OPUMP LM-B001 User manual

SMART BREATHING TRAINER
POWERED BY
Light&Move
TECH
Model: LM-B001
For more information, please visit: https://theopump.com/
Customer service: [email protected]
4000
3000
2000
1000
3500
2500
1500
500

4000
3000
2000
1000
3500
2500
1500
500
THANK YOU
FOR CHOOSING
2
Register on the Website to Get
Warranty Priorty VIP
Extra 1Year Warranty Customer Service Exclusive Discounts
Package List
Breathing
Trainer
Cotton Swab
×2
Extension
Tube
Mouthpiece
×2
Manual
SMART BREATHING TRAINER
POWERED BY
Light&Move
TECH
Model: LM-B001

Table of content
01 Important Safety Guidelines
02 Specifications
03 Getting to Know Your Smart Breathing Trainer
04 Indicator Light Instructions
05 Using Your Breathing Trainer
08 Care & Maintenance
09 Warranty
01
Important Safety Guidelines
Read all instructions before using the Breathing Trainer.
When using electrical appliance, basic safety precautions should always be
followed, including the following:
· Read all instructions carefully before using this product. Retain this user
manual for future reference.
· The appearance is different from the acutal product, please refer to the
actual product.
Warning:
1. Keep the device and accessories dry. Do not use heating products such as
microwave oven or hair dryer to dry the device and accessories.
2. DO NOT let the device drop, hit or be be stricken heavily.
3. Turn off the device before clean.
4. DO NOT wash or clean the device with strong chemical reagents or strong
detergents. Clean the dust with a cotton swab or a soft cloth.
5. DO NOT tamper, disassemble, or attempt to repair the device. If there is a
need to alter or repair, please contact our customer service team.
6. DO NOT use the device in the place that no wireless device is allowed.
7. Oral pressure occurs while using the breathing trainer, which may affect
implanted and personal medical devices, such as pacemaker, cochlear
implants, hearing-aid. Please consult your doctor before using if implanted
any medical device.
8. DO NOT use the device in dust, damp, dirty or magnetic places to aviod circuit
failure.
9. Use the device at the temperature between 5°C to 45°C. Too low or too high
temperature may cause device failure.
10. DO NOT place the device and accessories near heat or fire, such as electric
heater, microwave oven, etc.
11. Keep the device and accessories out of reach of children.
12. DO NOT keep the device in damp place to avoid device failure.

02
Specifications
Measuring Range:
Product Name:
Model:
Battery Capacity:
Battery Type:
Charging Input:
Charging Time:
Dimensions:
Weight:
Smart Breathing Trainer
LM-B001
0ml-4500ml
400mAh
Lithium battery
5V 1A
2hrs
100g
Material: ABS Plastic
35×35×136mm
Connection:
Display:
Battery Life:
Bluetooth 4.0
15 hrs
LED Lights
1
4
56
2
3
1
2
3
5
6
7
Getting to Know
Your Smart Breathing Trainer
Smart Breathing Trainer For Maintaining and Improving Inspiratory Volume and
Respiratory Fitness
Product Diagram
7
4
Flow Rate LED
Flow Volume LED
Power/Bluetooth LED
Charging Port
Power Switch
Air Hole
Air Inlet
03

400 0
300 0
200 0
100 0
3500
2500
1500
500
Indicator Light Instructions
Best
Better
Good
0ml-4500ml
Power/Bluetooth LED
Power LED
Work
Charging
Status
Power on
Bluetooth connected
Low battery
Charging
Fully charged
Light Effect
Always on
Short flash,
and then on
Intermittent flash
Slow flash
Always on
04
Using Your Breathing Trainer
1) Press the power switch for 2s, and
the power LED on.
2) Attach the mouthpiece to the air
hole of the trainer, or attach the
mouthpiece to the extention tube,
and attach the tube to the trainer
according to your own need.
3) Hold the trainer. Exhale normally.
Then place lips tightly around
mouthpiece.
4) Inhale slowly to raise Flow Volume
LED. For:
(a) Vital Capacity test: slowly inhale, and
try to raise Flow Volume LED as high
as possible. When inhalation is complete,
remove mouthpiece, and exhale normally.
Inhale slowly
05
1. Off-line Operation

(b) Breathing Trainer: slowly inhale,
and maintain the Flow Rate LED in the
“ Best ” （฀฀฀）flow range. Try to
raise Flow Volume LED to specified
volume level. When inhalation is
complete, remove mouthpiece, hold
the breath as specified, and exhale
normally. Reset and repeat trainer.
( Frequency of use and recommended
inspiratory volumes should be set
according to your own situation at the
direction of training courses, your
coach, physician or therapist. )
5) To shut down the trainer, press
the power switch for 2s and the power
LED off.
06
Note: DO NOT block air inlet of the breathing trainer during use.
Scan QR Code
Download＜OPUMP App＞
Best
300 0
200 0
100 0
2500
1500
500
07
2. Online Operation （Connect to the App)
1） App Installation
Search “OPUMP" in the Android Application Market, the iOS App Store, the
HUAWEI Application Market to download and install the App.
App downloaded via other channels may be unusable. Before pairing with your
equipment, make sure your equipment meets the following requirements:
iPhone 5S and above with iOS 10.0 and above system;
Android 5.0 and above with Bluetooth 4.0
2） Connect to the Breathing Trainer via Bluetooth
Open OPUMP App and Bluetooth of the phone, follow the instruction of the App
to register/log in and connect to the trainer.
3) OPUMP App
OPUMP App provides different courses and vital capacity test. You can set goals,
take the courses and record the training.

08
Care & Maintenance
The unit should be cleaned after every use.
-Clean the trainer with the cotton swab;
- Rinse mouthpiece and extension tube and shake dry；
Never immerse the trainer into water or any other liquid.
Note:
Mouthpiece and Extension Tube: Single Person Use Only.
09
Warranty
Thank you for purchasing OPUMP products. This product is guaranteed for one
year from the date of purchase.
By registering your product on our website (https://theopump.com/), the warranty
period can be extended to 24 months.
If you encounter any problems, please contact with us by the following way,
and attach your order number and detailed information about the problem. Under
normal circumstances, we will contact you within one working day.
Website: https://theopump.com/
After sales email: [email protected]
Please read the User Guide carefully and use it strictly according to the user
guide.
This warranty does not cover product damage caused by normal wear,
scratches, improper use，failure to follow the instructions in the User Manual
or use for commercial purposes.
For products purchased from retailers and distriutors, please contact the
corresponding retailers and distributors to provide you with the corresponding
after-sales service.

Predictive Nomogram
Inspiratory Capacity* (ml)**
FEMALE
1900 2100 2300 2500 2700 2900 3100 3300 3500
58’’
1.45m
60’’
1.52m
62’’
1.57m
64’’
1.63m
66’’
1.68m
68’’
1.72m
70’’
1.78m
72’’
1.83m
74’’
1.88m
1850 2050 2250 2450 2650 2850 3050 3250 3450
1800 2000 2200 2400 2600 2800 3000 3200 3400
1750 1950 2150 2350 2550 2750 2950 3150 3350
1700 1900 2100 2300 2500 2700 2900 3100 3300
1650 1850 2050 2250 2450 2650 2850 3050 3250
1600 1800 2000 2200 2400 2600 2800 3000 3200
1550 1750 1950 2150 2350 2550 2750 2950 3150
1500 1700 1900 2100 2300 2500 2700 2900 3100
1450 1650 1850 2050 2250 2450 2650 2850 3050
1400 1600 1800 2000 2200 2400 2600 2800 3000
1350 1550 1750 1950 2150 2350 2550 2750 2950
1300 1500 1700 1900 2100 2300 2500 2700 2900
20
25
30
35
40
45
50
55
60
65
70
75
80
AGE
IN
YEARS
HEIGHT
MALE
HEIGHT
58’’
1.45m
60’’
1.52m
62’’
1.57m
64’’
1.63m
66’’
1.68m
68’’
1.72m
70’’
1.78m
72’’
1.83m
74’’
1.88m
76’’
1.93m
78’’
1.98m
AGE
IN
YEARS
2000 2200 2400 2600 2800 3000 3200 3400 3600 3800 4000
1950 2150 2350 2550 2750 2950 3150 3350 3550 3750 3950
1900 2100 2300 2500 2700 2900 3100 3300 3500 3700 3900
1800 2000 2200 2400 2600 2800 3000 3200 3400 3600 3800
1750 1950 2150 2350 2550 2750 2950 3150 3350 3550 3750
1650 1850 2050 2250 2450 2650 2850 3050 3250 3450 3650
1550 1750 1950 2150 2350 2550 2750 2950 3150 3350 3550
1500 1700 1900 2100 2300 2500 2700 2900 3100 3300 3500
1400 1600 1800 2000 2200 2400 2600 2800 3000 3200 3400
1350 1550 1750 1950 2150 2350 2550 2750 2950 3150 3350
1300 1500 1700 1900 2100 2300 2500 2700 2900 3100 3300
1250 1450 1650 1850 2050 2250 2450 2650 2850 3050 3250
1700 1900 2100 2300 2500 2700 2900 3100 3300 3500 3700
20
25
30
35
40
45
50
55
60
65
70
75
80

This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
