Orion RXB-E User manual

MANUAL # 3941

Owner’s Manual
Orion RXB-E Kids Electric Balance Bike, FOR AGES 2-12
IMPORTANT: READ MANUAL CAREFULLY BEFORE
OPERATING
We care about the safety and comfort of our customers. This manual
will guide you through proper techniques in operating your Orion RXB-E
balance bike.
For any additional information, please visit: OrionPowersports.com
NOTE: Manual illustrations are for demonstration purposes only. Illustrations may not
reflect the exact appearance of the actual product. Specifications are subject to change
without notice. Please have your product Serial Number (S/N) or a copy of your receipt
before contacting us for warranty assistance and/or replacement parts.
WARNING: Riding a Electric balance bike does present potential risks and caution is
required. Like any riding product, an electric balance bike has inherent hazards
associated with its use (for example, falling off or riding it into a hazardous situation).
When riding the balance bike, it is possible to lose control or otherwise get into
dangerous situations. Both children and the adults responsible for supervising them,
must recognize that if such hazards occur, a rider can be seriously injured or die even
when using safety equipment and other precautions. RIDE AT YOUR OWN RISK.

Contents
These pages give an overview of the contents of your owner’s manual
Quick Reference ...................................................................................
1
Introduction .........................................................................................
2
A Few Words About Safety ...................................................................
4
Electric Balancer Pre-Riding Safety .......................................................
5
Before Riding .................................................................................................... 6
Safety Equipment..........................................................................................
9
Message To Riders .............................................................................. 10
Loading, Accessories & Modifications ................................................. 11
Safety Labels ...................................................................................... 13
Important Information ....................................................................... 14
Operating and Riding the Electric Balancer ......................................... 15
Electric Balance Bike Components ..........................................................
15
Power Mode ................................................................................................
17
How to Change the Modes of the Balancer ............................................
19
Safely Approaching or Re-Mounting the Bike ............................................
21
Loading and Unloading bike into a Vehicle .................................................... 21
Pre-Ride Inspection and Checklist ...........................................................
22
After Riding ..................................................................................................... 23
Charging ......................................................................................................
24
Repair and Maintenance .................................................................... 25
Tools Included in the Kit ................................................................................. 25
Test Brake ....................................................................................................
26
Adjust Brake ................................................................................................
26
Battery Removal .....................................................................................
27
Battery Installation .....................................................................................
30
Battery Disposal ......................................................................................
33
Troubleshooting Guide ....................................................................... 34
Cleaning and Appearance Care ........................................................... 35
Controller Diagram ............................................................................. 37
Specification ...................................................................................... 39
Spare Part Catalogue .......................................................................... 41
Parts Finder ....................................................................................... 47
Warranty ...................................................................................................
48
Disclaimer .......................................................................................... 49

1
Quick Reference
Model Version 12 in 16 in 20 in
Grips Universal MX
Handlebars Fat Bar 1” Clamp (25.4mm) x 520mm
Battery 24v, 5.2Ah 36v, 5.2Ah 48v, 5.2Ah
Charger 1.2-1.8Ah
Tires and Tubes 12”x 2.25-2.7 16”x 2.1-2.4 20” x 1.95

2
Introduction
Congratulations on the purchase of your new Electric Balance Bike!
With proper assembly and maintenance, it will offer you years of enjoyable
riding!
IMPORTANT:
Carefully read and follow this manual (and any other materials included
with this bike) before riding. Please retain this manual for future use. If this
bike was purchased for a child, it is the responsibility of the purchaser to
verify the bike has been properly assembled, and that the user has been
properly trained and instructed in use of the bike.
This manual is provided to assist you and is not intended to be a
comprehensive manual covering all aspects of maintaining and repairing
your bicycle. The bicycle you have purchased is a complex piece of
equipment that must be properly assembled and maintained in order to
be ridden safely.
The user or consumer assumes all risk of personal injuries, damage, or
failure of the bicycle or system and all other losses or damages to
themselves and others and to any property arising as a result of using the
bicycle.
DO NOT DISASSEMBLE, MODIFY OR REPLACE ELECTRICAL PARTS.
If you need to change any parts, please consult one of our
authorized dealers or contact customer service for additional help.
NOTE: YOUR INSURANCE POLICIES MAY NOT PROVIDE COVERAGE
FOR ACCIDENTS INVOLVING THE USE OF THIS BICYCLE. TO
DETERMINE IF COVERAGE IS PROVIDED YOU SHOULD CONTACT
YOUR INSURANCE COMPANY OR AGENT.

3
Introduction
DANGER: Failure to properly assemble and maintain your bicycle
could result in serious injury or death to the rider.
This manual contains important safety, performance and service
information. The purpose of this Owner’s Manual is to help you use your
bike safely in the manner it is intended and allow you to enjoy the
benefits it offers for many years to come. Please read it before you take
the first ride on your new bike, and keep it for reference. If you have any
questions or do not understand something, take responsibility for your
safety and contact Orion RXB-E customer service at 817-350-4520 or
[e-mail]
ALWAYS WEAR A PROPERLY FITTED HELMET WHEN YOU RIDE YOUR
BICYCLE. DO NOT RIDE AT NIGHT. AVOID RIDING IN WET CONDITIONS.

4
A Few Words About Safety
Your safety, and the safety of others, is very important and
operating this electric balance bike safely is an important
responsibility.
You could be SERIOUSLY HURT if you
don’t
follow instructions.
You could be HURT if you don’t
follow instructions.
WARNING
Always use an
approved helmet
& protective gear
Never use on
public roads
Never carry
passengers
This section presents some of the most important information
and recommendations to help you ride your electric balancer
safely.
Please take a few moments to read these pages. This section also
includes a special message for parents and location information for the
safety labels on your electric balancer.

5
Electric Balancer Pre-
Riding Safety
CAUTION: For your safety you must carefully read this manual and
follow its instructions. Your bicycle may come with additional instruction
sheets that cover features unique to your bike. Please ensure that you
read and become familiar with their contents and retain them with this
manual for future reference. Remember bicycles, in most areas, are
subject to the same laws, rules, and regulations as motor vehicles.
Always wear a Certified helmet when riding your bike. Learn
and follow local and state traffic use laws.
Any major service or adjustments on your bike not covered in this
manual should be carried out by a professional bicycle mechanic. If you
wish to make adjustments yourself, this manual contains important tips
on how to do it.
CAUTION: Any adjustments you make are entirely at your own risk. Do
NOT use your bike for freestyle and stunt riding, jumping or competitive
events. Do not ride your bike when any part is damaged or not working
properly. You must, for your safety and the safety of other users, consult
a professional bicycle mechanic for any questions on repairs or
maintenance.
WARNING: As with all mechanical components, the bicycle is
subjected to wear and high stresses. Different materials and
components react to wear or stress fatigue in different ways. As your
bicycle ages, you should inspect it more frequently to look for deformed,
cracked, bent, or loose components. Such conditions may lead to
sudden failure. This may possibly cause injuries to the rider. If something
is cracked or broken,
do not ride until repairs have been made.

6
Electric Balancer Pre-
Riding Safety
BEFORE RIDING
1.
WARNING – ON AND OFF -ROAD CONDITIONS: The condition of the
riding surface is very important to your safety. If the surface is wet, or has
sand, leaves, small rocks or other loose debris on the surface where you
plan to ride, carefully decrease the speed of the bicycle and ride with
extra caution. It will take a longer time and more distance to stop. Apply
the brakes sooner and with less force. Always apply the rear brake first
allowing time and distance for it to take effect. Then follow by cautiously
applying the front brake, in order to maintain control of the bicycle. Rapid
front brake application first may cause a front pitch over or fall. Learn to
use your brakes properly under controlled conditions until you learn
proper braking under all road conditions.
2.
NOTICE: State and federal regulations require a full set of
reflectors. Some state and local laws may require that your bike be
equipped with a warning device, such as a horn or bell and most
states require a
light. The manufacturer and many legal authorities DO NOT approve or
encourage riding at night. Vision is quite limited at dawn, dusk and at
night for bike riders, motorists and by-standers. If you must ride at night,
take extra precautions, use front and rear lights, wear flashers on your
arms, wear light-colored clothing, and plan your route to ride in well
lighted areas avoiding heavy traffic areas.
3.
NOTE: Always wear shoes when riding a bicycle and avoid loose
fitting clothes. Wear a cuff band or trouser clip to keep pants or other
loose clothing from getting caught in the chain wheel. Long sleeves, long
pants, gloves, eye protection, a DOT/CPSC approved helmet, elbow and
knee pads are recommended. Helmet use is required by law in many
states and is always a good idea for your safety.

7
Electric Balancer Pre-
Riding Safety
4.
CAUTION: WET WEATHER WARNING: Check your brakes frequently.
The ability to stop is critical to your safety. Roads are slippery in wet
weather so avoid sharp turns and allow more distance for stopping.
Brakes become less efficient when wet. Leaves, loose gravel and other
debris on the road can also lengthen stopping distance. If at all possible,
do not ride in wet weather. Vision and control are impaired, creating a
greater risk of accidents and injury.
5. CAUTION: A bicycle rider’s best defense against accidents is to be
alert to road conditions and traffic in the area. Do not wear anything that
restricts your vision or your hearing.
6.
When riding, ALWAYS WEAR A APPROVED BIKE HELMET . It may save
your life.
7. Obey all traffic regulations. Most traffic regulations apply to bike riders
as well as automobile operators. Observe all state and local traffic
regulations, signs and signals. Check with your local police station on
bicycle licensing and inspection, and where it is legal to ride your bike.
8.
ON AND OFF ROAD OPERATION: Avoid the following road hazards: drain
grates, pot holes, ruts, soft road edges, gravel, leaves (especially when
they are wet), uneven pavement, railroad crossings, manhole covers,
curbs, speed bumps, puddles, and debris as all have an effect on your
riding and may result in loss of control. Adjust your speed and the way
you use your brakes if you must ride in such areas.
9. If any components become loose while riding, (STOP!!) immediately
and tighten, or bring to a mechanic for repair.

8
Electric Balancer Pre-
Riding Safety
TO AVOID INJURY, THIS PRODUCT MUST BE PROPERLY ASSEMBLED
BEFORE USE. WE STRONGLY RECOMMEND THAT YOU REVIEW THE
COMPLETE ASSEMBLY GUIDE AND PERFORM CHECKS SPECIFIED IN
THE OWNER’S MANUAL BEFORE RIDING.
Just a minute spent before each ride can significantly improve your safety
and the enjoyment of your ride. EACH TIME before you ride make a habit
of performing the following safety checks:
•
Stand in front of the bicycle facing rearward and hold the front wheel
securely between your legs. Try to twist the handlebar and verify that they
do not move. Then pull the handlebars up, trying to lift the bike. There
should be no movement.
•
Try to push the front wheel from side to side and confirm that it feels
tight and will not wobble. Lift the front wheel up by the handlebars and
strike the wheel downward with the heel of your hand to confirm that it is
securely attached to the wheel. Spin the front wheel and confirm that it
does not wobble or contact the fork or brake pads.
•
Try to lift/push down on and twist the seat to confirm it is tight.
•
Look at the connection of the pedals to the crank arm. You should not
see pedal screw threads and the pedal should feel firm and be parallel to
the ground.
•
Apply your brake(s) and make sure they feel firm to the touch, and then
spin the wheel(s). Apply the brakes. The brakes should stop the wheel(s).
•
Check to be sure that the fenders and accessories (if equipped) are
firmly attached and will not contact any moving parts. Make sure all
reflectors are in position and not broken.
Now, put on your BICYCLE SAFETY HELMET and enjoy your ride. Your
safety is well worth just a minute. Also, be sure to read and follow the
warnings and instructions in this manual

9
Electric Balancer Pre-
Riding Safety
SAFETY EQUIPMENT
Orion RXB-E promotes the use of safety equipment during the use of your
electric balance bike; the following list is an advisory guideline of the
equipment that should be obtained before using your electric balancer for
the first time, and to be used for every ride regardless of experience and
skill level.
HELMET
A helmet is the most important piece of protective equipment
and should be worn at all times the electric balancer is being
ridden.
Ensure the helmet fits the operator snugly, is securely fastened
and provides good, all-round visibility. A poorly-fitting or loose
helmet can become dislodged in an incident and then offer no
protection at all.
EYE PROTECTION
Recommended to prevent eye injuries and prevent branches,
bugs, dust or sand hitting your face and distracting you.
Sunglasses are unlikely to provide adequate physical protection.
GLOVES
FOOTWEAR
CLOTHING
Sturdy footwear is recommended
Arms and legs should be covered to reduce abrasions to the
body, even in hot weather. Trousers should be close-fitting and
in good condition.

10
Message To Riders
Your safety is very important to Orion RXB-E. That’s why we urge you to
read this message before riding this electric balancer. You can help
prevent accidents by making good decisions about if, when, and how you
ride this electric balancer.
THINGS TO CONSIDER WHEN RIDING
The first decision you’ll need to make is whether you’re ready to ride.
Riding readiness varies widely from one person to another, and age and
size are not the only factors.
PHYSICAL ABILITY
An important consideration is that riders must be big enough to hold
the electric balancer up, get on, and comfortably sit on the seat with
both feet touching the ground. They should also be able to easily reach
and
work the brakes, throttle, and all other controls.
If you decide that you’re ready to safely operate this electric
balancer, make sure you carefully read and understand the owner’s
manual before riding. Also be sure that you have a helmet and
other appropriate riding equipment, and always wears it when
Operating the electric balancer or sitting on it.
SAFE AND RESPONSIBLE RIDING
When you put safety first, you can enjoy more peace of mind,
and you can enjoy more hours of safe off-road riding.

11
Loading, Accessories & Modifications
Orion RXB-E designed a rider-only electric balance bike. It was not
designed to carry a passenger or cargo. A passenger or cargo could
interfere with your ability to move around to maintain your balance
and control of the electric balancer.
In addition, exceeding the weight limits or carrying an unbalanced load
can seriously affect your bike’s handling, braking, and stability.
Adding accessories or making modifications that change this
electric balance bike design and performance can also make it unsafe.
Also, the weight of any accessories will reduce the maximum load the
electric balancer can carry
We recommend that you do not carry any cargo on this electric balancer.
ACCESSORIES & MODIFICATION
Modifying your electric balance bike or using non-Orion RXB-E accessories
can make your electric balance bike unsafe.

12
Loading, Accessories & Modifications
ACCESSORIES
We strongly recommend that you use only Orion RXB-E Genuine Parts and
Accessories that have been specifically designed or approved and tested
for your electric balance bike. Because Orion RXB-E cannot test all other
accessories, you must be personally responsible for proper selection,
installation, and use of non-Orion RXB-E accessories. Check with your
dealer for assistance and always follow this guideline:
Make sure the accessory:
- Does not reduce ground clearance and lean angle
- Limit steering travel
- Alter your riding position
- Interfere with operating any controls
MODIFICATIONS
We strongly advise you not to remove any original equipment or modify
your electric balance bike in any way that would change its design or
operation. Such changes could seriously impair your electric balancer
handling, stability, and braking, making it unsafe to ride.
We also advise you not to make any modifications or remove any equipment
that would make the electric balance bike illegal in your area.

13
Safety Labels

14
Important Information
FRONT WHEEL INSTALLATION:
The front axel is located in the tool kit. Please take a picture of it before you
install it. The washers and spacers are in the correct order. See pics below.
INSTALL THE FRONT AXLE IN THE ORDER SHOWN ABOVE
12in
16in

15
HANDLE BAR ASSEMBLY
Attach the
handlebars as
shown. There are 4
screws to assemble
or remove the
handlebar. The
Power S/W should
be at a 60-90 degree
angle, pointing
straight up. This
allows the small
riders to twist the
throttle all the way
open.

15
Operating and Riding the Electric Balancer
Please familiarize yourself with the components below.

16
Operating and Riding the Electric Balancer
1. Frame
2. Handlebar
3. Handlebar grip
4. Brake lever
5. Throttle
6. Front fork
7. Stem
8. Head Clamp
9. Front Wheel
10. Front axle
11. Charge Port
12. Footrest
13. Seat
14. Seat Post
15. Seat Clamp
16. Hub Motor
17. Rear Axle Nuts
18. Brake Caliper
19. Brake Disc
