

G

---

HDMI

IN1

IN2

IN3

IN4

IN5

IN6

H

I

J

K

L

M

Test mode

5-05(BD/DVD)

5-06(IN2)

5-07(CBL/SAT)

5-08(GAME)

5-09(PC)

5-10(AUX)

Composite Video

Monitor out

A

-

B

C

D

E

Component

OUT

F

---

G

---

HDMI

OUR

H

I

J

K

L

M

Table 2

TX-NR525/HT-R592/HT-RC550

OPERATION CHECK-3

2.TEST MODE(1/4)

2-1.TEST MODE FOR MODEL, DESTINATION AND FL DISPLAY

[NOTE] If VOL value is not 25(initial setting), test mode cannot be set.

a. Push STANDBY/ON key while pushing down TV/CD button button to display "TEST-".

b. Then push DIMMER(RT/PTY/TP) button and get the FL test mode.

c. In the FL test mode, TONE + button is FL TEST UP and TONE - button is FL TEST DOWN.

d. REC OUT and ZONE2 button's originally operation can't work when it is in FL test mode.

e. The contents of the step are as follows.

1. Lit all segment

2. Lit '23456789ABCDEF'

3. Lit a even number segment

4. Lit an odd number segment

5. The Destination setting is displayed. Please see the below for detail.

f. To close the FL test, push POWER button.

N R 5 2 5 D x 2 0 0 0

FL DIS Name Destination A B CD

A:Value of AD port of BAND

B:Value of AD port of INIT1

C:Value of AD port of INIT2

D:Value of AD port of INIT3

2-2. TEST MODE FOR OPERATION

a. Push STANDBY/ON button while pushing down TV/CD button to display "TEST-_".

b. Next, if the following keys are pushed, it becomes a each TEST MODE.

c. In the test mode, (TONE)- button is TEST MODE DOWN and (TONE)+ button is TEST MODE UP.

d. "TEST-1-00" and "TEST-1-01" are used to check a protection circuit, and the relay recovered in one second.

1-00 2-00 3-00 4-00 5-00 6-00 KEY TEST

BD/DVD MEMORY

(CINEMA FILTER)

IDLING TIMER FL TEST

TUNING MODE

(LATE NIGHT)

DIMMER

(RT/PTY/TP)

TEST MODE

FIRMWARE

COMBINATION

CHECK

ENTER When MMPU debug version(*1)

is displayed, push

"MEMORY(CINEMA FILTER)"

CHECK SUM

TEST MODE

CBL/SAT GAME PC AUX TV/CD

Display of Destination on TEST MODE.(Distination setting)

HT-R592

TX-NR525

HT-RC550

CBL/SATVCR/DVR GAME

HT-R592

TX-NR525

HT-RC550

Model Name Distination Number Writing Data

TX-NR525 Dx 2000 2000 TX-NR525 Dx N R 5 2 5 D x 2 0 0 0

TX-NR525 xx 8000 8000 TX-NR525 xx N R 5 2 5 x x 8 0 0 0

HT-RC550 Dx 2002 2002 HT-RC550 Dx R C 5 5 0 D x 2 0 0 2

FL Display

e.g.

(*1) MMPU debug version is displayed

Press twice the ON/ STANDBY key while pressing the DISPLAY key.

HT-R592 Dx 2028 2028 HT-R592 Dx H T 5 9 2 D x 2 0 2 8

HT-R592 xx 8028 8028 HT-R592 xx H T 5 9 2 x x 8 0 2 8

TX-NR525/HT-R592/HT-RC550

OPERATION CHECK-4

2.TEST MODE(2/4)

2-2. TEST MODE FOR OPERATION(Continue)

e. Test mode is as follows.

TEST

No

1-00

1-01

1-02

2-00

2-01

2-02

2-03

2-05

2-06

2-07

2-08

2-09

2-10

2-11

2-12

2-13

2-14

2-15

2-16

2-17

2-18

2-19

2-20

2-21

2-22

2-23

2-24

2-25

2-26

3-00

3-01

3-02

3-03

3-04

3-05

3-09

3-10

3-11

3-12

3-13

3-14

3-15

3-16

3-17

3-18

Analog Input

[Rec Sel]

(Zone2/Zone3)

BD/DVD (Off)

Multi channel

BD/DVD (Off)

"VCR/DVR (Off) H59

"VCR/DVR(Off) H59

CBL/SAT (Off) T5/H55"

"CBL/SAT (Off) H59

GAME(Off) T5/H55"

"GAME (Off) H59

PC(Off) T5/H55"

AUX (Off)

BD/DVD (Off)

TV/CD (Off)

BD/DVD (Off)

BD/DVD(Source)

MIC

AUX(Off)

PC (Off)

FM/Source

TV/CD

TV/CD (Off)

TV/CD

USB/(Source)

NET/(Source)

Listening Mode/

Input Format

Direct

Stereo(Direct)

DVD Direct

Multich Amp Test

ADC DSP 8ch Thru.

ADC DSP 7ch Thru.

ADC DSP 8ch Thru.

Automatic

DIR DSP 8ch Thru

Automatic

DIR DSP 8ch Thru

ADC DSP 8ch Thru.

DIR DSP 8ch Thru

Stereo(Direct)

ALL CH STEREO

Stereo(Direct)

VIDEO

Input

BD/DVD

VCR/DVR

CBL/SAT

GAME

PC

AUX

BD/DVD

AUX

PC

BD/DVD

Last

Compo-

nent V

IN1

-

BD/DVD

-

BD/DVD

-

HDMI

IN1

IN2

IN3

IN4

-

IN2

IN3

IN1

-

IN1

-

Digital Input

/Output

-

*OPT1

*COAX1

*OPT1

OPT1

COAX1

*OPT2

*COAX2

-

OPT1

-

Front USB

Rear USB

Front USB

NET

Config.

-

Y/L/L/L/L

-

Y/L/L/L/L

-

Master Vol.

NonTHX

(THX)

Max

MIN

Max

64

Max

64

62

64

57

45

MIN

64

Max

64

52

64

59

64

Max

64

MIN

57

48

Speaker

Relay

F/CS/SB/Z2

F

F/CS/SB

CS/SB

F/CS/SB

F

CS

F/CS/SB

F

F/Z2

F/CS/FH

F/Z2

F

etc.

SBL,SBR

SW=NO

SW:MUTE

SPRLF OFF

MICMUTE ON

Z2MUTE ON

"Output Level / Distortion"

Hum noise

Freq. Resp.

Separation

"Output Level / Distortion"

"NET connectioncheck "

*1 PROTECT

"*1 PROTECTFOR SBL ch"

TX-NR525,HT-R550 only

1.44.1kHz_16bit_1kHz_

0dBfs_L&R.wav *2

2.44.1kHz_16bit_-∞

dBfs_L&R.wav *2

3.44.1kHz_16bit_20Hz_

0dBfs_L&R.wav *2

4.44.1kHz_16bit_20kHz_

0dBfs_L&R.wav *2

5.44.1kHz_16bit_1kHz_

0dBfs_Lch.wav *2

6.44.1kHz_16bit_1kHz_

0dBfs_Rch.wav *2

7.48kHz_16bit_1kHz_

0dBfs_L&R.wav *2

display IP address

TX-NR525/HT-R592/HT-RC550

OPERATION CHECK-5

2.TEST MODE(3/4)

2-2. TEST MODE FOR OPERATION(Continue)

Auto Measurement Mode

TEST

No.

4-00

4-01

4-02

4-03

4-04

4-05

4-06

4-07

4-08

4-09

4-10

4-11

4-12

4-13

4-14

4-15

4-16

4-21

4-22

4-23

4-24

4-25

4-26

4-27

4-28

4-29

4-30

4-31

4-32

4-33

4-34

4-35

4-36

4-37

4-38

4-39

4-40

DSP Output ch

ALL

SW

FL,FR

FR,C,SL,SR,SBL,SBR,SW

FL,C,SL,SR,SBL,SBR,SW

FL,FR,SL,SR,SBL,SBR,SW

FL,FR,C,SR,SBL,SBR,SW

FL,FR,C,SL,SBL,SBR,SW

FL,FR,C,SL,SR,SBR,SW

FL,FR,C,SL,SR,SBL,SW

FL,FR,C,SL,SR,SBL,SBR

ALL

FL

FR

C

SL

SR

SBL

SBR

FL

FR

C

SL

SR

SBL

SBR

ALL

"FL,FR,C,SL,SR"

C,SL,SR,SBL,SBR

ALL

DSP Output

Frequency

1kHz

30Hz

20kHz

30Hz

10kHz

30Hz

1kHz

30Hz

1kHz

30Hz

+DC

-DC

+DC

-DC

+DC

-DC

+DC

-DC

+DC

-DC

+DC

-DC

+DC

-DC

Pulse

1kHz

30Hz

20kHz

DSP

Output

Voltage

-20dBFS

+Max

-Max

+Max

-Max

+Max

-Max

+Max

-Max

+Max

-Max

+Max

-Max

+Max

-Max

Max

0dBFS

-20dBFS

CConfig.

Y/L/L/L/L

N/L/L/L/L

Y/L/L/L/L

Master Vol.

64(-16dB)

58(-22dB)

64(-16dB)

Min(-80dB)

Max

58(-22dB)

55(-25dB)

59(-21dB)

Speaker

Relay

F/CS/SB

etc.

Mute:FL

Mute:FR

Mute:C

Mute:SL

Mute:SR

Mute:SBL *6

Mute:SBR *6

Mute:SW

*mut on

*1,*3

*1,*3,*6

*1,*3

*1,*3,*6

*1,*4

vol=55

*5,*6

DSP Gain

DSP Freq.Response

Characteristic(1)

Characteristic(2)

Separation

Muting

Volume Max.Attenuation

+DC Protect

-DC Protect

+DC Protect

-DC Protect

+DC Protect

-DC Protect

+DC Protect

-DC Protect

+DC Protect

-DC Protect

+DC Protect

-DC Protect

+DC Protect

-DC Protect

Current Protect

VOLH DET

IDLING TIMER

*5 : VOLH is detected and H/L of SEC1H is changed.

A detection level is the same as the normal mode.

When it is detected, light "FM STEREO" on FL TUBE.

20 mS

2 mS 2 mS

Max

*6 : SBL/SBR correspond only HT-R592.

*3 : When TEST No. 4-21 34 is setted, DC votage is putted out immediately at each channel. (within 100msec.)

*4 : The following signal is putted out at all channel continuously in TEST4-35

[Note] Do not connect the loudspeaker.

In all test modes, it is not concerned with detection of VOLH but SEC1H are made "H" fixation. (Except TEST4-36 and 4-37.)

*1: All SP-RELAYs are turned ON only at the time of this STEP.

Moreover, whether make RELAY restoration time at the time of protection operation into 1 second, and PROTECT input "H"

is detected how many times or it continues 1 second or more, RELAY is not held at OFF or POWER OFF is not carried out,

either.

When "H" is 1 seconds or more to PROTECT input and it is set to "L", RELAY is turned ON again.

Moreover, not any MUTE is outputted at the time of this STEP.

TX-NR525/HT-R592/HT-RC550

OPERATION CHECK-6

2.TEST MODE(4/4)

2-2. TEST MODE FOR OPERATION(Continue)

TEST

No.

5-00

5-01

5-02

5-03

5-04

5-05

5-06

5-07

5-08

5-09

5-10

6-00

6-01

6-02

6-03

6-04

6-05

6-06

6-07

6-08

6-09

6-10

6-11

6-12

Input selector

BD/DVD

PC

BD/DVD

VCR/DVR

CBL/SAT

GAME

PC

AUX

BD/DVD

CBL/SAT

BD/DVD

DIGITAL

INPUT

HDMI

-

HDMI

COAX1*

HDMI

HDMI ARC

HDMI

COMPO-

NENT/D4

IN1

-

IN1

-

IN2

-

IN1

IN2

IN1

Volume

MIN

33

43

MIN

43

50

HDMI

-

IN1

IN2

IN3

IN4

IN5

IN6

IN1

---

IN1

---

IN3

MODE

-

Through

HDMI I2S SIGNAL

HDMI DSD SIGNAL

HDMI SPDIF SIGNAL

Audio TV OUT = ON, VOL=0, ANALOG(BD)

Audio TV OUT = ON, VOL=0, I2S SIGNAL

HDMI AUDIO RETURN CHANNEL

HDMI DSD SIGNAL

VIDEO & HDMI TEST MODE

etc

Only 525/550

Audio TV Out

Audio TV Out (Only 525/550)

Audio TV Out

OUTPUT CH=L/R/C/SW/SL/SR

OUTPUT CH = SW/C

OUTPUT CH = SL/SR

OUTPUT CH = SBL/SBR

OUTPUT CH = L/R/C/SW/SL/SR

OUTPUT CH = SBL/SBR

HDMI OUT is blue back

Output CH = L/R to L/R

Output CH = C/SW to L/R

Output CH = SL/SR to L/R

f. Following frequencies are automatically written in the preset memory, when the unit goes into test mode.

FM

AM

FM

AM

PRESET No.

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

MD*

89.9MHz

97.9MHz

98.9MHz

107.1MHz

107.9MHz

100.1MHz

88.1MHz

104.1MHz

95.3MHz

106.7MHz

530KHz

630KHz

990KHz

1440KHz

1710KHz

670KHz

830KHz

1310KHz

1200KHz

530KHz

87.5MHz

107.9MHz

103.7MHz

104.5MHz

1180kHz

1220kHz

MW*(10k)

89.90MHz

97.90MHz

98.90MHz

107.10MHz

107.90MHz

100.10MHz

88.10MHz

104.10MHz

95.30MHz

106.70MHz

530KHz

630KHz

990KHz

1440KHz

1710KHz

670KHz

830KHz

1310KHz

1200KHz

530KHz

87.50MHz

108.00MHz

104.00MHz

104.20MHz

1180kHz

1220kHz

MP*,MG*

MW*(9k)

89.90MHz

97.90MHz

98.90MHz

107.10MHz

107.90MHz

100.10MHz

88.10MHz

104.10MHz

95.30MHz

106.70MHz

522KHz

630KHz

990KHz

1440KHz

1611KHz

666KHz

828KHz

1314KHz

1197KHz

522KHz

87.50MHz

108.00MHz

104.00MHz

104.20MHz

1179kHz

1215kHz

NOTES

1. DSP Thru of Listening Mode outputs L Input signal to L/C/SL/SBL, and outputs R Input signal to R/SR/SBR/SW.

2. Config. is in order of SW/Front/Center/Surround/Surround Back

3. Mute is function to stop output(from the channel) by using inner DSP programming.

4. When Listening Mode is DSP through, an analog switch is changed into the state of SURROUND.

5. At the time of PRTCTTHM detection, it is displayed on FLT as "THERMAL PROTECT".

HT-R592

EXPLODED VIEW

EXPLODED VIEW(OVERALL)

A005

A099

A101

A201

A202

A205

A211

A212

A213

A214

A225

A227

A701

A709

T901

P900

P901 U0010 U0011

U0012

U0030

U0031

U0040

U0041

U0060

U0061

U0062

U0063

U0064

U0065

U0080

U009

Q6050

Q6051 Q6052

Q6053

Q6054

Q6060

Q6061 Q6062

Q6063

Q6064

Q6056 Q6066

Q6055 Q6065

A003

A723

A214

F6401

F6402

F901

P8001

P701

U0014

3TTB+8B(3BC)

x 9 pcs.

A721

Heatsink

Rear Panel

MDS,MDF only

e.g. MDC type

SCREW

3TTB+8B(3BC)

x 4 pcs.

SCREW

3TTB+8B(3BC)

SCREW

3TTB+8B(3BC)

SCREW

2.6TTB+8B(3BC)

x 22 pcs.

SCREW

3P+6FN(3BC) x 5 pcs.

SCREW

3TTB+8B(3BC)

x 27 pcs.

SCREW

3TTF+10B(3BC)

x 2 pcs.

SCREW

3SMS8W.SW+14B(CU)

x 14 pcs.

SCREW

4TTC+8C(3BC)SR

x 4 pcs.

Except MDS, MDF type

SCREW

3TTB+8B(3CM)SR

SCREW

3TTB+8B(3BC) x 4 pcs.

SCREW

3TTB+8B(3BC)

x 3 pcs.

SCREW

3TTB+8B(3BC)

x 4 pcs.

SCREW

3TTB+8B(3BC)

x 2 pcs.

SCREW

3TTB+8B(3BC)

x 2 pcs.

SCREW

3TTB+8B(3BC)

SCREW

3TTB+8B(3BC)

x 3 pscs.

MDC only

TX-NR525/626/ HT-R592/ DTR-30.5 TX-NR525/626/ HT-R592/ DTR-30.5

SCHEMATIC DIAGRAMS-01(PART-1)

BLOCK DIAGRAM AUDIO SECTION

MAIN R

REC R

SUB L

REC L

SPRLZ2

SPRLSB

SPRLCS

MAIN L

SBRELAY

PRERELAY

SBZ2MUT

SPRLF

AMUT

Z2MUTE

Q7401

FRONT BOARD

MIC DET

MIC AMP

MIC

OPT1

SPI

FRONT RIGHT

Subwoofer

AV=+20dB

(FL/FR)

(CT/SW)

(SL/SR)

(BL/BR) 8ch DAC

LPF

+6dB

LPF

+6dB

LPF

+6dB

LPF

+6dB

LPF

+6dB

LPF

+6dB

LPF

+6dB

LPF

SPI

TRANSMITTERS

RS232

IR

REMOTE SENSOR

RS232

CENTER

SURR. LEFT

SURR. RIGHT

FRONT RIGHT

AUX IN

(FRONT IN)

XOUT

XTAL-X501

5MHz

XIN

BCK NET

LRCK NET

DATA NET

MCK NET

CX LRCK

CX SCLK

DSP FLR

DSP SLR

DSP CSW

DIR LRCK

DIR FLR

DSP SBLR

DIR BCK

ADSP MCK

OVERCURRENT DET

MDIO Controls

USB EN VBUS

RMII Controls

RMII RX

RMII TX

VBUS

DATA+

DATA-

SPI

SP to Micom

COAX 2

12V TRIDDER

CONTROL

SPI to Micom

HDMI BCK

HDMI LRCK

HDMI FLR

OPT2

OPT1

COAX2

COAX1

HDMI MCK

SURR. BACK

LEFT

XTAL

RJ-45

EtherMAC

MDIO Controls

RMII Controls

RMII TX

RMII RX

HI SIDE SW

USB EN VBUS

OVERCURRENT DET

+5V

DATA-

DATA+

VBUS YKF45-0029N

USB

DATA-

DATA+

VBUS YKF45-0029N

USB

USB VBUS

IN7

DSP

HDMI MCK

HDMI BCK

HDMI LRCK

HDMI FLR

SPDIF

OUT

IN1

IN2

HDMI Tx HDMI Rx

Q3001: D830K

AVD7623Q8101

Q8302

Q8201

Q8101

X-TO

X-Tl MCLK

XTAL

X171

LPF

+6dB

DIG SD1

DIG SD0

DIG CLK

BCK NET

LRCK NET

DATA NET

MCK NET

DIR LRCK

DIR FLR

DIR BCK

DIR MCK

2ch ADC

DIR

Q301

Q1002

2ch DAC

Q304

CENTER

Q4102

Q4101

Q4107

Q4104

Q4103

(SL/SR)

(CT/SW)

(FL/FR)

(BL/BR)

DSP SLR

DSP CSW

CX SCLK

CX LRCK

DSP SBLR

DSP FLR

DIR MCK

DIG CLK

DIG SDO

VMSDO

VMCLK

VMSDI

+6dB

LPF

+6dB

LPF

+6dB

LPF

+6dB

LPF

+6dB

LPF

+6dB

LPF

+6dB

FR

FL

C

SW

SR

SL

SBR

SBL

LPF

DIGSDI

DIGSDO

DIGCLK

CLK

SDO

SDI

CLK

SDO

SDI

SPI

EEPROM

RI

INTERFACE

COAX 1

RI

LEFT

ZONE2 SPK

(HDMI SLC)

(HDMI SDA)

HT-R592

TX-NR525

TX-NR626

DTR-30.5

TX-NR626/ DTR-30.5

HT-R592

TX-NR525

HT-R592

DTR-30.5 ONLY

DTR-30.5

TX-NR626

TX-NR525

T5, T6-->

<--H59

T5, T6-->

BD/DVD

VCR/DVR

<--H59

T5, T6-->

(BD/DVD)

<--H59

T5, T6-->

VCR/DVR OUT

(CBL/SAT)

CBL/SAT

<--H59

T5, T6-->

GAME

<--H59

TVCD

<--H59

T5, T6-->

(TV/CD)

(PHONO)

T6-->

<--H59/T5

4P 4P 4P

2P 2P

IR IN

IR OUT

12V TRIGGER A

12V TRIGGER B

12V TRIGGER C

TONE

INVERTING

FR

CEN

SL

SR

SW

SBL

Downmix

FL/FR -12dB

SW +3.5dB

SBR

FL

Q4003

FRONT LEFT

SBR

SURR. RIGHT

SURR. BACK.LEFT

SURR. BACK.RIGHT

SURR. LEFT

TUNER PACK

from Micom

Q4001

SURR. BACK

RIGHT

DTR-30.5

TX-NR525 Series

TX-NR626 Series

BAHDM1337

BAHDM1347

BAHDM1357

SPEAKER TERMINALS

MICOM

Q705

HT-R592

TX-NR525

TX-NR626

DTR-30.5

Q1004

Q1005

Q701

Z2NET R

Z2NET L

ONLY

TX-NR525

TX-NR626

DTR-30.5

Q351

HEADPHONES

HT-R592

ONLY

TX-NR626

DTR-30.5

(SR)

R2A15218FP

ZONE2 SPK

RIGHT

POWER AMPLIFIER

SURR L

SURR R

+29dB

Q4111

Q4112

Q4113

Q4114

Q4105 Q4115

Q4116Q4106

FL

FR

C

SW1

SBL

SBR

SR

Z2L OUT

Z2R OUT

SW2

ZONE2 L

ZONE2 R

DTR-30.5

ONLY

DTR-30.5

ONLY

TX-NR626

DTR-30.5

ONLY

Q4117

(SBR)

(SBL)

(SL)

(FR)

CEN

SR

SW

SBL

SL

PREOUT

DTR-30.5

ONLY

(GAME)

T5, T6-->

(PC)

Z2 L

Z2 R

Q4100

Q4110

Zone2 SPK

HT-R592

(LEVER TYPE)

BATRM1335 2/2

TX-NR626

DTR-30.5

ONLY

Zone2 SPK

(Banana TYPE)

HT-R592

Q701

TX-NR525

SR DIRECTION

SL DIRECTION

C DIRECTION

SW DIRECTION

FL DIRECTION

FR DIRECTION

SBL DIRECTION

SBR DIRECTION

Q4303 Q4302

TONE

Zone2 in(R-ch)

EXCEPT D3

R2A15218FP

Q4301

ZONE FUNCTION

DR-30.5 ONLY

(FL-OUT)

(FR-OUT)

(SBR-OUT)

(SBL-OUT)

Z2 out(L-ch)

Z2 out(R-ch)

Z2 R Line/preout

Zone2 in(L-ch)

SR

SL

SBR

SBL

SW

C

FL

FR

FL

(FL)

MODEL NO. HT-R592/ TX-NR525/ HT-RC550/ TX-NR626/ HT-RC560/ DTR-30.5

BLOCK DIAGRAM (PART-1) AUDIO SECTION

2013. 01. 10.

FRONT LEFT

BATRM1089 1/1

BATRM1335 1/2

(SR)

(SL)

(FL)

(FR)

(SBR)

(SBL)

(FR-IN2)

(IN-R9)

(SBR-IN)

(SUBRC-IN)

(FL-IN2)

(IN-L9)

(SUBLC-IN)

(SBL-IN)

BATRM1089 1/2

BADG1345 1/2

BADG1345 2/2

NC

(NC)

NC

SL

R L

L

R

L

R

L

R

L

R

L

R

L

R

L

R

L

R

L

R

L

R

L

R

L

R

L

R

L

R

L

R

L

R

L

R

Z2 L Line/preout

HT-R592

HT-R592 Series

MPD70F3746GJ

LTAD

RTAD

PCM1754DBQR

PCM1690DCAR DTR-30.5

TX-NR626

HT-R592

TX-NR525

PCM1681PWPR

PCM9211PTR TX-NR525

HT-R592

TX-NR626

DTR-30.5

PCM9211PTR

SII9573CTUC

PS331TQFP64GTR

TX-NR525

TX-NR626/ DTR-30.5

(REPEATER)

TRANSCEIVER

HDMI

Q201: DA808K

BADIS1370 1/4

BADIS1330 1/5

BADIS1340 1/4

BADIS1370 2/4

BADIS1330 2/5

BADIS1340 2/4

BADIS1370 3/4

BADIS1340 3/4

BADIS1330 4/5

BADIS1330 3/5

BADIS1370 4/4

BADIS1330 5/5

BADIS1340 4/4

1 12

132

6

21

20

17

18

23

24

12

11

8

9

14

15

5

3

6

73

86

81

82

85

72

78

79

70

71

68

69

66

67

64

65

62

76

75

91

90

59

58

61

60

63

55

54

46

47

40

96

39

100

37

99

36

44

97

41

38

98

43

93

42

95

45

94

83

84

2

43

78

44

100

42

79

45

99

98

97

40

41 11

9

3

5

21

23

A

1

2

3

4

5

B C D E F G H

6

7

8

IJ K

Vin1

Vin2

Vin3

Vin4

Vin5

Yin1

PBin1

PRin1

ISOIN

ISOOUT

Vin6

Vin7

Yin2

PBin2

PRin2

PRin3

PBin3

Yin3

CEC

TMDS

DDC

RPWR

HPD

TMDS

DDC

RPWR

HPD

TMDS

DDC

RPWR

HPD

DDC

RPWR

HPD

TMDS

HPD

DDC

TMDS

I2C

MUTE

UPort

I2C

I2S

S/PDIF

I2S

CEC

ARC S/PDIF

CB1

CR1

Y2

CB2

CR2

Y1

GAME/TV

AUX1

(FRONT)

COMPOSITE VIDEO INPUT

DVD

VCR/DVR

CBL/SAT

COMPONENT VIDEO INPUT

PY

PB

PR

CV

NJM1328

ISO

Y

CB

CR

COMPONENT

OUT

MONITOR

VCR/DVR

COMPOSITE VIDEO OUTPUT

HDMI IN1

HDMI IN2

HDMI IN3

HDMI IN4 Rx Port A

Rx Port C

HDMI 4Rx Tx

Rx Port B Tx

Rx Port D

ADV7623

Q8101

HDMI OUT

Model No. HT-R592

SCHEMATIC DIAGRAM (PART-2) BLOCK DIAGRAM(VIDEO)

08-11-2012

6dB

DRV

6dB

DRV

HP DET

+5V

DDC

CEC

TMDS

HP DET

+5V

DDC

CEC

TMDS

HP DET

+5V

DDC

CEC

TMDS

HP DET

+5V

DDC

CEC

TMDS

HP DET

+5V

DDC

CEC

TMDS

+5V Hot Plug

HT-R592

SCHEMATIC DIAGRAMS-02(PART-2)

BLOCK DIAGRAM VIDEO SECTION

HT-R592

A

1

2

3

4

B C D E

HT-R592

SCHEMATIC DIAGRAMS-03(PART-3)

BLOCK DIAGRAM DIGITAL AUDIO SECTION

HT-R592

HDMI_SLR

HDMI_SBLR

DIR_LRCK

DIR_BCK

HDMI_SPDIF

DSP_FLR

CX_LRCK

DIR_MCK

CX_LRCK

DIR_LRCK

DIR_BCK

DSP_FLR

DSP_SLR

HDMI_LRCK

DIR_MCK

CX_SCLK

HDMI_CSW

DIR_FLR

DSP_SLR

CX_SCLK

HDMI_FLR

HDMI_LRCK

HDMI_BCK

HDMI_MCK

DIR_MCK

HDMI_MCK

HDMI_BCK

HDMI_LRCK

HDMI_FLR

HDMI_SLR

HDMI_CSW

HDMI_SBLR

HDMI_SPDIF

DSP_CSW

DSP_SBLR

DSP_CSW

DSP_SBLR

HDMI_SPDIF

DSP_FLR

CX_LRCK

CX_SCLK

DIR_MCK

DIR

AUXIN1

ADC

MAIN OUT

DIR/ADC

A

C

D

ANALOG

DOMAIN

Q201

DA808

I2S1

I2S2

I2S3

DSD0B

DSD2B

DSD1A

DSD1B

DSD2A

DSD0A

HBR1st

HBR2nd

HBR3rd

HBR4th

I2S DSD HBR

HDMI Input S/PDIF & Analog

Input

N/A LR Clock

Master Clock

Bit Clock

I2S0 I2S0

LR ClockLR Clock

N/A

N/AN/A

DSP

DIR

Q301

MPIO_CMPIO_B

DIVIDE

HDMI Rx

USB

4

S/PDIF

INPUT

XTAL

24.576MHz

Q8101

256x48K

USB DATA

HDMI Tx

XTAL

11.2896MHz

PCM9211

256x44.1K

No USE

PCM1681

Q302

DAC

Model No. HT-R592

SCHEMATIC DIAGRAM (PART-3) BLOCK DIAGRAM (DIGITAL AUDIO)

08-11-2012

20 SCKO

19 BCK

18 LRCK

17 DOUT

5SCK

7BCK

8LRCK

6DATA1

137 USB0_DP

138 USB0_DM

124 AXR0[11]/AXR2[0]/GP3[11]

113 AXR0[2]/AXR2[3]/GP3[2]

112 AXR0[1]/ACLKX2/GP3[1]

115 AXR0[3]/AXR2[2]/GP3[3]

111 AXR0[0]/AFSR2/GP3[0]

127 AFSX0/GP2[13]/BOOT[10]

160 AHCLKX1/EPWM0B/GP3[14]

126 ACLKX0/ECAP0/APWM0/GP2[12]

123 UART1_TXD/AXR0[10]/GP3[10]

131 AFSR0/GP3[12]

121 AXR0[8]/GP3[8]

125 AHCLKX0/AHCLKX2/USB_REFCLKIN/GP2[11]

130 ACLKR0/ECAP1/APWM1/GP2[15]

22 EMA_OE/UHPI_HDS1/AXR0[13]/GP2[7]

10 MPIO_C3

9MPIO_C2

8MPIO_C1

7MPIO_C0

96

MCLK_OUT 95

SCLK_OUT 94

AP5_OUT 88

AP1_OUT 89

AP2_OUT 90

AP3_OUT 91

AP4_OUT

87

AP0_OUT

68

MCLK_IN 69

SCLK_IN 70

AP5_IN 76

AP1_IN

15 MPO0

16 MPO1

39 XTI

4MPIO_A1

11 MPIO_B0

12 MPIO_B1

13 MPIO_B2

14 MPIO_B3

116 AXR0[4]/GP3[4]

118 AXR0[6]/ACLKR2/GP3[6]

117 AXR0[5]/AFSX2/GP3[5]

122 UART1_RXD/AXR0[9]/GP3[9]

12 DATA3

11 DATA2

13 DATA4

A

1

2

3

4

B C D E

Onkyo HT-R592 User manual

Popular Receiver manuals by other brands
