Optoma W501 User manual

Unsurpassed performance and
reliability
Outstanding brightness and color
accuracy for the most impactful
presentations
Vertical lens shift for installation
exibility
Future proof your installation with
comprehensive connectivity
CONNECTIVITY (May require optional accessories)
DELIVER POWERFUL PRESENTATIONS
DIGITAL
CAMERAS
CAMCORDERS
GAME
CONSOLES
TABLETS
SMART
PHONES
COMPUTERS SET TOP BOXES
3D BLU-RAY/DVD PLAYERS
Roku®Apple TV®
LARGE VENUE PROJECTOR
W501
HD
The Optoma W501 was designed to
deliver unsurpassed performance and
reliability to meet your installation needs.
Its powerful 5000 lumens output and
impressive 15,000:1 contrast ratio deliver
remarkably bright presentations with sharp
text and color-rich graphics.
To ensure it will perform to your current
and future needs, the W501 features
a comprehensive I/O panel and the
most advanced feature sets in its class.
Outstanding features on this remarkable
product include HDMI and DVI for digital
connectivity, over-the-network presentation
capability, wireless presentation capability
via optional USB dongle, vertical lens
shift and discrete audio inputs including
microphone input for maximum installation
convenience.

LARGE VENUE PROJECTOR — W501
OPTICAL/TECHNICAL SPECIFICATIONS
Display Technology Single 0.65" DC3 DMD
DLP®Technology by Texas Instruments™
Native Resolution WXGA (1280 x 800)
Maximum Resolution VGA: UXGA (1600 x 1200)
HDMI: HD (1920 x 1080)
Brightness 5000 lumens
Contrast Ratio 15,000:1 (full on/full off)
Displayable Colors 1.07 Billion
Lamp Life and Type* 4000/3000/2500 Hours
(ECO+/ECO/normal) 280W
Projection Method Front, rear, ceiling mount, table top
Keystone Correction Auto Keystone, ±40° Vertical
Uniformity > 85%
Aspect Ratio 16:10 Native, 16:9 and 4:3 compatible
Throw Ratio (Distance/Width) 1.45–2.17
Projection Distance 3.3ʹ–32.8ʹ(1–10m)
Image Size (Diagonal) 23.4ʺ–300ʺ(0.6–7.6m)
Projection Lens F=2.42 ~ 2.98, f=20.77 ~ 31.13 mm,
1.5x manual zoom and focus
Lens Shift Vertical 112% ~ 128% offset
Audio Two 15-Watt speakers
Noise Level (STD/Bright) 27dB
Remote Control IR remote mouse with laser
Operating Temperature 41–113°F (5–45°C), 85% max humidity
Power Supply AC input 100–240V, 50–60Hz,
auto-switching
Power Consumption Max 355W (Normal), Min 279W (Eco+),
<0.5W (standby-ECO)
COMPATIBILITY SPECIFICATIONS
Computer Compatibility UXGA, WXGA, SXGA+, SXGA, XGA, SVGA,
VGA resized, VESA, PC and Macintosh
compatible
Video Input Compatibility NTSC, PAL, SECAM, SDTV (480i),
EDTV (480p), HDTV (720p, 1080i/p)
3D Compatibility†Top and bottom, side by side, frame packing,
HQFS (See user manual for details). 3D
glasses are needed and sold separately.
Vertical Scan Rate 24–85Hz, 120Hz, 144Hz
Horizontal Scan Rate 15.3–91.1KHz
User Controls Complete on-screen menu, adjustment in
27 languages
I/O Connection Ports HDMI v1.4, DVI-D, two VGA-in, VGA-out,
S-video, composite video, two stereo audio-in,
stereo RCA audio-in, mic-in, stereo audio-out,
RJ45, RS-232C, Two USB-A, Two USB-B,
12V trigger
Loop Through (Audio, VGA) Monitor: D-Sub 15 pin VGA output
Audio-out: Stereo 3.5 mm mini-jack
(functional in both normal and standby modes)
PHYSICAL SPECIFICATIONS
Security Kensington®Lock Port, security bar
and keypad lock
Weight 9.9 lb (4.5 kg)
Dimensions (W x H x D) 15.2" x 6" x 11" (386 x 152 x 279 mm)
www.OptomaUSA.com
Copyright © 2013 Optoma Technology, Inc. DLP® and the DLP logo are registered trademarks of
TexasInstruments.Allothertrademarksarethepropertyoftheirrespectiveowners.Allspecications
subject to change at any time.
Warranty
3-Year Optoma Express Service, 1-Year on Lamp
What Comes in the Box
AC power cord, VGA to VGA cable, remote control, batteries for remote,
multilingual CD-ROM user’s manual, quick start card and warranty card
Optional Accessories
HDMI cable, ceiling mount, VGA to component cable, RS-232 cable and
Optoma screens
Accessory Part Numbers
Lamp: BL-FU310A Mount: BM-5001U
Remote: BR-5046L USB adapter: BI-EXTBGN
DLP®Link™3D glasses: BG-ZD301
UPC 796435 41 802 1
RS-232C
VGA1-in/YPbPr
VGA2-in/YPbPr
12V Out
Audio-out
RCA Audio-in Video
Audio-in Mic Kensington
Lock Port
HDMIS-Video USB Display USB-A
VGA-out USB
Mouse DVI-D RJ45
Power
Source
Left
Page Up
Laser
Keystone
Brightness
HDMI
S-Video
ECO+
Freeze
Re-SYNC
Right
Page Down
Volume
Zoom
AV mute
Video
3D
VGA
Menu
Enter
Four Directional
Select Keys for
Mouse Emulation
USB
Mouse On/Off
User Dened Function
†3D content can be viewed with either RF or DLP Link active shutter glasses when projector
is used with a compatible 3D player. RF 3D glasses require the use of the RF 3D emitter.
Please visit www.OptomaUSA.com for more information
*Lamp life is dependent on many factors, including lamp mode, display mode, usage,
environmental conditions and more. Lamp brightness can decrease over time.
