Beam™
User Guide
Wireless Transmitter for
HeadMouse®Extreme and Swifty™
(Adaptive switch not included with Beam)

Beam User Guide
Origin Instruments Corporation P a g e | 2
Table of Contents
Table of Contents.........................................................................2
Legal Notices................................................................................3
FCC / CE Notice...........................................................................3
Application Disclaimer ..................................................................4
Introduction...................................................................................5
Questions and Answers................................................................7
Configuration................................................................................8
HeadMouse Extreme..................................................................10
Swifty..........................................................................................11
General Care and Maintenance..................................................12
Customer Support ......................................................................12
Warranty Information..................................................................13
Notes:.........................................................................................15

Beam User Guide
Origin Instruments Corporation P a g e | 3
Legal Notices
Information in this User Guide is provided “as is” by Origin
Instruments, is subject to change without notice, does not
represent a commitment on the part of Origin Instruments, and is
provided without warranty of any kind, either expressed or implied,
including any implied warranties of merchantability or fitness for a
particular purpose. No part of this document may be reproduced
or transmitted in any form or by any means, electronic or
mechanical, including photocopying, recording or information
storage and retrieval systems, for any purpose other than the
purchaser’s personal use, without the express written permission
of Origin Instruments.
Origin Instruments is not responsible for any problems caused by
unauthorized modification of Beam and will not be responsible for
direct or consequential damages associated with any use of the
Beam product.
FCC / CE Notice
Products bearing the CE marking have been tested and are
declared by Origin Instruments Corporation of 854 Greenview
Drive, Grand Prairie, Texas 75050, USA to be in conformity with
the following standards or other normative documents and
following the provisions of the Electromagnetic Compatibility
Directive, 89/336/EEC:
EN 55022 Class B Emissions (Radiated Emission)
EN 61000-4-2, Electrostatic Discharge Immunity
EN 61000-4-3, Radiated Immunity
EN 61000-4-4, Fast Transient

Beam User Guide
Origin Instruments Corporation P a g e | 4
Origin Instruments Corporation has tested the Beam and found
that it complies with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a
residential installation.
Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may
cause undesired operation.
If this product is suspected of causing interference to a radio or
television receiver, remove and apply power to the equipment and
determine whether it is the cause of the disturbance. If a problem
exists, the user is encouraged to try and correct the problem by
one of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and the
receiver.
3. Reorient the equipment cables.
4. Consult the dealer or Origin Instruments for additional
suggestions.
Information in this document is subject to change without notice
and does not represent a commitment on the part of Origin
Instruments Corporation.
Application Disclaimer
Beam is designed for use by people who have limited or no motor
capability enabling them to operate switch activated devices.
However, it should not be used in an application where personal
injury or property loss could occur if the Beam failed for some
reason. Origin Instruments products are not authorized for
use as surgical aids or as part of a system intended to
support or sustain life. The user assumes full responsibility for
determining the suitability of Beam for the intended application.

Beam User Guide
Origin Instruments Corporation P a g e | 5
Introduction
Thank you for being a Beam customer!
The battery powered Beam transfers the state of up to three
normally-open switches directly to the HeadMouse® Extreme or
Swifty™. The Beam is an infrared device, but it doesn’t require a
clear optical path to the HeadMouse or Swifty. The light can
bounce off the ceiling, walls and even the user. However, as the
batteries discharge Beam may require a more direct and clear line
of sight. Always replace the Alkaline AA-cells as a set. With typical
use the batteries should last for several months.
When used with the HeadMouse Extreme, adaptive switches
emulate the “LEFT”, “RIGHT”, and “MIDDLE” buttons of a
standard desktop mouse. When used with an Apple Macintosh,
the HeadMouse Extreme uses the “LEFT” input for the primary
mouse button and the “RIGHT” input to generate a Control-Click.
When used with Swifty the buttons are defined by Swifty or by the
software using Swifty.
Figure 1
(a) Beam connector panel.
(b) 1/8-inch (3.5-mm) Stereo microphone plug. A Mono plug looks the same
except it does not have a Ring contact –Sleeve contact extends to the insulator
separating it from the Tip.

Beam User Guide
Origin Instruments Corporation P a g e | 6
Beam has three 1/8-inch (3.5-mm) microphone jacks and accepts
commonly available adaptive switches.
A photograph of the Beam rear panel and a stereo microphone
plug are shown in the Figure 1. Mono and stereo plugs can be
used in any jack; however, only the J1 socket has the capability to
monitor the second button of a dual switch. If a dual button switch
is plugged into J2 or J3 only one button will be seen, the other will
be ignored.

Beam User Guide
Origin Instruments Corporation P a g e | 7
Questions and Answers
Can I use a dual position (stereo) switch with Beam?
Absolutely. Switch combinations such as Sip/Puff or Left/Right can
directly connect using a single stereo cable. Simply plug the
stereo cable into J1. This greatly reduces the complexity of
cabling. Similarly, if you are integrating two switches into an
adaptive mount, we recommend the use of stereo cabling for
connection to Beam.
Can I use Beam with HeadMouse and Swifty?
Yes. However, in general you cannot use two Beams with different
HeadMouse systems or Swiftys in the same room at the same
time.
Must I point the Beam directly at the receiver?
In general light from the receiver will bounce off the walls, ceiling
and other things in the immediate vacinity of the Beam and make
it to the receiver. Certainly if Swifty is plugged into the back of a
computer under a desk a more direct path may be necessary. In
this situation one should purchase a Swifty Cable Kit and use the
USB extender to remote mount Swifty.
How do I get joystick buttons when using Beam with Swifty?
Even though the label indicates Beam sends mouse buttons it
actually just tells Swifty that one or more of the buttons have been
switched. Swifty in conjunction with its mode setting determines
which buttons it will emulate –mouse, joystick, or keyboard.
How long will the batteries last?
With typical use the batteries should last for several months.
However, if you notice intermittent behavior or that a more direct
line-of-sight is needed between Beam and the receiver a fresh set
of batteries may improve the situation.

Beam User Guide
Origin Instruments Corporation P a g e | 8
Configuration
Beam has the capability to determine if a mono or stereo plug is inserted
into J1. If a stereo plug is used, see Figure 1(b), both “Left” and “Right”
mouse buttons will be derived from this connector. The “Left” button will
come from the Tip and the “Right” button will come from the Ring. If a
plug is inserted into J3 the Beam will now use the Tip of J3 as the “Right”
button. In all cases the “Middle” button will use the Tip of J2. For all jacks
switch common is the Sleeve.
Figure 2
The mode switch or jumper is used to instruct the Beam to automatically
determine whether a stereo or mono switch is plugged into J1.
(a) Shows the version of Beam that uses a mode switch.
(b) Shows the version of Beam that uses a mode jumper.
NOTE: In both photos the switch and jumper are shown in Auto
mode. Even though the switch appears to be in the opposite
position from the jumper, internally the switch connects the pin
opposite the actuator.
If the mode jumper is positioned as shown in the Figure 2 (factory
default) then Beam will automatically determine if a stereo plug is
used. If the jumper is in the opposite position shown Beam will
work with stereo plugs, but ignore the J1-Ring contact, illustrated

Beam User Guide
Origin Instruments Corporation P a g e | 9
in Figure 1(b). This jumper is accessed by removing the four
enclosure screws In some versions of Beam there is an access
hole under the battery door that will allow the mode switch to be
changed without opening the enclosure.
Note: By default the Beam automatically determines whether a stereo or mono
plug has been inserted in J1. However, there may be times after moving plugs
between jacks and changing between mono and stereo plugs that the Beam will
temporarily be confused. During these times the Beam may transmit a continuous
right button for up to 30-seconds. If this is a problem, the internal jumper may be
used to configure J1 as a mono jack.

Beam User Guide
Origin Instruments Corporation P a g e | 10
HeadMouse Extreme
The optional HeadMouse Extreme is a precise and efficient head-
controlled access device for computers and augmentative
communication devices. It mounts on the computer and tracks
head position in order to wirelessly control the mouse pointer.
Adaptive switches can be connected to HeadMouse directly or
wirelessly using Beam.
HeadMouse Extreme features:
Built-in receiver for Beam for wireless switch input
Wireless head-controlled mouse emulation
Fast and responsive cursor control
USB mouse interface
Very low power
Light weight
Pocket size

Beam User Guide
Origin Instruments Corporation P a g e | 11
Swifty
Swifty, is a USB adaptive switch interface with an integrated
wireless receiver, can be used with Beam. Swifty accepts industry
standard 3.5 mm stereo or mono plugs and directly interfaces up
to two adaptive switches to a computer. Swifty is powered from
the USB host and does not require external power. Swifty uses
standard USB Human Interface Device (HID) drivers and works
with Windows, Macintosh and Linux computers, and many AAC
devices. When used with Beam up to three switches may be
wirelessly interfaced to a computer.
Swifty features:
Built-in receiver for Beam for wireless switch input
Extremely low latency
3.5-mm (1/8-inch ) stereo jack
Mouse button emulation
Joystick button emulation
Keyboard emulation
Full speed USB device
USB powered
Weighs ½ –ounce (14 –grams)
2–by 0.2–by 0.5–inches (51–by 20–by 13–mm)
Works with Windows, Mac and Linux

Beam User Guide
Origin Instruments Corporation P a g e | 12
General Care and Maintenance
Beam may be cleaned with a damp cloth, but it should never be
soaked with any water or cleaning solution. Do not allow any kind
of liquid in our around the Beam connector panel.
Customer Support
Customer support is provided by Origin Instruments during the
hours of 8:30 a.m. to 5:30 p.m. Central Standard Time (CST),
Monday through Friday.
Please email suppor[email protected] or call 972.606.8740.

Beam User Guide
Origin Instruments Corporation P a g e | 13
Warranty Information
Origin Instruments warrants that Beam will be free from defects in
materials and workmanship for a period of one (1) year from the
date of shipment. If the product proves defective during this
warranty period, Origin Instruments will, at its option, repair or
replace the defective product.
In order to obtain service under the foregoing warranties, the
Customer must notify Origin Instruments of the defect prior to the
expiration of the warranty period.
The foregoing warranties will not apply to any defect, failure, or
damage caused by improper use, or improper or inadequate
maintenance and care. Origin Instruments will not be obligated to
furnish service under these warranties (a) to repair damage
resulting from attempts by unauthorized personnel to install,
repair, or service the product; (b) to repair damage resulting from
improper use or connection to incompatible equipment; or (c) to
service a product that has been modified or integrated with other
products when the effect of such modification or integration
increases the time or difficulty of servicing the product.
The foregoing warranties are given by Origin Instruments with
respect to company products in lieu of any other warranties,
expressed or implied. Origin Instruments disclaims any implied
warranties of merchantability or fitness for a particular purpose.
Origin Instruments’ responsibility to repair or replace defective
products is the sole and exclusive remedy provided to the
customer for breach of any of these warranties. Origin Instruments
will not be liable for any indirect, special, incidental or
consequential damages irrespective of whether Origin Instruments
has advance notice of the possibility of such damage.
Products no longer covered by warranty may be suitable for
repair. Contact Origin Instruments for an estimated repair fee.

Beam User Guide
Origin Instruments Corporation P a g e | 14
Before returning product for repair, please send an email to:
[e-mail] or call 972.606.8740 to request a Return
Materials Authorization (RMA) Number. Once RMA number is
assigned, product must be returned postage pre-paid with all
components to:
Origin Instruments Corporation
ATTN: Customer Service –RMA (insert your number)
854 Greenview Drive
Grand Prairie, TX 75050-2438 USA
For repairs during warranty period, Origin Instruments will pay for
the return of the product to the Customer if the shipment is to a
location within the United States. For non-warranty repairs and for
warranty repairs outside of the United States, the Customer will be
responsible for paying all shipping charges, duties, taxes, and any
other charges associated with the return of the product.

Beam User Guide
Origin Instruments Corporation P a g e | 15
Notes:

Beam User Guide
Origin Instruments Corporation P a g e | 16
Origin Instruments Corporation
854 Greenview Dr.
Grand Prairie, TX 75050
USA
Voice: 972-606-8740
Fax: [phone]
Email: [email protected]
Web: www.orin.com
Shop: http://shop.orin.com
©2013 Copyright by Origin Instruments Corporation. All rights reserved. HeadMouse
is a registered trademark of Origin Instruments Corporation. Swifty and Beam are
trademarks of Origin Instruments Corporation. All other designated trademarks and
brands are the property of their respective owners.
