HTX-22HDX
SERVICE MANUAL
SERVICE MANUAL
RC-720S
V1.4a
R
DIGITAL SURROUND SYSTEM
Black model
MODEL HTX-22HDX(B)
230V AC, 50Hz
120V AC, 60Hz
B MPP
B MDC
Ref. No. 4204
042010
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK ON THE
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.

HTX-22HDX
FIRMWARE UPDATE-1
DSP Update procedure
HTX-22HDX Rear Panel
OPTICAL
IN
2
DIGITAL
OUT
OPTICAL
Connection Example
PC (Personal Computer) For a different shape of OPTICAL terminal,
Use a conversion adapter.
L
R
DIGITAL
ANALOG
REMOTE
CONTROL
OUT
OUT
OPTICAL
CD player
OPTICAL
IN
2
DIGITAL
OUT
OPTICAL
[Preparation]
1. PC (Personal Computer) which can play back wav files and output digital audio signal at 44.1 kHz (sampling frequency).
2. Software: Given wav-formatted FW Store it in the PC in advance (PC Update) or burn a CD-R with it as a music disc (CD Update).
3. Connection: DIGITAL (OPTICAL/COAXIAL) OUTPUT of PC/CD Player --> DIGITAL (OPTICAL/COAXIAL) INPUT of HTX-22HDX.
* PC needs to be able to handle wav files and output digital audio signal at Sampling Frequency 44.1 kHz.
* For wav-compatible PCs which do not output audio signal at the above specification,
use a commercially-available USB-AUDIO interface unit. e.g. Onkyo-made ND-S1
* Set Sampling frequency to 44.1 kHz and also set Volume to Maximum.
For further information, please see Owner’s manual of your PC.
* Instead of PC, CD players with DIGITAL output terminal can be used.
Note: CD players need to output digital audio signal at 44.1 kHz of Sampling frequency.
Some CD players and DVD players are not suitable for update because they process audio signal to output.
Burn a CD-R as music disc.

HTX-22HDX
FIRMWARE UPDATE-2
DSP Update procedure
D:1.00/10218aDX
Main1.01/10326AB
ChsumM:98E1708B
S/PDIF Update..
* It depends on the version.
* It depends on the version.
* It depends on the version.
TOTAL / AUTO
TOTAL / AUTO
DSP / AUTO
Standby mode
Writing...
Complete!
Clear
S/PDIF Update.. *Playback starts
(Playback time: about 19 seconds.)
(about 25 seconds.)
<NOTE>
1.
“Writing” will not be shown even more than about 19 seconds passed
after starting playback, audio signal does not output at Sampling
frequency: 44.1kHz.
Check the connection and settings and try again.
When another try results in failure again, use the other update method.
2.
DURING FW UPGRADE,
DO NOT TURN OFF THE UNIT. DO NOT REMOVE ANY CONNECTIONS.
These operation will not allow FW Upgrade any more, and
the whole board or IC will need replacing.
[Procedure]
1. Set MASTER VOLUME value to 10.
2. Hold down [INPUT] button and then press [ON/STANDBY] button.
Main FW version will be displayed.
3. Press [LISTENING MODE] button.
DSP FW version will be displayed.
4. Press [LISTENING MODE] button.
Check Sum will be displayed.
5. Press [INPUT] button.
* Pressing [LISTENING MODE] button changes AUTO ---> COAX1 ---> OPT1 ---> AUTO
6. Press [INPUT] button. (No change)
7. Press [LISTENING MODE] button.
* TOTAL ---> DSP ---> MAIN ---> DSP ----> MAIN
8. Press [INPUT] button.
9. PC upgrade: Play back the wav file stored in your PC.
CD upgrade: Play back the FW CD-R with the connected CD player.
After playback ends (about 19 seconds.), writing will start. It takes about 25 seconds.
<NOTE>Make sure that ”PCM” is shown before starting playback.
About 19 seconds later, the message will change from S/PDIF Update.. to Writing...
When “Writing...” will not be shown, the output music data is not correct.
Check the connection and settings.
10. Turn on the unit and confirm the new version number.

HTX-22HDX
EXPLODED VIEWS-1
OVERALL / SPEAKER SECTION
HTX-22HDX
SP12
SP01a/b
SP02a/b
SP06
x 5 pcs
SP15a/b
SP03
SP05
x 4 pcs.
SP05
x 8 pcs.
SP04
x 4 pcs.
A034
x 2 pcs
A033
x 3 pcs
A032
A134
---Rear---
See "EXPLODED VIEWS-2"

HTX-22HDX
EXPLODED VIEWS-2
AMPLIFIER SECTION
HTX-22HDX
A062
A045
A052
A025
A016
A012
A021 A018
E892
A140
A014
L=70mm
A001
A003
A002
A039
A130
A022
L=95mm U02-2
U02
U03
U03-1
U03-2
U03-5
(NSP)
U03-4
U03-3
U01 U02-1
U02-3
(NSP)
P7051
A101
A142
A143
A138
E895
E889
F901
T901
A020
x 4 pcs
A009
x 4 pcs
A050
x 2 pcs
A008
x 6 pcs
A010
x 4 pcs
E890
x 7 pcs
A105
x 14 pcs
A106
x 4 pcs
(3 x 6mm)
A023
x 6 pcs
A042
x 4 pcs
A024
x 2 pcs
A136
x 2 pcs
A024
x 4 pcs
A019
x 2 pcs
A028
x 2 pcs
A107
x 4 pcs
A108
x 4 pcs Q5001A
See “PC BOARD PARTS LIST”
A132
L=150mm
A132
L=150mm
A144
x 2 pcs
(FELT)
A046
L=80mm

HTX-22HDX
EXPLODED VIEWS-3
HTX-22HDXST <L / R>
HTX-22HDX
SP20a/b
"HTX-22HDXST <L>" "HTX-22HDXST <R>"
TERMINAL :
White / Black
TERMINAL :
Red / Black
<Note>
Cannot remove the speaker grill.

HTX-22HDX
SCHEMATIC DIAGRAMS - 1/8
POWER SUPPLY SECTION
A
1
2
3
4
5
BCDEFGH
APOWER
+BSUB
GNDDG
+BDG
POFF
FLAC2
FLAC1
-VP
+5VDIS
AMPAC1
AMPAC2
AMPAC4
AMPAC3
DGAC1
DGAC2
STBY:14.66V
P-ON:12.5V
F9001T901 T9002
JJ
T1AL250VPP
DC
NPT-1520JQ
NPT-1520JQ
NPT-1520GQ
2.5A/125V
2.5A/125V
BAPS-0434
BAPS-0331
BAETC-0335
BAETC-0438 JJ: AC100V/50Hz
/60Hz
PP: AC230V/50Hz
DC: AC120V/60Hz
TO BAAF-0326TO BAAF-0326
NPT-1577J
NPT-1577P
NPT-1577D
TO BADIS-0435(SA-205HDX)
TO BADIS-0332(HTX-22HDX)
1.25V--->22mA
R9001---68(1/2W) Jtype
100(1/2W) D,Ptype
-27.2V
+12.6V
+10.2V
1(1/2W) J,Ptype
R9106---2.2(1/2W)Dtype
C9003
103M/275VAC
C9002
472/250V
R9003
100K
D9008
RL1N4003 D9003
RL1N4003
D9002
RL1N4003
D9112
RL1N4003
C9009
4.7/50
C9007
470/16
+
R9104
33K
C9105
47/50
D9009
RL1N4003
R9002
10(1/2W)
R9004
68(1/2W)
P9501A
1
2
3
4
C9001
472/250V
JL9004A
1
2
3
4
5
6
7
C9106
223K
Q9001
KRC105S
D9007
UDZS4.3B
R9105
2.2(1/2W)
T9002
NPT-1520JQ
9
8
6
5
4
1
D9005
KDS4148U
D9004
KDS4148U
D9001
KDS4148U
L9001
NCH-3581
2
14
3
D9006
S1NB60-4062
1
3
4
2
C9110
473
C9005
223J
AC_CORD
F9001B F9001A
P9001
2
1
C9004
104J
P9002B
1
P9002A
1
P9003
AC_INLET
1
2
RL9001
4
32
1
P7003B
5
4
3
2
1
C9104
470/50
R9103
5.6K
R9102
5.6K
Q9101
2SC2235
D9113
UDZS16B
D9105
UDZS16B
T901
Val
8
9
10
11
12
13
14
15
16
17 6
5
2
R9001
C9006
2200/16
R9106
R9101
22(1/4W)
AGAINST FIRE HAZARD, REPLACE
VA
FOR CONTINUED PROTECTION
AND RATING INDICATED.
ONLY WITH FUSE OF SAME TYPE
CAUTION
ATTENTION
ET CALIBRATION COMME INDIQUE.
D'INCENDIE, REMPLACER UNIQUEMENT
PERMANENTE CONTRE LES RISQUES
AFIN D'ASSURER UNE PROTECTION
PAR UN FUSIBLE DE MEME TYPE
VA
E LENT.POUR UNE PROTECTION PERMANENTE,N'UTILISER
INDIQUE LA QU LE PRESENT SYMBOL EST APPOSE.
QUE DES FUSIBLES DE MEME TYPE. CE DARNIER EST
CE SYMBOLE INDIQUE QUE LE FUSIBLE UTLISE EST
FOR CONTINUED PROTECTION AGAINST FIRE
RATING REFER TO THE MARKING ADJACENT TO THE SYMBOL.
HAZARD,REPLACE WITH SAME TYPE FUSE. FOR FUSE
THIS SYMBOL LOCATED NEAR THE FUSE INDICATES
THAT THE FUSE USED IS SLOW OPERATING TYPE
THE COMPONENTS IDENTIFIED BY MARK ARE CRITICAL FOR SAFETY
REPLACE ONLY WITH PART NUMBER SPECIFIED.
VOLTAGE (MEASURED WITH VOLTMETER) IS DC VOLTAGE.(NO INPUT SIGNAL).
ALL PNP TRANSISTORS ARE EQUIVALENT TO 2SA1015-GR UNLESS OTHERWISE NOTED.
ALL NPN TRANSISTORS ARE EQUIVALENT TO 2SC1815-GR UNLESS OTHERWISE NOTED.
ALL DIODES ARE EQUIVALENT TO 1SS133 UNLESS OTHERWISE NOTED.
ELECTROLYTIC CAPACITORS ( ) ARE IN uF/WV.
ALL CAPACITORS ARE IN pF/50WV UNLESS OTHERWISE NOTED.
EX) 030- 3pF 330- 33pF 331- 330pF 333- 0.033uF
ALL RESISTORS ARE IN OHMS 1/4WATTS UNLESS OTHERWISE NOTED.
THE THICK LINES ON PC BOARD ARE THE PRINTING SIDE OF THE PARTS.
EX) PRINTING SIDE
CIRCUIT IS SUBJECT TO CHANGE FOR IMPROVEMENT.
!
NOTE

HTX-22HDX
SCHEMATIC DIAGRAMS - 2/8
POWER AMP. SECTION
A
1
2
3
4
5
BCDEFGH
FR
FL
SR
SL
C
SW
VOLH
+BSUB
+BDG
APOWER
POFF
GND
GND
GND
GND
GND
GND
-27V
+27V
-27V
+27V
-27V
+27V
+27V
-27V
-27V
+27V
+5VDG
+5VDG
+27V
-27V
SPRLCS
SPRLF
RCPOWER
RCPOWER
GNDDG
GNDDG
FR_SPOUT
FL_SPOUT
GND
SL_SPOUT
SR_SPOUT
AMPAC1
AMPAC4
FR_SPOUT
C_SPOUT
+BDG
C_SPRL
SLR_SPRL
FLR_SPRL
DGAC1
DGAC2
POFF
+BDG
APOWER
+BSUB
GNDDG
SW_SPOUT
FL_SPOUT
GNDLR
NO.2BAAF-0326
+27V
-27V
NC
+12.6V
12V_RELAY
+5.0V
to ASP SECTION
GNDLR
12V_RELAY
SURR ch AMP
FRONT ch AMP
CENTER ch AMP
SW ch AMP
AMPAC2
AMPAC3
SL/SR OUT
From BAPS-0331(HTX-22HDX) From BAPS-0434(SA-205HDX)
FL/FR OUT
SW OUT
SW OUT
C OUT
To BAHDM-0324
(for HTX-22HDX)
To BATRM-0437
To BATRM-0334
(for SA-205HDX)
NC
(for SA-205HDX)
(for HTX-22HDX)
NC
&PCB&auevh021
2
1
C5011
104
C5012
104
C5112
104
C5108
NC
R5001
1K
R5003
1K
C5006
NC
R5004
1K
R5006
1K
C5008
NC
R5101
1K
R5103
1K
R5104
1K
R5106
1K
R5114
4.7(1W)
C5009
220/10
C5010
220/10
C5110
220/10
R5113
4.7(1W)
R5014
4.7(1W)
R5013
4.7(1W)
C5111
104
C5103
471
C5101
471
C5003
471
C5001
471
C5007
NC
C5005
NC
C5013
NC
C5014 NC
C5114 NC
C5113
NC
R5201
1K
R5203
1K
C5207
NC
Q5201
LM2876
1
2
3
4
5
6
7
8
9
10
11
+V
NC
OUTPUT
-V
NC
NC
GND
MUTE
-IN
+IN
NC
C5203
NC
C5204
NC
C5205
220/10
Q5301
LM3886
1
2
3
4
5
6
7
8
9
10
11
+V
NC
OUTPUT
-V
+V
NC
GND
MUTE
-IN
NC
+IN
C5301
471
R5303
1K
C5303
NC
C5304
NC
C5305
220/10
R5307
4.7(1/2W)
C5201
471
C5109
220/10
C5002
47/50
C5004
47/50
C5104
47/50
C5202
47/50
C5302
47/50
R5301
1K
C9504
8200/35
+
R5207
4.7(1/2W)
C5206
104
C9503
8200/35
+
C5306
104
E901
1
2 3
4
C9202
10000/16
P9102B
13
12
11 10
9
8
7
6 5
4
3
2
1
R9205
47
Q9203
2SC2712
R9206
47
Q9204
2SC2712
R9207
47
Q9205
2SC2712
R9208
47
R9220
470(1W)
Q9206
2SC2712
R9221
56
Q9207
2SC2712
RL5301
2
5
61
4
3
C5307
102
D5301
1SS352
C9502
334
C9501
334
D9502 1SS352
C9505 102K
RL9501
1
2 3
4
RL9502
2
1 4
3
P9802
1
2
3
4
R9209
2.2(1/2W)
Q9201
78M053
O
2G 5HT
1I
R9222
6.8(1W)
C9204
47/25
+
C9203
223K
R9223
6.8(1W)
D9501
RS1505M
1
2
4
3
C9201
334
D9204
D3SBA20
1
3
4
2
Q9202
2SC2712
P9803
1
2
3
4
C5106
NC
P9804
1
2
3
4
Q5101
LM4766
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
OUT-B
VCC-A
OUT-A
VEE
GND-A
-IN_A
MUTE-A
+IN_A
NC
GND-B
MUTE-B
-IN_B
+IN_B
NC
VCC-B
C5105
NC
C5107
NC
R5002
47K
R5005
47K
R5102
47K
R5105
47K
R5108
56K
R5107
56K
R5202
47K
R5204
56K
C5308
NC
R5304
56K
R5302
47K
R5305
12K
R5205
12K R5110
12K R5109
12K
R5010
12K
R5008
56K
R5009
12K
F5001
3.5A
P9805
CLAMPER
1
D5901 1SS352
D5902 1SS352
D5903 1SS352
D5904 1SS352
D5906
1SS352
D5905
1SS352
D5907
UDZS3.3B
P9801
1
2
3
4
R5905
47K
R5906
47K
R5904 47K
R5903 47K
R5902 47K
R5901 47K
R9218
2.2K
R9216
2.2K
R9214
2.2K
R9212
2.2K
R9210
2.2K
R9211
47K
R9213
47K
R9215
47K
R9217
47K
R9219
47K
R5306
2.2K
R5206
2.2K
R5112
2.2K
R5111
2.2K
R5012
2.2K
R5011
2.2K
Q5001
LM4766
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
OUT-B
VCC-A
OUT-A
VEE
GND-A
-IN_A
MUTE-A
+IN_A
NC
GND-B
MUTE-B
-IN_B
+IN_B
NC
VCC-B
R5007
56K
R5908
NC
R5907
470K
C5901
1/50
JL9004B
7
6
5
4
3
2
1
P5001B
1
2
3
4
5
P5101B
5
4
3
2
1
P5301B
1
2
P5201B
2
1
P9501B
4
3
2
1
P8105C
1
2
JL9103B
5
4
3
2
1
C9506
NC
P5302
2
1
P5304
NC
1C5309
NC
J5043 7.5
L5301 NCH-1647
1
3 4
2
J5044 7.5
C5102
47/50

HTX-22HDX
SCHEMATIC DIAGRAMS - 3/8
AUDIO SIGNAL PROCESSOR SECTION
A
1
2
3
4
5
BCDEFGH
AMUT
AMUT
ADC_L
ADC_R
DAC_FR
DAC_FL
DAC_SW
DAC_CT
DAC_SR DAC_SL
DAC_SBR
DAC_SBL
-15V
+15V
ADC_R
ADC_L
MICOUT
VOL_DATA
VOL_CLK
VOLH
AMUT
IN2R
IN1L
IN2L
IN1R
SBR
MICOUT
SBR
SBL
SBL
SW
C_OUT
SBL
SBR
+15V
-15V
SW
SW
C
FR FL
SL
SR
VOLH
SW
C
FR
FL
SR
SL
VOLH
1N3L
IN3R
AMUT
GND
GND
GND
GND
-27V
-27V
+27V
+27V
-15V
+15V
IN2R
IN2L
IN1R
IN1L
SL_OUT
SR_OUT
GND
-15V
SW_OUT
MICOUT
L_OUT
R_OUT
DMIXL
DMIXR
C_OUT
SBR_OUT
SBL_OUT
+15V
+15V
-15V
L_OUT
R_OUT
DAC_FR
DAC_SW
DAC_FL
SA-205HDX Only
SW
Rch
Lch
Rch
Lch
Lch
Rch
IN3
IN2
IN1
GNDLR
Subwoofer
Rch
Lch
GND
BAAF-0326 NO.1
SB PreOut
Rch
Lch
Downmix
to MAIN AMP SECTION
54mA
47.7mA
47.7mA
6.3mA
6.3mA 53.3mA
0.43W
Cut off 350Hz
Cut off 1.6KHz/Gain 20dB
0.44W
Headphone
(Only for SA-205HDX )
R5694 220K
R5693 220K
R5692 220K
R5691 220K
R5695 220K
R5696 220K
R5699 220K
R5700 220K
R5587 10K
C5666
220/25
C5667
220/25
R5698
220K
R5697
220K
R5579
220K
P4101B
1
2
3 4
5
6
7
8
9
10
11
12
13
P4102B
1
2
3
4
5
6
7
8
9
10
11
12
13
R5511
2.2
C5509
221J
R5549
220K
R5503
330
R5504
330
R5543
220K
R5544
220K
R5505
330
R5545
220K
R5546
220K
C5506
221J
C5505
221J
C5504
221J
C5503
221J
R5501
NC
R5502
NC
R5512
NC
C5501
NC
C5502
NC
P5901
NC
4
2
1
3
R5541
0
R5542
0
Q5607
RN1441
R5607
220K
R5627
100
Q5617 RN1441
C5607
47/50
R5626
100
C5606
47/50
R5606
220K
Q5605
RN1441
R5605
220K
R5625
100
C5605
47/50
Q5615
RN1441
Q5606
RN1441 Q5616 RN1441
Q5603
RN1441
R5603
220K
R5623
100
C5603
47/50
R5624
100
R5604
220K
Q5604
RN1441
C5604
47/50
Q5614
RN1441
Q5613
RN1441
R5610
270
Q5630B
NJM4580
5
6
8
7
R5641
680 R5642
680
C5641
474
R5600
10K
R5643
10K
R5620
100
R5681 220K
R5714
10K
R5713
10K
R5704
220K
R5703
220K
C5711
222
C5708
47/25
C5707
47/25
C5704
10/50
C5703
10/50
C5712
222
Q5701B
NJM4580
6
5
7
8
Q5701A
NJM4580
3
2
1
4
JL7202B
1
2
3
C5632 103J
R5632
15K
R5631
47K
C5631 221
C5600
47/50
Q5600
RN1441
Q5610
RN1441
R5633
1.2K
C5642
1/50
C5630
47/25
R5613
220
R5614
220
R5615
220
R5616
220
R5617
220
R5688
22(1W)
R5690
6.8(1/2W)
C5672
10/50
C5673
10/50
Q5671
79M15
3O2
I
4 1
G
Q5670
78M15
3O
2G
4
1
I
C5671
104
C5670
104
R5689
22(1W)
R5687
6.8(1/2W)
R5667
150(1/2W)
R5666
150(1/2W)
R5715 150(1/2W)
R5716 150(1/2W)
C5678
47/50
C5677
47/50
R5595 10K
C5591 330J
Q5503B
NJM4580
7
8
6
5
Q5503A
NJM4580
1
2
3
4
R5594 10K
C5590 330J
R5591
22K
R5599
22K
R5590 12K
R5598 12K
C5552 47/25
C5556 47/25
C5555 47/25
C5554 47/25
C5553 47/25
C5557 47/25
C5558 47/25
R5589
10K
R5588 10K
R5684
150(1W)
D5671
UDZS6.8B
D5672
UDZS6.8B
JL5902A 1
R5596
330
R5597
3.3K
R5592
330
R5593
3.3K
+6.9V
C5674
470/16
-6.92V
C5551 47/25
R5506
330
R5513
NC
C5611 NC
C5612
NC
Q5501
R2A15218FP
80 NC10
79 INL9
78 INR9
77 NC9
76 INLA/RECL1
75 INRA/RECR1
74 NC8
73 INL8
72 INR8
71 INL7
70 INR7
69 INL6
68 INR6
67 INL5
66 INR5
65 INL4
64 INR4
63 INL3
62 INR3
61 INL2
60 INR2
59 INL1
58 INR1
57 NC7
56 AGND7
55 ADCR
54 ADCL
53 NC6
52 AVEE
51 MUTE
50 CLOCK
49 DATA
48 DGND
47 SUBR 46 SUBL
45 SBLCIN
44 SBRCIN
43 FRIN2
42 FLIN2 41 SRIN2
40 SLIN2
39 SWIN2
38 CIN2
37 SBRIN2 36 SBLIN2
35 NC5
34 TRER
33 BASSR2
32 BASSR1 31 NC5
30
AVCC
29
NC4
28
TREL
27
BASSL2
26
BASSL1
25
NC3
24
FRC
23
FROUT
22
AGND6
21
FLOUT
20
FLC
19
AGND5
18
CC
17
COUT
16
AGND4
15
SWOUT
14
SWC
13
NC2
12
SRC
11
SR_OUT
10
AGND3
9
SLOUT
8
SLC
7
AGND2
6
SBRC
5
SBROUT
4
AGND1
3
SBL_OUT
2
SBLC
1
NC1
100
SBRIN1
99
SBLIN1
98
SRIN1
97
SLIN1
96
SWIN1
95
CIN1
94
FRIN1
93
FLIN1
92
NC14
91
RECL3
90
RECR3
89
NC13
88
NC12
87
NC11
86
INL11/RECL5
85
INR11/RECR5
84
INL10/RECL4
83
INR10/RECR4
82
INLB/RECL2
81
INRB/RECR2
D5673
NC
C5675
470/16
D5674 NC
P5903
3
2
1
P5902
7
2
1
3
5
4
6
R5507
NC
R5508
NC
R5548
NC
R5547
NC
C5507
NC
C5508
NC
P5904
NC
4
2
1
3
C5601
NC
R5510
NC
C5602
NC
R5601
NC
R5602
NC
Q5601
NC
Q5602
NC
R5611
NC
R5612
NC
R5621
NC
R5622
NC
Q5611
NC
Q5612 NC
R5705
5.6K
R5706
5.6K
R5707
5.6K
R5708
5.6K
R5509
2.2K
D5001
NC
R5683
150(1W)
C5709
100/10
C5710
100/10
C5701
10/50
C5702
10/50
R5701
3.3K
Q5703
RN1441
R5702
3.3K
Q5704
RN1441
R5709 10K
C5705 101
C5706 101
R5710 10K
R5634 10K
Q5630A
NJM4580
3
2
1
4
R5630
220
R5717 NC
R5718 NC
R5711
47
R5712
47
Q5705
RN1444
Q5706
RN1444
C5608
NC
C5609
NC
C5610
NC

SCHEMATIC DIAGRAMS - 4/8
MICROPROCESSOR SECTION
HTX-22HDX
A
1
2
3
4
5
BCDEFGH
RI
FSI
FSO
ROMSDO
CEC_IO
KEYINT0
DIRRST DIGSDI
DIRCS DIGCLK
DIGSDO
RI
+5VST
KEY0
DIGCLK
DIGSDO
DIGSDI
MPOWER
VOLCLK
VOLDATA
SPRLCS
SPRLF
HPDET
POFF2
FLDCS
FLDSDO
FLDCLK
FLDRST
+5VST
+3.3VST
+3.3VMPU
+3.3VDG
+5VA
RCPOWER
MPOWER
POFF
+BSUB
+5VDG
FANCTRL
FSI FSO
HDMIRST
HDMIINT2 HDMISCL
HDMIPDN
POFF HDMISDA
HDMIINT
DRST
INPSEL
SYSOUT
SYSIN
HDMIINT_TX
RMCK
DACCS
DIGCLK
DIGSDO
DACMUTE
CX_SCLK
DSPLR
DSPCSW
DSPSLR
DSPSBLR
DACRST
FLMD0
DIR_SDOUT
DIRINT0
AP1_OUT
MCLK_OUT
SCLK_OUT
AP0_OUT
AP5_OUT
FCLK
FSO
HS
OC_DCK
OC_DDI
OC_DDO
FLMD0
FSI
RESET
RESET
DRST
OC_DMS
MPOWER
+3.3VMPU
DSPCSW
DSPSLR
DSPSBLR
CX_SCLK
RMCK
CX_LRCK
CEC_IO
DIGCLK
DIGSDO
INPSEL ARC_SPDIF
DIR_BCK
DIR_LRCK
DIR_SDOUT
AP1_OUT
AP5_OUT
SCLK_OUT
MCLK_OUT
HDMIPDN HDMIRST
HDMISDA
HDMISCL
HDMIINT
HDMIINT2
HDMIINT_TX
DSPRST
DSPCS
AP0_OUT
DSPINT2
DSPINT1
DSPINT0
+3.3VMPU
DSPLR
DIGSDI
ROMCLK
DACRST
DACMUTE
DACCS
DIRCS
DIRRST
HS
DIRINT0
DSPINT2
DSPINT1
DSPINT0
DSPCS
DSPRST
CEC_IO
REMIN
FCLK
FLMD0
MICMUT
LEDSTBY
LEDTHRU
+3.3VMPU
+5VDIS
FLDRST
FLDCS
FLDCLK
FLDSDO
VOLA
REMIN
LEDSTBY
LEDTHRU
KEYINT0
KEY0
KEYINT0
+15VA
-15VA
GNDA
GNDA
MICDET
VOLB
MICOUT
HPDET
MICMUT
VOLB
VOLA
MICDET
THERMAL
VOLH
FLMD1
KEY0
DIR_BCK
DIR_LRCK
OC_DDO
OC_DDI
OC_DMS
OC_DCK
RESET
INT3
INT2
INT1
BAND
SPRLCS
SPRLF
AMUT+3.3VST
+15VA
DAC_FR
DAC_FL
DAC_SW
DAC_CT
DAC_SR
DAC_SL
DAC_SBR
DAC_SBL
-15VA
VOLH
AMUT
VOLDATA
VOLCLK
MICOUT
ADC_R
ADC_L
GNDA
GND
GND
GND
GND GND GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GNDD
GND
GND
FAN
+BDG
GNDFAN
RCPOWER
DIRINT1
ADC_L
ADC_R
DIRINT1
CX_LRCK
+3.3VDG
+5VA
DIRINT1
AP0_OUT
RMCK
FANCTRL
AMUT_I
GNDFAN
GND
+5VDG GND
THERMAL
-15VOP
+15VOP
OPT2
OPT1
COAX
TO FAN
RI
BH33FB1WG
P7501B
FLASH WRITERDEBUGGER TO BAHDM-0324TO BAHDM-0324
TO BADIS-0435
TO BADIS-0332
TO BAAF-0326
LIST
LIST
LIST
TO BASW-0333
TO BAAF-0326 TO BAAF-0326
BADG-0327
+5.0V
+3.3V
+3.3V
+12.6V
+10.2V
-15.0V
+15.0V
R794
R802
R795
R803
R796
R804
R797
INT1
INT2
BAND
INT3
NC NC NC
NC NC
00
0
0
0
0
0
NC
10K
10K
10K
10K 10K
33K
33K
10K
10K
10K
33K 10K 10K
10K33K
R805
NC NC
10K
R709
10K 10K
10K
10K
10K
NCR705
VOL
MIC
NCNC YESP7001B
P7501B NCYES YES YES
NCYESDIS
NC
YES YES
HP
R856
R712
C700
0
NC10K
R855
R773
C706
000
102J
NC
NCNC
47K
NC
NC NC NC
000
102J
NC
NCNC
47K
NC
NC NC NC
SA-205HDXHTX-22HDX
MJJ MDC MPP MJJ
LIST
P7004B
BAETC-0328
L100
BLM21PG221SN1
R100
470
C101
101J
R749 47
R746 10K R747 47
R742 10K
R713 10K C701 104Z
R739 47
R714 47
R750 47
R732 47
R738 47 R734 10K R737 10K
R731 47
R730 47
R729 47 R733 47
C713 104ZC717 104Z
R715 47
C702 104Z
R722 47 R723 47
R728 47
R727 47
R726 47
R725 47 R724 47 R716 47
R717 47 R718 47 R736 220 R735 220
R719 47
R758 10K
Q704
KRC107S
R767 27K
C715
102K
R721 47
R849 47
R488
1.8K
R492
4.7K
R490
4.7K
R496
4.7K
R484
1.5K
R485
2.7K
R480
560
R481
1K
R494
680
C102
104Z
D101
KDS4148U
C484 101J
C480
222J
C486
682J
C482
221J
R107
330
C110
104Z
C106 080D
R109 10K
R108 82K
R102
75
C104
101J
R101
10
L101
LBC2518T2R2M
L102
LBC2518T2R2M
C103
104K
R103
220K
C301 104Z
C300 221J
R303 220
R304 330 R305 330 R306 330
R307 330
R808 2.7K
C714 102K
R813 47K
C721 104Z
C719
4.7/50
C722 104Z
Q713
KRA107S
R840
10K
R845 100 R846 100
R801 10K
R806 10K
R809 4.7K
Q711
KRC102S
R831 47
R802 R803
R804
R805
Q709
KRC104S
D703
KDS4148U
L701
BLM18PG181SN1D
R811 22K
R821 47
R820 47
R818 47
R819 47
R823 47
R822 47
R824 47
R828 47
R832 10K
R826 47
R825 47
C718 104Z
R812 22K
R810
4.7K
R807
10K
R830 10K
R834 10K
R835 10K
R836 10K
R829 10K
R814 1M
R817 47
R816 47
R815 47
C724
104Z
D702
KDS4148U
C716 100/10
R302
330
C317 104Z
R341
220
C310
104Z
C313
470/10
L306
LBC2518T4R7M
L304
LBC2518T4R7M
C322 470/10
R342
680
C318 472K
C321
473K
C316 47/25
C323
223K
C109104Z
R789 10K
R784 10K
R791 47
R777 4.7K
R775 47
R768 47
R766 47
R752 10K
R755 220
R754 220
R753 220
R760 10K
R757 10K
R756 10K
R762 47
R763 47
R761 10K
R800 10K
R795
R796
R797
R780 47
R765 1M
R786 47
R799 22K
R778 220
R787 220
R785 220
R783 220
R798 22K
R788 220
R793 10K
R769 10K
R764 10K
R781 10K
R774 10K
R776 10K
C712 100/10
Q707
S-812C50AUA-C3E
I
G
O
R748 47
R703 10K
C452 47/25
C453 47/25
C454 47/25
C455 47/25
R850 10K
R720 47
R853 47
R837
1K
R790
10K
C108 106K/6.3
P100
1
2
3
R861 10
R860 10
C725 10/50
P702
2
1
C705
104Z
D102
KDS4148U
Q101
74HCU04F
7GND
6
5
4 3 2
114
VCC
13
IN6
12
OUT6
11
IN5
10
OUT5
9
IN4
8
OUT4
X701
R324 330
R321 330
R327 330
R493
4.7K
R487
1.5K
R486
2.7K
R489
1.8K
R497
4.7K
R495
680
R491
4.7K
R483
560
R482
1K
R450
15K
R451
15K
R434
22K
R435
22K
R404
1.8K
R405
1.8K
R453
15K
R452
15K
R454
15K
R455
15K
R407
1.8K
R406
1.8K
R436
22K
R437
22K
R438
22K
R439
22K
R408
1.8K
R457
15K
R456
15K
R458
15K
R459
15K
R411
1.8K
R410
1.8K
R440
22K
R441
22K
R442
22K
R443
22K
R449
15K
R448
15K
R433
22K
R409
1.8K
C418
471J C420 471J C421 471J
C485
101J
C481
222J
C487
682J
C483
221J
R311 10K
R310 10K
R309 47
R301 47
R300 47
R308 47
L303 LM182
R841
220K
Q712
KRC102S
Q714
KRA107S
R839 47K
R838 10K
R842 10K
R843 10K
R844 10K
R847 10K
R848 10K
R312 10K
R335 330
R334 330
R330 10K
R329 10K
C314 470/10
C315 104Z
R325 47
R322 47
R328 10K
R314 10K
R317 47
R319 47
C303
470/10
C311
47/25
R313 47
R340 4.7K
R331 47
R337 330
R338 330
R339 330
R344 330
R318 47
R320 47
R326 47
R323 47
R315 47
C309 104
R343 NC
C325 221J
R333 330
C425 47/25
C426 47/25
C305
104
C312
104
Q302
PCM9210
25 MC/SCL
26 MS/ADR1
27 MODE
28 RXIN7/ADR1
29 RXIN6/ALRCKI0
30 RXIN5/ABCKI0
31 RXIN4/ASCKI0
32 RXIN3
33 RXIN2
34 RST
35 RXIN1
36 VDDRX
37 RXIN0 38 GNDRX
39 XTI 40 XTO
41 AGND
42 VCC 43 FILT 44 VCOM
45 AGNDAD 46 VCCAD
47 VINL
48 VINR
1
ERROR/INT0
2
NPCM/INT1
3
MPIO_A0
4
MPIO_A1
5
MPIO_A2
6
MPIO_A3
7
MPIO_C0
8
MPIO_C1
9
MPIO_C2
10
MPIO_C3
11
MPIO_B0
12
MPIO_B1
13
MPIO_B2
14
MPIO_B3
15
MPO0
16
MPO1
17
DOUT
18
LRCK
19
BCK
20
SCKO
21
DGND
22
DVDD
23
MDO/ADR0
24
MDI/SDA
R432
22K
C416
471J
C726 100/10
C112
100/10
C113 100/10
Q710
XC6221B332MR
1VIN
2GND
3STBY 4
NC
5
VOUT
R794
R110
330
C100
104Z
E100
P101
1
2
3
U100
JSR1165-001recieving
2
GND
3
VCC
1
IN
U101
JSR1165-001recieving
2
GND
3
VCC
1
IN
C711 220/25
R707 10K
R710 10K
R711 10K
R708 10K
R704 10K R706 10K
R851 10K
R852 10K
R701 10K
R700 10K
R702 10K
P700A
9
8 7
6 5
4
3 2
1
P8102B
1
2 3
4 5
6
7 8
9
10
11 12 13
14
15
16
17
18
19
20 21
22
23
24
P8101B
1
2 3
4
5 6
7
8
9
10
11
12
13 14
15
16
P701A
9
8
7
6 5
4
3
2
1
R792 47
R782 10K
R827 NC
P7001B
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
C304
NC
C307 NC
C308 NC
C326
NC
R759 47
R779 10K
D701 NC
C700
C706
C704 102K
P7004B
3
2
1
Q483:B
NE5532APSR
6
5
7
Q701
MPD70F3746
109
PDL4/AD4
110 PDL5/AD5/FLMD1
111 PDL6/AD6
112 PDL7/AD7
113 PDL8/AD8
114 PDL9/AD9
115 PDL10/AD10
116 PDL11/AD11
117 PDL12/AD12
118 PDL13/AD13
119 PDL14/AD14
120 PDL15/AD15
121 PDH0/A16
122 PDH1/A17
123 PDH2/A18
124 PDH3/A19
125 PDH4/A20
126 PDH5/A21
127 PDH6/A22
128 PDH7/A23
129 P715/ANI15
130 P714/ANI14
131 P713/ANI13
132 P712/ANI12
133 P711/ANI11
134 P710/ANI10
135 P79/ANI9
136 P78/ANI8
137 P77/ANI7
138 P76/ANI6
139 P75/ANI5
140 P74/ANI4
141 P73/ANI3
142 P72/ANI2
143 P71/ANI1
144 P70/ANI0
1
AVREF0
2AVSS
3P10/ANO0
4P11/ANO1
5AVREF1
6P00/TIP61/TOP61 7P01/TIP60/TOP60
8FLMD0
9VDD
10 REGC
11 VSS
12 X1
13 X2 14 RESET
15 XT1 16 XT2
17 P02/NMI 18 P03/INTP0/ADTRG 19 P04/INTP1
20 P05/INTP2/DRST
21 P06/INTP3
22 P40/SIB0/SDA01
23 P41/SOB0/SCL01
24 P42/SCKB0 25 P30/TXDA0/SOB4
26 P31/RXDA0/INTP7/SIB4
27 P32/ASCKA0/SCKB4/TIP00/TOP00 28 P33/TIP01/TOP01
29 P34/TIP10/TOP10 30 P35/TIP11/TOP11
31 P36
32 P37 33 EVSS 34 EVDD
35 P38/TXDA2/SDA00
36 P39/RXDA2/SCL00
37
P50/TIQ01/KR0/TOQ01/RTP00
38
P51/TIQ02/KR1/TOQ02/RTP01
39
P52/TIQ03/KR2/TOQ03/RTP02/DDI
40
P53/SIB2/KR3/TIQ00/TOQ00/RTP03/DDO
41
P54/SOB2/KR4/RTP04/DCK
42
P55/SCKB2/KR5/RTP05/DMS
43
P60/RTP10
44
P61/RTP11
45
P62/RTP12
46
P63/RTP13
47
P64/RTP14
48
P65/RTP15
49
P66/SIB5
50
P67/SOB5
51
P68/SCKB5
52
P69/TIP70/TOP70
53
P610/TIP71
54
P611/TOP71
55
P612/TIP80/TOP80
56
P613/TIP81/TOP81
57
P614
58
P615
59
P80/RXDA3/INTP8
60
P81/TXDA3
61
P90/A0/KR6/TXDA1/SDA02
62
P91/A1/KR7/RXDA1/SCL02
63
P92/A2/TIP41/TOP41
64
P93/A3/TIP40/TOP40
65
P94/A4/TIP31/TOP31
66
P95/A5/TIP30/TOP30
67
P96/A6/TIP21/TOP21
68
P97/A7/SIB1/TIP20/TOP20
69
P98/A8/SOB1
70
P99/A9/SCKB1
71
P910/A10/SIB3
72
P911A11/SOB3
73
P912/A12/SCKB3
74
P913/A13/INTP4
75
P914/A14/INTP5/TIP51/TOP51
76
P915/A15/INTP6/TIP50/TOP50
77
PCD0
78
PCD1
79
PCD2
80
PCD3
81
PCS0/CS0
82
PCS1/CS1
83
PCS2/CS2
84
PCS3/CS3
85
PCM0/WAIT
86
PCM1/CLKOUT
87
PCM2/HLDAK
88
PCM3/HLDRQ
89
PCM4
90
PCM5
91
PCS4
92
PCS5
93
PCS6
94
PCS7
95
PCT0/WR0
96
PCT1/WR1
97
PCT2
98
PCT3
99
PCT4/RD
100
PCT5
101
PCT6/ASTB
102
PCT7
103
BVSS
104
BVDD
105
PDL0/AD0
106
PDL1/AD1
107
PDL2/AD2
108
PDL3/AD3
C720 4.7/50
R400
2.2K
R401
2.2K
R402
2.2K
R403
2.2K
C400
151J
C401
151J
C402
151J
C403
151J
C404
151J
Q402:B
NJM4580M-D
2
3
1
C405
151J
C408
151J
Q403:B
NJM4580M-D
2
3
1
C409
151J
Q403:A
NJM4580M-D
4
5 6
8
7
C410
151J
C411
151J
Q483:A
NE5532APSR
3
2
8
1
4
Q401:A
NE5532APSR
4
5 6
8
7
Q401:B
NE5532APSR
2
3
1
L305
LBC2518T4R7M
E101
R770
NC
Q482:A
NE5532APSR
6
5
4
7
8
Q482:B
NE5532APSR
3
2
1
Q481:A
NE5532APSR
1
8
3
2
4
Q481:B
NE5532APSR
6
5
7
Q480:A
NE5532APSR
7
4
6
5
8
Q480:B
NE5532APSR
3
2
1
P9102A
1
2
3
4
5
6
7
8
9
10
11
12
13
L702
BLM18PG181SN1D
Q703
KRA102S
Q705
KRC104S
R772
2.2K
C707
470/10
P4102A
13
12
11
10
9
8
7
6
5
4
3
2
1
P4101A
13
12
11
10
9
8
7
6
5
4
3
2
1
C45047/25
C45147/25
R416
120K
R417
120K
R418
120K
R419
120K
R420
270K
R421
270K
R422
270K
R423
270K
R424
270K
R425
270K
R426
270K
R427
270K
Q402:A
NJM4580M-D
4
5
6
8
7
C406
103J
C407
103J
C419
333J
R773
C412
#151J
C413
#151J
C414
#151J
C415
#151J
R412
#1.8K
R413
#1.8K
R414
#1.8K
R415
#1.8K
R428
#270K
R429
#270K
R430
#270K
R431
#270K
R444
#22K
R445
#22K
R446
#22K
R447
#22K
R460
#15K
R461
#15K
R462
#15K
R463
#15K
C422
#471J C423 #471J
Q404:B
#NJM4580M-D
2
3
1
Q404:A
#NJM4580M-D
4
5
6
8
7
C457 #47/25
C456 #47/25
C708
0.47/50
C417
471J
C709
474J
C302 470/16
L300
LBC2518T4R7M
Q301
PCM1690
1RSV2
2RSV1
3RSV2
4RSV1
5RSV2
6LRCK
7BCK
8DIN1
9DIN2
10 DIN3
11 DIN4
12 VDD
13 DGND
14 SCKI
15 RST
16 ZERO1
17 ZERO2
18 AMUTEI
19 AMUTEO
20 MD/SDA/DEMP
21 MC/SCL/FMT
22 MS/ADR0/RSV
23 TEST/ADR1/RSV
24 MODE
49 THPAD
25
VCC1
26
VCOM
27
AGND1
28
RSV2
29
VOUT8+
30
VOUT8-
31
VOUT7+
32
VOUT7-
33
VOUT6+
34
VOUT6-
35
VOUT5+
36
VOUT5-
37
VOUT4+
38
VOUT4-
39
VOUT3+
40
VOUT3-
41
VOUT2+
42
VOUT2-
43
VOUT1+
44
VOUT1-
45
RSV2
46
AGND2
47
VCC2
48
RSV2
L301
LBC2518T4R7M
R347 330
C728 106K/6.3
C727 104Z
L103
LBC2518T2R2M
L302 0
R351 0
L352
#0
L351
#BLM18PG181SN1D
Q303
#CY2302
1FBIN
2IN
3GND
4FS0 5
FS1
6
OUT1
7
VDD
8
OUT2
C351 #104Z C352 #106K/6.3
Q715
2SA965
R741
1.2K
R745
820
R744
1K
R751
330
R743
4.7K
Q716
2SC1815
R740
22K
D704
KDS4148U
R352
#47
C703
220/25
R855
R856
R854 NC
R709
R705
Q708
S-812C33AUA-C2N
I
G
O
Q700
R1EX25064ASA00A
1CS
2SO 3WP
4GND 5
SI
6
SCK
7
HOLD
8
VCC
R833 0
C723 104Z
C982 104Z
JL981B
3 2
1
X301
24.576MHz
C319
180D
C320 180D
R981 100K
C901
220/25
C902
220/25
R901 22(1/4W)
R902 22(1/4W)
C306 NC
C105
106K/6.3
C981
104Z
JL981A
1
2 3
Q981
LM61CIZ
3V
2O
1
G
Q981A
1 2
C107
104Z
R771
220
C115
330J
C114
330J
C116
104Z
R712

HTX-22HDX
SCHEMATIC DIAGRAMS - 5.1/8
DISPLAY SECTION (HTX-22HDX)
A
1
2
3
4
5
BCDEFGH
KEYINT0
KEY0
GND
LEDTHRU
+3.3VST
REMIN
LEDSTBY
GND
GND
+5VDIS
-VP
FLDRST
FLDCS
FLDSDO
FLDCLK
FLDRST
FLDCS
FLDSDO
FLDCLK
-VPB
+5VDIS
FAC1
FAC2
BASW-0333
VOL-
VOL+
ON/STANDBY
INPUT
MODE
LISTENING
TO BADG-0327
TO BAPS-0331
BADIS-0332
TO BADG-0327
STANDBY
HDMI THRU
+5.0V
+3.3V
+3.3V
S7501
S7502
S7503 S7504 S7505
R7531
270
R7532
330
R7533
470
R7534
560
P7003A
1
2
3
4
5
P7501A
11
10
9
8
7
6
5
4
3
2
1
Q7501
M66005
49
SEG2
50 SEG1
51 SEG0
52 VCC2
53 DIG15/SEG39
54 DIG14/SEG38
55 DIG13/SEG37
56 DIG12/SEG36
57 DIG11
58 DIG10
59 DIG9
60 DIG8
61 DIG7
62 DIG6
63 DIG5
64 DIG4
1DIG03
2DIG02
3DIG01
4DIG00
5_RESET
6_CS
7SCK
8SDATA
9P1
10 P0
11 VCC1
12 XOUT
13 XIN
14 VSS
15 SEG35
16 SEG34
17
SEG33
18
SEG32
19
SEG31
20
SEG30
21
SEG29
22
SEG28
23
SEG27
24
VP
25
SEG26
26
SEG25
27
SEG24
28
SEG23
29
SEG22
30
SEG21
31
SEG20
32
SEG19
33
SEG18
34
SEG17
35
SEG16
36
SEG15
37
SEG14
38
SEG13
39
SEG12
40
SEG11
41
SEG10
42
SEG9
43
SEG8
44
SEG7
45
SEG6
46
SEG5
47
SEG4
48
SEG3
R7542
1K
C7541
100/6.3
C7542
NC
R7541
120
C7543
102K
U7541
GP1UE271RKVF
1
2
3
Q7505
KTC3875-GR
Q7504
KTC3875-GR
D7503
UDZS3.9B
D7561 SLI-343URC
R7562
2.2K
R7561
2.2K
C7510
104Z
L7502
BLM21PG221SN1
Q7502
1F11 7G01
8G02
9G03
10 G04 11 G05 12 G06
13 G07
14 G08 15 G09
16 G10
17 G11 18 G12
19 13G
20 14G
21 15G 22 16G 23 NC
24 NC
25 NC
26 P01 27 P02
28 P03
29 P04
30 P05
31 P06
32 P07
33 P08 34 P09
35 P10 36 P11 37 P12
38 P13
39 P14 40 P15
41 P16
42 P17 43 P18
44 P19
45 P20
46 P21
47 P22
48 P23
49 P24
50 P25
51 P26
52 P27
53 P28
54 P29
55 P30
56 P31
57 P32
58 P33 59 P34
60 P35 66 F23
C7508
100/6.3
C7517 104Z
C7516 104Z
R7501
100K
C7513
33/50
C7515
100/16
C7514
104Z
C7512
104Z
C7511
104Z
C7509
104Z
C7502 104Z
C7507
101J
C7505 101J
C7504 101J
C7503 101J
C7501
104Z
R7502 3.3K
R7506
27K
R7505 220
R7504 220
R7503 3.3K
L7501
BLM21PG221SN1
C7524
104Z
R7510
120
C7522 104Z
C7521 104Z
P7004A
1
2
3
C7523
10/50
R7508
470
R7507
470
D7502 UDZS4.3B
D7562 SLI-343Y8C-TE7
AGAINST FIRE HAZARD, REPLACE
VA
FOR CONTINUED PROTECTION
AND RATING INDICATED.
ONLY WITH FUSE OF SAME TYPE
CAUTION
ATTENTION
ET CALIBRATION COMME INDIQUE.
D'INCENDIE, REMPLACER UNIQUEMENT
PERMANENTE CONTRE LES RISQUES
AFIN D'ASSURER UNE PROTECTION
PAR UN FUSIBLE DE MEME TYPE
VA
E LENT.POUR UNE PROTECTION PERMANENTE,N'UTILISER
INDIQUE LA QU LE PRESENT SYMBOL EST APPOSE.
QUE DES FUSIBLES DE MEME TYPE. CE DARNIER EST
CE SYMBOLE INDIQUE QUE LE FUSIBLE UTLISE EST
FOR CONTINUED PROTECTION AGAINST FIRE
RATING REFER TO THE MARKING ADJACENT TO THE SYMBOL.
HAZARD,REPLACE WITH SAME TYPE FUSE. FOR FUSE
THIS SYMBOL LOCATED NEAR THE FUSE INDICATES
THAT THE FUSE USED IS SLOW OPERATING TYPE
THE COMPONENTS IDENTIFIED BY MARK ARE CRITICAL FOR SAFETY
REPLACE ONLY WITH PART NUMBER SPECIFIED.
VOLTAGE (MEASURED WITH VOLTMETER) IS DC VOLTAGE.(NO INPUT SIGNAL).
ALL PNP TRANSISTORS ARE EQUIVALENT TO 2SA1015-GR UNLESS OTHERWISE NOTED.
ALL NPN TRANSISTORS ARE EQUIVALENT TO 2SC1815-GR UNLESS OTHERWISE NOTED.
ALL DIODES ARE EQUIVALENT TO 1SS133 UNLESS OTHERWISE NOTED.
ELECTROLYTIC CAPACITORS ( ) ARE IN uF/WV.
ALL CAPACITORS ARE IN pF/50WV UNLESS OTHERWISE NOTED.
EX) 030- 3pF 330- 33pF 331- 330pF 333- 0.033uF
ALL RESISTORS ARE IN OHMS 1/4WATTS UNLESS OTHERWISE NOTED.
THE THICK LINES ON PC BOARD ARE THE PRINTING SIDE OF THE PARTS.
EX) PRINTING SIDE
CIRCUIT IS SUBJECT TO CHANGE FOR IMPROVEMENT.
!
NOTE

HTX-22HDX
SCHEMATIC DIAGRAMS - 6/8
DSP SECTION
A
1
2
3
4
5
BCDEFGH
TDI_2
EMU0_DSP
EMU1_DSP
TRST
TDI_1
TMS_DSP
TCK_DSP
A11
A8
A9
A7
A6
A5
A4
CKE
CLK
UDQM
D8
D9
D10
D12
D11
D14
D13
D15
D15
D7
D14
D6
D13
D5
D12
D4
D11
D3
D10
D2
D9
D1
D8
D0
OE
FLCS
BA1
GPIO4
A20
DSPRST
D7
D6
D5
D4
D3
D2
D1
D0
CAS
WE
LDQM
A0
A3
A2
A1
A10
BA1
BA0
SDCS
RAS
WE
A11
GPIO7
GPIO2
GPIO1
A9
A8
A10
A7
TDI_1
TMS_DSP
TCK_DSP
EMU1_DSP
EMU0_DSP
TDI_2
TCK
EMU0
TCK_RET
TDO
PD
TMS
TDI
GPIO6
GPIO5
A6
A5
A4
A3
A2
A1
A0
DSPCS
DIGSDO
DIGCLK
DIGSDI
GPIO4
GPIO2
GPIO3
DSPINT1
DSPINT0
AP5_OUT
RMCK
DIR_BCK
TRST
EMU1
TRST
+3.3VHD
+1.8VHD
GND
+1.25VDSP
+3.3VROM
+3.3VRAM
+3.3VDSP
+3.3VHD
GPIO3
DIR_LRCK
RMCK
CX_LRCK
CX_SCLK
DSPSBLR
DSPSLR
DSPLR
DSPCSW
DSPINT2
DSPRST
DIR_SDOUT
AP0_OUT
GPIO1
AP2_OUT
AP3_OUT
AP4_OUT
GND
A0
A1
A6
A5
A4
A9
A8
A7
A10
A3
A2
A11
OE
CKE
BA1
BA0
RAS
SDCS
UDQM
GPIO6
GPIO7
GPIO5
A20
D11
D10
D9
D8
D15
D14
D13
D12
D3
D2
D1
D0
D7
D6
D5
D4
CLK
WE
FLCS
LDQM
CAS
DIGSDI
DSPCS
DIGSDO
DSPINT0
DSPINT2
DSPINT1
DSPRST
DIGCLK
CX_SCLK
CX_LRCK
DSPLR
DSPCSW
DSPSBLR
DSPSLR
RMCK
DIR_BCK
DIR_LRCK
DIR_SDOUT
AP5_OUT
AP4_OUT
AP3_OUT
AP2_OUT
AP0_OUT
+3.3V
+1.25V
TO BAHDM-0324 HDMI PART
BAHDM-0324
R8303 2.2K
R8300 47
R8305 1K
R8304 47
R8307 47
R8314 47
R8317 330
R8325 330
R8327 330
R8329 330
R8331 330
R8334 330
R8335 330
R8338 330
R8315 47
R8316 47
R8318 0
R8319 0
R8321 0
R8323 0
R8337 330C8316 104Z
C8317 104Z
C8318 104Z
C8319 104Z
C8320 104Z
C8321 104Z
C8322 104Z
C8323 104Z
C8300 104Z
C8301 104Z
C8302 104Z
C8303 104Z
C8304 104Z
C8305 104Z
C8324 104Z
R8333 0
C8325
106K/6.3
C8348
106K/6.3
R8345 10K
R8344 10K
R8310 10K
R8311 10K
R8313 10K R8312 10K
R8336 330
C8327
100/4
C8326
104Z
C8329 104Z
L8301
LM182
R8343
330
L8300
BLM18PG181SN1D
L8302
ACF451832-333
R8353 4.7K
R8354 4.7K R8356 4.7K
R8355 4.7K R8352 4.7K
C8350 104Z
C8332
104Z
C8343 220/4
L8307
BLM18PG181SN1D
R8309 10K
R8308 10K
R8301 330
R8302 330
X8300
17.734MHz
L8308
BLM18PG181SN1D
L8305
BLM18PG181SN1D
L8304
BLM18PG181SN1D
R8357 10K
C8342 220/4
C8314 104Z
C8315 104Z C8312
102J
C8308 104Z
C8309 104Z
C8310 104Z
C8306 104Z
C8307 104Z R8306 47
C8311 101J
R8350
10K
L8303
#BLM18PG121SN1D
R8339 330
L8309
LM182
R8342
47
R8340 330
R8341
47
TP8300
TP8302
TP8303
TP8304
TP8305
TP8306
TP8307
TP8308
TP8309
TP8310
P8300
JTAG
2
4
6
8
10
12
14 13
11
9
7
5
3
1
Q8301:B
D790E001BZDH300
A2 DVDD
A15 DVDD
B1 DVDD
B16 DVDD
D4 DVDD
D5 DVDD
D12 DVDD
D13 DVDD
E4 DVDD
E13 DVDD
J14 DVDD
M4 DVDD
M13 DVDD
N5 DVDD
N12 DVDD
P8 DVDD
R1 DVDD
R16 DVDD
T2 DVDD
T15 DVDD
E6 CVDD
E7 CVDD
E8 CVDD
E9 CVDD
E10 CVDD
E11 CVDD
G5 CVDD
G12 CVDD
H5 CVDD
H12 CVDD
J5 CVDD
J12 CVDD
K5 CVDD
K12 CVDD
M6 CVDD
M7 CVDD
M8 CVDD
M9 CVDD
M10 CVDD
M11 CVDD
T16
VSS
T10
VSS
T7
VSS
T1
VSS
M12
VSS
M5
VSS
L12
VSS
L11
VSS
L10
VSS
L9
VSS
L8
VSS
L7
VSS
L6
VSS
L5
VSS
K16
VSS
K11
VSS
K10
VSS
K9
VSS
K8
VSS
K7
VSS
K6
VSS
K1
VSS
J11
VSS
J10
VSS
J9
VSS
J8
VSS
J7
VSS
J6
VSS
H11
VSS
H10
VSS
H9
VSS
H8
VSS
H7
VSS
H6
VSS
H3
VSS
G16
VSS
G11
VSS
G10
VSS
G9
VSS
G8
VSS
G7
VSS
G6
VSS
G1
VSS
F12
VSS
F11
VSS
F10
VSS
F9
VSS
F8
VSS
F7
VSS
F6
VSS
F5
VSS
E12
VSS
E5
VSS
A16
VSS
A10
VSS
A7
VSS
A1
VSS
Q8304
K4S641632K-UC60
1VDD
2DQ0
3VDDQ
4DQ1
5DQ2
6VSSQ
7DQ3
8DQ4
9VDDQ
10 DQ5
11 DQ6
12 VSSQ
13 DQ7
14 VDD
15 LDQM
16 WE
17 CAS
18 RAS
19 CS
20 BA0
21 BA1
22 A10
23 A0
24 A1
25 A2
26 A3
27 VDD 28
VSS
29
A4
30
A5
31
A6
32
A7
33
A8
34
A9
35
A11
36
NC
37
CKE
38
CLK
39
UDQM
40
NC
41
VSS
42
DQ8
43
VDDQ
44
DQ9
45
DQ10
46
VSSQ
47
DQ11
48
DQ12
49
VDDQ
50
DQ13
51
DQ14
52
VSSQ
53
DQ15
54
VSS
Q8306 TC74VHC541FT
20 VCC
19 _G2
18 Y1
17 Y2
16 Y3
15 Y4
14 Y5
13 Y6
12 Y7
11 Y8 10
GND
9
A8
8
A7
7
A6
6
A5
5
A4
4
A3
3
A2
2
A1
1
_G1
C8331
104Z
C8337
104Z
C8341
104Z
C8340
104Z
C8333
104Z
C8328
104Z
C8313
104Z
C8349
104Z
C8347
104Z
Q8303
ES29LV160ET-70TG
1A15
2A14
3A13
4A12
5A11
6A10
7A9
8A8
9A19
10 A20
11 WE
12 RESET
13 NC
14 WP/ACC
15 RY/BY
16 A18
17 A17
18 A7
19 A6
20 A5
21 A4
22 A3
23 A2
24 A1 25
A0
26
CE
27
GND
28
OE
29
Q0
30
Q8
31
Q1
32
Q9
33
Q2
34
Q10
35
Q3
36
Q11
37
VCC
38
Q4
39
Q12
40
Q5
41
Q13
42
Q6
43
Q14
44
Q7
45
Q15/A-1
46
GND
47
BYTE
48
A16
C8330
104Z
C8335 106K/6.3
C8334 106K/6.3
C8336 106K/6.3
Q8307
XC6220B12BPR
3NC
2VSS
1CE 5
VOUT
4
VIN
L8306
BLM21PG221SN1
R8371
33X4
1
R8372
33X4
1
R8373
33X4
1
R8320 10K
R8328 10K
R8326 10K
TP8301
R8374
33X4
1
R8376
33X4
1
R8375
33X4
1
R8377
33X4
1
Q8301:A
D790E001BZDH300
B14 SPIO_SOMI/I2C0_SDA
B15 SPIO_SIMO
C16 SPIO_CLK/I2C0_SCL
C15 SPIO_SCS/I2C1_SCL
D16 SPIO_ENA/I2C1_SDA
G2 RESET
A14 AXR0[0]
B13 AXR0[1]
A13 AXR0[2]
B12 AXR0[3]
A12 AXR0[4]
B11 AXR0[5]/SPI1_SCS
A11 AXR0[6]/SPI1_ENA]
B10 AXR0[7]/SPI1_CLK
B9 AXR0[8]/AXR1[5]/SPI1_SOMI
A9 AXR0[9]/AXR1[4]/SPI1_SIMO
B8 AXR0[10]/AXR1[3]
A8 AXR0[11]/AXR1[2]
B7 AXR0[12]/AXR1[1]
B6 AXR0[13]/AXR1[0]
A6 AXR0[14]/AXR2[1]
B5 AXR0[15]/AXR2[0]
B3 AHCLKR0/AHCLKR1
A5 ACLKR0
B4 AFSR0
C2 AHCLKX0/AHCLKX2
A4 ACLKX0
A3 AFSX0
J2 OSCIN
J3 OSCOUT
J4 OSCVDD
J1 OSCVSS
H2 CLKIN
K2 PLLHV
K13 UHPI_HD[0]
K14 UHPI_HD[1]
M14 UHPI_HD[2]
L13 UHPI_HD[3]
L14 UHPI_HD[4]
N13 UHPI_HD[5]
N14 UHPI_HD[6]
P14 UHPI_HD[7]
E14 UHPI_HD[8]
F14 UHPI_HD[9]
F13 UHPI_HD[10]
G14 UHPI_HD[11]
G13 UHPI_HD[12]
H14 UHPI_HD[13]
H13 UHPI_HD[14]
J13 UHPI_HD[15]
H1 UHPI_HD[16]/HHWIL
G3 UHPI_HD[17]
G4 UHPI_HD[18]
F3 UHPI_HD[19]
F4 UHPI_HD[20]
E3 UHPI_HD[21]
D3 UHPI_HD[22]
C3 UHPI_HD[23]
P2 UHPI_HD[24]
N2 UHPI_HD[25]
N3 UHPI_HD[26]
M3 UHPI_HD[27]
L3 UHPI_HD[28]
L4 UHPI_HD[29]
L2 UHPI_HD[30]
H4 UHPI_HD[31]
C6 UHPI_HBE[0]
C5 UHPI_HBE[1]
C4 UHPI_HBE[2]
B2 UHPI_HBE[3]
D9 UHPI_HCNTL[0]
C10 UHPI_HCNTL[1]
C9 UHPI_HAS
D8 UHPI_HRW
D7 UHPI_HDS[1]
C7 UHPI_HDS[2]
C8 UHPI_HCS
D6 UHPI_HRDY
D10
AMUTE2/HINT
C11
AFSX2
D11
ACLKX2
C12
AFSR2
C13
ACLKR2
C14
AHCLKR2
N1
EMU[1]
M1
EMU[0]
K4
TRST
M2
TDO
L1
TDI
K3
TMS
P1
TCK
D14
EM_WAIT
E16
EM_RW
D15
EM_OE
R15
EM_WE_DQM[3]
P13
EM_WE_DQM[2]
T13
EM_WE_DQM[1]
R4
EM_WE_DQM[0]
R14
EM_CLK
T14
EM_CKE
T3
EM_WE
F16
EM_RAS
R3
EM_CAS
E15
EM_CS[2]
F15
EM_CS[0]
H16
EM_BA[1]
G15
EM_BA[0]
P7
EM_D[31]/UHPI_HA[15]
N8
EM_D[30]/UHPI_HA[14]
N9
EM_D[29]/UHPI_HA[13]
P9
EM_D[28]/UHPI_HA[12]
N10
EM_D[27]/UHPI_HA[11]
P10
EM_D[26]/UHPI_HA[10]
N11
EM_D[25]/UHPI_HA[9]
P11
EM_D[24]/UHPI_HA[8]
R2
EM_D[23]/UHPI_HA[7]
N4
EM_D[22]/UHPI_HA[6]
P3
EM_D[21]/UHPI_HA[5]
P4
EM_D[20]/UHPI_HA[4]
P5
EM_D[19]/UHPI_HA[3]
N6
EM_D[18]/UHPI_HA[2]
P6
EM_D[17]/UHPI_HA[1]
N7
EM_D[16]/UHPI_HA[0]
R9
EM_D[15]
T9
EM_D[14]
R10
EM_D[13]
R11
EM_D[12]
T11
EM_D[11]
R12
EM_D[10]
T12
EM_D[9]
R13
EM_D[8]
T4
EM_D[7]
R5
EM_D[6]
T5
EM_D[5]
R6
EM_D[4]
T6
EM_D[3]
R7
EM_D[2]
R8
EM_D[1]
T8
EM_D[0]
C1
AMUTE0
D2
AMUTE1
D1
AHCLKX1
E2
ACLKX1
E1
ACLKR1
F2
AFSX1
F1
AFSR1
P12
EM_A[12]
P15
EM_A[11]
H15
EM_A[10]
P16
EM_A[9]
N15
EM_A[8]
N16
EM_A[7]
M15
EM_A[6]
M16
EM_A[5]
L15
EM_A[4]
L16
EM_A[3]
K15
EM_A[2]
J15
EM_A[1]
J16
EM_A[0]
EMIF ADRESS
UHPI
EMIF DATA
EMIF CONTROL
R8379
33X4
1
R8351
75
R8378
33X4
1
R8346 1M
Q8302
TC7WU04FU
1
2
3
4GND 5
6
7
8
VD
C8338
080D
C8339
120D

SCHEMATIC DIAGRAMS - 7/8
HDMI SECTION
HTX-22HDX
A
1
2
3
4
5
BCDEFGH
HDMIPDN
HDMIRST
AP5_OUT
SCLK_OUT
MCLK_OUT
AP2_OUT
AP0_OUT
AP1_OUT
HDMIINT2
AP3_OUT
AP4_OUT
CX_SCLK
HDMIINT_TX
HDMIINT
CX_LRCK
DSPLR
SPI_SCL
+3.3VDVDDIO
CS
SPI_SDA
TX_C+
TX_1+
TX_1-
TX_2-
TX_0-
TX_C-
TX_2+
CEC
HEAC+
TX_0+
TX_HPDIN
CEC_IO
+12VDG
+1.8VHD
+5V_TX
RMCK
GND
GND
+1.8VHD +3.3VHD
GND
HP_CTRLA
5V_DETA
DDCA_SDA
+3.3VHD
HP_CTRLD
HP_CTRLB
HP_CTRLA
DDCA_SCL
HP_CTRLA
RXA_C-
RXA_C+
RXA_0-
RXA_2-
RXA_1+
RXA_1-
RXA_0+
RXA_2+
CEC
HP_CTRLB
DDCB_SDA
DDCB_SCL
RXB_C-
RXB_C+
RXB_0-
RXB_2-
RXB_1+
RXB_1-
RXB_0+
RXB_2+
CEC
DDCD_SDA
RXD_C+
RXD_0-
RXD_2+
RXD_2-
RXD_1+
RXD_1-
RXD_0+
DDCD_SCL
RXD_C-
HP_CTRLD
5V_DETD
CEC
5V_DETA
DDCA_SDA
5V_DETB
RXD_C-
RXD_C+
RXD_0+
RXD_0-
RXD_1+
RXD_1-
RXC_0+
RXC_1+
RXC_1-
RXC_0-
RXC_C-
RXC_C+
RXD_2+
RXD_2-
TX_C-
TX_C+ TX_0+
TX_0-
TX_1+
TX_1-
TX_2+
TX_2-
RXC_2+
DDCD_SCL
DDCD_SDA
HP_CTRLD
5V_DETD
RXC_2-
TXDDC_SCL
TXDDC_SDA
DDCC_SCL
HDMISDA
HDMISCL
RXA_C+
RXA_C-
RXA_0-
DDCA_SCL
RXA_0+
RXA_1-
RXA_2- 5V_DETB
HP_CTRLB
RXB_0-
DDCB_SDA
DDCB_SCL
RXB_C- RXB_C+
RXB_0+
RXB_1+
RXB_1-
RXB_2+ RXB_2-
DDCC_SDA
RXA_2+
RXA_1+
HP_CTRLC
5V_DETC
+1.8VTXPVDD
+1.8VTXPLVDD
+1.8VTXAVDD
+1.8VDVDD
+3.3VTVDD
+1.8VCVDD
+3.3VHD
+1.8VHD
SPI_CS
SPI_SO
+1.8VPVDD
ARC+
HPD_ARC-
TXDDC_SDA
TXDDC_SCL
DSPINT2
DSPINT1
DIGSDI
CX_SCLK
CX_LRCK
DSPLR
DSPCSW
DSPSBLR
DSPSLR
RMCK
DIR_BCK
DIR_LRCK
DIR_SDOUT
AP5_OUT
AP4_OUT
AP3_OUT AP2_OUT
AP0_OUT
DIGCLK
DSPCS
DIGSDO
DSPRST
DSPINT0
CEC_IO DIGCLK DIGSDO
INPSEL
+3.3VMPU
CX_SCLK
DSPLR
DSPCSW DSPSLR DSPSBLR
CX_LRCK
GND
GND
GND GND
RMCK
HDMIPDN
HDMIRST
HDMISDA
HDMISCL
HDMIINT HDMIINT2 HDMIINT_TX
DSPRST
DSPCS DSPINT1
DSPINT0
MCLK_OUT SCLK_OUT
AP5_OUT
AP1_OUT
DIR_SDOUT
DIR_LRCK
DIR_BCK
AP0_OUT ARC_SPDIF
DSPINT2
DIGSDI
GND
GND
SPI_HOLD
SPI_SI
SPI_SCK
FLASH WRITER
+3.3V
+1.8V
TO BAAF-0326
HDMI OUT
HDMI IN 1 HDMI IN 2 HDMI IN 3
BAHDM-0324
NIC
DEC
DSPBSY
TO BAHDM-0324 DSP PART
TO BADG-0327 TO BADG-0327
TOP-UNDER
Front
Rear
13521
24 22 8 6 4
971523 11
12 10141618
1719
20
13
2
+12.6V
C8122 104Z
C8115 104Z
C8113 104Z
C8127 104Z
R8130 100C8135 102K
R8132 100
C8143 102K
R8133 33
R8134 33
R8135 33
R8136 10K
R8143 33C8153 104Z
R8144 10K
R8146 100
R8147 100
R8149 100C8169 104Z
R8151 10K
R8154 22
C8177 104Z
C8179 104Z
R8160
47K
R8163 47
R8164 47
R8165 47
R8166 22
R8167 22 R8168 22
R8169 NC
R8170 47K
C8193
106K/6.3
R8187
10K
TP8100TP8104TP8105TP8106TP8113TP8115
C8121 104Z
C8134 104Z
C8160 104Z
C8175 104Z
C8182 104Z
C8184 104Z
C8186 104Z
C8188 104Z
C8191
NC R8175
NC
R8193
NC
C8146 104Z
C8148 104Z
C8114 103K
C8125 103K
C8144 104Z
C8130 103K
C8145 103K
C8155 103K
C8170 103K
C8178 103K
C8187 103K
C8185 103K
C8189 103K
C8183 103K
C8180 103K
C8176 103K
C8172 104Z
C8173 103K
C8168 103K
C8150 103K
C8147 103K
C8142 103K
C8124 103K
C8116 103K
R8119 1K
R8138 33
C8119 104Z
C8111 104Z
C8109 104Z
C8107 104Z
C8105 104Z
C8103 104Z
C8104 103K
C8106 103K
C8108 103K
C8110 103K
C8112 103K
C8120 103K
TP8116
R8129 10K
R8121 1K
R8173
820F
TP8112
R8207
10K
R8162 47
R8208 0
R8209 0
R8155 22X4
L8105
0
R8191 10K
L8114
BLM18PG181SN1D
C8197 104Z
C8195
106K/6.3
R8176
47K
R8161
NC
R8156 4.7K
R8157 4.7K
TP8110
P8191
1
2
3
4
5
6
7
8
R8206
NC
R8205
0
C8129
080D
X8100
28.6363MHz
R8158 10K
R8126 27KF
R8127 10KF
C8126
223K
L8102
BLM18PG181SN1D
L8103
BLM18PG181SN1D
C8131 106K/25
C8138
104Z
C8139
106K/6.3
C8140
106K/6.3
C8141
106K/6.3
L8104
7E08Q-100M-RA
C8132 106K/25
D8100
XBS303V17R
Q8102
MP2363DN-LF-Z
5FB
6COMP
7EN
8SS 1
BS
2
IN
3
SW
4
GND
9
TH
L8106
BLM18PG181SN1D
R8140 10KF
R8141 10KF
C8149
223K
L8108
BLM18PG181SN1D
C8154 100/16
C8157 106K/25
C8158 104Z
C8159
220/4
C8165
106K/6.3
C8166
106K/6.3
C8171
102K
C8174
104Z
R8171
1.8K
R8172
1.8K
C8194
102K
R8181
47
C8202 104Z
D8102
KDS4148U
C8164
106K/6.3
Q8103
MP2363DN-LF-Z
5FB
6COMP
7EN
8SS 1
BS
2
IN
3
SW
4
GND
9
TH
C8156 106K/25
D8101
XBS303V17R
L8110
L8111
L8113
L8112
Q8104
SN74CB3Q3305PWR
8VCC
72OE
62B
52A 4
GND
3
1B
2
1A
1
1OE
L8109
7E08Q-100M-RA
R8128
NC
R8124
NC
R8142
NC
C8162
NC
P8105B
1
2
C8161
104Z
C8136
104Z
L8101
BLM18PG181SN1D
R8125 680K
C8133
220/4
R8137 1.5K
TP8114
R8255 #1K
R8174
68
R8122
47K
R8118
1K
C8117
102K
R8102
47K
R8100
1K
C8152
102K
C8192
102K
R8177
1K
R8178
0
R8182
47K
R8183
NC
C8218
102K
C8100
102K
R8262
#100K
R8264
#100K
C8118
102K
R8266
#100K
R8261
10K
R8263
10K
R8265
10K
TP8103
R8203 10K
R8123
NC
TP8101
TP8102
R8101
0
R8120
0
R8103
NC
Q8261
DTC123JKA
Q8262
DTC123JKA
Q8264
DTC123JKA
Q8263
DTC123JKA
Q8265
DTC123JKA
Q8266
DTC123JKA
L8107
BLM18PG181SN1D
R8131
5.6K
C8128
103K
C8137
151J
R8145
3.3K
R8139 680K C8151
682K
C8163
105Z
C8208 106K/6.3
C8209 106K/6.3
C8210 106K/6.3
C8211 106K/6.3
C8212 106K/6.3
C8213 106K/6.3
C8216 106K/6.3 C8217 106K/6.3
C8501 105Z
C8502 105Z
C8503 105Z
Q8501
XC6221B182MR
1
VIN 2
VSS 3
CE
4NC
5VOUT
L8501 BLM18PG181SN1D
L8502 BLM18PG181SN1D
L8120 BLM18PG181SN1D
L8121 BLM18PG181SN1D
L8118 BLM18PG181SN1D
L8503
BLM18PG181SN1D
L8116 BLM18PG181SN1D
L8115
#BLM18PG181SN1D
L8119 #BLM18PG181SN1D
L8117 #BLM18PG181SN1D
Q8101
ADV7623
1
DDCC_SCL
2
CVDD
3
CGND
4
RXC_C-
5RXC_C+
6TVDD
7RXC_0-
8RXC_0+
9CGND
10 RXC_1-
11 RXC_1+
12 TVDD
13 RXC_2-
14 RXC_2+
15 HP_CTRLD
16 5V_DETD
17 DGND
18 DVDD
19 DDCD_SDA
20 DDCD_SCL
21 CVDD
22 CGND
23 RXD_C-
24 RCD_C+
25 TVDD
26 RXD_0-
27 RXD_0+
28 CGND
29 RXD_1-
30 RXD_1+
31 TVDD
32 RXD_2-
33
RXD_2+
34
CVDD
35
CGND
36
TXPVDD
37 TXPLVDD
38 TXPGND
39 TXPLGND 40 EXT_SWING
41 HPD_ARC-
42 ARC+
43 TXDDC_SDA
44 TXDDC_SCL
45 TXAVDD
46 TXGND
47 TXC-
48 TXC+
49 TXGND
50 TX0-
51 TX0+
52 TXGND
53 TX1-
54 TX1+
55 TXAVDD
56 TX2-
57 TX2+
58 TXGND
59 CEC
60 DGND
61 DVDD
62 ALSB
63 CSB
64 EP_SCK 65 EP_CS
66 EP_MOSI
67 EP_MISO
68 MCLK_IN
69 SCLK_IN
70 AP5_IN
71 AP4_IN
72 DGNDIO
73
DVDDIO
74
AP3_IN
75
AP2_IN
76
AP1_IN
77
AP0_IN
78
SDATA
79
SCL
80
DGND
81
DVDD
82
INT
83
INT2
84
INT_TX
85
DGNDIO
86
DVDDIO
87
AP0_OUT
88
AP1_OUT
89
AP2_OUT
90
AP3_OUT
91
AP4_OUT
92
DGND
93
DVDD
94
AP5_OUT
95
SCLK_OUT
96
MCLK_OUT
97
RESETB
98
PWRDNB
99
PGND
100
PVDD
101
XTAL
102
XTAL1
103
PVDD
104
PGND
105
HP_CTRLA
106
5V_DETA
107
RTERM
108
DDCA_SDA
109
DDCA_SCL
110
CVDD
111
CGND
112
RXA_C-
113
RXA_C+
114
TVDD
115
RXA_0-
116
RXA_0+
117
CGND
118
RXA_1-
119
RXA_1+
120
TVDD
121
RXA_2-
122
RXA_2+
123
HP_CTRLB
124
5V_DETB
125
DGND
126
DVDD
127
DDCB_SDA
128
DDCB_SCL
129
CVDD
130
CGND
131
RXB_C-
132
RXB_C+
133
TVDD
134
RXB_0-
135
RXB_0+
136
CGND
137
RXB_1-
138
RXB_1+
139
TVDD
140
RXB_2-
141
RXB_2+
142
HP_CTRLC
143
5V_DETC
144
DDCC_SDA
C8205
104Z
R8179
10
R8180100
R8184100
R8185100
R8188
10
C8196
105K
C8198
105K R8189100
Q8107
S-812C50BUC
5NC
4SW 3
GND
2
IN
1
OUT
C8201
106K/6.3
R8210
1K
P8107
1D2+
2D2 Shield
3D2-
4D1+
5D1 Shield
6D1-
7D0+
8D0 Shield
9D0-
10 CK+
11 CK Shield
12 CK-
13 CERemote
14 NC
15 DDC CLK
16 DDC DATA
17 GND
18 +5V
19 HP DET
20
22 Shield 23
Shield
21
P8103
23 Shield
21
1
D2+
2
D2 Shield
3
D2-
4
D1+
5
D1 Shield
6
D1-
7
D0+
8
D0 Shield
9
D0-
10
CK+
11
CK Shield
12
CK-
13
CERemote
14
NC
15
DDC CLK
16
DDC DATA
17
GND
18
+5V
19
HP DET
20
22
Shield
P8104
23 Shield
21
1
D2+
2
D2 Shield
3
D2-
4
D1+
5
D1 Shield
6
D1-
7
D0+
8
D0 Shield
9
D0-
10
CK+
11
CK Shield
12
CK-
13
CERemote
14
NC
15
DDC CLK
16
DDC DATA
17
GND
18
+5V
19
HP DET
20
22
Shield
P8108
23 Shield
21
1
D2+
2
D2 Shield
3
D2-
4
D1+
5
D1 Shield
6
D1-
7
D0+
8
D0 Shield
9
D0-
10
CK+
11
CK Shield
12
CK-
13
CERemote
14
NC
15
DDC CLK
16
DDC DATA
17
GND
18
+5V
19
HP DET
20
22
Shield
R8194 NC
P8101A
16 15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
P8102A
24
23
22
21
20
19
18 17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
R8195
220
D8251
#UDZS5.6B
D8253
#KDS4148U
Q8251
#TC74VHCT08AFT
1
2 3
4
5 6 7GND 8
9
10
11
12
13 14
VCC
R8254
#100K
C8252 #104Z
C8251
#10/16
R8253
#100K
D8252
#KDS4148U
R8252
#1K
R8251
#10K
L8122
#BLM18PG181SN1D
Q8108
#NC7SZ08
1INA
2INB
3GND 4
OUTY
5
VCC
R8196 #4.7K
C8203 #104Z
C8123
070D
R8197 #47
R8198
NC
Q8106
EN25Q32A-100HIP
1CS
2SO
3WP
4GND 5
SI
6
SCK
7
NC
8
VCC

HTX-22HDX
SCHEMATIC DIAGRAMS - 8.1/8
SPEAKER TERMINAL SECTION
A
1
2
3
4
5
BCD
FL_SPOUT
FR_SPOUT
C_SPOUT
SR_SPOUT
SL_SPOUT
+12.6V
C_SPRL
SLR_SPRL
FLR_SPRL
SP OUT
FL
FR
C
SL
SR
TO BCAF-0326
TO BCAF-0326
TO BCAF-0326
TO BCAF-0326
BATRM-0334
J5855
L5855
R5855 10(1/2W)
L5854
R5854 10(1/2W)
J5854
L5851
J5851
R5851 10(1/2W)
C5854
102J
J5852
L5852
R5852 10(1/2W)
C5855
102J
C5856
102J
C5863
102J
C5862
102J
P5851
11 GND
5
10
4
9
3
8
2
7
1
6
12 GND
C5857
103J
C5858
103J
C5859
103J
C5860
103J
C5861
103J
C5853 102J
D5853
KDS4148U
L5853
R5853 10(1/2W)
J5853
D5852
KDS4148U
C5852 102J
C5851 102J
D5851 KDS4148U
JL9103C
1
2
3
4
5
P5001C
1
2
3
4
5
P5201C
2
1
P5101C
1
2
3
4
5
RL5851
6
5
2 3
4
1
RL5852
2
5
6 1
4
3
RL5853
2
5
6 1
4
3
P5901
CLAMPER
1

HTX-22HDX
PACKING PROCEDURE
TOP/ BOTTOM
FRONT
FRONT
MPP
HTX-22HDX
HTX-22HDX
HTX-22HDX
MPP
HTX-22HDX
HTX-22HDX
02
06
04
08(Inner)
09(Outer)
06
20
06
06
13
03 01a/b
10
10
11a/b
11a/b
A809
A817
21
3.5m x 2 pcs
(Red line)
14
(4 pcs)
(Rubber feet
for subwoofer)
22
(8 pcs)
(Rubber feet
for front speakers)
07
07
P901
A819
(MPP)
A830
A832
(MDC)
A811
x 2 pcs
06
08(Inner)
09(Outer)
A833
A834
(MPP)
A835
(MPP)
Front
Front
Front

1/50 PAGE
HTX-22HDX
<Note>
Parts marked by "NSP" are generally unavailable because
they are not in our Master Spare Parts List.
<Notes>
<MPP> : European model only
<MDC> : Canadian model only
EXPLODED VIEW PARTS LIST
AMPLIFIER SECTION
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
EXPLODED [CHASSIS SCREW]
EXPLODED A001 CLEAR PLT MDC/MPP 1 28192295 N
EXPLODED A002 F BRACKET --- 1 27111573A N<MPP>
EXPLODED A002 F BRACKET MDC 1 27111588 N<MDC>
EXPLODED A003 KNOB (TOP) 1 28326815A N
EXPLODED A008 SCREW 3TTB+8B(3BC) 6 838430088GR
EXPLODED A009 SCREW 3TTB+8B(3BC) 4 838430088GR
EXPLODED A010 SCREW 3TTB+8B(3BC) 4 838430088GR
EXPLODED A012 CHASSIS --- 1 27100520B N
EXPLODED A014 TAPE TAPE(CLOTH-8U) 1 29110082
EXPLODED A016 CUSHION 20x20xt0.5 1 28141465GR
EXPLODED A018 SHLD PLT (F) 1 27150529A N
EXPLODED A019 RIVET P-RIVET NRP-345 2 880009
EXPLODED A020 SCREW 4TTC+8C(3BC) 4 830440089GR
EXPLODED A021 HEAT SINK --- 1 27160644
EXPLODED A022 TAPE TAPE(CLOTH-8U) 1 29110082
EXPLODED A023 SCREW 3SMS8W.SW+14B(CU) 6 801634
EXPLODED A024 SCREW 3TTB+8B(3BC) 6 838430088GR
EXPLODED A025 SCREW 3TTB+8B(3BC) 1 838430088GR
EXPLODED A028 SCREW 3TTB+8B(3BC) 2 838430088GR
EXPLODED A032 COVER --- 1 28210053A N
EXPLODED A033 SCREW 3TTB+8B(3BC) 3 838430088GR
EXPLODED A034 CUSHION --- 2 28141765
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
!ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.

2/50 PAGE
EXPLODED A039 B PLATE DHS-8.8 1 28133433
EXPLODED A042 HOLDER KGLS-10RT 4 27190428A
EXPLODED A045 RETAINER (H) 1 27142173 N
EXPLODED A046 TAPE TAPE(CLOTH-8U) 1 29110082
EXPLODED A050 SCREW 3TTB+8B(3BC) 2 838430088GR
EXPLODED A052 SPACER (Dia6‐3‐1.0) 1 27270492
EXPLODED A062 HOLDER HOLDER KGLS-18S 1 27190470
EXPLODED A101 REAR PANEL MPP 1 27124117A N<MPP>
EXPLODED A101 REAR PANEL MDC 1 27124118B N<MDC>
EXPLODED A105 SCREW 3TTB+8B(3BC) 14 838430088GR
EXPLODED A106 SCREW 3P+6FN(3BC) 4 82143006GR
EXPLODED A107 SCREW (FAN) 4 801643A
EXPLODED A108 BUSHING (FAN) 4 28170089A
EXPLODED A130 CUSHION (tr) 1 28141786
EXPLODED A132 CUSHION (t5x150x40) 2 28141781
EXPLODED A134 CUSHION (t8x15x10) 1 28141782
EXPLODED A136 CUSHION (18×10×4) 2 28141836 N
EXPLODED A138 TAPE TAPE(CLOTH-8U) 1 29110082
EXPLODED A140 CUSHION (BUTYL) 1 28141748
EXPLODED A142 CUSHION (BUTYL) 1 28141748
EXPLODED A143 CUSHION (BUTYL) 1 28141748
EXPLODED A144 CUSHION (FELT) 2 28141793
EXPLODED A150 LABEL POP 1 NSP NNSP

3/50 PAGE
EXPLODED [TRANS COIL]
EXPLODED T901 P TRANS NPT-1577P 1 2301947 !<MPP>
EXPLODED T901 P TRANS NPT-1577D 1 2301985 N!<MDC>
EXPLODED [SW TRM]
EXPLODED E889 FAN 9S0612H405 1 24502329
EXPLODED F901 FUSE 1A-SE-EAK FUSE 1 252070GR !<MPP>
EXPLODED F901 or FUSE 1A-SE-TL250V ( 1) 252271GR !<MPP>
EXPLODED F901 FUSE 2.5A-UL/T-233 1 252321GR !<MDC>
EXPLODED F901 or FUSE 2.5A-T/UL-ST2 ( 1) 252254GR !<MDC>
EXPLODED P7501 FFC NCFC7-111512 1 2047111512
EXPLODED [OTHER]
EXPLODED E890 WIRE TIE BSK-1 7 260208
EXPLODED E892 IB CUSHION W15*3t TAPE 1 28141585
EXPLODED E895 CLIP CS-1U 1 27255004
EXPLODED [TUNER UNIT]
EXPLODED U01 HDMI PC board ass'y BAHDM-0324-1A * 1 1B246524-1A N
EXPLODED U02 AMPLIFIER PC board ass'y BAAF-0326-1B * 1 1B246526-1B N <MPP>
EXPLODED U02 AMPLIFIER PC board ass'y BAAF-0326-1D * 1 1B246526-1D N <MDC>
EXPLODED U02-1 MICROPROCESSOR PC board ass'y BADG-0327-1B 1 1B246527-1B N<MPP>
EXPLODED U02-1 MICROPROCESSOR PC board ass'y BADG-0327-1D 1 1B246527-1D N<MDC>
EXPLODED U02-2 THERMAL SENSOR PC board ass'y BAETC-0328-1B 1 1B246528-1B N<MPP>
EXPLODED U02-2 THERMAL SENSOR PC board ass'y BAETC-0328-1D 1 1B246528-1D N<MDC>
EXPLODED U02-3 HOLDER PC board BAETC-0329-1B 1 1B246529-1B N<MPP>
EXPLODED U02-3 HOLDER PC board BAETC-0329-1D 1 1B246529-1D N<MDC>
EXPLODED U03 POWER TRANS. PC board ass'y BAPS-0331-1B * 1 1B246531-1B N <MPP>
EXPLODED U03 POWER TRANS. PC board ass'y BAPS-0331-1C * 1 1B246531-1C N <MDC>
EXPLODED U03-1 DISPLAY PC board ass'y BADIS-0332-1B 1 1B246532-1B N<MPP>
EXPLODED U03-1 DISPLAY PC board ass'y BADIS-0332-1C 1 1B246532-1C N<MDC>
EXPLODED U03-2 SWITCH PC board ass'y BASW-0333-1B 1 1B246533-1B N<MPP>
EXPLODED U03-2 SWITCH PC board ass'y BASW-0333-1C 1 1B246533-1C N<MDC>
EXPLODED U03-3 SPEAKER TERMINAL PC board ass'y BATRM-0334-1B 1 1B246534-1B N<MPP>
EXPLODED U03-3 SPEAKER TERMINAL PC board ass'y BATRM-0334-1C 1 1B246534-1C N<MDC>
EXPLODED U03-4 AC INLET PC board ass'y BAETC-0335-1B 1 1B246535-1B N<MPP>
EXPLODED U03-4 AC INLET PC board ass'y BAETC-0335-1C 1 1B246535-1C N<MDC>
EXPLODED U03-5 HOLDER PC board BAETC-0336-1B 1 1B246536-1B N<MPP>
EXPLODED U03-5 HOLDER PC board BAETC-0336-1C 1 1B246536-1C N<MDC>
EXPLODED SPEAKER SECTION

4/50 PAGE
EXPLODED REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
EXPLODED SP01a COMPLETE UNIT ALL (With AMP UNIT / With SPEAKER UNIT) 1000-HTX22HDXBMPPCSER N<MPP>
EXPLODED SP01b COMPLETE UNIT ALL (With AMP UNIT / With SPEAKER UNIT) 1000-HTX22HDXBMDCCSER N<MDC>
EXPLODED SP02a COMPLETED ASS'Y Without AMP UNIT (With SPEAKER UNIT) 1000-HTX22HDXBMPPESER N<MPP>
EXPLODED SP02b CABINET ASS'Y Without AMP UNIT (With SPEAKER UNIT) 1000-HTX22HDXBMDCESER N<MDC>
EXPLODED SP03 WOOFER UNIT WF / 16cm 3ohm 1 300-DX22HDX1600
EXPLODED SP04 FOOT --- 4 D243-TX2201B-00
EXPLODED SP05 SCREW BIND HEAD 4 x 25mm (SP UNIT/FOOT) 12 411-BE4025AB1
EXPLODED SP06 SCREW BIND HEAD 4 x 20mm (AMP) 5 411-BE4020AB1
EXPLODED SP12 NETWORK ASS'Y UNIT-AMP L=500 1 310-X22HDX-11
EXPLODED SP15a SPEC LABEL MPP 1 600-HDXMPP-00 N
EXPLODED SP15b SPEC LABEL MDC 1 600-HDXMDC-00 N
EXPLODED SP16 UL LABEL --- 1 660-HTS770-00 <MDC>
EXPLODED SP20a SPEAKER ASS'Y HTX-22HDX ST (B)MP 1 ANM1SX22H-BM70 N<MPP>
EXPLODED SP20b SPEAKER ASS'Y HTX-22HDX ST (B)MC 1 ANM1SX22H-BM10 N<MDC>
HTX-22HDX
PRINTED CIRCUIT BOARD PARTS LIS
T
PWB1 U01 HDMI PC board (BAHDM-0324-1A *)
PWB1 CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
PWB1 [SEMI CONDUCTOR]
PWB1 D8100 DIODE XBS303V17R 1 22380365R2

5/50 PAGE
PWB1 D8101 DIODE XBS303V17R 1 22380365R2
PWB1 D8102 C-DIODE KDS4148U 1 223283R2
PWB1 D8102 or C-DIODE 1SS352 ( 1) 223234R2
PWB1 D8102 or C-DIODE 1SS355 ( 1) 223269R2
PWB1 D8102 or C-DIODE MA2J111 ( 1) 223279R2
PWB1 Q8101 IC ADV7623 1 22242625R3
PWB1 Q8102 IC MP2363DN-LF-Z 1 22242627R2
PWB1 Q8103 IC MP2363DN-LF-Z 1 22242627R2
PWB1 Q8104 IC SN74CB3Q3305PWR 1 22242258R2
PWB1 Q8106 IC EN25Q32A-100HIP 1 222W0112R2
PWB1 Q8107 IC S-812C50BUC-C5ET2G 1 22242407R2
PWB1 Q8261 TR DTC123JKA 1 2216690R2
PWB1 Q8262 TR DTC123JKA 1 2216690R2
PWB1 Q8263 TR DTC123JKA 1 2216690R2
PWB1 Q8264 TR DTC123JKA 1 2216690R2
PWB1 Q8265 TR DTC123JKA 1 2216690R2
PWB1 Q8266 TR DTC123JKA 1 2216690R2
PWB1 Q8301 IC D790E001BZDH300Z 1 22242514R3
PWB1 Q8302 IC TC7WU04FU(TE12L_F) 1 22240935R2
PWB1 Q8303 IC ES29LV160ET-70TG 1 222W0069R3
PWB1 Q8303 or IC S29AL016J70TFI010 ( 1) 222W0100R3
PWB1 Q8303 or IC ES29LV160FT-70T ( 1) 222W0101R3
PWB1 Q8303 or IC MX29LV160DTTI-7 ( 1) 222W0104R3
PWB1 Q8304 IC K4S641632K-UC60 1 22242462R2
PWB1 Q8304 or IC K4S641632N-LC60 ( 1) 22242603R2
PWB1 Q8304 or IC EM638165TS-7G ( 1) 22242607R2
PWB1 Q8306 IC TC74VHC541FT(EKJ) 1 22274541E1R2TO
PWB1 Q8307 IC XC6220B12BPR 1 22242642R2 N
PWB1 Q8501 IC XC6221B182MR 1 22242632R2
PWB1 [TRANS COIL]
PWB1 L8101 CORE BLM18PG181SN1D 1 2350005R1
PWB1 L8102 CORE BLM18PG181SN1D 1 2350005R1
PWB1 L8103 CORE BLM18PG181SN1D 1 2350005R1
PWB1 L8104 CHOKE COIL 0182-7E08Q-100M-RA 1 231396M100R2
PWB1 L8105 C-CARBON R RN72K1J-000JE 1 435030004R1
PWB1 L8106 CORE BLM18PG181SN1D 1 2350005R1
PWB1 L8107 CORE BLM18PG181SN1D 1 2350005R1
