HD73 Home Theater Projector
NDarkChip3™ DLP®technology
N1100 lumens with a 6000:1
contrast ratio (in ImageAI™mode)
NFaroudja DCDi™ image
optimization
NBrilliantColor™ technology
NTrueVivid™ color enhancement
N Wide angle zoom lens with
throw ratio of 1.58-1.90:1
NLight shield design and
ultra-quiet operation
NDual digital HD connectivity
(DVI and HDMI)
HD73 − The Next Level of 720p Excellence
The Optoma HD73 is a native 720p home theater projector that offers
amazing performance and picture quality. Based on Texas Instruments’
DarkChip3 DLP chipset, the HD73 also features the latest color
processing technologies that deliver higher brightness and more vibrant
colors to the projected image. With 1100 lumens and a 6000:1 contrast
ratio (with ImageAI), the Optoma HD73 takes the high-definition home
theater projector to a higher level.
TM
FEATURES

Specificationssubject to change without notice. Copyright ©2007
Optoma Technology, Inc. DLP®andthe DLP logo are registered
trademarks of Texas Instruments.All other names mentioned herein
are property of their respective owners. [Data-HD73-003-052507]
HD73 Home Theater Projector
AVAILABLE AT
Dual universal
joints give precise
and flexible mounting
options
13.56inches
9.67 inches
PROJECTION DISTANCE/IMAGE SIZE
Projection Distance
(feet)
6
8
10
12
16
14
18
52.28
69.71
87.14
104.57
139.42
122.00
156.85
43.48
57.97
72.46
89.96
115.94
101.45
130.44
Minimum Diagonal
(inches)
Maximum Diagonal
(inches)
Bering™ Ceiling
Mount
SPECIFICATIONS
Single 0.65” DarkChip3™ DLP®Technology by Texas Instruments
1100 Lumens
7 lbs (3.2 kg)
WXGA (1280 x 768)
1080p (1920 x 1080)
13.56” x 3.72” x 9.67” ( 344 x 94 x 246 mm)
6000:1 in ImageAI™ Mode and 4500:1 (Full On/Full Off)
27dB (STD)
220W UHP / 3000 Hours (STD)
Faroudja DCDi™
28” - 304” (0.7 - 7.7 m)
3.9’ - 39’ (1.2 - 11.9 m)
UXGA, SXGA+, WXGA, XGA, SVGA, VGA Compression, VESA
Standards, PC and Macintosh Compatible
NTSC (M, 3.58/4.43 MHz), PAL (B, D, G, H, I, M, N),
SECAM (B, D, G, K, K1, L), HDTV (720p, 1080i/p)
16:10 Widescreen Native with Support for 4:3 and 16:9
F/2.5~2.8, f = 22.25~26.69mm,
1.2x Manual Focus/Digital Zoom
±15° Horizontal and Vertical
1.58 to 1.90:1 (Distance/Width)
43 to 120 Hz
AC Input 100 - 240V, 50-60 Hz
285W ± 10% Full Power, < 13W Standby Power
Operating: 5 - 35°C, 80% Humidity (Max.)
Storage: -20 - 60°C, 80% Humidity (Max.)
10-bit per Channel Color Processing
Front, Rear, Ceiling Mount, Table Top
90%
HDMI, DVI w/HDCP, Component Video, Composite Video (RCA),
S-Video, RS-232, Two IR Receivers, +12V Trigger
One Kensington®Lock Port
Composite Video Cable, S-Video Cable, Remote Control,
Batteries for Remote, Lens Cap, User’s Manual, Quick Start
Guide, Warranty Card and Power Cord
2 Years Optoma Express Replacement Service, 1 Year on Lamp
Ceiling Mount Kit, GrayWolfII™ Series Screens, DVI to DVI Cable,
HDMI to HDMI Cable, Carrying Case and Gold Service Warranty
796435 21 996 3
Display Technology
Brightness(Typical)
Weight
Resolution
Maximum Resolution
Dimensions (W x H x D)
Contrast Ratio
NoiseLevel
Lamp Type / Life
ImageOptimization
ImageSize (Diagonal)
Projection Distance
Computer Compatibility
Video Compatibility
Aspect Ratio
Projection Lens
Keystone Correction
Throw Ratio
Vertical Refresh Rate
Power Supply
Power Consumption
Operating Temperature
Displayable Colors
Projection Method
Uniformity
I/O Connectors
Security
Standard Accessories
Warranty
Optional Accessories
UPC
+12V Trigger
RS-232
S-Video
Component Video
Composite Video
HDMI
DVI w/HDCP
Kensington Lock
BrilliantColor™Technology
With Without
With the new advanced, 10-level
BrilliantColor color-processing system, the
projector delivers higher brightness and
more vibrant scenes while providing truer,
more stunning colors to the picture.
TrueVivid™Image Processing
With Without
With TrueVivid image processing, the
picture quality is enhanced for veritable
video fidelity, including better depth and
adds a deeper 3D look to any image.
Image and color enhancement technologies
Image Artificial Intelligence
auto adjusting light intensity output
Increases clarity in
lighter areas...
But makes dark
areas washed out.
Increases detail
in darker areas...
But makes lighter
areas appear dark.
HIGH LUMENS ALONE
HIGH CONTRAST ALONE
ImageAI™"Image Artificial Intelligence", Optoma's
auto adjusting light intensity output, delivers an amazing
1100 lumens AND 6000:1 contrast ratio!
ONLY ImageAI™GIVES YOU BOTH!
HIGH 1100
LUMENS
for amazing
clarity in light
image areas...
PLUS
HIGH 6000:1
CONTRAST
for details in dark
areas and shadows
