Orange-Casual OC-WK-005 User manual

OC-WK-005
3-Pieces Bistro Set
W
A
R
R
A
N
T
Y
1
Y
E
A
R
1
Orange-Casual
Thank you for choosing Orange-Casual!
Our goal is to provide high quality outdoor furniture with
outstanding customer service-all at an affordable price.
Please let us know how we are doing!
Problems?
(Missing pieces, wrong pieces...)
We will fix it Immediately. Send us an email at
[email protected]. If you are not satisfied with our
customer service, pls send your comments to
[email protected].
Happy?
Please leave us a review!
You can make others happy too!

IMPORTANT, RETAIN FOR
FUTURE REFERENCE:
READ CAREFULLY.
Safety
For domestic use only.
Don't tighten all the bolts before the product is fully assembled.



Periodic structural checks of this product should be
It would be useful to ask someone to help you assemble
the product.
undertaken, do not use if you have any doubts about its
Do not stand on the seat.
Do not sit on the armrest.
Do not let children play with this product.
Maximum load per seat: 250 lbs.
At the beginning of the season

product are secure, do not use if you have any doubts
At the end of the season
This product should be stored under cover during
prolonged spells of adverse weather (wet or cold) and
also during the winter (ideally in a garden shed or
garage).
Always clean and dry thoroughly before storage.
- 1 -

Tips for Cushions
1
3
OK
2
In order to compress the package, we put the cushions in
the gap of some parts. So there may be crinkle on the fabric.
Don’t worry. Just flap every corner of the cushion evenly and
it will get back into its original shape soon.
- 2 -

- 3 -
Item
no.
Reference
Image Description Qty.
A
B
C
D
E
F
G
H
Seat Base
Seat Back
COMPONENT LIST - ARMCHAIR X 2
Washer
Right Armrest
Left Armrest
1
1
1
1
9
9
1
1
M6X35
Head Cap Screws
Seat Cushion
Allen Key

NOTE:
When tightening the screws, tighten sequentially.
DO NOT tighten any screws fully and then move on to the next one.
This may cause the frame to warp.
If there is still wobbles or screw holes cannot be aligned,loosen the
screws and execute this same process.
If the Chair is not stable it could lead to damage to the product.
Attach the Seat Base (A) to the Right Armrest (B) by securing with Head Cap
Screws (F) and Washers (E). Do this in 2 places.
1
- 4 -
x2
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.

Attach the Seat Back (D) to the Right Armrest (B) and Seat Base (A) by securing with
Head Cap Screws (F) and Washers (E). Do this in 3 places.
2
- 5 -
x3
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.

Attach the Left Armrest (C) to the Seat Back (D) and Seat Base (A) by
securing with Head Cap Screws (F) and Washers (E). Do this in 4 places.
3
- 6 -
x4
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.

4
- 7 -
H
Place the chair on a level surface, then place Seat Cushion (H) on the
chair. Your chair is ready for use.
5
x9
G
NOTE:IF ANY SCREW HOLES CANNOT BE ALIGNED,
LOOSEN ALL THE SCREWS AND GO BACK STEP
1 AND RESTART ASSEMBLY.
Tighten all 9 Screws into place
with Allen Key (G).

- 8 -
Item
no.
Reference
Image Description Qty.
J
K
L
M
N
E
F
G
Table Top
Back Panel
Table Bottom
COMPONENT LIST - TABLE
Washer
Table Leg
Table Leg
1
1
1
1
1
8
8
1
M6X35
Head Cap Screws
Allen Key

- 9 -
NOTE:
When tightening the screws, tighten sequentially.
DO NOT tighten any screws fully and then move on to the next one.
This may cause the frame to warp.
If there is still wobbles or screw holes cannot be aligned,loosen the
screws and execute this same process.
If the Table is not stable it could lead to damage to the product.
Attach the Table Leg (K) to the Table Top (J) by securing with Head Cap
Screws (F) and Washers (E). Do this in 1 place.
1
KF
E
J
x1
x1
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.

- 10 -
Attach the Back Panel (M) to the Table Leg (K) and Table Top (J) by securing
with Head Cap Screws (F) and Washers (E). Do this in 2 places.
2
x2
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
M
F
E
K
J
x2

Attach the Table Leg (L) to the Table Top (J) and Back Panel (M) by
securing with Head Cap Screws (F) and Washers (E). Do this in 2 places.
3
- 11 -
x2
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
L
F
E
M
J
x2

Attach the Table Bottom (N) to the Table Legs (L) &(K) and Back Panel (M)
by securing with Head Cap Screws (F) and Washers (E). Do this in 3
places.
4
- 12 -
x3
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
F
E
N
L
K
M
x3

- 13 -
Place the table on a level surface
and adjust height for balance. Your
table is ready for use.
5
x8
G
NOTE:IF ANY SCREW HOLES CANNOT BE ALIGNED,
LOOSEN ALL THE SCREWS AND GO BACK STEP
1 AND RESTART ASSEMBLY.
Tighten all 8 Screws into place with
Allen Key (G).
6
Adjust height
for balance Adjust low for balance
Adjust Pre-installed levellers
height for balance
