INTRODUCTION
Thank you for selecting the Oregon ScientificTM Weather
Station Advanced (BAR628HG / BAR628HGU). This
device bundles precise time keeping, weather forecast,
and indoor and outdoor temperature and humidity
monitoring features into a single tool you can use from
the convenience of your home.
In this box, you will find:
• Main unit
• Remote sensor (THGR122NX)
• Main unit batteries, 3 x UM-3 (AA) 1.5V
• Remote sensor batteries, 2 x UM-4 (AAA) 1.5V
Keep this manual handy as you use your new product.
It contains practical step-by-step instructions, as well as
technical specifications and warnings you should know.
Weather Station Advanced
Model: BAR628HG /
BAR628HGU
User Manual

EN
2
1
2
3
4
5
6
1
2
3
5
4
6
7
8
PRODUCT OVERVIEW
FRONT VIEW
1. LCD display
2. and : Increase or decrease setting / activate or
deactivate RF Clock
3. MODE: Change display / settings
4. : View alarm status; set alarm
5. CHANNEL: Switch remote sensor
6. : Press to activate or deactivate alarm
BACK VIEW
1. SNOOZE button
2. Wall mount hole
3. Battery compartment (cover on)
4. Table stand
5. Battery compartment (cover off)
6. °C / °Fswitch
7. MEM: View current, maximum, and minimum
temperature / humidity readings
8. RESET hole

3
EN
LCD DISPLAY
A. Weather Forecast Area
B. Outdoor Temperature & Humidity Area
C. Indoor Temperature & Humidity Area
D. Clock / Alarm / Calendar Area
1. Weather display
2. Outdoor humidity
3. Sensor signal
4. Low battery icon for sensor
5. Outdoor temperature
6. Indoor humidity
7. Indoor icon
8. Low battery icon for main unit
9. Indoor temperature
10. Time
11. Radio Frequency (RF) reception icon
12. Alarm activated
13. Alarm setting
14. Calendar
15. Moon phase
1
3
4
2
5
7
8
6
9
11
12
13
10
14
15
A
B
C
D
1. Wall mount hole
2. RESET hole
3. CHANNEL number (1-3)
4. Battery compartment
(Battery compartment cover not shown)
1
2
1
2
3
4
REMOTE SENSOR (THGR122NX)
1. LCD display
2. LED status indicator

EN
4
TABLE STAND OR WALL MOUNT
Use the stand on the back of the main unit / remote
sensor, or mount it on a wall with a nail.
To attach the main unit stand:
To use the main unit wall mount:
To use the remote sensor stand or wall mount:
REMOTE SENSOR (THGR122NX)
This product is shipped with a THGR122NX Thermo /
Hygro Sensor that collects Temperature and Humidity
data. Data can be collected from up to 3 sensors.
Additional sensors sold separately.
SETUP SENSOR
1. Open the remote sensor battery compartment with a
small Phillips screwdriver.
2. Insert the batteries, matching the polarity (+ and -) as
shown in the battery compartment.
SWITCH OPTION
Channel Channel 1-3. If you are using more than
one sensor, select a different channel for
each sensor.
GETTING STARTED
BATTERIES
Batteries are supplied with this product:
Main unit 3 x UM-3 (AA) 1.5V batteries
Remote unit 2 x UM-4 (AAA) 1.5V batteries
Insert batteries before first use, matching the polarity
(+ and -) as shown in the battery compartment. For best
results, install batteries in the remote sensor before the
main unit. Press RESET after each battery change.
NOTE Do not use rechargeable batteries.
shows when batteries are low.
NOTE It is recommended that you use alkaline batteries
with this product for longer performance.
UNIT LOCATION
Main Indoor Temperature /
Humidity Area
Remote Outdoor Temperature /
Humidity Area
Installing the batteries:
CHANGE SETTINGS
To change, time, calendar and language settings:
1. Press and hold MODE for 2 seconds to enter setting
mode.
2. Press or to change settings. (To reach the
setting you want quickly, press and hold or .)
3. Press MODE to confirm.

5
EN
3. Set the channel. The switch is located in the battery
compartment.
4. Place the sensor near the main unit. Press RESET
on the sensor. Then, press and hold MEM and
CHANNEL on the main unit to initiate signal sending
between the sensor and the main unit. The reception
icon on the main unit will blink for approximately 3
minutes while it is searching for the sensor. (Refer to
the"DataTransmission"section formore information.)
5. Close the remote sensor battery compartment.
6. Secure the sensor in the desired location using the
wall mount or table stand.
For best results:
• Insert the batteries and select the channel before
you mount the sensor.
• Placethe sensorout ofdirect sunlightand moisture.
• Do not place the sensor more than 30 metres (98
feet) from the main (indoor) unit.
• Position the sensor so that it faces the main
(indoor) unit, minimizing obstructions such as
doors, walls, and furniture.
• Place the sensor in a location with a clear view to
the sky, away from metallic or electronic objects.
• Position the sensor close to the main unit during
coldwinter monthsas below-freezingtemperatures
may affect battery performance and signal
transmission.
You may need to experiment with various locations to
get the best results.
DATA TRANSMISSION
Data is sent from the sensor(s) every 40 seconds. The
reception icon shown in the Temperature and Humidity
Areas show the status.
SEARCH FOR SENSOR
To search for a sensor, press and hold MEM and
CHANNEL (on the main unit) for 2 seconds.
NOTE If the sensor is still not found, check the batteries,
obstructions, and remote unit location.
NOTESignals fromhouseholddevices suchas doorbells,
electronic garage doors, and home security systems
may cause temporary reception failure. This is normal
and does not affect general product performance. The
reception will resume once the interference ends.
CLOCK
The clock automatically synchronizes the current time
and date when it is brought within range of the radio
signal DCF77 generated from Frankfurt, Germany for
CentralEurope(modelBAR628HG)or MSF60generated
from Anthorn, England (model BAR628HGU).
NOTE The signals are collected by the main unit when
it is within 1500 km (932 miles) of a signal.
Initial reception takes 2-10 minutes, and is initiated when
you first setup the unit, and whenever you press RESET.
Once complete, the reception icon will stop blinking. The
icon is shown in the Clock Area.
To force a manual search for clock signals, press and
hold for 2 seconds. If no signal is found, check the
batteries.
TURN CLOCK ON / OFF
Perform this step if you cannot receive clock signals.
Press and hold for 2 seconds. Then, manually set the
clock following the “Set Clock” instructions (below).
The signal icon indicates that the clock feature is ON.
No icon means that it is OFF.
SET CLOCK / CALENDAR
You only need to do this if you have disabled the clock
feature (for example, if you are too far from or cannot
receive a signal).
1. Press and hold MODE for 2 seconds. The Clock Area
will blink.
2. Select the hour, minute, year, month, day, and day of
the week language. Press or to change the
setting.
3. Press MODE to confirm.
The language options are (E) English, (F) French, (D)
German, (I) Italian, and (S) Spanish.
STRONG SIGNAL WEAK SIGNAL NO SIGNAL
ICON DESCRIPTION
Main unit is searching for
sensors.
At least 1 channel has been
found.
Channel 1 is selected (number
will change depending on the
sensor you select).
--- shows in Outdoor The selected sensor cannot
Temp / Humidity Area be found. Search for the
sensor or check batteries.

EN
6
SELECT TEMPERATURE UNIT
Slide the °C / °Fswitch into the desired location. The
switch is located in the main unit battery compartment.
The setting for the main unit overrides the remote sensor
setting.
SELECT CHANNEL NUMBER
Press CHANNEL to switch between sensors 1-3.
The icon shows the selected sensor.
To auto-scan between sensors, press and hold
CHANNEL for 2 seconds. Each sensor’s data will be
displayed for 3 seconds. To end auto-scan, press
CHANNEL or MEM.
NOTE If you use a sensor that collects only temperature
data, humidity will not be shown.
NOTE For more information on the sensor see “Remote
Sensor THGR122NX” Section.
MINIMUM / MAXIMUM RECORDS
The MEM button is located in the main unit battery
compartment. Press MEM to toggle between current,
maximum (MAX) and minimum (MIN) records. To clear
the records, press and hold MEM for 2 seconds. A beep
will sound to confirm that the memory has been cleared.
MOON PHASE
The Calendar must be set for this feature to work, see
“Set Clock” section.
• Press or to view the moon phase for the next
or previous day.
• Press and hold or to scan quickly through the
years (2001 to 2099).
KINETIC-
WAVE
ICON
DESIG- Indoor Remote Remote Remote
NATED Display Display Display Display
DISPLAY Channel 1 Channel 2 Channel 3
New Moon
Waxing Crescent
First Quarter
Waxing Gibbous
Full Moon
Waning Gibbous
Last Quarter
Waning Crescent
SWITCH CLOCK DISPLAY
Press MODE to toggle between Clock with Seconds and
Clock with Weekday display.
ALARM
This product is equipped with a 2-minute crescendo
alarm.
VIEW ALARM SETTINGS
Press . The alarm time and alarm status will show in
the Clock Area.
SET ALARM
1. Press to switch to alarm display.
2. Press and hold again for 2 seconds. The alarm
settings will blink.
3. Select the hour and minute. Press or to change
settings. Press to confirm.
ACTIVATE ALARM
Press to activate or deactivate the alarm. shows in
the Clock / Alarm Area when the alarm is activated.
SILENCE ALARM
When the alarm time is reached, the crescendo alarm
will sound for 2 minutes. To silence the alarm:
• Press SNOOZE to silence it for 8 minutes.
OR
• Press any key except SNOOZE to mute the alarm
and activate it again after 24 hours.
If no button is pressed, the alarm will automatically
silence after 2 minutes. It will then sound again after 8
minutes.
WEATHER FORECAST
This product forecasts the next 12 to 24 hours of weather
within a 30-50 km (19-31 mile) radius with 70 to 75
percent accuracy. The weather forecast is always
displayed.
SUNNY PARTLY CLOUDY RAINY
CLOUDY
TEMPERATURE AND HUMIDITY
Thisproduct candisplaycurrent,minimum,and maximum
temperatures and humidity percentage information
collected by the remote sensors and main (indoor) unit.
Outdoordata iscollected anddisplayed every40 seconds.
Indoor data is collected and displayed every 10 seconds.

7
EN
RESET SYSTEM
The RESET button is located in the main unit battery
compartment. Press RESET when you change the
batteries and whenever performance is not behaving as
expected (for example, unable to establish radio
frequency link with remote sensor or clock).
SAFETY AND CARE
Clean the product with a slightly damp cloth and alcohol-
free, mild detergent. Avoid dropping the product or
placing it in a high-traffic location.
WARNINGS
This product is designed to give you years of service if
handledproperly. OregonScientificwillnotberesponsible
for any deviations in the usage of the device from those
specified in the user instructions or any unapproved
alterationsorrepairs ofthe product.Observethe following
guidelines:
• Never immerse the product in water. This can
cause electrical shock and damage the product.
• Do not subject the main unit to extreme force,
shock, or fluctuations in temperature or humidity.
• Do not tamper with the internal components.
• Do not mix new and old batteries or batteries of
different types.
• Donot userechargeable batterieswith thisproduct.
• Remove the batteries if storing this product for a
long period of time.
• Do not scratch the LCD display.
NOTE The technical specification of this product and
contents of this user guide are subject to change without
notice. Images not drawn to scale.
TROUBLESHOOTING
PROBLEM SYMPTOM REMEDY
Calendar Strange date / Change language
month (➔5)
Clock Cannot adjust clock Disable clock (➔5)
Cannot auto- 1. Adjust batteries
synchronize the (➔4)
date and time 2. Press RESET
(➔7)
3. Manually activate
clock feature (➔5)
Temp Shows “LLL” or Temperature is
“HHH” out-of-range
Remote Cannot locate Checkbatteries(➔5)
sensor remote sensor Check location (➔5)
Cannot change Checksensors. Only
channel one sensor is
working (➔5)
Data does not Initiate a manual
match main unit sensor search (➔5)
SPECIFICATIONS
MAIN UNIT DIMENSIONS
L x W x H 116 x 55 x 127 mm
(4.6 x 2.2 x 5 inches)
Weight 186g(6.6 ounces)without
battery
REMOTE SENSOR DIMENSIONS
L x W x H 92 x 60 x 20 mm
(3.6 x 2.4 x 0.79 inches)
Weight 63 grams (2.22 ounces)
without battery
TEMPERATURE
Unit °C / °F
Indoor range -5°C to 50°C
(23°F to 122°F)
Outdoor range -20°C to 60°C
(-4°F to 140°F)
Resolution 0.1°C (0.2°F)
RELATIVE HUMIDITY
Range 25% to 95%
Resolution 1%
Memory Minimum / maximum
WEATHER FORECAST
Display Rainy, cloudy, partly
cloudy, sunny
REMOTE SENSOR (THGR122NX)
RF frequency 433 MHz
Range 30 metres (98 feet) with
no obstructions
Transmission every 40 seconds
Channel No. 1-3
CLOCK
RF Clock Auto or manual (disabled)
Clock display HH:MM:SS
Hour format 12hr AM / PM
(Model BAR628HGU)
24hr (Model BAR628HG)
Calendar DD / MM; weekday in
5 languages (E, D, F, I, S)

EN
8
Alarm Single alarm with
2-minute crescendo and
8-minute Snooze
POWER
Main unit batteries 3 x UM-3 (AA) 1.5V
Sensor batteries 2 x UM-4 (AAA) 1.5V
NOTE It is recommended that you use alkaline batteries
with this product for longer performance.
ABOUT OREGON SCIENTIFIC
Visit our website (www.oregonscientific.com) to learn
more about Oregon Scientific products. If you’re in the
US and would like to contact our Customer Care
department directly,
pleasevisit:www2.oregonscientific.com/service/support
OR
Call 1-800-853-8883.
For international inquiries, please visit:
www2.oregonscientific.com/about/international
EU-DECLARATION OF CONFORMITY
Hereby, Oregon Scientific, declares that this Weather
StationAdvanced(Model: BAR628HG /BAR628HGU) is
in compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC. A copy of the
signed and dated Declaration of Conformity is available
on request via our Oregon Scientific Customer Service.
COUNTRIES RTTE APPROVAL COMPLIED
All EC countries, Switzerland
and Norway
CH
N

9
EN
© 2007 Oregon Scientific. All rights reserved.
P/N: 086L003567-069

EN
10
Weather Station Advanced
Model: BAR628HG / BAR628HGU
User Manual
