Oregon Scientific RMR391PA User manual

1
EN
Slim Projection Clock with Indoor/
Outdoor Temperature
Model: RMR391P / RMR391PA /
RMR391PU
USER MANUAL
CONTENTS
Overview .................................................................. 2
Front view ............................................................. 2
Back view ............................................................. 2
Bottom view .......................................................... 3
Remote sensor ..................................................... 3
Getting started ......................................................... 3
Power supply ......................................................... 3
Remote sensor. ..................................................... 4
Sensor data transmission ..................................... 4
Clock ........................................................................ 5
Clock reception .................................................... 5
Manually set clock ................................................ 5
Alarm ........................................................................ 5
Temperature ............................................................. 6
Projection ................................................................ 6
Backlight ................................................................. 6
Reset ........................................................................ 7
Precautions ............................................................. 7
Specifications ........................................................ 8
About Oregon Scientific ......................................... 8
EU-Declaration of conformity ................................ 8
FCC Statement ......................................................... 9

2
EN
OVERVIEW
FRONT VIEW
1
6
7
8 9 10 11
5
3
4
2
1. SNOOZE / LIGHT: activate snooze alarm; turn on
backlight / projector; flip projected image 180º
2. Projector
3. : clock signal reception indicator
4. : adapter disconnected
5. : alarm time is displayed
6. : remote sensor reception indicator
7. : indoor temperature is displayed
8. : daily alarm is ON
9. AM/PM
10. Calendar format
11. +ZONE: time zone offset
BACK VIEW
1 2 3 4 6 7 8 5
1. ºC / ºF: select temperature unit
2. / : increase / decrease value of the setting;
activate / deactivate clock reception signal
3. ON·PROJECTION·OFF: enable / disable
continuous projection
4. : view alarm status; set alarm; activate / deactivate
alarm function
5. BACKLIGHT·HI·OFF·LO: enable / disable continuous
backlight; select brightness
6. MODE: set clock
7. TEMP: toggle between indoor / outdoor temperature
display; initiate auto-toggle
8. RESET: reset unit to default settings

3
EN
BOTTOM VIEW
1
2
1. Adapter socket
2. Battery compartment
REMOTE SENSOR
1. LED status indicator
2. Wall mount hole
3. Battery compartment
4. RESET hole: Reset unit to default settings
5. CHANNEL switch: Select channel 1
GETTING STARTED
POWER SUPPLY
2 x CR2032 batteries
To insert batteries:
1. Remove the battery compartment cover.
2. Insert the batteries, matching the polarities.
3. Press RESET after each battery change.
LOCATION MEANING
Clock area Main unit batteries low
Outdoor / indoor
temperature area Sensor batteries low
1 x adapter:
Alternatively, use the adapter supplied to power the
unit. For continuous use of projector / backlight, adapter
must be installed.
Make sure the adapter is not obstructed and is easily
accessible to the unit.
NOTE The main unit and adapter should not be
exposed to wet conditions. No objects filled with liquid,
such as vases, should be placed on the main unit and
adapter.
To completely disconnect from power, the adapter
should be disconnected from the main unit.
will appear when power supply is not
connected.
1
2
3
4
5

4
EN
REMOTE SENSOR
To set up the remote sensor:
1. Slide open the battery compartment.
2. Slide channel switch to select channel 1.
3. Insert the battery, matching the polarities.
4. Press RESET after each battery change.
5. Close the battery compartment.
6. Place the sensor within 30 m (98 ft) of the main unit
using the table stand or wall mount.
The transmission range may vary depending on many
factors. You may need to experiment with various
locations to get the best results.
NOTE We recommend that you use alkaline batteries
with this product for longer usage and consumer grade
lithium batteries in temperatures below freezing.
SENSOR DATA TRANSMISSION
Outdoor sensor:
The main unit will automatically search for the outdoor
sensor. The sensor reception icon in the remote sensor
area shows the status:
ICON DESCRIPTION
Main unit is searching for
sensor(s)
A channel has been found
The sensor cannot be
found.
NOTE If the sensor is not found, check the batteries,
obstructions, and remote unit location.
For best results:
• Place the sensor out of direct sunlight and
moisture.
• Position the sensor so that it faces the main unit,
minimizing obstructions such as doors, walls and
furniture.
• Place the sensor in a location with a clear view to
the sky, away from metallic / electronic objects.
• Position the sensor close to the main unit during
cold winter months as below-freezing temperatures
may affect battery performance and signal
transmission.
TIP Ideal placements for the sensor would be in any
location on the exterior of the home at a height of not
more than 1.5 m (5 ft) and which can shield it from direct
sunlight or wet conditions for an accurate reading.

5
EN
CLOCK
CLOCK RECEPTION
This product is designed to synchronize its clock
automatically with a clock signal.
RMR391P: EU: DCF-77 signal: within 1500 km (932
miles) of Frankfurt, Germany.
RMR391PU: UK: MSF-60 signal: within 1500 km (932
miles) of Anthorn, England.
RMR391PA: WWVB-60 signal: within 3200km (2000
miles) of Fort Collins Colorado.
To enable / disable signal reception:
Press and hold to enable, or to disable signal
reception.
NOTE Reception takes 2-10 minutes. If the signal is
weak, it can take up to 24 hours to get a valid signal.
If signal reception is unsuccessful, place your unit next
to a window, press and hold to force another signal
search.
Clock signal reception indicator:
STRONG SIGNAL WEAK / NO SIGNAL
MANUALLY SET CLOCK
To set the clock manually, disable the clock signal
reception first.
1. Press and hold MODE.
2. Press or to change the settings.
3. Press MODE to confirm.
4. The setting order is: time zone offset, 12/24-hr
format, hour, minute, year, day / month format,
month, day and language.
RMR391P / RMR391PU: Time zone offset sets the
clock +/- 23 hours from the received clock signal time.
If you have deactivated the clock signal reception, do
not set a value for time zone.
NOTE If you enter +1 in the time offset setting, this will
give you your local time plus one hour. If you are in the
US (RMR391PA) set the clock to:
PA for Pacific time MO for Mountain time
CE for Central time EA for Eastern time
NOTE The language options are (E) English, (S)
Spanish, (I) Italian, (F) French and (D) German.
ALARM
To set the alarm:
1. Press and hold to enter alarm-setting mode.
2. Press / to set hour / minute.
3. Press to confirm. indicates alarm is ON.

6
EN
To toggle alarms ON / OFF:
1. Press to display alarm time.
2. Press again to turn alarm ON / OFF.
To silence the alarm:
• Touch SNOOZE / LIGHT to silence it for 8 minutes
OR
• Press any other key to turn the alarm off and
activate it again after 24 hours.
TEMPERATURE
To toggle temperature unit:
• Press °C / °F.
To toggle between outdoor / indoor sensor
readings:
• Press TEMP. / indicates indoor and
outdoor temperature.
To auto toggle indoor / outdoor temperature displays:
• Press and hold TEMP.
To deactivate auto toggle function, press TEMP.
PROJECTION
NOTE For continuous projection, install adapter.
To activate / deactivate continuous projection
(when adapter is connected):
• Slide PROJECTION switch to ON / OFF.
Image can still be projected when no adapter is
connected. However, when the battery power is low /
exhausted, the projection feature will be disabled.
To project image briefly:
• Touch SNOOZE / LIGHT.
To flip projected image by 180º:
• Touch SNOOZE / LIGHT.
To adjust location of projected image:
• Swivel the projection arm as required.
NOTE If projection is illuminated, do not look directly
into the projector.
NOTE To save battery life, the projector and backlight
will only operate continuously when adapter is
installed.
BACKLIGHT
NOTE Install adapter to use backlight function. When
the adapter is not connected, the backlight feature will
be disabled.

7
EN
To activate continuous backlight:
• Slide BACKLIGHT switch to HI / LO.
For a brighter display, select HI. For a dimmer
display, select LO.
To deactivate continuous backlight:
• Slide
BACKLIGHT switch to OFF. (Touch SNOOZE/
LIGHT to turn backlight on for 5 seconds).
RESET
Press RESET to return to the default settings.
PRECAUTIONS
• Do not subject the unit to excessive force, shock,
dust, temperature or humidity.
• Do not cover the ventilation holes with any items
such as newspapers, curtains etc.
• Do not immerse the unit in water. If you spill liquid
over it, dry it immediately with a soft, lint-free cloth.
• Do not clean the unit with abrasive or corrosive
materials.
• Do not tamper with the unit’s internal components
This invalidates the warranty.
• Only use fresh batteries. Do not mix new and old
batteries.
• Images shown in this manual may differ from the
actual display.
• When disposing of this product, ensure it is
collected separately for special treatment and not
as normal household waste.
• Placement of this product on certain types of
wood may result in damage to its finish for which
Oregon Scientific will not be responsible. Consult
the furniture manufacturer’s care instructions for
information.
• The contents of this manual may not be reproduced
without the permission of the manufacturer.
• Do not dispose old batteries as unsorted municipal
waste. Collection of such waste separately for
special treatment is necessary.
• Please note that some units are equipped with a
battery safety strip. Remove the strip from the
battery compartment before first use.
NOTE The technical specifications for this product
and the contents of the user manual are subject to
change without notice.
NOTE Features and accessories will not be available
in all countries. For more information, please contact
your local retailer.

8
EN
SPECIFICATIONS
TYPE DESCRIPTION
MAIN UNIT
L x W x H 175 x 80 x 18 mm
(6.9 x 3.2 x 0.7 in)
Weight 240 g (8.47 oz)
without battery
Temperature Unit °C / °F
Temperature range -20°C to 60°C
Signal frequency 433 MHz
Power 2 x CR2032 batteries /
3V adapter
REMOTE UNIT (THN132N)
L x W x H 92 x 60 x 20 mm
(3.6 x 2.4 x 0.8 in)
Weight 62 g (2.22 ounces)
Transmission range 30 m (98 ft) unobstructed
Temperature range -30°C to 60°C
(-22°F to 140°F)
Power 1 x UM-3 (AA) 1.5V battery
ABOUT OREGON SCIENTIFIC
Visit our website (www.oregonscientific.com) to learn
more about Oregon Scientific products. If you’re in
the US and would like to contact our Customer Care
department directly, please visit:
www2.oregonscientific.com/service/support.asp
For international inquiries, please visit:
www2.oregonscientific.com/about/international.asp
EU-DECLARATION OF CONFORMITY
Hereby, Oregon Scientific, declares that this Slim
Projection Clock with Indoor/Outdoor Temperature
(Model: RMR391P / RMR391PA / RMR391PU) is in
compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC. A copy
of the signed and dated Declaration of Conformity
is available on request via our Oregon Scientific
Customer Service.
COUNTRIES RTTE APPROVAL COMPLIED
All EU countries, Switzerland CH
und Norwegen N

9
EN
FCC STATEMENT
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
WARNING Changes or modifications not expressly
approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
NOTE This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio / TV
technician for help.
DECLARATION OF CONFORMITY
The following information is not to be used as contact
for support or sales. Please visit our website at www2.
oregonscientific.com/service for all enquiries.
We
Name: Oregon Scientific, Inc.
Address: 19861 SW 95th Ave.,Tualatin,
Oregon 97062 USA
Telephone No.: 1-800-853-8883
declare that the product
Product No.: RMR391P / RMR391PA /
RMR391PU
Product Name: Slim Projection Clock with Indoor/
Outdoor Temperature
Manufacturer: IDT Technology Limited
Address: Block C, 9/F, Kaiser Estate,
Phase 1,41 Man Yue St.,
Hung Hom, Kowloon,
Hong Kong
is in conformity with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received,
including interference that may cause undesired
operation.
