Orbit T1.9 IWM User manual

T1.9 IWM USER MANUAL

GB

DearCustomer,

Wearepleased,thatyouhavechosenanOrbitFitnessEquipment.Thisqualityproducthasbeendesigned
forin‐homeuseandhasbeentestedandcertifiedaccordingtotheEuropeanNormEN957‐1/6 . Please
carefullyreadtheinstructionspriortoassemblyandfirstuseandbesuretokeeptheinstructionsfor
referenceandmaintenance.
Wewishyoulotsofsuccessandfunwhiletraining,







GB
CustomerService
Tobestpossiblesupportyouinthecaseofproblemswithyourproduct,wewouldaskyoutopleasequote
theproductModelNameandSerialNumber.
Thesecanbefoundonthestickerundersideyourproduct.
Modelname:
Serialnumber:

WasteDisposal




Contact
Ifyouhavequestionsyoucannotresolvewiththehelpofthismanual,orneedtoorderreplacementparts
Pleasecalltheoutletfromwhereyoupurchasedthismachine.
Pleasehavetheproductmodelname,numberandserialnumberreadywhenyoucall.




Physiqueproductsarerecyclable.Attheendofitsusefullifepleasedisposeof
thisarticlecorrectlyandsafely(localrefusesites).
Batteriesandaccumulatorsdonotbelonginthedomesticwaste.Please,
disposethisarticlecorrectly(localrefusesites).

GB
Precautions

Beforeassemblingorusingthetreadmill,pleasereadthefollowinginstructionscarefully.Theycontain
importantinformationforuseandmaintenanceoftheequipmentaswellasforyourpersonalsafety.
Keeptheseinstructionsinasafeplaceformaintenancepurposesorfororderingspareparts.

Product‐Scope:Thisproductismadeforhomeuseonlyandtesteduptoamaximumbody
weightof115kilograms.
Product‐Performance:ThistreadmillistestedtotheEuropeanStandardEN957‐1/6HB.The
equipmentisnotsuitablefortherapeutictraining.
Product‐Scope:Noisecompliance:Thistreadmillmeetstherequirementsofthenoisepollution
standards.
Product‐Performance:Thenoisecreationoftreadmillisunder70db.
Product‐Maintenance:Forkeepingtherunqualityusetheprovidedsiliconsprayeverymonthor
afteraworkingtimeof115kilometersbetweenthebeltandtherunningsurface.
Product‐Maintenance:Searchfornoisyparts:Ifyoushouldnoticeunusualnoises,likegrinding,
clackingetc.trytolocateitandhaveitrepairedbyaprofessional.Makesurethetreadmillis
notuseduntilafterrepairshavebeenmade.
Product‐Feature:Thespeedcanbechangedbythecomputer.
Use‐SafetyKeySystem:Insertthesafetykeyinsafetykeybasethenfoldupsafetykeytolight
upthescreenofconsoleandfolddownsafetykeytoturnoffthescreenofconsole.Ifconsole
cannotbelightedupbyfoldupthesafetykeyorconsolecannotbeturnedoffbyfolddownthe
safetykey,whichwillbethatsafetykeySystemismalfunction.
Use‐Safetykey:Afterfoldupsafetykeyasthesafetykeyisvertical,whichmeansthetreadmill
isunderusing,whenuserpulloutthesafetykeybackwards,whichwillfolddownthesafetykey
asthesafetykeyishorizontalandpoweredoffthemachine.
Use‐Safety:Thefunctionoftheemergencystop:TheSafetyKeyfunctionsastheemergency
stop.Inanemergencysituation,removetheSafetyKeyfromtheconsoleandthetreadmillwill
cometoastop.

Use‐Scope:Theexercisermaynotbeusedbypersonswithaweightofover115kg.
Use‐Scope:Thisproductisdesignedforthephysicalexercisebyadults.Pleaseensurethatchildren
onlyuseitunderadultsupervision
Use‐Environment:Ensurethatthosepresentareawareofpossiblehazards,e.g.movableparts
duringtraining.
Use‐Environment:Ensurethatsufficientspaceisavailabletousethehomeexerciserwith2mlongx
1mwideofclearancebehinditand1mofclearanceforitsflanks.
Use‐Environment:Placethehomeexerciseronaneven,non‐slipperysurface.
Use‐Environment:Pleaseensurethatliquidsorperspirationneverentertheelectronic.

GB
Use‐Environment:Keeptheequipmentindoors,awayfrommoistureanddust.Donotputthe
equipmentinagarage,coveredpatioornearwater.Ifstoredinthislocationyouwarrantywillbe
affected.
Use‐Environment:Theproductismadeforhomeuseonly.Warrantyandmanufacturer'sliabilitydo
notextendtoanyproductordamagetotheproductcausedbycommercialuse.
User‐Health:Consultyourphysicianbeforestartingwithanyexerciseprogramstoreceiveadviceon
theoptimaltrainingtechnique.
User‐Health:Incorrect/excessivetrainingcancausehealthinjuries.
User‐Health:Ifyoufeelsickness,chestpain,fitsofdizzinessorbreathlessnessduringyourtraining,
stoptrainingimmediatelyandconsultyourphysician.
Product‐Preparation:Ensurethattrainingonlystartsaftercorrectassembly,adjustmentand
inspectionofthehomeexerciser.
Product‐Preparation:Followthestepsoftheassemblyinstructioncarefully.
Product‐Preparation:Onlyusesuitabletoolsforassemblyandaskforassistanceifnecessary.
Product‐Preparation:OnlyuseoriginalYowzapartsasdelivered(seechecklist).
Product‐Preparation:Tightenalladjustablepartstopreventsuddenmovementwhiletraining.
Product‐Preparation:Wesuggestusinganequipmentmattopreventdamageontheground.
Use‐Instruction:Pleasefollowtheadviceaspercorrecttrainingtechniqueasdetailedinthe
instructions.
Use‐Instruction:Donotusethehomeexerciserwithoutshoesorwithloosefittingfootwear.
Use‐Safety:Beawareofthepositionandproperfixationofadjustableormovingpartswhilemounting
ordismountingthehomeexerciser.
Use‐Safety:Allowthebelttofullystopbeforedismounting.
Use‐Safety:Payattention:neverinsertanypartofyourbodyorclothesintothebodyofthe
treadmillwhileitisrunningorreadyforuse.
Use‐Safety:Attachtheemergencystopcordtoyourclothingbeforestartingthetreadmill.The
Treadmillhasanemergencystopmechanismforyoursafety.Beforestartingyourworkout,fasten
thecordofthesafetykeytoyourclothing.Ifthetreadmillhasbeenshutdownbyremovingthe
safetykey,restartitbyreinsertingthekey.Anautomaticrestartofthetreadmillbeltdoesnot
occur.Anunmonitoreduseofthetreadmillbyotherpeoplecanbepreventedbyremovingthe
safetykeyandkeepingitsafelyhidden.Incaseofanyemergency,holdontightlytothehandrailor
handlebarwithbothhandsandleavethetreadmillbymeansoftheanti‐slippingsurfaceofthe
lateralplatform.Activatetheemergencestopmechanism(safetycut‐out).
Use‐Safety:Pleasekeepthesafetykeyinasafeplaceandensurethatitiskeptoutofreachof
children!
Product‐Power‐Safety:Theunitrequiresapowersupplyof220V–240V/50Hz.Itshouldbe
connectedtoasafetysocketwithadedicated10Afuse.Beforepoweringonandusingtheunit
confirmthatthetheunitispluggedintotheappropriatepowersupply(observemarkings)hasbeen
connectedproperly.

GB
Product‐Maintenance:Iftheequipmentisinregularuse,checkallitscomponentsthoroughlyevery
1–2months.Payparticularattentiontothetightnessofboltsandnuts.Thisappliesespeciallytothe
securingboltsforsaddleandhandlebars.
Product‐Maintenance:Incorrectrepairsandstructuralmodifications(e.g.removalorreplacementof
originalparts)mayendangerthesafetyoftheuser.
Product‐Maintenance:Damagedcomponentsmayendangeryoursafetyorreducethelifetimeofthe
equipment.Forthisreason,wornordamagedpartsshouldbereplacedimmediatelyandtheuser
shouldrefrainfromusingtheequipmentuntilthishasbeendone.
Product‐Maintenance:OnlyuseoriginalYowzareplacementparts.
Product‐Maintenance:Donotunderanycircumstancescarryoutelectricalrepairsoralterations
yourself.Alwaysensurethatsuchworkisdonebyaproperlyqualifiedelectrician/mechanicorthe
adviseoftheTechnicalSupportteamissoughtfirstly
Product‐Maintenance:Disconnecttheapparatusfromthemainsbeforedoingrepair,maintenance
orcleaningwork.
WARNING!Heartratemonitoringsystemsmaybeinaccurate.Overexercisingmayresultin
seriousinjuryordeath.Ifyoufeelfaintstopexercisingimmediately.






GB


GB
Assembly




























GB
Unfold

1.
2.
"CLICK"


GB
3.
4.
1
2


GB
Folding

1.
2.
1
2


GB
3.









4.














GB
5.











6.










GB
IWMWEIGHTSCALESETUP




GB
Transport











GB
CorrectUse













Correctbiomechanicalposition:Pleaserefertoleft
picture.Runningstraightonthetreadmillismade
easierbyfocusingonafixedobjectinfrontofyouin
theroom.Runasifyouwantedtoapproachthe
object.Alwayskeepadistancewhichyoucanreach
thefronthandbar.

Majorexercisetype:Thisequipmentfocusesonyour
lowerbody,anditcantrainyourthighandshank
muscles

Important:Incorrect/excessivetrainingcancause
healthinjuries.















GB
Adjustingtheincline













Thetreadmillhastwolevelsofinclination:
Thelevelcanbechangedbyadjustingtheinclinationleg.Usethehandle(A)toliftthetreadmillwith
onehandandadjusttheinclinationlegwiththeotherhandasshowninthedrawing(B).


















GB
DeckLubrication


















GB:
DeckLubrication
Thewalkingbelthasbeenpre‐lubricatedatthe
factory.However,itisrecommendedthatthe
walkingboardbecheckedperiodicallyfor
lubricationtoensureoptimaltreadmill
performance.Pleaseensurethelubricationofthe
runningbeltischeckedevery4‐6weeksafterthe
initial100miles/kilometersofuse.
Every30daysor30hoursofoperationliftthe
sidesofthewalkingbeltandfeelthetopsurface
ofthewalkingboardasfarasyoucanreach.If
youfeelsignsofsilicone,nofurtherlubricationis
required.Ifitfeelsdrytothetouch,followthe
instructionsbelow.Pleaseuseanon‐petroleum
basedsilicone.
Toapplylubricanttothewalkingbelt:
1. Positionthewalkingbeltsothattheseamis
locatedontopandincenterofthewalking
board.
2. Insertthespraynozzleintothesprayheadof
thelubricantcanifanozzleisrequired.
3. Whileliftingthesideofthewalkingbelt,
positionthespraynozzlebetweenthe
walkingbeltandtheboardapproximately6"
fromthefrontofthetreadmill.Applythe
siliconespraytothewalkingboard,moving
fromthefrontofthetreadmilltotherear.
Repeatthisontheothersideofthebelt.
Sprayapproximately4secondsoneachside.
4. Allowthesiliconeto"set"for1minute
beforeusingthetreadmill.














GB
RunningbeltAdjustment











Runningbeltadjustment
Thisinformationformspartoftheselfmaintenanceandmustbecarriedoutperiodicallybytheuser*
Propermaintenanceisveryimportanttoensureyourtreadmillisalwaysintopworkingcondition.
ImpropermaintenancecouldcausedamageorshortenthelifeofyourtreadmillandexceedtheLIMITED
WARRANTYcoverage.
IMPORTANT:Neveruseabrasivesorsolventstocleanthetreadmill.Topreventdamagetothe
computer,keepliquidsawayandkeepitoutofdirectsunlight.Inspectandtightenallpartsofthe
treadmillregularly.Replaceanywornpartsimmediately.

BeltAdjustment
Therunningbelthasbeenadjustedproperlybythefactory.Howevertransportation,unevenflooringor
otherunpredictedreasonscouldcausethebelttoshiftoffcentreresultinginthebeltrubbingwiththe
plasticsiderailorendcapsandpossiblycausingdamage.To adjustthebeltbacktoitsproperposition
pleasefollowthedirectionsbelow:
Ifthebelthasonlymovedby1‐2mmthiswillnotaffecttheoperationofyour
treadmill
1.Ifyourbelttendstowalktotheright,simplyadjusttheleftbelttensionboltbyturningit1/4 turncounter
clockwise.Followwithatest.
2.Ifyourbelttendstowalktotheleft,rotatethelefttensionboltclockwise1/4 turnsatatime,and
followwithatest.Ifthebeltcontinuestowalktotheleft,simplyadjusttherighttensionboltcounter
clockwise.
3.Ifyourbeltappearstobeloose,simplytightenbothboltsevenly1/4turn.Ifitappearstight,simply
loosenbothboltsevenly1/4 turn.
WARNING!Therearetwowhitelinewith8mmwidthonthetwosideoftherunningbeltbutstillhave
gapsawayfrombothsiderails,ifanysideofwhitelinehavebeentotallycoveredbysiderail,itmeans
therunningbeltisnotinthemiddle,whichmaycauserunningbeltrubbingsiderail.Therefore,ifthe
runningbeltisnotinthemiddlethentherunningbeltshouldbeadjustedtoproperpositiontokeepthe
samegapsbetweensiderailsandrunningbelt.
Forrunningbeltadjusting,therunningbeltmustbeadjustedundertherunningbeltisrunningwithin
8‐10km/hspeedandtoclockwisefastentherightsideofrearrollerbyhexkeyortoanticlockwiseloose
theleftsideofrearrollerbyhexkeywhenwhitelineofrightsidehasbeentotallycoveredbyrightside
railtillthiswhitelinetotallyexposed.Ontheotherhand,clockwisefastentheleftsideofrearrollerby
hexkeyortoanticlockwiseloosetherightsideofrearrollerbyhexkeywhenwhitelineofleftsidehas
beentotallycoveredbyleftsiderailtillthiswhitelinetotallyexposed
Donotovertightenrollers!Thiswillcauseprematurerollerbearingfailure!
8mm white lines
