Onstep EQ5 GoTo Manual

OnStep EQ5 GoTo
BUILD INSTRUCTIONS
By Oddvar S. Næss

Revisions
Version
Reason for revision
Date
By
A
First issue
11 May 2021
OSN
B
Corrections to the ST4 interface (pullup resistors)
21 May 2021
OSN
Information
This instruction contains information not essential for building a OnStep GoTo System. For
readers that want to jump right into the building instruction please go directly to the
instructions page.
The following building instructions are mainly based on my experience when modifying my
old Sky-Watcher EQ5 mount, but can also be adapted to many other mounts. Main steps are
general, but items and configuration might be mount/controller specific. Please refer to the
OnStep Wiki for other controllers and mounts.

Content
Background 4
Building instructions 5
OnStep Controller 5
Bill of materials 5
Software 6
Arduino IDE and configuration files 6
Flashing instructions 6
Electrical assembly 7
Connection diagram 7
Figure 1 - Connection diagram 7
Assembly instructions 8
Figure 2 - R1 10k Resistor 8
Figure 3 - Driver Slots Jumper Settings (M0, M1, M2) 8
Figure 4 - LV8729 Driver orientation 9
Figure 5 - LV8729 Resistor locations 10
Figure 6 - Tuning Vref 10
Figure 7 - ST4 Resistor network 11
Figure 8 - ST4 SIP unit soldered to the CNC V3 Shield 11
Figure 9 - OnStep Controller with RJ45 Connectors 12
Figure 10 - Motor brackets with RJ45 Connectors 12
Mechanically assembly 13
3D Printed parts 13
Additional items complimenting my setup, but not related to OnStep directly: 13
Telescope and camera: 13
Thank you! 13

Background
I’ve always had an interest in astronomy as well as photography. Right up until the
coronavirus hit us I was using some of my spare time doing wide angle Milky Way
photography, going to remote locations with minimal light pollution to maximise the results.
However, as the society was gradually shut down during the increased corona restrictions
applied by the Norwegian gouvernments I started to investigate how I could pursue this
hobby from my home. I was also in need of some in-house projects to burn off some of the
free time I had these days. Soon after I was searching for used second hand telescope
mounts, preferably the Sky-Watcher EQ5. When the mount was found and bought the
intention was to use this mount with my original DSLR and lens, but I got carried away and
bought a used SharpStar 61EDPH (Mk I) and EvoGuide 50ED as well. This should be a
good beginner starting point for some wide field astrophotography.
The mount came with the original RA Motor Drive system. When testing the new setup from
our porch this seemed to work quite well. However, slewing took forever and finding targets
that I could not easily see through the finderscope was next to impossible (nebulas etc.). I
thought I could live with this, but that was just until I realised how long it took to make all the
photos needed for some decent stacking results later on in the process. I had quite a few
freezing nights outside (this was during winter time in Norway) before I realized I had to look
for alternatives, else I would probably give up this new hobby of mine.
Based on my experience so far I had a few ideas of what I wanted to achieve now:
● A system I could remote control from the warm inside of my house or car
● It had to be able to run on battery power for some hours
● It should function as a stand-alone system (no internet required)
● Ideally modular and portable
A few evenings of googling made me bump into OnStep and a few months later I could
finally confirm I had a fully working GoTo mount and celestial tracker that gave me very
satisfactory results. Not only that, but connecting the OnStep controller to a Raspberry Pi
running with Astroberry made for an impressive system overall.
Looking back at all the time I invested in finding solutions, information, how-to’s and such I
thought I would try to help others in the same situation starting from scratch with little or no
knowledge of electronics nor astronomy. During this project I’ve made notes along the way
and did partial documentation of the process and the parts used for my specific
configurations. Based on these I decided to make this build instruction in the hopes it might
be of help for others finding themselves in the situation that I did.
NOTE: Please keep in mind that this is done with my best intentions, but remember that I am
also just an amateur - most of the things involved related to this OnStep controller are like
magic to me so I would strongly recommend that you do your own research and read the
Wiki thoroughly.

Building instructions
OnStep Controller
Bill of materials
Item:
Qty.:
Price ($)
URL
WEMOS D1 R32 ESP32 WiFi BT Development Board
1
7.00
LINK
Arduino CNC V3 Shield
1
3.50
LINK
LV8729 Drivers
3
18.00
LINK
NEMA17 Stepper Motor 0.9deg 1.68A 40mm*
2
34.00
LINK
GT2 12t 6.35mm bore 6mm belt pulley (DEC shaft)
1
4.00
LINK
GT2 16t 6.35mm bore 6mm belt pulley (RA shaft)
1
3.00
LINK
GT2 48t 5mm bore 6mm belt pulley (Stepper shafts)
2
9.00
LINK
GT2 6mm 150 Closed Loop Timing Belt (RA Axis)
1
4.00
LINK
GT2 6mm 140 Closed Loop Timing Belt (DEC Axis)
1
3.00
LINK
RJ45 breakout boards (Pack of 6pcs, but only 5 needed)
6
6.00
LINK
RJ11 / RJ12 / 6P6C Breakout Board
1
12.00
LINK
NodeMCU ESP8266**
1
3.00
LINK
DS3231 Real Time Clock***
1
1.50
LINK
Set of Dupont 20cm Jumper Wire (FF/MM/FM)
1
8.00
LINK
Set of 5.5x2.1mm DC Power Plugs (F/M)
1
5.50
LINK
Total cost
121.50
* Cheap stepper motor, but not the most efficient one. Based on some forum posts there
seems to be versions of this motor rated for 0.9A only with similar performance. This should
probably be considered if you’re aiming for maximum energy efficiency (ie. maximum battery
life etc.)
** I used a NodeMCU ESP8266 DevBoard I already had from an earlier project (and it’s
been dead stable), but the Wiki recommends the Wemos D1 Mini version.
*** I’m not really sure if this RTC is adding any real benefit or improvements to this system,
but since these cost next to nothing I figured it was best to include it just to be on the safe
side.

Software
Arduino IDE and configuration files
1. Follow the OnStep Wiki instructions carefully for setting up Arduino IDE correctly for
flashing both the Wemos R32 and the ESP8266 (Link and Link). Pay special
attention to Library versions!
2. Download OnStep V4.x Master File and extract to default Arduino sketch folder
(Direct Download Link)
3. Download and populate the Configuration Calculation sheet with correct values for
your mount, stepper motors and gears (Direct Download Link):
a. 400 steps motors with 0.9deg
b. 32 microsteps
c. Axis 1 Gear Ratio 1 with my setup = 3 (48/16)
d. Axis 1 Gear Ratio 2 for EQ5 = 144 (EQ5 internal worm gear)
e. Axis 2 Gear Ratio 1 with my setup = 4 (48/12)
f. Axis 2 Gear Ratio 2 for EQ5 = 144 (EQ5 internal worm gear)
g. Desired Slewing Speed = 3
4. Then we need to use the Web Configurator for making a new config.h (Link):
a. 4.x Masterfile selected
b. Equatorial mount selected
c. Desired Slewing Speed = 3
d. Select 400step 0.9deg motor for both axis
e. Select 32 micro steps
f. Axis 1 Gear Ratio 1 with my setup = 3 (48/16)
g. Axis 1 Gear Ratio 2 for EQ5 = 144 (EQ5 internal worm gear)
h. Axis 2 Gear Ratio 1 with my setup = 4 (48/12)
i. Axis 2 Gear Ratio 2 for EQ5 = 144 (EQ5 internal worm gear)
j. DS3231 I2C RTC enabled
k. ST4 Port for guiding enabled
l. All else is left at default or “NO”
m. Generate the “Config.h” file and replace the Config.h file in the folder from
step 2.
Flashing instructions
5. Flashing the Wemos R32 with Arduino IDE:
a. Connect the Wemos R32 to the computer and start Arduino IDE
b. Open the onstep.ino file in the folder from step 2.
c. Identify correct board type (ESP32 Dev Module) and com port
d. Select “Upload” to start the flashing process
e. When flashing is done disconnect the Wemos R32
6. Flashing the ESP8266 Wifi Module with Arduino IDE:
a. Connect the ESP8266 to the computer and start Arduino IDE
b. Open the wifi.ino file in the folder from step 2.
c. Identify correct board type (Generic ESP8266 Module) and com port
d. Select “Upload” to start the flashing process
e. When flashing is done disconnect the ESP8266
7. That's it for the software part. Now we need to connect everything...

Electrical assembly
Connection diagram
Figure 1 - Connection diagram
NOTE: Wiki instructions for the electrical connections are excellent so make sure to read it
before following the instructions on the next pages (Link).

Assembly instructions
1. We’ll begin by cutting off the R1 (R5) 10㏀ resistor on the Arduino CNC V3 Shield to
remove the pullup to 5Vdc as the Wemos R32 is based on 3.3Vdc:
Figure 2 - R1 10k Resistor
2. The LV8729 drivers can be configured for 32 microsteps by inserting 2 jumpers on
the CNC shield in slot M0 and M2 (also M1 and M3 on some versions). This must be
done for each driver slot that will be used (leave the middle jumer slot empty - Link):
Figure 3 - Driver Slots Jumper Settings (M0, M1, M2)

3. Now insert all the LV8729 drivers into their sockets. Make sure that the “En - Enable”
pin is located in the upper left corner and that the Vref adjustment screw is pointing
down or towards you when you have the shield oriented in such a way that all the
text is in its normal readable orientation.
Figure 4 - LV8729 Driver orientation
4. Connect everything, except the motors, together according to the “Figure 1 -
Connection diagram”.
5. Before we connect the motors we have to make sure to adjust the drivers correctly
with regards to the motor ratings and the correct type of drivers. This must be done
with the motors disconnected (Never connect or disconnect a stepper motor if the
system is powered up!). Formula to find the current starting point for Vref is:
Motor Max Amp * 1.41 * 0.4 = Starting Amp for Vref” (Link).
In my case this would be: 1.68A * 1.41 * 0.4 = 0.95A
Note: The LV8729 has a current limit of 1.8A. Since the motor is rated for 1.68A this will be
our limiting factor and we’re comfortably within the operational constraints of the driver. The
general recommendation seems to be not to load the motors with more than 70%.

6. Now that we have the starting Amp for Vref we need to identify the actual Vref.
However, the LV8729 seems to come in two flavours; some with 2x 100Ω resistors,
and some with 2x R220Ω resistors. You find what version you have by checking the
resistors on the underside of the drivers. Mine had 2x R220Ω.
Figure 5 - LV8729 Resistor locations
Now, by using the following formulas you can identify correct Vref (Link):
2x R100Ω: Desired motor Amps * 0.5 = Vref
2x R220Ω: Desired motor Amps * 1.1 = Vref
In my case this would be: 0.95A * 1.1 = 1.05V
7. Adjusting the Vref potentiometer on the LV8729 driver is quite easy if you're able to
connect a probe from the multimeter to one of the Gnd-points (ground) on the
Arduino CNC Shield and the other probe to the skrewdriver you're actually adjusting
the potentiometer with. That way you’ll have a live view of the adjustments and you
can easily hit your target.
Figure 6 - Tuning Vref
Note: If the motors are struggling when moving/slewing when you test the build with a
fully loaded mount you can adjust in 0.1A increments until you have stable
movements. I ended up with Vref=1.1V (equals 1Amp and 60% of max motor rating).

8. For those that would want to utilize the ST4 connection for a guide camera and/or
hand controller the connections to the to CNC V3 shield should have a reference
level (pullup to 3.3Vdc in this case). Otherwise these connections might act as
antennas where stray voltages could change the logic level of the line and introduce
noise, making the connection unstable and give spurious results. To avoid this it is
recommended to add a resistor network or a SIP (2k or 2.2k should work fine)
according to below illustrations:
Figure 7 - ST4 Resistor network
A good practical example for adding a SIP to the underside of the CNC V3 shield can
be found in the Wiki and also shown here (example by Ken Hunter):
Figure 8 - ST4 SIP unit soldered to the CNC V3 Shield

9. Now we’re ready to connect all remaining parts. This is mostly a straight forward job,
and most parts can be directly connected with jumper wires, except maybe the
stepper motors. Some motors are delivered with pre-made plugs/connectors on both
ends, but others are not. However, in either case we probably need to extend these
cables so we have some room to move the mount in all directions (this is especially
important for the DEC Axis) relative to where we mount the OnStep Controller on our
rigs. I used RJ45 Breakout Boards for this. This way I could simply connect or
disconnect the motors with standard network patching cables.
Figure 9 - OnStep Controller with RJ45 Connectors
Figure 10 - Motor brackets with RJ45 Connectors
10. Now you can test the system with all motors connected (not necessarily to the
mount) and everything powered up. Verify full functionality by any of the possibilities
(Link) and observe how the motors are reacting. If any of the motors are going in the
wrong direction this can easily be rectified in the software; In Arduino IDE open the
onstep.ino file and in the Config.h file locate the “#define
AXISn_DRIVER_REVERSE” line (n is the affected axis 1,2,3 or 4) and set this to
“ON”. Save and re-flash the software to the Wemos R32. This axis should now move
in the opposite direction.

Mechanically assembly
3D Printed parts
- Nema17 Brackets: https://www.thingiverse.com/thing:4853748 (Partial remix of the
excellent https://www.thingiverse.com/thing:4682671 adjusted for the RJ45 ports)
- OnStep Case w/Bracket for EQ5: https://www.thingiverse.com/thing:4853768
Additional items complimenting my setup, but not related to OnStep
directly:
- Raspberry Pi 4 with Astroberry as main server connected to the OnStep Controller
(Link)
- Cheap Chinese PS3 Game Controller for manual slewing through Astroberry (Link)
- 3D printed Standalone Polar Scope LED illumination by a CR2032 battery (Link)
- 3D Printed Raspberry PI Case: Slim version of
https://www.thingiverse.com/thing:3723561
- Raspberry PI w/EQ5 Bracket: https://www.thingiverse.com/thing:4853773
- 3D Printed Power Bank Bracket for EQ5: https://www.thingiverse.com/thing:4853776
- Everything is powered by a 20.000mAh PD 12V capable power bank with special
12V PD Trigger cables for the OnStep (Link and Link).
Telescope and camera:
- Main Telescope: SharpStar 61EDPH (Mk1) w/flattener
- Finder scope: Sky-Watcher EvoGuide 50ED (soon to be guide scope)
- Camera: Nikon D3300 and Nikon D750
Thank you!
Thanks to the creator and all the contributors of OnStep I now have a low budget, wireless,
highly accurate tracker and GoTo system. I’m now able to polar align the mount, do a one
star alignment and then go inside and do everything else from my cosy warm sofa - no more
hours of freezing in below zero celsius here in Norway for these night time photos.
