Optical Systems Design OSD2254P Series User manual

OPERATOR MANUAL
OSD2254P SERIES
6-PORT REDUNDANT RING
GIGABIT ETHERNET SWITCH WITH
PoE++ SOURCE

OPTICAL SYSTEMS DESIGN
DOC ID: 10115206
OSD2254P OPERATOR MANUAL
PAGE 3
INDEX 1
1 TECHNICAL SUMMARY........................................................................................................ 5
1.1 BRIEF DESCRIPTION ............................................................................................................ 5
1.1.1 OVERVIEW............................................................................................................................................. 5
1.1.2 APPLICATIONS...................................................................................................................................... 6
1.1.3 FEATURES AND BENEFITS................................................................................................................. 6
1.2 TECHNICAL SPECIFICATIONS ........................................................................................... 7
1.3 OSD2254P PORT ALLOCATION........................................................................................... 8
2 INSTALLATION AND OPERATION..................................................................................... 9
2.1 INTRODUCTION .................................................................................................................... 9
2.2 INSTALLATION ..................................................................................................................... 9
2.2.1 WARNING AND PRECAUTIONS......................................................................................................... 9
2.2.2 OSD2254P DRAWINGS AND DIMENSIONS .................................................................................... 10
2.2.3 LOCATION ........................................................................................................................................... 11
2.2.4 POWER SUPPLY CONNECTIONS ..................................................................................................... 11
2.2.5 OSD2254P ALARM CONNECTION.................................................................................................... 12
2.2.6 USB CONNECTOR............................................................................................................................... 13
2.2.7 LED INDICATORS ............................................................................................................................... 15
2.2.8 CONTROLS........................................................................................................................................... 16
2.2.9 FITTING SFP CONNECTORS ............................................................................................................. 17
2.3 OSD2254P OPERATION....................................................................................................... 18
2.3.1 CONNECTIONS.................................................................................................................................... 18
2.4 T YPE -A USB P ORT .................................................................................................................. 20
2.5 COMMAND LINE INTERFACE .......................................................................................... 21
2.5.1 TERMINAL EMULATION SETUP...................................................................................................... 21
2.5.2 COMMAND LINE FUNCTIONS ......................................................................................................... 22
3 MAINTENANCE...................................................................................................................... 27
3.1 INTRODUCTION .................................................................................................................. 27
3.2 EXTERNAL INSPECTION ................................................................................................... 27
3.3 ROUTINE MAINTENANCE................................................................................................. 27
4 WARRANTY ............................................................................................................................ 28
4.1 WARRANTY PERIOD.......................................................................................................... 28
4.2 REPAIRS................................................................................................................................ 28
4.2.1 WARRANTY REPAIRS........................................................................................................................ 28
4.2.2 OUT-OF-WARRANTY REPAIRS........................................................................................................ 28
4.2.3 SITE REPAIRS ...................................................................................................................................... 28
4.2.4 EXCLUSIONS ....................................................................................................................................... 28
FIGURE 1: OSD2254P TYPICAL RING CONFIGURATION .............................................................. 5
FIGURE 2: OSD2254P PORT ALLOCATION....................................................................................... 8
FIGURE 3: OSD2254P MOUNTING DIMENSIONS .......................................................................... 10
FIGURE 4: OSD2254P POWER SUPPLY CONNECTIONS............................................................... 11
FIGURE 5: ALARM OUTPUTS ........................................................................................................... 12
FIGURE 6: CONTACT CLOSURE OUTPUT ...................................................................................... 12
FIGURE 7: USB TYPE B CLI PORT.................................................................................................... 13
FIGURE 8: WIN XP INSTALLATION................................................................................................. 14
FIGURE 9: PORT/LED ......................................................................................................................... 15
FIGURE 10: OSD2254P CONTROLS .................................................................................................. 16
FIGURE 11: OSD2254P 8-WAY DIP SWITCH ................................................................................... 16
FIGURE 12: FITTING/REMOVING SFP CONNECTORS ................................................................. 17
FIGURE 13: REDUNDANT RING CONFIGURATION ..................................................................... 18
FIGURE 14: REDUNDANT RING CONNECTION ............................................................................ 19
FIGURE 15: BUS CONNECTION........................................................................................................ 19
FIGURE 16: OSD2254P MICRO USB CONNECTOR ........................................................................ 20
FIGURE 17: SERIAL PORT SETTINGS.............................................................................................. 21

OPTICAL SYSTEMS DESIGN
DOC ID: 10115206
OSD2254P OPERATOR MANUAL
PAGE 4
FIGURE 18: TOPOLOGY CHECK....................................................................................................... 23
FIGURE 19: TOPOLOGY CHECK....................................................................................................... 24
FIGURE 20: LOCAL NODE CHECK................................................................................................... 25
FIGURE 21: VERSION CHECK........................................................................................................... 26
TABLE 1: TECHNICAL SPECIFICATIONS ......................................................................................... 7
TABLE 2: DC OR AC POWER CONNECTION.................................................................................. 11
TABLE 3: ALARM CONNECTIONS................................................................................................... 12
TABLE 4: LED FUNCTION ................................................................................................................. 15
TABLE 5: OSD2254P 8-WAY DIP SWITCH SETTINGS................................................................... 16
TABLE 6: CURRENT LIMITING SWITCH SETTINGS .................................................................... 17
TABLE 7: TERMINAL COMMAND LINES ....................................................................................... 22

OPTICAL SYSTEMS DESIGN
DOC ID: 10115206
OSD2254P OPERATOR MANUAL
PAGE 5
Note: Can be OSD2254,
OSD2251 or OSD2244
1TECHNICAL SUMMARY
1.1 BRIEF DESCRIPTION
1.1.1 OVERVIEW
The OSD2254P is a 6-port industrial switch with redundant ring Gigabit Ethernet and PoE++ Source
providing simple network management with real-time monitoring. It has four 10/100/1000Base-T RJ45
copper ports and two SFP ports for ring/bus configuration.
The OSD2254P incorporates redundant ring technology providing maximum reliability on critical
networks. In the event of device or fiber failure the data path will automatically switch to a secondary
path in less than 2ms per hop to maintain ring network integrity.
The OSD2254P has Power over Ethernet++ (PoE++) function and operates as a Power Source
Equipment (PSE). The OSD2254P PoE++ can provide up to 60W to each RJ45 port to Powered
Devices (PD). The unit will operate on either singlemode or multimode fiber. Operation over a network
of hundreds of kilometers is possible by use of the appropriate optical devices. It normally requires two
fibers but is optionally available for one fiber operation per port.
A major benefit of the OSD2254P is its reliable and consistent performance over the -20°C to +75°C
temperature range that allows it to be used in uncontrolled environments such as roadside cabinets,
mine sites and factories.
FIGURE 1: OSD2254P TYPICAL RING CONFIGURATION

OPTICAL SYSTEMS DESIGN
DOC ID: 10115206
OSD2254P OPERATOR MANUAL
PAGE 6
1.1.2 APPLICATIONS
▲ Any network utilising a mix of copper
and fiber
▲ Industrial IP communications
▲ Self-healing Gigabit Ethernet
backbone networks
▲ Networks using Power over Ethernet
devices such as cameras, intercoms,
access control, telephones, etc.
1.1.3 FEATURES AND BENEFITS
▲ Complies with IEEE802.3i/802.3u/
802.3ab 10/100/1000Base-T,
IEEE802.3u, 100Base-Fx,
IEEE802.3z 1000Base-Lx/Sx
standards
▲ Has a total of six ports: four fixed
copper ports for 10/100/1000Base-T
and two SFP ports for the fiber ring
▲ A network diameter of hundreds of
kilometers is practical
▲ Ring reconfiguration in the case of
cable or switch failures takes less than
two milliseconds per hop
▲ MDI/MDIX Crossover: no need for
crossover cables
▲ Supports IEEE802.3af/at Alternative
B cable wiring
▲ Can be used with either singlemode
or multimode fiber over a variety of
link budgets
▲ Available for operation over 1 or 2
fibers
▲ Auto-Negotiation for half or full
duplex operation
▲ Complies with the IEEE802.3af/at
standard including compliant powered
device (PD) signature detection and
classification
▲ Provides up to 60W to each port
▲ Supports 10KB jumbo frames
▲ Powered by either one or two non-
critical 46 to 57V
DC
supplies
▲ Operates over the temperature range
of -20°C to +75°C
▲ SFP module sold separately
▲ Compatible with the OSD2244 or
OSD2251 Gigabit Ethernet Switches.
▲ OSDview Lite Network Management
System
▲ DIN rail Mounting
▲ Available for operation in Ring or
point-to-point configuration

OPTICAL SYSTEMS DESIGN
DOC ID: 10115206
OSD2254P OPERATOR MANUAL
PAGE 7
1.2 TECHNICAL SPECIFICATIONS
TABLE 1: TECHNICAL SPECIFICATIONS
SPECIFICATION PERFORMANCE
Electrical Data Interface IEEE802.3i/802.3u/802.3ab/802.3af/802.3at, 10/100/1000Base-T Ethernet
Electrical Data Rate 10, 100, 1000Mbps with energy detect, auto negotiate, auto MDIX
Jumbo Frame Support 10KB
Optical Data Interface IEEE802.3z 1000Base-Lx/Sx or IEEE802.3u 100Base-Fx
Optical Data Rate 100Mbps or 1000Mbps user selectable
Operating Mode
Ring or non-ring user selectable
Half or full duplex for 10/100
Full duplex for 1000
Pause frames for 1000Mbps flow control
Electrical Data Connectors RJ45
Alarms Ring to Bus
High Temperature
Alarm Interface Optoisolated MOSFET rated at 100mA @ 46V maximum
PoE IEEE802.3af, IEEE802.3at and PoE++
Operating Mode Alternative A & B (Pins 1/2, 3/6, 4/5 and 7/8)
Optical Port Connectors SFP
SFP Options Short haul, long haul, single fiber operation, etc.
Please consult OSD DATASHEET #100210000x or contact OSD
Indicators
4x Copper Link
4x Copper Activity
4x PoE Operation on RJ45s
2x SFP Speed/Activity/Link on SFPs
1x Power/temperature Alarm
1x Initialise/Ring/Bus
Dimensions (mm) 43W x 91D x 130H
Weight 0.58kg
Power Requirements 46 to 57V
DC
@ 1.5A maximum (attached powered device dependant)
>52V
DC
recommended for PoE+ or ≥55V
DC
for 60W
Power Connector 4 way 5.08mm terminal block
Alarm Connector 4 way 3.5mm terminal block
Operating Temperature -20°C to +75°C
Relative Humidity 0 to 95% non-condensing
1022254P02

OPTICAL SYSTEMS DESIGN
DOC ID: 10115206
OSD2254P OPERATOR MANUAL
PAGE 8
1.3 OSD2254P PORT ALLOCATION
Front Panel: There are four fixed copper ports for 10/100/1000Base-T and two SFP ports.
Top Panel: The top panel consists of a 4-way 5.08mm terminal block power connector and a 4way
3.5mm terminal block alarm connector.
Bottom Panel: 8-Way DIP switch, Micro USB connector and a Type-B USB connector.
Each section will be described further throughout this manual.
FIGURE 2: OSD2254P PORT ALLOCATION
Front Panel
Top Panel
Bottom Panel
Power Port
Alarm Port
Configuration Port
Micro USB Port
Console Port
Copper Port 1
Copper Port 2
Copper Port 3
Copper Port 4
SFP Port 5
SFP Port 6

OPTICAL SYSTEMS DESIGN
DOC ID: 10115206
OSD2254P OPERATOR MANUAL
PAGE 9
2INSTALLATION AND OPERATION
2.1 INTRODUCTION
This section outlines the methods required to install and operate the OSD2254P successfully. It should
be studied carefully if damage to the equipment or poor results are to be avoided.
This equipment has been fully tested prior to dispatch and is ready for immediate operation. However it
is advisable to check for external transportation damage before operation. If damage is evident, return
the unit with the packaging to your supplier immediately.
2.2 INSTALLATION
2.2.1 WARNING AND PRECAUTIONS
▲ ELECTROMAGNETIC COMPATIBILITY
WARNING: This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
▲ OPTICAL OUTPUT OPERATION
WARNING: Laser Safety: Class 1 Laser Product per IEC/EN 60825-1:20011 standard.
Class 1
The OSD2254P is a Class 1 laser product.
PRECAUTIONS
▲ All service personnel should be provided training as to the hazards of direct viewing of laser
radiation and of the precautionary measures during servicing of equipment
▲ Areas where laser products are installed should be restricted in access to trained service
personnel only and appropriate warning signs posted in the work area.
▲ All laser apertures should be covered by protective covers when not connected to optical
fibers. Never leave outputs uncovered.
▲ Laser equipment should be positioned above or below eye level where possible. Apertures
should be positioned away from personnel.
▲ Protective eyewear should be worn in the vicinity of laser equipment.

OPTICAL SYSTEMS DESIGN
DOC ID: 10115206
OSD2254P OPERATOR MANUAL
PAGE 10
2.2.2 OSD2254P DRAWINGS AND DIMENSIONS
The OSD2254P is designed to be wall mounted onto a DIN-Rail (35mm top hat) fixture. The unit
dimensions (excluding connectors, SFPs, etc) is shown in Figure 3 below
FIGURE 3: OSD2254P MOUNTING DIMENSIONS
43mm
91mm
130mm

OPTICAL SYSTEMS DESIGN
DOC ID: 10115206
OSD2254P OPERATOR MANUAL
PAGE 11
2.2.3 LOCATION
As with any electrical devices, the OSD2254P should be placed where it will not be subjected to
extreme temperatures, humidity, or electromagnetic interference. Specifically, the site selected should
meet the following requirements:
•The ambient temperature should be between -20°C to 75°C.
•The relative humidity should be less than 95 percent, non-condensing.
•Surrounding electrical devices should not exceed the electromagnetic field (RFC) standards.
•Make sure that the switch receives adequate ventilation. Do not block the ventilation holes on
any side of the switch.
Note: Without proper cooling and control (lowering) of ambient temperature, the components within
the OSD2254P can be subject to increased heat shortening the longevity and reliability. It is thus good
engineering practice to ensure the unit is installed in a well ventilated area.
2.2.4 POWER SUPPLY CONNECTIONS
The OSD2254P requires external power to the Redundant DC Terminal Block Power Connector
located at the top of the unit. Always ensure that the power is off before any installation.
Redundant DC Terminal Block Power Inputs
There are two pairs of power inputs for use with redundant power sources. Only one power input is
required to be connected to run the switch.
Step 1: Connect the DC power to the appropriate power source, connect the plug-able terminal block
on the OSD2254P switch and then turn power on.
Step 2: Disconnect the power if you want to shut down the switch.
TABLE 2: DC OR AC POWER CONNECTION
External Power Pin Specification
Power 1 + 46V
DC
to 57V
DC
@ 1.5A*
Power 1 0V Ground – 0V
Power 2 + 46V
DC
to 57V
DC
@ 1.5A*
Power 2 0V Ground – 0V
Earth Ground Connection
* ≥52V
DC
recommended for PoE+ or ≥55V
DC
for 60W PoE
FIGURE 4: OSD2254P POWER SUPPLY CONNECTIONS

OPTICAL SYSTEMS DESIGN
DOC ID: 10115206
OSD2254P OPERATOR MANUAL
PAGE 12
2.2.5 OSD2254P ALARM CONNECTION
The OSD2254P has two monitoring alarm outputs: 1) Ring to Bus Alarm and 2) Temperature Alarm.
The alarm connections and conditions for alarm outputs are as set out in Table 3. There are four pins on
the 3.5mm terminal block used alarm output. Maximum ratings the OSD2254P relay can drive is
100mA @ 46V
(max)
. Note: Alarm output has no polarity.
TABLE 3: ALARM CONNECTIONS
Alarm
Output Alarm1 Ring /Bus Status Alarm CH2 Temperature
Open Ring Less than 90°C
Closed Bus* Higher than 90°C
*Note: Bus alarm is only triggered after a ring connection is established.
FIGURE 5: ALARM OUTPUTS
FIGURE 6: CONTACT CLOSURE OUTPUT
Alm1
Alm2
OSD2254P

OPTICAL SYSTEMS DESIGN
DOC ID: 10115206
OSD2254P OPERATOR MANUAL
PAGE 13
2.2.6 USB CONNECTOR
The OSD2254P has a USB – Type B connector located on the bottom of the unit that is used for
Command Line Interface (CLI) from the PC to the OSD2254P via the PC’s USB connector. See
section 2.5 for further CLI information.
FIGURE 7: USB TYPE B CLI PORT
To operate and control the OSD2254P using the CLI an OSD2254P driver will be required to be
installed onto the PC being used. The driver can be found on the included CD or on the OSD website.
Please contact OSD sales if the driver cannot be found or installed. For Windows XP, Vista and
Windows 7: CP210x_VCP_Win_XP_S2K3_Vista_7.exe. For Windows 2000:
CP210x_VCP_Win2K.exe
USB Type B - CLI Port

OPTICAL SYSTEMS DESIGN
DOC ID: 10115206
OSD2254P OPERATOR MANUAL
PAGE 14
FIGURE 8: WIN XP INSTALLATION

OPTICAL SYSTEMS DESIGN
DOC ID: 10115206
OSD2254P OPERATOR MANUAL
PAGE 15
2.2.7 LED INDICATORS
FIGURE 9: PORT/LED
TABLE 4: LED FUNCTION
No
Function LED Colour Function
On Blink Off Green Gr/Am Amber

- Activity No Activity 1Gbps - -

Link - No Link - - On

Link Activity No Link 1Gbps - 100Mbps

Power - No Power Power - -

Ring/Bus Initial - Ring - Bus*

Load Detect - No Load LD - -
* Always Amber in non-ring mode

















OPTICAL SYSTEMS DESIGN
DOC ID: 10115206
OSD2254P OPERATOR MANUAL
PAGE 16
2.2.8 CONTROLS
The OSD2254P has an 8-way DIP switch to control a number of functions. Table 5 outlines the
function of each switch.
FIGURE 10: OSD2254P CONTROLS
FIGURE 11: OSD2254P 8-WAY DIP SWITCH
TABLE 5: OSD2254P 8-WAY DIP SWITCH SETTINGS
SWITCH
NUMBER DESCRIPTION FUNCTION SWITCH POSITION
1 Current Limiting See Table 6 for Current Limiting function OFF*
2 Current Limiting See Table 6 for Current Limiting function OFF*
3 Not Used - OFF*
4 Not Used - OFF*
ON
5 Ring/Bus Ring
Non-Ring
OFF*
ON
6 Port 5 Fiber Speed 1000Mbps
100Mbps
OFF*
ON
7 Port 6 Fiber Speed 1000Mbps
100Mbps
OFF*
ON
8 Programming Mode Normal Operation
Programming Mode
OFF*
ON
* Default settings.
ϮPD dependant
Note: The unit requires a power cycle (Off/On) for any switch position change to take effect.
ON
OFF
1 2 3 4 5 6 7 8
8-Way DIP Switch

OPTICAL SYSTEMS DESIGN
DOC ID: 10115206
OSD2254P OPERATOR MANUAL
PAGE 17
TABLE 6: CURRENT LIMITING SWITCH SETTINGS
Some PD devices are non-standard and require current limiting to function and not damage equipment.
It is advised to check PD device current requirements and set the current limits according to Table 6.
2.2.9 FITTING SFP CONNECTORS
Care should be taken when inserting/removing the SFP connectors from SFP port 3 and 4as SFP
modules are Electrostatic (ES) sensitive and Electrostatic Discharge (ESD) precautions should be taken
when installing. Ensure that the SFP is fully engaged and latched into position.
Inserting SFP – Ensure that the SFP lever is in the locked position and insert into appropriate SFP
port. Gently push the SFP until it locks into place. Remove plastic/rubber dust cap and fit fiber cable or
RJ45 plug.
Removing SFP – Remove fiber connector or RJ45 plug. Pull the SFP lever down to unlock SFP from
housing. Using the lever, gently pull the SFP out.
Fiber SFP
Copper SFP
FIGURE 12: FITTING/REMOVING SFP CONNECTORS
CURRENT LIMIT SW1 SW2
Manual Current Limit Disabled OFF OFF
425mA OFF ON
850mA ON OFF
1275mA (60W) ON ON
1750mA (90W) ON ON
Inserting
SFP
Removing
SFP
1
2
Inserting
SFP
Removing
SFP
1
2

OPTICAL SYSTEMS DESIGN
DOC ID: 10115206
OSD2254P OPERATOR MANUAL
PAGE 18
2.3 OSD2254P OPERATION
When using the OSD2254P for the first time, check that the unit is in good condition with no visible
damage.
Upon power up check that the indicators illuminate accordingly on power up (see Table 4).
2.3.1 CONNECTIONS
For RJ45 connection use Category 5 (CAT5) or higher. Length should be no more than 100 meters.
For singlemode fiber connections, fiber used must be 9/125µm singlemode fiber.
For multimode fiber connections, fiber used must be 50/125µm or 62/125µm multimode fiber.
Plug in the appropriate connectors for system configuration;
–RJ45 cable to fixed copper ports (port 1 and 2) and copper SFP modules
–LC or SC fiber cable to fiber SFP modules.
Redundant Ring Operation
The OSD2254P connected in a redundant ring topology providing maximum reliability on critical
networks. In the event of device or fiber failure the data path will automatically switch to a secondary
path in less than 2ms per node to maintain ring network integrity.
FIGURE 13: REDUNDANT RING CONFIGURATION

OPTICAL SYSTEMS DESIGN
DOC ID: 10115206
OSD2254P OPERATOR MANUAL
PAGE 19
To connect the OSD2254P in a redundant ring configuration ports 5 and 6 must be used together with
fiber SFPs. The non-ring ports (ports 1,2,3,4) should be used to connect to your Ethernet devices (eg.
Cameras, PLCs, computers, etc.)
Figure 14 shows the connection method. Typically the SFP used would be a fiber SFP with duplex LC
connectors. The dashed line indicates the closed loop, but more OSD2254P units can be connected to
the ring as required using this topology. Ensure that the switch settings for port 5 and 6 are set to
1000Mbps (1Gbps) – see Table 5.
FIGURE 14: REDUNDANT RING CONNECTION
Bus Operation
To connect the OSD2254P in a bus configuration ports 5 and 6 must be used together with fiber SFPs.
The remaining ports (ports 1,2,3,4) should be used to connect to your Ethernet devices (eg. Cameras,
PLCs, computers, etc.)
FIGURE 15: BUS CONNECTION
Connect more OSD2254P units as required using this topology
Connect more OSD2254P units as required using this topology

OPTICAL SYSTEMS DESIGN
DOC ID: 10115206
OSD2254P OPERATOR MANUAL
PAGE 20
2.4 TYPE-A USB PORT
The Micro USB Port is used for uploading firmware updates. All OSD2254P units will be shipped with
the latest firmware already installed. This port has no function for end user.
FIGURE 16: OSD2254P MICRO USB CONNECTOR
Micro USB Port
