orfit AIO 3.0 LOXON User manual

Page 1 of 2
INSTRUCTIONS FOR USE
AIO 3.0 LOXON™SET FOR 54CM
WIDE BASE PLATES FOR
QUANTUM™COUCH (MR Safe) (set
of 2)
Article No. : 38230
A. GENERAL PRODUCT INFORMATION
The product referred to in these instructions is a device used to
fix the 54 cm wide AIO Solution 3.0 base plates from Orfit
Industries onto Qfix Quantum™couches.
B. PRODUCT RANGE
This product can be used with all 54 cm wide AIO Solution 3.0
base plates.
C. FIXATION TO THE BASE PLATE
Mount the Loxon™blocks to the side of the base plate using the
plastic countersunk M5 x 20 screws and a screwdriver.
Use 2 sets of the AIO 3.0 Loxon™for Quantum™couch on the 54
cm wide AIO 3.0 Base Plates for fixation on a Qfix Quantum™
couch top. When only one set of Loxon™blocks is used,
combine it with a 2-pin indexing bar. Information on these
other parts can be found in the respective ‘instructions for use’
and the Orfit website: http://www.orfit.com/en/fixation-
devices/.
D. INDEXING AND REMOVING
Simply position the base plate with the Loxon™over the
Quantum™half-moon recesses in the couch top and push down
until the base plate is lying flush on the couch top.
Lift the base plate in order to remove of the couch top.
E. PRECAUTIONS FOR USE
When using the base plate in overhang, always make sure that
there is weight on the caudal part of the base plate to avoid
tilting. When moving the patient, always move from caudal to
cranial.
It is recommended to use a combination of Loxon blocks and 2-
pin bar when using the base plate in overhang.
DO NOT EXCEED OVERHANG LINE WHEN USING THE BASE
PLATE IN OVERHANG!
Make sure the screws are tightened so there is no play of the
base plate during setup and treatment.
Do not mount the Loxon™when positioned in the cut-outs of
the Quantum™couch top.
Replace the O-rings when cracks appear.
The plastic screws can be damaged if excessive force is used
during assembly with a screwdriver.
F. PROPERTIES
F.1 Physical Properties
Dimensions: L 27.5 mm x W 33 mm x H 24 mm
Weight: 12 g
F.2 Mechanical Properties
The Loxon™is made of POM. This provides the necessary
stability to get accurate patient positioning even under frequent
use.
This product is made entirely of electrically non-conductive,
non-metallic and non-magnetic materials and is MRI safe.
Warning: keep metal wrenches out of the MRI room.
F.3 Dosimetric Properties
Because of the high density of the POM, do not use in the path
of the beam.
G. STORAGE
Always store the product in a safe place to prevent it from
getting damaged.
Store the product between +10°C (50°F) and 40 °C (122°F).
Set 2
Set 1
Note:
It is prohibited to make alterations to this text without prior approval from Orfit Industries.
THE AIO SOLUTION® is a registered trademark of ORFIT INDUSTRIES N.V. LOXON™is a trademark of ORFIT INDUSTRIES N.V. QUANTUM™is a trademark of Qfix.
www.orfit.com
Ref. No.
502
62
VERSION 3
LAST UPDATE: 26/04/2023
REVISION DATE: 26/04/2023
Page 2 of 2
H. MAINTENANCE AND WASTE MANAGEMENT
This product can be cleaned and disinfected by means of soapy
water or an isopropanol based disinfectant, applied with a soft
cloth. If unsure about the cleaning fluid, do not use. Never use
aerosol sprays, corrosive cleaning agents, solvents or abrasive
detergents. Further cleaning instructions can be found in the
Orfit Cleaning Guidelines.
Periodic checks of the product should be done to insure the
parts are not worn and require repair or replacement. Do not
attempt to make repairs yourself. Contact your distributor if
there are any questions or concerns.
The product can be disposed of with household waste.
I. ADDITIONAL INFORMATION
For additional information such as distributor contact
information, product brochures, Safety Data Sheets and
regulatory information, please visit our website www.orfit.com.
