NCP1680 - Totem Pole CrM Controller Evaluation
Board User's Manual
EVBUM2822/D
Introduction
The NCP1680 is a Critical Conduction Mode (CrM)
Power Factor Correction (PFC) controller IC designed to
drive the bridgeless Totem Pole PFC (TPFC) topology. The
bridgeless totem pole PFC consists of two totem pole legs:
a fast switching leg driven at the PWM switching frequency
and a second leg that operates at the AC line frequency. This
topology eliminates the diode bridge present at the input of
a conventional PFC circuit, allowing significant
improvement in efficiency and power density.
Figure 1. NCP1680 Evaluation Board
The NCP1680 Evaluation Board (EVB) user guide
demonstrates a universal line, 300 W totem pole PFC built
using NCP1680. NCP1680 is intended for Industrial power
supplies, Telecom/5G/Networking power, USB PD,
Gaming consoles, UHD TV power supplies, and Lighting
applications. TPFC topology eliminates the need for
heatsinks or forced air in the NCP1680 EVB while operating
at an ambient of 25°C.
Table 1. KEY SPECIFICATIONS
Description Value Unit
Input Voltage Range 90−265 Vac
Line Frequency Range 47−63 Hz
Output Voltage 395 V
Output Power 300 W
Output Ripple < 5 %
PF @ Full Load > 0.95
THD @ Full Load < 10 %
Inductor Value 150 mH
Inductor Core Size/Geometry PQ3220
Bulk Capacitor Value 200 mF
Maximum Frequency 130 kHz
NOTE: NCP1680 EVB is a high voltage demonstration
board. It can accept an input voltage of 90 Vac to
265 Vac and the output voltage of the board is
395 Vdc nominally. This EVB is for
demonstration purposes only and should not be
used to power any loads other than an electronic
load. Only trained professionals in using high
voltage equipment should handle the board and
appropriate safety precautions should be
followed.
EVBUM2822/D
www.onsemi.com
2
TYPICAL APPLICATION SCHEMATIC
Figure 2. Typical Application Schematic of a CrM Totem Pole PFC Utilizing NCP1680
VL
VAC
+
_
NCP51530
HI
LI
COM
LO VCC
HB
HO
VB
ZCD
SR2
SR1
NCP1680
POLARITY
PWMH
LVSNS1PFCOK
FB
LVSNS2
PWML
SRH
ZCD
PGND
SKIP
FAULT
VCC
RAUX
0 V
+400 V
+++− −
+++−−
Vac
400−Vac
VO
VO
RLOAD
RZCD
AUX
VCC
SRL
SRH
SRL
NCP51820
VDD
VBST
SW
HOSRC
VDDH
HOSNK
LOSRC
VDDL
PGND
LOSNK
HIN
LIN
SGND
EN
DT
S1
S2
VCC
GND
VCC
As shown in Figure 2, the slow leg switches (SR1 & SR2)
are high voltage silicon−based FETs, also known as super
junction (SJ) FETs, and the fast leg switches (S1 & S2) are
Enhancement−mode Gallium Nitride (eGaN) devices. Since
NCP1680 employs a CrM control architecture where the
inductor current resets back to zero before the next
switching cycle, low reverse recovery charge (Qrr) SJ FETs
can also be utilized for the fast leg albeit with slightly
inferior performance, but better cost structure. As
a controller the NCP1680 is agnostic to the fast leg switch
technology. Wide−Bandgap (WBG) devices such as Silicon
Carbide (SiC) or eGaN are recommended for optimal
performance. SiC is a good choice for lower frequency
applications while eGaN is an excellent choice for both low
frequency and high frequency applications.
The NCP1680 evaluation board is designed such that
engineers interested in this novel topology can easily probe
various signals and learn the intricacies of TPFC. The fast
leg half bridge is implemented on a daughter card where the
fast leg switches are driven using NCP51820, a high voltage
eGaN half−bridge driver; the slow leg switches are driven
using NCP51530, a high voltage Si FET half−bridge driver.
The NCP1680 employs a novel current limit scheme where
a simple resistor placed in the return path between bulk
ground and the IC ground, is utilized for current limiting.
The Zero Current Detection (ZCD) resistor is further
utilized for drive control of the synchronous switch in the
fast leg.
Additionally, the NCP1680 requires only a single
auxiliary winding to sense switch node valleys (in positive
half−line cycle) and switch node peaks (in negative half line
cycle). This novel scheme results in the main boost switch
being turned on with minimal voltage across the switch
improving efficiency and reducing EMI.
EVBUM2822/D
www.onsemi.com
3
BOARD DESCRIPTION AND TEST SETUP
Figure 3. NCP1680 Evaluation Board along with a Daughter Card Featuring Fast Leg Switches
The evaluation motherboard and daughter card are shown
in Figure 3. The motherboard includes multiple I/O
connectors and test points to simplify instrumentation and
waveform capture during the evaluation process. A brief
description and pinout of the I/O connectors is shown in
Table 2, and a listing of the test points plus the respective
circuit node is shown in Table 3.
There are some key points worth mentioning regarding
the I/O connectors and test points:
•The pins labeled GND and VOUT_RTN are NOT
electrically common. GND and VOUT_RTN are
physically separated by the ZCD resistor and the user
should take precaution to not short these two nodes
together. For example, the ground lead of an
Earth−connected oscilloscope probe should not be
simultaneously connected to both GND and
VOUT_RTN.
•The EVB requires an external VCC bias supply. It is
recommended to connect this bias supply at the J3
connector or across the TP8−TP10 test points. The
recommended operating range for VCC is 12–18 V with
a current sourcing capability greater than 10 mA. Once
the EVB has been enabled, VCC can fall as low as 9 V
before the NCP1680 UVLO circuit disables the
controller. A VCC voltage greater than 20 V will trip the
EVB over−voltage protection (OVP) and latch off the
controller.
•J6 – AC Input connector is pinned out for a 3−wire AC
input connection. However, the chassis GND connection
is not required and can be left open. The user should
determine the appropriate input connection based on their
application requirements.
•J10 – SKIP header should be open to allow normal
operation of the EVB. Placing a jumper across the J10
header will force the EVB into Skip/Standby mode
operation, described later.
•J11 – Inrush current limiter (ICL) bypass is populated by
default. If the user wishes to operate the NCP1680 EVB
with an ICL then J11 must be removed before populating
the ICL at REF DES RT2.
•J12 – Daughter card interface is not keyed. User should
take precaution that the daughter card is correctly oriented
into J12. Furthermore, user must take precaution that the
daughter card is never inserted or removed while VCC is
applied to the motherboard, doing so can damage EVB.
Table 2. I/O CONNECTOR DESCRIPTIONS
REF DES Function Pinout
J1, J7, J8, J9 GND Peg 1. GND
J2 DC Output
Voltage
1. VOUT_RTN
2. N/C
3. VOUT
J3 VCC 1. VCC
2. GND
J4 PFCOK Skip
Interface
1. CNTRL Signal
2. GND
J6 AC Input
Voltage
1. AC Line
2. Chassis GND
3. AC Neutral
J10 SKIP Control
Header
1. CNTRL
2. GND
J11 Inrush Current
Limit Bypass
1. VOUT_NTC
2. VOUT
J12 Daughter Card
Interface
1−6: VOUT_NTC
7−12: VBRIDGE
13−18: PWRGND
19−28: N/C
29−32: GND
33−34: PWML/LIN
35−36: PWMH/HIN
37−38: VCC
EVBUM2822/D
www.onsemi.com
4
Table 3. TEST POINT DESCRIPTIONS
REF DES Node REF DES Node
TP1 NCP1680 AUX Pin TP13 Slow Leg Bridge Node
TP2 GND @ NCP51530 Driver TP14 VOUT
TP3 NCP1680 FB Pin TP15 VOUT_RTN
TP4 NCP1680 PFCOK Pin TP16 NCP1680 SRH
TP5 NCP51530 VCC1 TP17 NCP1680 SRL
TP6 NCP1680 ZCD Pin TP18 PWRGND
TP7 VOUT_SNS TP19 NCP1680 SKIP Pin
TP8 NCP1680 VCC Pin TP20 NCP1680 LVSNS2 Pin
TP9 NCP1680 Polarity Pin TP21 NCP1680 LVSNS1 Pin
TP10 GND @ J3 Connector TP22 NCP1680 PWMH/HIN
TP11 Haversine @ L2 Inductor TP23 NCP1680 PWML/LIN
TP12 Fast Leg Bridge Node TP24 NCP1680 Fault Pin
In order to replicate the data published in this design note,
the following test set up is recommended:
•For higher power measurements (> 10% load), always
arrange the connection so that the voltmeters at input and
output are as close to NCP1680 evaluation board (UUT)
as possible to avoid power loss due to resistance of the
wiring or any other instrumentation.
•For input power measurement, please read power
measurement directly from the power meter. Do not
multiply V
AC and IAC measurements, this is the apparent
power of UUT. The power measurement provides the real
power consumed by the UUT.
•Do not use the electronic load reading for output voltage
measurement. A separate DMM placed directly across
output (TP14−TP15) will produce a more accurate
reading than the eLoad and cancels some of the
instrumentation power loss in ammeter.
Figure 4. Test Setup for NCP1680 EVB
Power Meter
VAC
UUT eLoad
A
V
A
V
EVBUM2822/D
www.onsemi.com
7
Soft−Start
Figure 9. Soft−Start
Ch. 1 (Yellow): Line Current
Ch. 2 (Blue): Polarity
Ch. 3 (Purple): PFCOK
Ch. 4 (Green): Bulk Voltage
Load Transient
Figure 10. Load Transient
10% to 100% Load Step 100% to 10% Load Step
In the above waveforms, NCP1680’s dynamic response enhancer (DRE) limits the lower bulk voltage to 367 V while the
output overvoltage protection (OVP) limits the upper bulk voltage to 418 V. Transient data was captured at 115 Vac.
Ch. 1 (Yellow): Line Current
Ch. 2 (Blue): PWML
Ch. 3 (Purple): PWMH
Ch. 4 (Green): Bulk Voltage
EVBUM2822/D
www.onsemi.com
8
Input Current Waveforms and Output Ripple at Various Line Voltages
Figure 11. Input Current Waveforms and Output Ripple at Various Line Voltages
Skip/Standby Mode Control
The NCP1680 features a Skip/Standby mode which
enables the application to achieve very good no−load and
light−load performance. The device must be externally
commanded to enter the Skip mode by pulsing the PFCOK
pin or grounding the SKIP pin, and in a typical application
this control signal would be provided by a downstream
DC−DC converter. For the NCP1680 motherboard,
additional circuitry shown in Figure 12 has been designed in
to allow the user to easily transition the EVB into the
Skip/Stanbdy mode without the use of a downstream
converter.
The J10 header which is a standard 2 position, 100 mil
pitch connector header, provides a path to GND for the SKIP
pin. The user can operate the EVB in Skip mode by placing
a mating jumper (such as TE Connectivity 382811−6) across
the header, grounding the SKIP pin. J10 is conveniently
located on the PCB away from any high voltage nodes so
that the jumper can be placed while the EVB is in live
operation. Nonetheless, the user should exercise caution
when placing this jumper to prevent injury to themselves or
damage to the EVB.
EVBUM2822/D
www.onsemi.com
9
Figure 12. NCP1680 EVB Skip Interfaces
The second skip interface on the EVB is at the J4
connector which can be used to connect in a function
generator to pulse the PFCOK pin. For the NCP1680 to enter
skip mode the PFCOK pin must be pulsed below 400 mV for
a duration greater than 50 ms as is shown in Figure 13. It is
recommended that the function generator output be a signal
with 0–5 V amplitude where the output remains at 5 V for
at least 100 ms to meet the threshold requirements on the
PFCOK pin.
Figure 13. PFCOK Skip−Entry Signal (Ch1 = Bulk Voltage, Ch2 = PFCOK, Ch4 = SKIP)
Once skip mode has been entered the NCP1680 controller
will regulate the bulk voltage with a form of hysteretic
control, meaning that the bulk voltage will cycle between its
nominal regulation voltage and ~94% of nominal
regulation. The frequency at which the bulk voltage cycles
will be dependent on the output load. To maintain the EVB
in skip/standby mode it is necessary to continue pulsing the
PFCOK pin wherein every PFCOK pulse must meet the
previously stated voltage and timing threshold
requirements. The pulse frequency to maintain skip mode
must be faster than the frequency at which the bulk voltage
cycles between nominal regulation and 94% of nominal
regulation. Hence it is technically possible to operate the
EVB in skip mode at any load level and often in applications,
skip operation may be necessary up to 5–10% of the rated
load. Figure 14 shows skip mode operation with the EVB
loaded at 20 W. A lighter load, or no load will result in much
longer cycle frequency and better performance.
EVBUM2822/D
www.onsemi.com
10
Figure 14. NCP1680 Skip Mode Operation (Ch1 = Bulk Voltage, Ch2 = PFCOK, Ch4 = SKIP)
Control Loop Measurement
The NCP1680 controller is embedded with an internal
compensator circuit which provides the necessary loop
bandwidth to ensure good power factor performance, and
also provides sufficient phase & gain margin at the loop
crossover frequency to ensure stable and robust operation of
the application. Verification of the control loop
characteristics is a good practice for any power supply
design. The NCP1680 motherboard provides a 1 kW
injection resistor and test points (TP14, TP7) around the
injection resistor enabling the use of a network analyzer with
an isolated injection transformer to measure the loop
response of the EVB. Figure 15 shows the loop response of
the NCP1680 EVB with 300 W load, measured at 115 VAC
and 230 VAC. The loop bandwidth measures from ~ 8–11 Hz
with about 70°of phase margin and > 14 dB of gain margin.
EVBUM2822/D
www.onsemi.com
11
Figure 15. EVB Bode Plots @ 300 W; 115 V on Top; 230 V on Bottom
Thermal Performance
The NCP1680 EVB and daughter card where also
evaluated for thermal performance while operating at
90 VAC and 300 W. Thermal images of the fast leg GaN
HEMTs, the boost inductor, and the slow leg silicon FETs
are shown in Figure 16. These images were captured in
a25°C ambient environment with no external air flow. The
high efficiency performance of the TPFC is evident in the
device temperatures where the fast and slow leg switches
measure below 60°C, a modest 35°C rise above room
temperature. The daughter card PCB is also designed in
a manner that eliminates the need for an additional heatsink
to be mounted to the board. The PCB’s internal copper
planes function as heat sinking and the temperature rise of
the fast leg switches is well controlled by these copper
planes.
Figure 16. Thermal Measurement of Fast Leg eGaN Switches, Boost Inductor, and Slow leg Si FETs
EVBUM2822/D
www.onsemi.com
20
BILL OF MATERIALS
Table 4. BILL OF MATERIALS – MOTHERBOARD
Item Qty REF DES Value Description Manufacturer MPN
PCB
Footprint
Substitution
Allowed
1 1 C7 1nF CAP CER 1000 pF 50 V
C0G/NP0 0603
Kemet C0603X102J5GAC7867 603 Yes
2 1 C10 22 pF CAP CER, NPO 22 pF
50 V
Wurth 885012006053 603 Yes
3 1 C11 0.1 mFCAP CER 0.1 mF 50 V
10% X7R 0603
Murata GCM188R71H104KA57D 603 Yes
4 1 C14 10 n CAP CER 10 nF 50 V
X7R 0603
Yageo CC0603KRX7R9BB103 603 Yes
5 1 C15 0.1 mFCAP CER 0.1 mF 50 V
10% X7R 0603
Murata GCM188R71H104KA57D 603 Yes
6 1 C17 0.1 mFCAP CER 0.1 mF 50 V
10% X7R 1206
Kemet C1206C104K5RACAUTO 1206 Ye s
7 1 C19 10 mFCAP CER 10 mF 25 V
10% X7R 1206
Samsung CL31B106KAHNNNE 1206 Yes
8 1 C25 22 mFCAP ALUM 22 mF 20%
50 V RADIAL
Nichicon UVK1H220MDD1TD Radial Yes
9 1 C29 22 nF CAP CER 22 nF 50 V
X7R 0603
Kemet C0603C223K5RACTU 603 Yes
10 1 C30 1mFCAP CER 1 mF 25 V
10% X7R 0603
Samsung CL10B105KA8NNNC 603 Yes
11 1 C31 22 mFCAP CER 22 mF 25 V
10% X5R 1206
Samsung CL31A226KAHNNNE 1206 Yes
12 2 C1−2 820 nF Cap, X Type, 275 V, AC,
Polypropylene
Kemet R46KI382040P0 MBox,
Radial
No
13 2 C12−13 1nF CAP CER 1 nF 630 V
X7R 1206
Yageo CC1206KKX7RZBB102 1206 Yes
14 2 C16, C18 100 mFCAP ALUM 100 mF 20%
450 V Rad. 18 x 40 mm
United Chemi−Con EKXG451ELL101MM40S Round,
Radial
Yes
15 2 C20−21 0.1 mFCAP CER 0.1 mF 630 V
10% X7R 1210
Kemet C1210C104KBRAC7800 1210 Yes
16 2 C22−23 2.2 nF CAP FILM 2200 pF 20%
1.25 kVDC RAD
Kemet PHE850EA4220MA01R17 Radial,
13 x 4 mm
No
17 1 C24 1nF CAP CER 1000 pF 50 V
C0G/NP0 0603
Kemet C0603X102J5GAC7867 603 Yes
18 1 C26 2.2 nF CAP CER 2200 pF 50 V
X7R 0603
Kemet C0603C222M5RACTU 603 Yes
19 2 C27−28 DNP CAP CER DNP
Placeholder 0603
NA NA 603 No
20 3 C4, C8−9 220 pF CAP CER 220 pF
C0G/NPO 0603
Kemet C0603C221J5GACTU 603 Yes
21 2 C5−6 2.2 nF Cap, Disc, Y Type,
760 VAC
Kemet C961U222MWWDBA7317 Box, Axial No
22 1 D6 ES1J Diode Ultrafast 600 V
SOD−123−FL
onsemi ES1JFL SOD−123_
FL
No
23 2 D1−2 S3M Diode GEN PURP 1 kV
3A
onsemi S3M SMC No
24 3 D3−5 BAT54H Diode Schottky 30 V
200 mA (DC) Surface
Mount SOD−323
onsemi BAT54HT1G SOD−323_
rev3
Yes
25 4 D7−10 MMSD4148 DIODE GEN PURP
100 V 200 mA SOD123
onsemi MMSD4148T1G SOD−123 Yes
26 1 F1 5A Fuse, 8.4 x 4 mm,
5.08 mm spacing
Bel Fuse RSTA 5 AMMO Thru−Hole Yes
27 1 J10 Connector, Header,
100Mil spacing
Amphennol 67997−224HLF Thru−Hole Yes
28 1 J11 Jumper, 1 mm dia.
10.16 mm, Gold
Harwin D3082−05 Thru−Hole Yes
Table of contents
Other onsemi Microcontroller manuals
