Original BTC Hatton 5 User manual

Hatton 5
Instruction Manual
Floor Light
MADE IN BRITAIN
ORIGINALBTC.COM
[phone]
UNIT 21 / 22 AVENUE ONE, STATION LANE, WITNEY, OX28 4XZ, ENGLAND
Established in 1990, Original BTC manufactures relaxed, familiar lighting for traditional and
contemporary homes.
All products are hand-assembled in Oxford from high quality components, produced in the UK.

Hatton 5 Floor Light
FF568
230V ac 50Hz IP20
* Warm white (2700k) low energy lamps recommended.
** Wattage value provided as a guide to suitable lamps. Lower wattage than stated may be used.
Safety Instructions
Cleaning and Maintenance
These instructions are provided for your safety in order to prevent the risk of Fire, Electric shock or
Injury. Please retain for future reference. When fitting is in operation, some parts will become hot;
take care when using/handling.
- Ensure the lamp type and max wattage is followed- do not exceed. Take care not to overtighten
lamp.
- Do not touch the lamp (bulb) or lamp holder while in operation, as both become very hot.
- Turn off and unplug fitting, leaving lamp to cool before changing lamp. Dispose of old lamps
carefully.
- Adjust light fitting only when power to the fitting is off and has been left to cool.
- Never leave a fitting without a lamp in position.
- Keep light fitting away from combustible materials such as soft furnishings.
- Ensure children do not play with the light fitting.
- Ensure the light is positioned on a solid, level and non-slip surface and make sure the position of
the cable does not pose a trip hazard.
- If the electrical flex or electrical components become damaged at any point, the fitting must be
unplugged from the power supply immediately and not operated until the damaged parts are
fixed/replaced.
- For use in a dry, indoor environment only. Ensure the fitting does not come into contact with any
liquids.
Metal finishes should only be cleaned with a soft, dry cloth. Do not use polishes or abrasives. Glass
can be cleaned by hand, using a soft damp cloth with a diluted mild detergent (nonabrasive) if
necessary. Switch off power to the fitting before cleaning.
A unique style floor light with a beautiful multi faceted bone china shade. The Hatton’s chrome base
and black cotton braided cable provide a contemporary and authentic edge.
E27 GLS BALL
LAMP GUIDANCE
TYPE* WATTAGE** BASE SHAPE
ü
ü
ü
ü
INCANDESCENT
CFL
ECO-HALOGEN
LED
100W MAX
18W
70W
12W
When handling the light, always support from below - do not lift from the shade.
!
Lamp assembly
1. Carefully place the shade over
the lampholder so it rests on the
locator disc
2. Place the spacer locator disc
around the base of the lampholder
so it sits centrally at the base of
the shade.
3. Place the spacer over the top of
the lampholder, so it is aligned
with the spacer locator disc and
secure by screwing on the shade
ring to the lampholder.
- Do not overtighten.
4. Insert the bulb
Locator disc
Shade
Lampholder
bulb
Shade ring
Spacer
Spacer
Locator disc
