Optical Systems Design OSD2184P User manual

OPERATOR MANUAL
OSD2184P
MICRO 10/100/1000Base-T to 100Base-
Fx/1000Base-X
3-PORT SWITCH
With IEEE802.3af/at/bt and PoH PoE Source

OPTICAL SYSTEMS DESIGN
DOC ID: 10119601
OSD2184P OPERATOR MANUAL
PAGE 4
INDEX 1
1 TECHNICAL SUMMARY........................................................................................................ 6
1.1 BRIEF DESCRIPTION ............................................................................................................ 6
1.1.1 OVERVIEW......................................................................................................................... 6
1.1.2 APPLICATIONS.................................................................................................................. 6
1.1.3 FEATURES AND BENEFITS............................................................................................. 6
1.2 TYPICAL CONFIGURATION................................................................................................ 7
1.3 PRODUCTS AND OPTIONS .................................................................................................. 7
1.4 TECHNICAL SPECIFICATIONS ........................................................................................... 8
1.5 FRONT AND REAR PANELS .............................................................................................. 11
2 INSTALLATION AND OPERATION................................................................................... 12
2.1 INTRODUCTION .................................................................................................................. 12
2.2 INSTALLATION ................................................................................................................... 12
2.2.1 WARNING AND PRECAUTIONS................................................................................... 12
2.2.2 OSD2184P DRAWINGS AND DIMENSIONS ................................................................ 13
2.2.3 POWER SUPPLY CONNECTIONS ................................................................................. 14
2.2.4 LOCATION........................................................................................................................ 15
2.2.5 FIXED RJ45 COPPER PORT PIN ASSIGNMENTS........................................................ 15
2.2.6 LED INDICATORS ........................................................................................................... 16
2.2.7 CONTROLS ....................................................................................................................... 17
2.2.8 FITTING SFP CONNECTORS.......................................................................................... 18
2.2.9 BASIC CONNECTIONS ................................................................................................... 19
2.3 SINGLE/DUAL SIGNATURE PD OPERATION ................................................................. 20
2.3.1 SINGLE SIGNATURE PD ................................................................................................ 20
2.3.2 DUAL SIGNATURE PD ................................................................................................... 20
2.4 COMMAND LINE INTERFACE (CLI)................................................................................. 21
2.4.1 TERMINAL EMULATION SETUP.................................................................................. 21
2.4.2 COMMAND LINE FUNCTIONS...................................................................................... 22
2.5 WEB GUI ............................................................................................................................... 25
2.5.1 LOGGING ON TO THE SWITCH.................................................................................... 26
2.5.2 GUI MENU ........................................................................................................................ 26
3 MAINTENANCE...................................................................................................................... 34
3.1 INTRODUCTION .................................................................................................................. 34
3.2 EXTERNAL INSPECTION ................................................................................................... 34
3.3 ROUTINE MAINTENANCE................................................................................................. 34
4 WARRANTY ............................................................................................................................ 35
4.1 WARRANTY PERIOD.......................................................................................................... 35
4.2 REPAIRS................................................................................................................................ 35
4.2.1 WARRANTY REPAIRS.................................................................................................... 35
4.2.2 OUT-OF-WARRANTY REPAIRS.................................................................................... 35
4.2.3 SITE REPAIRS .................................................................................................................. 35
4.2.4 EXCLUSIONS ................................................................................................................... 35

OPTICAL SYSTEMS DESIGN
DOC ID: 10119601
OSD2184P OPERATOR MANUAL
PAGE 5
FIGURE 1: OSD2184P TYPICAL CONFIGURATIONS....................................................................... 7
FIGURE 2: FRONT AND REAR PANELS .......................................................................................... 11
FIGURE 3: DIMENSIONS .................................................................................................................... 13
FIGURE 4: DIN RAIL MOUNTING..................................................................................................... 13
FIGURE 5: POWER SUPPLY CONNECTIONS.................................................................................. 14
FIGURE 6: FIXED RJ45 ETHERNET CONNECTORS....................................................................... 15
FIGURE 7: LED INDICATORS............................................................................................................ 16
FIGURE 8: CONTROLS........................................................................................................................ 17
FIGURE 9: FITTING/REMOVING SFP CONNECTORS ................................................................... 18
FIGURE 10: BASIC CONNECTIONS.................................................................................................. 19
FIGURE 11: SINGLE SIGNATURE PD............................................................................................... 20
FIGURE 12: DUAL SIGNATURE PD.................................................................................................. 20
FIGURE 13: CLI PORT SETTINGS ..................................................................................................... 21
FIGURE 14: CLI “?” COMMAND........................................................................................................ 22
FIGURE 15: CLI – VERSION CHECK ................................................................................................ 23
FIGURE 16: CLI – POE DUMP ............................................................................................................ 23
FIGURE 17: CLI – IP CONFIGURATION ........................................................................................... 24
FIGURE 18: CLI – DEFAULT SETTING............................................................................................. 24
TABLE 1: PRODUCTS AND OPTIONS................................................................................................ 7
TABLE 2: TECHNICAL SPECIFICATIONS ......................................................................................... 8
TABLE 3: POE CONFIGURABLE PARAMETERS VIA WEB-GUI ................................................. 10
TABLE 4: POWER CONNECTION ..................................................................................................... 14
TABLE 5: LED FUNCTION ................................................................................................................. 16
TABLE 6: 3-WAY DIP SWITCH SETTINGS...................................................................................... 17
TABLE 7: POE MODE.......................................................................................................................... 18
TABLE 8: CLI COMMAND LIST ........................................................................................................ 22

OPTICAL SYSTEMS DESIGN
DOC ID: 10119601
OSD2184P OPERATOR MANUAL
PAGE 6
1TECHNICAL SUMMARY
1.1 BRIEF DESCRIPTION
1.1.1 OVERVIEW
The OSD2184P is a 3-port industrial ethernet switch offering Power over Ethernet meeting the latest
IEEE802.3bt PoE specification with continued support for devices requiring IEEE802.3af/at and
HDBase-T (PoH) PoE. Each of the two RJ45 ports is capable of providing 90W of power with a total
power budget of 170W. This allows the latest PoE devices such as IP cameras, Wireless Access Points,
microwave links and VOIP phones to be easily connected to your network. With a compact design the
OSD2184P can easily be mounted inside a network enclosure or a Smart Pole using the DIN rail or
wall mounting brackets provided. Additionally, the OSD2184PW version can be powered from a
12VDC to 57VDC supply. A rugged IP30 casing, fan-less design and wide operating temperature range
from -40 to +75ºC make this product ideally suited for use in a wide range of harsh industrial
environments.
1.1.2 APPLICATIONS
▲ Any network utilising a mix of copper
and fiber
▲ Networks using Power over Ethernet
devices such as cameras, intercoms,
access control, telephones, etc.
▲ Industrial IP communications
▲ Gigabit Ethernet networks
1.1.3 FEATURES AND BENEFITS
▲ Complies with
IEEE802.3i/802.3u/802.3ab
10/100/1000Base-T, IEEE802.3u 100
Base-Fx, IEEE802.3z 1000Base-
Lx/Sx standards
▲ Has two fixed 10/100/1000Base-T
copper ports and one
100Mbps/1000Mbps SFP port
▲ Auto MDI/MDIX on copper ports
(support both straight through and
crossover cables)
▲ Can be used with either singlemode or
multimode fiber over a variety of link
budgets
▲ Complies with the IEEE802.3af/at/bt
and HDBaseT PoH standards
▲ Provides up to 90W to each RJ45
port, up to 170W in total
▲ User selectable PoE mode setup
▲ Web browser based Graphical User
Interface (GUI)
▲ Available for operation over 1 or 2
fibers
▲ Powered by non-critical 48 to 57VDC
supplies for OSD2184P or 12 to
57VDC for OSD2184PW (voltage
booster version)
▲ Operates over the temperature range
of -40 to +75°C.
▲ PoE mode setting from GUI or Push
Button
▲ Remote PoE on/off control and status
monitoring
▲ Supports 10KB jumbo frames.
▲ SFP module sold separately.
▲ DIN rail or surface mounting.

OPTICAL SYSTEMS DESIGN
DOC ID: 10119601
OSD2184P OPERATOR MANUAL
PAGE 7
1.2 TYPICAL CONFIGURATION
Figure 1 below indicates the typical set-up for an OSD2184P system.
FIGURE 1: OSD2184P TYPICAL CONFIGURATIONS
1.3 PRODUCTS AND OPTIONS
There are two options available for the OSD2184P as identified in Table 1 below. This must be
specified at time of sale.
TABLE 1: PRODUCTS AND OPTIONS
ITEM DESCRIPTION
OSD2184P Standard version, input voltage range 50 – 57VDC
OSD2184PW OSD2184P with integrated voltage booster, supporting wide input voltage
range 12 – 57VDC
SFP Module See OSD SFP datasheet #1021000XX

OPTICAL SYSTEMS DESIGN
DOC ID: 10119601
OSD2184P OPERATOR MANUAL
PAGE 8
1.4 TECHNICAL SPECIFICATIONS
TABLE 2: TECHNICAL SPECIFICATIONS
SPECIFICATION PERFORMANCE
Electrical
Electrical Data Interface IEEE802.3i/802.3u/802.3ab 10/100/1000Base-T Ethernet
Electrical Data Rate 10, 100, 1000Mbps, auto negotiation, auto MDI/MDIX
Optical Data Interface IEEE802.3z 1000Base-Lx/Sx or IEEE802.3u 100Base-Fx
Optical Data Rate 100Mbps or 1000Mbps (DIP Switch control)
Operating Mode Half or full duplex for 10/100, Full duplex only for 1000Mbps
Electrical Data Connector RJ45 x 2
Supported PoE Modes IEEE802.3af/at, IEEE802.3bt HDBaseT PoH (user selectable via pushbutton)
More PoE modes are selectable via Web-GUI
PoE Pinout
2 pair output mode – Alternative A (pins 1/2 positive, 3/6 negative)
4 pair output mode – Alternative A & B
(pins 1/2 positive/ 3/6 negative & 4/5 positive, 7/8 negative)
OSD2184P PoE Power Input Voltage: +46V
DC
to +57V
DC
@ 8W + PoE output power for PD devices
Output PoE Voltage: Vin – Vdrop
OSD2184PW PoE Power Input Voltage: +12V
DC
to +57V
DC
@ 15W + PoE output power for PD devices
Output PoE Voltage: 56 to 57V - Vdrop
Output PoE V
drop
per port PoE voltage drop per port <0.5V @30W, <1V @60W, <1.5V @ 90W
Console Port Mini USB
Management
Standard Interface Web browser based Graphical User Interface (Web-GUI)
Command Line Interface (CLI)
DIP Switch Controls
1. Software Program
2. 100 or 1000Mbps on the fiber port
3. PoE enable/disable
Push Button PoE mode selection
Optical
Optical Port Connector SFP (LC connectors for 2-fiber operation and SC for 1-fiber operation)
SFP Options Short haul, long haul, single fiber operation, etc
Please consult OSD datasheet #1021000XX or contact OSD
Physical
Operating Temperature -40°C to +75°C
Relative Humidity 0 to 95% non-condensing
Power Connector 2 Way 3.5mm Terminal Block
Indicators
2x Copper Link/Activity on RJ45
2x Copper Speed on RJ45
2x PoE On/Off
4x PoE Mode
1x Power On/Off
1x SFP Link/Speed on SFP
Dimensions (mm) 90W x 88D x 49H
Weight 0.4kg
1022184P04

OPTICAL SYSTEMS DESIGN
DOC ID: 10119601
OSD2184P OPERATOR MANUAL
PAGE 9
PoE Output Power Budget (Total Power of Two Copper Ports)

OPTICAL SYSTEMS DESIGN
DOC ID: 10119601
OSD2184P OPERATOR MANUAL
PAGE 10
TABLE 3: POE CONFIGURABLE PARAMETERS VIA WEB-GUI
Operating Mode Legacy detection
options
Pair number
options Maximum Power options
BT Enable, Disable 2 15W, 30W
4 15W, 30W, 60W, 90W
PoH Disable 2 45W
4 90W
Pre-BT Enable, Disable 2 30W
4 60W
Mode 4P CDP Enable 2 30W
4 60W
BT Special Enable 2 45W
BT Class0=Class4 Enable 2 30W
4 60W, 90W
2P 3Finger Enable 2 30W
4P 4Finger Enable 4 60W
BT with PoH Enable 2 45W
4 90W
BT PoH Like on all
Class Enable 2 45W
4 90W
BT Special Class 4 Enable 2 30W
4 60W

OPTICAL SYSTEMS DESIGN
DOC ID: 10119601
OSD2184P OPERATOR MANUAL
PAGE 11
1.5 FRONT AND REAR PANELS
The front panel consists of one fixed copper port for 10/100/1000Base-T, one SFP port and a 2-way
terminal block power connector while the rear panel has one fixed copper port for 10/100/1000Base-T,
a 3-way DIP switch and a USB port. The SFP device is sold separately giving the user choice to use
either one or two fiber communications with various optical power outputs depending on the distance
required. Each section will be described further throughout this manual.
Front Panel
Rear Panel
FIGURE 2: FRONT AND REAR PANELS
Fixed RJ45 Copper Port 1
SFP Port 2
Power Input
3-way DIP-
Switch
Fixed RJ45 Copper Port 3
USB port
PoE Mode Push Button
Erase/Restore Push Button

OPTICAL SYSTEMS DESIGN
DOC ID: 10119601
OSD2184P OPERATOR MANUAL
PAGE 12
2INSTALLATION AND OPERATION
2.1 INTRODUCTION
This section outlines the methods required to install and operate the OSD2184P successfully. It should
be studied carefully if damage to the equipment or poor results are to be avoided.
This equipment has been fully tested prior to dispatch and is ready for immediate operation. However it
is advisable to check for external transportation damage before operation. If damage is evident, return
the unit with the packaging to your supplier immediately.
2.2 INSTALLATION
2.2.1 WARNING AND PRECAUTIONS
▲ ELECTROMAGNETIC COMPATIBILITY
WARNING: This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
▲ OPTICAL OUTPUT OPERATION
WARNING: Laser Safety: Class 1 Laser Product per IEC/EN 60825-1:2014 standard.
Class 1
The OSD2184P is a Class 1 laser product.
PRECAUTIONS
▲ All service personnel should be provided training as to the hazards of direct viewing of laser
radiation and of the precautionary measures during servicing of equipment
▲ Areas where laser products are installed should be restricted in access to trained service
personnel only and appropriate warning signs posted in the work area.
▲ All laser apertures should be covered by protective covers when not connected to optical
fibers. Never leave outputs uncovered.
▲ Laser equipment should be positioned above or below eye level where possible. Apertures
should be positioned away from personnel.
▲ Protective eyewear should be worn in the vicinity of laser equipment.

OPTICAL SYSTEMS DESIGN
DOC ID: 10119601
OSD2184P OPERATOR MANUAL
PAGE 13
2.2.2 OSD2184P DRAWINGS AND DIMENSIONS
The standard OSD2184P is designed to be mounted on an even surface and to be secured by means of
M4 or smaller screws. All dimensions are in mm. The unit also can be mounted on a standard DIN rail
with the OSD2184P DIN Rail bracket (supplied with 4 screws).
FIGURE 3: DIMENSIONS
FIGURE 4: DIN RAIL MOUNTING
Rear view
Supplied DIN
clip + 4x screws
Rear view with
DIN fitted

OPTICAL SYSTEMS DESIGN
DOC ID: 10119601
OSD2184P OPERATOR MANUAL
PAGE 14
2.2.3 POWER SUPPLY CONNECTIONS
IMPORTANT! There are two options available for the OSD2184P: The OSD2184P and OSD2184PW.
The Table below (Table 4) indicates the power requirements for each. They both require external DC
power which is connected via the 2-way terminal block located on the front panel as shown in Figure 5.
CAUTION
It is highly recommended to wait about 30 seconds before reconnecting the PD
after the PD has been disconnected from the unit. This will prevent a high inrush
current being applied to the unit. Although the OSD2184P/PW has a high inrush
current tolerance (400mA for 50 to 75ms as per the IEEE802.3at standard), inrush
currents higher than 1.5A may damage the device.
TABLE 4: POWER CONNECTION
OSD Version External Power Pin
Specification
OSD2184P + +46V
DC
to +57V
DC
@ 8W
OSD2184PW + +12V
DC
to +57V
DC
@ 12W
-
0V
Chassis Ground connection
point
FIGURE 5: POWER SUPPLY CONNECTIONS
-
+
Front Panel
Rear Panel
!

OPTICAL SYSTEMS DESIGN
DOC ID: 10119601
OSD2184P OPERATOR MANUAL
PAGE 15
2.2.4 LOCATION
As with any electrical device, the OSD2184P should be placed where the unit will not be subjected to
extreme temperatures, humidity, or electromagnetic interference. Specifically, the site selected should
meet the following requirements:
•The ambient temperature should be between -40°C to 75°C (-72°F
to 167°F).
•The relative humidity should be less than 95 percent, non-condensing.
•Surrounding electrical devices should not exceed the electromagnetic field (RFC) standards.
•Make sure that the switch receives adequate ventilation. Do not block or obstruct the
ventilation holes on any side of the switch.
2.2.5 FIXED RJ45 COPPER PORT PIN ASSIGNMENTS
The OSD2184P/PW complies with IEEE802.3af/at and IEEE802.3bt HDBaseT standards, and is
capable of supplying up to 90W of PoE per RJ45 port. The OSD2184P supports Alternative A & B
(pins 1/2, 3/6 & 4/5, 7/8). Four pair output mode transmits power over all 8 pins. Bidirectional data as
well as power terminate on all 8 pins. Both or either ports can optionally support dual signature PD.
Figure 6 shows the pin configuration for the fixed RJ45 copper port.
FIGURE 6: FIXED RJ45 ETHERNET CONNECTORS
1: Bidirectional Data A+, DC+
2: Bidirectional Data A-, DC+
3: Bidirectional Data B+, DC-
4: Bidirectional Data C+, DC+
5: Bidirectional Data C-, DC+
6: Bidirectional Data B-, DC-
7: Bidirectional Data D+, DC-
8: Bidirectional Data D-, DC-
LINK/ACT SPD
8 7 6 5 4 3 2 1
Fixed Copper Port

OPTICAL SYSTEMS DESIGN
DOC ID: 10119601
OSD2184P OPERATOR MANUAL
PAGE 16
2.2.6 LED INDICATORS
FIGURE 7: LED INDICATORS
TABLE 5: LED FUNCTION
No
FUNCTION
Indicator On LED Colour Off Blinking
PoE PoE Enable Green
(1)
No PoE -
LNK/ACT Copper Link Activity Amber No Copper Link Activity
(2)
SPD Copper
Speed 1Gbps Green 10/100Mbps
-
LNK SPD Fiber
Speed
100Mbps Amber
No Optical Link -
1Gbps Green
PWR Power On Green Power Off -
PoE Mode See Table 7 Green See Table 7 -
Notes:
(1)
When PoE LED is on it indicates that the unit is supplying power to the PSE
(2)
Activity indicates traffic for copper port








OPTICAL SYSTEMS DESIGN
DOC ID: 10119601
OSD2184P OPERATOR MANUAL
PAGE 17
2.2.7 CONTROLS
The OSD2184P/PW has a number of control functions: a 3-Way DIP Switch, Erase/Restore push
button and a PoE Mode push button.
FIGURE 8: CONTROLS
3-Way DIP Switch
THE 3-WAY DIP SWITCH IS USED TO CONTROL A NUMBER OF FUNCTIONS.
Figure 8 outlines the function of each switch. For correct operation, set the required switch settings
before powering the unit.
TABLE 6: 3-WAY DIP SWITCH SETTINGS
SWITCH
NUMBER DESCRIPTION SWITCH POSITION FUNCTION
1 Function OFF User Mode*
ON Programming Mode
2 Optical Port Speed OFF 1000BASE-X*
ON 100BASE-X
3 CTRL OFF PoE Disabled
ON PoE Enabled*
* Default settings .
ERASE/RESTORE Push Button
The ERASE/RESTORE push button erases most recent IP configuration settings and resets the unit to
Factory Default Setting
•Ensure DIP switch 1 is in “Default” mode (OFF position) and the unit is off (not powered)
when performing reset.
•Press and hold the Reset button for 10 seconds and power up the unit.
•Wait for unit to restart.
•The factory default setting is now restored. The IP address is set to 192.168.0.99.
ON Position
OFF Position
1 2 3
Function
Optical Port Speed
Control
PoE Mode
Erase Restore

OPTICAL SYSTEMS DESIGN
DOC ID: 10119601
OSD2184P OPERATOR MANUAL
PAGE 18
PoE Mode Push Button
The PoE Mode push button is used to control the PoE settings. Pressing the push button will cycle
through the different modes as set out in the table below.
TABLE 7: POE MODE
LED
NUMBER DESCRIPTION MODE FUNCTION
1 BT Mode 4 Pair power output, 90W Max, High Inrush
Current Mode off
2 PoH Mode 4 Pair power output, 90W Max, High Inrush
Current Mode off
3 BT Mode 2 Pair power output, 30W Max, High Inrush
Current Mode off
4 Custom
Mode
Set by the GUI settings. If there are no
customized settings this mode will be skipped.
2.2.8 FITTING SFP CONNECTORS
Care should be taken when inserting/removing the SFP connectors from the SFP port as SFP modules
are Electrostatic (ES) sensitive and Electrostatic Discharge (ESD) precautions should be taken when
installing. Ensure that the SFP is fully engaged and latched into position.
Inserting SFP – Ensure that the SFP lever is in the locked position and insert into appropriate SFP
port. Gently push the SFP until it locks into place. Remove plastic/rubber dust cap and fit appropriate
fiber cable.
Removing SFP – Remove fiber connector. Pull the SFP lever down to unlock SFP from housing.
Using the lever, gently pull the SFP out.
Fiber SFP
FIGURE 9: FITTING/REMOVING SFP CONNECTORS
Inserting
SFP
Removing
SFP
1
2

OPTICAL SYSTEMS DESIGN
DOC ID: 10119601
OSD2184P OPERATOR MANUAL
PAGE 19
2.2.9 BASIC CONNECTIONS
Figure 10 shows basic user connections to the OSD2184P/PW.
FIGURE 10: BASIC CONNECTIONS
Ethernet cable
LC Fiber cable SFP
Power
Chassis Ground
Ethernet cable

OPTICAL SYSTEMS DESIGN
DOC ID: 10119601
OSD2184P OPERATOR MANUAL
PAGE 20
2.3 SINGLE/DUAL SIGNATURE PD OPERATION
The OSD2184P supports single, dual or either single/dual signature PD by automatically detecting the
user PD signature.
2.3.1 SINGLE SIGNATURE PD
A “single signature PD” shares the same detection signature, classification signature, and maintains
power signature between both pair sets.
FIGURE 11: SINGLE SIGNATURE PD
2.3.2 DUAL SIGNATURE PD
A “dual signature PD” has independent detection signatures, classification signatures, and maintains
power signatures on each pair set. It enables the load to work with two pair PSEs eg. A surveillance
camera built with dual signature PD can have one pair connected to the camera and the other pair to a
fan or heater. Note that dual signature PDs require two parallel PD interfaces, one for each pair set,
where the power from the two PSEs are summed after each PD interface ie Camera (25W) + fan (10W)
= 35W from one port.
FIGURE 12: DUAL SIGNATURE PD
