Oregon Professional Series User manual

Oregon® 120V Professional Series™
EHT120VX-NA
Extended Hedge Trimmer /
Taille-haie tube long / Cortasetos extendido
Original Instruction Manual
Manuel d’instruction original
Manual de instrucciones original

Instruction Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–21
Manuel d'instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22-39
Manual de instrucciones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40-57

4Hedge Trimmer Model EHT120VX-NA
Table of Contents
Table of Contents
Important Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Safety Signal Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
General Power Tool Safety Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Safety Symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
At a Glance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Unpacking and Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Unpacking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Before Starting Work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Batteries and Battery Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Fitting the Backpack Battery Carrier . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Fit the Harness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Balance the Hedge Trimmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Starting the Hedge Trimmer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Stopping the Hedge Trimmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Stealth Mode™. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Tool Reactivation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Dashboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Adjust the Cutting Blades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Cutting Techniques . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Lubricating the Gearbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Sharpening the Blades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Tightening the Blade Attachment Screws. . . . . . . . . . . . . . . . . . . . . . . . .17
Tightening the Blade Nuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
California Emission Control Air Index Information . . . . . . . . . . . . . . . . . . . . . . . .19
Commercial Warranty and Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Limited Warranty Coverage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Servicing Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Contact Us. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
California Emission Control Warranty Statement . . . . . . . . . . . . . . . . . . . . . . . .21
©  Blount, Inc. Pricing and specifications subject to change without notice. All rights reserved. Oregon® is a registered trademark of Blount, Inc.
in the United States and/or in other countries.

5
Hedge Trimmer Model EHT120VX-NA
Important Safety Information
Important Safety Information
WARNING: To reduce the risk of injury, read and understand this instruction manual before
using this product.
Save this manual for future reference.
Safety Signal Definitions
SYMBOL SIGNAL MEANING
DANGER Indicates that if the danger is not avoided, it will cause serious
property damage, injury or death.
WARNING Indicates that if the warning is not heeded, it can cause property
damage, serious injury or death.
CAUTION Indicates that if precautions are not taken, it may cause minor or
moderate injury, or property damage.
IMPORTANT Following this instruction will increase satisfaction with the tool.
General Power Tool Safety Warnings
WARNING: Read all safety warnings
and instructions. Failure to follow the
warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers
to your mains-operated (corded) power tool or
battery operated (cordless) power tool.
WORK AREA SAFETY
• Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
• Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks which may ignite the dust
or fumes.
• Keep children and bystanders away while
operating a power tool. Distractions can
cause you to lose control.
ELECTRICAL SAFETY
• Power tool plugs must match the outlet.
Never modify the plug in any way.
Unmodified plugs and matching outlets will
reduce the risk of electric shock.
• Avoid body contact with earthed or
grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There
is an increased risk of electric shock if your
body is earthed or grounded.
• Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock. **
• Do not abuse the cord. Never use the cord
for carrying, pulling, or unplugging the
power tool. Keep cord away from heat, oil,
sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric
shock.
• When operating a power tool outdoors,
use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.

6Hedge Trimmer Model EHT120VX-NA
Important Safety Information
• If operating a power tool in a damp
location is unavoidable, use a ground fault
circuit interrupter (GFCI) protected supply.
Use of a GFCI reduces the risk of electric
shock. *
** Item above: “Do not expose power tools to rain
or wet conditions.” is applicable to power tools
in general; however, Oregon battery operated
V Professional Series tools have been
specifically designed for operation during
exposure to rain or wet conditions.
* Item above: “If operating a power tool in a damp
location is unavoidable, use a ground fault circuit
interrupter (GFCI) protected supply.” is applicable
to corded power tools in general; however, use
of a GFCI with Oregon battery operated V
Professional Series tools is not applicable.
PERSONAL SAFETY
• Stay alert, watch what you are doing
and use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the influence of
drugs, alcohol or medication. A moment of
inattention while operating power tools may
result in serious personal injury.
• Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, non-skid safety
shoes, hard hat or hearing protection used for
appropriate conditions will reduce personal
injuries.
• Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or battery
pack, picking up or carrying the tool.
Carrying power tools with your finger on the
switch or energizing power tools that have the
switch on invites accidents.
• Remove any adjusting key or wrench
before turning the power tool on. A wrench
or a key left attached to a rotating part of the
power tool may result in personal injury.
• Do not overreach. Keep proper footing
and balance at all times. This enables
better control of the power tool in unexpected
situations.
• Dress properly. Do not wear loose clothing
or jewelry. Keep your hair, clothing and
gloves away from moving parts. Loose
clothes, jewelry or long hair can be caught in
moving parts.
• If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used. Use of dust collection can reduce dust-
related hazards.
• Do not let familiarity gained from
frequent use of tools allow you to become
complacent and ignore tool safety
principles. A careless action can cause severe
injury within a fraction of a second.
POWER TOOL USE AND CARE
• Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
• Do not use the power tool if the trigger
does not turn it on and off. Any power tool
that cannot be controlled with the trigger is
dangerous and must be repaired.
• Disconnect the plug from the power
source and/or remove the battery pack,
if detachable, from the power tool before
making any adjustments, changing
accessories, or storing power tools Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
• Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions
to operate the power tool. Power tools are
dangerous in the hands of untrained users.
• Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts, and any other condition
that may affect the power tool’s operation.
If damaged, have the power tool repaired
before use. Many accidents are caused by
poorly maintained power tools.
• Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are
easier to control.
• Use the power tool, accessories and
tool bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to
be performed. Use of the power tool for
operations different from those intended could
result in a hazardous situation.
• Keep handles and grasping surfaces dry,
clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow
for safe handling and control of the tool in
unexpected situations.

7
Hedge Trimmer Model EHT120VX-NA
Important Safety Information
7
BATTERY TOOL USE AND CARE
• Recharge only with the charger specified
by the manufacturer. A charger that is
suitable for one type of battery pack may
create a risk of fire when used with another
battery pack.
• Use power tools only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury and
fire.
• When battery pack is not in use, keep
it away from other metal objects, like
paper clips, coins, keys, nails, screws or
other small metal objects that can make a
connection from one terminal to another.
Shorting the battery terminals together may
cause burns or a fire.
• Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, seek medical
help. Liquid ejected from the battery may
cause irritation or burns.
• Do not use a pack or tool that is damaged
or modified. Damaged or modified batteries
may exhibit unpredictable behavior resulting in
fire, explosion or risk of injury.
• Do not expose a battery pack or tool to fire
or excessive temperature. Exposure to fire
or temperature above  °C ( °F) may
cause explosion.
• Follow all charging instructions and do not
charge the battery pack or tool outside
the temperature range specified in the
instructions. Charging improperly or at
temperatures outside the specified range may
damage the battery and increase the risk of
fire.
SERVICE
• Have your power tool serviced by a
qualified repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
• Never service damaged battery packs.
Service of battery packs should only
be performed by the manufacturer or
authorized service providers.
EXTENDED HEDGE TRIMMER SAFETY
WARNINGS
DANGER: Keep hands away from blade.
Contact with blade will result in serious personal
injury.
• Do not use the extended-reach hedge
trimmer in bad weather conditions,
especially when there is a risk of lightning.
This decreases the risk of being struck by
lightning.
• To reduce the risk of electrocution, never
use near any electrical power lines.
Contact with or use near power lines may
cause serious injury or electric shock resulting
in death.
• Always use two hands when operating
the extended-reach hedge trimmer. Hold
the extended-reach hedge trimmer with both
hands to avoid loss of control.
• Always use head protection when
operating the extended-reach hedge
trimmer overhead. Falling debris can result
in serious personal injury.
• Keep all parts of the body away from the
cutter blade. Do not remove cut material
or hold material to be cut when blades
are moving. Make sure the transportation
lockout is activated when clearing jammed
material. Blades coast after being turned
off. A moment of inattention while operating the
hedge trimmer may result in serious personal
injury.
• Carry the hedge trimmer by the handles
with the cutter blade stopped. When
transporting or storing the hedge trimmer,
always fit the blade cover. Proper handling of
the hedge trimmer will reduce possible personal
injury from the cutter blades.
• Do not use any accessories other than those
specified for Oregon Professional Series
Extended-reach Hedge Trimmer. The use of
any other accessory or attachment may increase
the risk of injury.
• Keep guards in place and in working order.
• Keep blades sharp.
• Hold the power tool by insulated gripping
surfaces only because the cutter blade
may contact hidden wiring. Cutter blades
contacting a “live” wire may make exposed
metal parts of the power tool “live” and could
give the operator an electric shock.
• Oregon Professional Series V tools have
been specifically designed for safe operation
during exposure to rain or in wet conditions,
but should be stored in a dry location.

8Hedge Trimmer Model EHT120VX-NA
Important Safety Information
Safety Symbols
These symbols appear on the EHTVX-NA.
SYMBOL MEANING EXPLANATION
Safety alert A danger, warning, or caution.
Follow instructions
Read and follow instructions in this manual
carefully before assembling, operating, or
servicing the product.
Protect bystanders
Clear the area of bystanders, children, and pets
within a minimum 50 ft (15 m) radius.
Encourage bystanders to wear eye protection.
Avoid overhead electrical
lines
Maintain a distance from overhead electric lines
with a minimum 50 ft (15 m) radius.
Keep body away from blades Keep all parts of your body away from the cutting
area and the cutting attachment.
Risk of eye injury
Protect your eyes and face
Wear protective safety glasses or goggles, a
face mask, and if necessary, an approved safety
hardhat. Guard against dust and debris-related
injuries and illnesses by controlling dust at the
source if possible.
Protect your body
Wear the appropriate, approved personal
protective equipment, including hearing
protection and substantial footwear.
Protect your hands
Wear heavy-duty, non-slip work gloves to
improve your grip and help protect your hands
when operating the tool.

9
Hedge Trimmer Model EHT120VX-NA
At a Glance
At a Glance
120v
1
3
2
4
4.1
4.2
4.5
4.6
4.7
4.3
10
11
13
12
5
6
7
8
9
7.1
5.1
2.2
2.1
4.4
4.4

10 Hedge Trimmer Model EHT120VX-NA
At a Glance
 Powerhead
 Powerhead Clamp
. Locking Screw/Washer
. Clamp Screws/Washers
 Power Socket
 Control Handle
. Transportation Lockout
. Trigger-Lock Lever
. Variable Speed Trigger
. Clamp Screws
. Dashboard
. Stealth Mode Indicator
. Stealth Mode Button
 Harness Loop
. Loop Screw
 Spacer Sleeve
 Front Handle
. Handle Screws/Washers
 Drive Tube
 Internal Drive Shaft
 Blade Adjustment Lever
 Hedge Trimmer Attachment
. Gearbox
. Blade Adjustment Plate
. Blade Adjustment Pin
. Filler Zerk Top
. Filler Zerk Bottom
. Locking Screw/Washer
. Clamp Screw/Washer
. Blade Attachment Screws
 Cutting Blades
 Blade Cover
 Combination Tool
 Blocking Pin/Rubber Stopper
(stored inside of Combination Tool)
11.2
11.1
11.6
11.7
11.8
11.8
11.4
11.3
11.5
15
14

11
Hedge Trimmer Model EHT120VX-NA
Unpacking and Assembly
Unpacking and Assembly
Unpacking
What’s in the boxes?
The hedge trimmer requires assembly before
use. These items ship with the hedge trimmer:
• Powerhead
• Front trimmer handle
• Drive tube assembly
• Harness loop
• Hedge trimmer attachment assembly
with cover
• Combination tool with blocking pin
Remove the hedge trimmer assemblies from
each box and inspect them carefully to ensure
no damage has occurred during shipping and
that no parts are missing. If any parts are
damaged or missing, do not use the hedge
trimmer. Contact Oregon®Customer Service to
obtain replacement parts at ...
Assembly
Place tool assemblies on a workbench.
. Loosen the harness loop screw () and
slide onto the motor housing end of the
drive tube. Wait until fully assembled to
tighten the screw.
. Remove the powerhead locking screw/
washer on the bottom of the powerhead ().
. Loosen the recessed control handle clamp
screws () and the powerhead clamp
screws (). Insert the motor housing end of
the drive tube through the control handle
and into powerhead clamp until it is firmly
seated in the powerhead ().
. Rotate the drive tube to locate and align to
the hole in the powerhead. Insert the
powerhead locking screw/washer () and
tighten to  inch-pounds with the included
combination tool..
WARNING: To reduce risk of injury, the
locking screw must be in place and tightened
properly.
. Tighten the powerhead clamp screws to 
inch-pounds with the included combination
tool.
. Position the control handle so that the
throttle cable is taut (). Align the control
handle to center the battery indicator over
the drive tube and tighten the recessed
clamp screws to  inch-pounds.
1
2
4
3
5
2
6

12 Hedge Trimmer Model EHT120VX-NA
Unpacking and Assembly
. Slide the harness loop to the control handle
() and tighten the clamp screw to  inch-
pounds.
. Slide the spacer sleeve to the harness
loop ().
. Loosen the screws on the front handle and
slide it onto the drive tube ().
. Push and rotate the internal drive shaft until
it seats into the powerhead ().
. Loosen the clamp screw on the hedge
trimmer attachment. Push and rotate the
hedge trimmer attachment until it couples
with the drive shaft ().
. Rotate to locate and align to the hole in the
drive tube. Insert the attachment locking
screw/washer and tighten to  inch-
pounds..
WARNING: To reduce risk of injury, the
locking screw must be in place and tightened
properly.
. Tighten attachment clamp screw to 
inch-pounds ().
. Align and adjust the front handle for a
comfortable working position and tighten
the clamp screw to  inch-pounds ().
Reposition as needed.
7
8
9
10
11
12
13

13
Hedge Trimmer Model EHT120VX-NA
Operation
Operation
Intended Use
Use your edger equipped with the appropriate
cutting attachment only for edging in grass,
weeds, and soft green plants. Do not use it for
other purposes, since misuse may result in
personal injury or property damage, including
damage to the machine.
Before Starting Work
Read the Original Instruction
Manual for the Battery and
Backpack Battery Carrier carefully
before assembling, operating, or
servicing the product.
• Check the battery, tool, and backpack battery
carrier are in good condition.
• Check for misalignment or bending of moving
parts, breakage of parts, and any other
condition that may affect the power tool’s
operation.
• Check that all guarding is in place and in good
condition.
• Check condition of backpack harnesses,
straps, and zippers.
• Make sure the battery cable, plug, and power
socket are not damaged.
To repair or replace any damage or worn
part, contact Oregon or an authorized Oregon
servicing dealer.
Batteries and Battery Charging
• Batteries must be used, stored and charged
within battery use, storage, charging
temperature ranges outlined in the
Specifications section of this manual.
• Oregon V Professional Series tools are
intended for use only with Oregon V
Professional Batteries. Read and follow all
instructions provided in the Oregon V
Professional Battery Operators Manual.
• Oregon V Professional Batteries must be
charged only by Oregon V Professional
Charger. Read and follow all instructions
provided in the Oregon V Professional
Charger Operators Manual.
Fitting the Backpack
Battery Carrier
WARNING: The Oregon Professional
Series Batteries should only be used with a
battery carrier supplied by Oregon. Failure to
use any other carrier or method may result in
injury.
• Insert the Oregon Professional Series Battery
into the Backpack Battery Carrier.
• Insert the plug of the battery cable into the
battery socket—make certain the battery
plug is completely seated into the power
socket of the battery.
• Lift the backpack on your body and fit the
carrier as described in the Oregon Backpack
Battery Carrier Instructions Guide.
Fit the Harness
• Put on shoulder strap.
• Adjust length of strap. The carabiner ()
should be about a hand’s width below
operator’s hip.
• Detach harness by pressing down on the
carabiner bar and pull the harness loop () out
of the carabiner.
1
2

14 Hedge Trimmer Model EHT120VX-NA
Operation
Balance the Hedge Trimmer
• Attach carabiner to the harness loop on the
drive tube.
• Loosen the screw ().
• Adjust harness loop.
• Tighten screw.
• Check position and comfort by allowing
trimmer to hang freely.
• Make adjustments as necessary.
Starting the Hedge Trimmer
• Before plugging in the Hedge Trimmer
make certain the transportation lockout is
activated.
• Fully insert the plug into the power socket.
When fully inserted, the LED lights on the
dashboard will activate and be accompanied
by an audible beep.
• Hold the power tool by both hands, with one
hand on the control handle and one hand on
the handle grip.
• Deactivate the transportation lockout.
• Engage the trigger-lock lever and press the
variable speed trigger to activate the blade.
Continue to press the variable speed trigger
for extended operation.
Stopping the Hedge Trimmer
• Release the variable speed trigger to stop the
blade.
• Upon release of the variable speed trigger,
remove your hand from the trigger-lock lever.
Stealth Mode™
The Oregon EHTVX-NA has a Stealth
Mode which reduces peak speed by . The
EHTVX-NA in Stealth Mode can reduce noise
up to  and extend run time more than .
• To activate Stealth Mode, press the Stealth
Mode button beneath the dashboard. A blue
light above the button indicates the tool is in
Stealth Mode.
• Press the button again to deactivate Stealth
Mode and return to full speed.
Tool Reactivation
When the hedge trimmer has not been in use
for  seconds it will enter a dormant mode,
during which engaging the trigger lock lever
and pressing the variable speed trigger will
result in the blue Stealth Mode light blinking
rapidly.
• Press the Stealth Mode button and the hedge
trimmer will immediately re-activate and the
dashboard will show battery charge state.
3
120v

15
Hedge Trimmer Model EHT120VX-NA
Operation
Dashboard
The dashboard is located on the control handle of the Oregon EHTVX-NA and displays the
current charge state of the battery connected to the tool and any faults from the tool or battery.
INDICATORS
LEDs
5 green LEDs 4 green LEDs 3 green LEDs 2 green LEDs 1 green LED 1 red LED
MEANING Full charge
100% to 81% 80% to 61% 60% to 41% 40% to 21% 20% to 10% Low power <10%
To determine the approximate number of hours the tool has been operated, insert the battery plug
and press the Stealth Mode button for  seconds.
INDICATORS
LEDs
none blue LED flash
SOUND
1 beep beep
MEANING <49 hours 1 blue LED flash and beep
for every 50 hours

16 Hedge Trimmer Model EHT120VX-NA
Operation
Adjust the Cutting Blades
WARNING: To reduce risk of injury,
disconnect the battery from the power tool
before making any adjustments, changing
accessories, or transporting.
The angle of the cutting blades can be
adjusted into  possible working positions
between ° and °.
Steps for adjusting the angle of the cutting
blades:
CAUTION: To reduce risk of injury,
install guard over blades while performing
adjustment.
• Pull back on the pin ().
• Use lever () to adjust the joint by one or
several holes.
• Release pin and ensure it engages a hole in
the plate ().
Cutting Techniques
OVERHEAD TRIMMING
Hold the hedge trimmer vertically with both
hands and move it across the material.
WARNING: Trimming material
overhead can cause fatigue. To minimize
risk of accidents, plan overhead cuts
beforehand and keep overhead cutting time
to a minimum.
• Use head protection when operating the
extended-reach hedge trimmer overhead.
HORIZONTAL TRIMMING
Angle the trimming head if necessary. Hold the
trimming bar at a ° to ° angle while moving
the hedge trimmer horizontally in an arc to
sweep cuttings to the ground.
VERTICAL TRIMMING
Angle the trimming head if necessary and
move the hedge trimmer vertically in an arc.
135°
4
65

17
Hedge Trimmer Model EHT120VX-NA
Maintenance
Maintenance
Lubricating the Gearbox
WARNING: To reduce risk of injury,
disconnect the battery from the power tool
before making any adjustments, changing
accessories, or transporting.
CAUTION: To reduce risk of injury,
check the grease level after every 
hours of operation and add Premium High
Temperature Lithium Wheel Bearing
Grease Grade NLGI  as follows:
• Unscrew filler zerks.
• Assess grease level on the inside of gearbox.
• Refit and firmly tighten the filler zerks.
• If no grease was visible, use a grease gun
fitted with a needle tip adapter (see below) to
insert no more than  g (. oz.) of grease into
the gearbox.
Sharpening the Blades
WARNING: To reduce risk of injury,
disconnect the battery from the power tool
before making any adjustments, changing
accessories, or transporting.
For the best performance of the tool make sure
that the cutting blades are sharp, have no nicks
or blunt edges, and do not hang up or catch
when running the hedge trimmer.
Periodically file away nicks and burrs on the
blades to ensure they move freely.
Sharp and free-moving cutting blades cut more
easily than dull or sticky ones.
Replace the cutting blades when they can no
longer be sharpened.
Tightening the Blade
Attachment Screws
WARNING: To reduce risk of injury,
disconnect the battery from the power tool
before making any adjustments, changing
accessories, or transporting.
Periodically check the  blade attachment
screws to maintain blade connection. Firmly
tighten as needed.
Tightening the Blade Nuts
WARNING: To reduce risk of injury,
disconnect the battery from the power tool
before making any adjustments, changing
accessories, or transporting.
Periodically check the  blade nuts to maintain
blade spacing. Firmly tighten as needed with
the  mm socket end on the combination tool.

18 Hedge Trimmer Model EHT120VX-NA
Troubleshooting
Troubleshooting
All of the tools in the Oregon Professional Series have the ability to self-diagnose issues.
Below is a table of fault codes the tool can display through the dashboard.
INDICATORS POSSIBLE
CAUSE
RECOMMENDED
ACTION
LEDs SOUND
none none Trigger not pulled. Pull trigger.
No power. Make certain the plug
is fully seated in socket.
1 continuous red light
red
steady on Cutting head is
jammed.
Disconnect the battery
plug from tool and
remove obstruction
from cutting head.
1 slow blinking red light
red
slow beep
(repeating) Battery is fully
discharged. Charge battery.
alternating green and red lights
green red
rapid beep
(repeating) Battery fault.
Try a different battery.
Contact authorized
repair center.
4 green, 1 red, 1 blue quick blinking lights
green green green green red blue
very rapid
short beep
(repeating) Hardware fault.
Unplug, wait 30
seconds, plug back in.
Service tool.
Contact authorized
repair center.
1 short, 1 long blinking red light
red
1 short,
1 long beep Battery too hot. Try a different battery.
Allow battery to cool.
2 short, 1 long blinking red light
red
2 short,
1 long beep Tool over temp.
Allow tool to cool.
Check for blocked
vents.
4 green and 1 red continuous lights
green green green green red
none
Failed dashboard. Replace dashboard.
5 blinking green lights
green green green green green
none Trigger pulled
while battery plug
inserted.
Release trigger.
Unplug tool.
Check for stuck trigger.
Plug in tool.

19
Hedge Trimmer Model EHT120VX-NA
Specifications
Specifications
For a full list of replacement parts, please visit OregonProducts.com.
HEDGE TRIMMER EHT120VX-NA
Weight (w/ blade) 14.4 lb (6.5 kg)
Length (w/ blade) 86 in (2184 mm)
Blade length 22 in (558 mm)
Blade cutter gap .89 in (22.6 mm)
Blade angle locking adjustment 135° (13 working points)
HIGH STEALTH MODE
Blade cutting speed 1425 rpm 1140 rpm
Bystander decibel rating
(per ANSI B172.1) 60 dB(A) 54 dB(A)
Run time estimates
(with BX975 Battery) 4.0 hours 5.7 hours
TEMPERATURE RANGES
Operating temperature range 14°F to 113°F (-10°C to 45°C)
Charging temperature range 32°F to 86°F (0°C to 30°C)
Storage temperature range -4°F to 140°F (-20°C to 60°C)
California Emission Control Air Index Information
California Emission Control Air Index Information
The Air Index of this engine is 0
0 2 4 6 8 10
Most Clean Least Clean
Note: The lower the Air Index, the less pollution.
This engine is certified to be emissions
compliant for the following use: 300 hours
Emissions Durability Period
The stated Durability Period listed on Oregon 120V Professional Series equipment refers
only to the minimum emissions period tools must meet or exceed to qualify as Zero
Emission Equipment in the State of California.

20 Hedge Trimmer Model EHT120VX-NA
Commercial Warranty and Service
Commercial Warranty and Service
Limited Warranty Coverage
Oregon offers the original purchaser as the
end-user a two () year limited warranty, and
a ninety () day limited warranty on products
purchased for rent to other end-users. Visit
www.OregonProducts.com for complete
Oregon® V Professional Series™ product
warranty and service information.
The Oregon V Professional Series limited
warranty covers the following products:
BLV-NA Backpack Blower, STV-NA
String Trimmer, HTV-NA Hedge Trimmer,
EGV-NA Edger, BX-UV Battery, BX-
UV Battery, C-NA Charger, CDVX-
NA Battery-to-Tool Cable, BPBXOR-UV
Backpack and, BPBXSY-UV Backpack.
Purchaser is responsible for maintaining
original proof of purchase.
Servicing Equipment
Oregon V Professional Series tools
and equipment (tools, batteries, chargers,
backpacks, accessories and components) are
designed to be serviceable by a qualified repair
person using only original Oregon replacement
parts. Only use Oregon Authorized Service
Centers. Visit www.OregonProducts.com for
a list of Authorized Oregon V Professional
Series Service Center locations, access product
manuals, review authorized replacement and
service parts and view how-to videos.
Contact Us
You can call Oregon’s customer service
department at ---, ext. . We’re
here to take your calls between : a.m. and
: p.m. (Pacific Time) Monday through Friday.
You can also email us at TechnicalServices@
oregonproducts.com for warranty and service
information. You can find an authorized service
center listed at www.OregonProducts.com.
Address:
Attn: Oregon Technical Services
RE: OPE – V Series
 SE International Way
Portland OR  USA
