Orion OSD-400 User manual

OSD-400/OSD-800/OSD-1600
Digital Video Recorder
Installation / User Manual

OSD-400/OSD-800/OSD-1600
Install & User Manual
-
Firmware 3.X
1
Warning
1. Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of Used Batteries
According to the Instructions
Important Notice
2. Do not place heavy objects on the top of the product.
3. This equipment is indoor use and all the communication wiring is limited to inside of the
building.
4. Product is for indoor use. It is not weatherproof. Use product with referring to its
environmental specifications (Temperature & Humidity). To clean the product, gently
wipe the outside with a clean dry cloth.
5. Product uses AC power of 110V ~ 240V. Be cautious not to cause electric damages to
product.
6. Be careful not to drop the product. Physical shocks may harm the product including
internal HDD. In addition, be sure the product is secured after installation.
7. Product is made of metal. Therefore you can hurt human beings if you throw it to them
or hit on them. When installing product, be cautious to locate on safe places where
children are unreachable.
8. If Product does not operate properly, please contact the closest Orion distributor for
after sales service. Tampering or disassembling the product will void the warranty.
9. Security surveillance laws may differ for each country. Therefore, please contact the
local region first to avoid any surveillance law violations.

OSD-400/OSD-800/OSD-1600
Install & User Manual
-
Firmware 3.X
2
10. Rack Mount Instructions - The following or similar rack-mount instructions are included
with the installation instructions:
11. Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the
operating ambient temperature of the rack environment may be greater than room
ambient. Therefore, consideration should be given to installing the equipment in an
environment compatible with the maximum ambient temperature (Tma) specified by the
manufacturer.
12. Reduced Air Flow - Installation of the equipment in a rack should be such that the
amount of air flow required for safe operation of the equipment is not compromised.
13. Mechanical Loading - Mounting of the equipment in the rack should be such that a
hazardous condition is not achieved due to uneven mechanical loading.
14. Circuit Overloading - Consideration should be given to the connection of the equipment
to the supply circuit and the effect that overloading of the circuits might have on
overcurrent protection and supply wiring. Appropriate consideration of equipment
nameplate ratings should be used when addressing this concern.
15. Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained.
Particular attention should be given to supply connections other than direct connections
to the branch circuit (e.g. use of power strips).
The content of this manual can differ according to firmware or Software upgrading, and the
standard and appearance of products may be changed for the improvement of quality without
an advance notice.

OSD-400/OSD-800/OSD-1600
Install & User Manual
-
Firmware 3.X
3
Contents
KEY FEATURES ........................................................................................................................... 8
INSTALL MANUAL ..................................................................................................................... 11
1 FEATURE.............................................................................................................................. 11
1.1 Supplied Accessories.................................................................................................... 11
1.2 Description & Function.................................................................................................. 12
1.2.1 Front .......................................................................................................................... 12
1.2.2 REAR ........................................................................................................................ 13
1.2.3 REMOTE CONTROLLER ......................................................................................... 14
2 INSTALLATION .................................................................................................................... 16
2.1 Installation and Connection........................................................................................... 16
2.1.1 Connecting & Running .............................................................................................. 16
2.1.1.1 Connecting camera................................................................................................ 16
2.1.1.2 Connecting monitor................................................................................................ 16
2.1.1.3 Connecting Audio................................................................................................... 17
2.1.1.4 Supplying Power.................................................................................................... 17
2.2 Running OSD menu...................................................................................................... 18
2.2.1 OSD menu configuration ........................................................................................... 18
2.2.1.1 Dialogue box to edit a word ................................................................................... 19
2.2.2 Setting remote controller ........................................................................................... 19
2.2.2.1 Setting ID of DVR .................................................................................................. 19
2.2.2.2 Selecting ID ........................................................................................................... 20
2.2.2.3 Operable range of remote controller...................................................................... 20
2.2.2.4 Loading the batteries into the remote controller .................................................... 20
2.2.3 Install examples......................................................................................................... 21
2.2.3.1 Basic configuration ................................................................................................ 21
2.2.3.2 Advanced configuration ......................................................................................... 21
2.2.3.3 External storage & Back up configuration ............................................................. 21
2.2.3.4 Internet/ Intranet configuration............................................................................... 22
2.2.4 Basic Setting ............................................................................................................. 22
2.2.4.1 Viewing Image ....................................................................................................... 22
2.2.4.2 Setting Date & Time............................................................................................... 23
2.2.4.3 Record Setting ....................................................................................................... 25
2.3 Connecting and configuring DIO ports.......................................................................... 26
2.3.1 Wire Handling............................................................................................................ 26
2.3.2 Inserting & removing wire.......................................................................................... 27

OSD-400/OSD-800/OSD-1600
Install & User Manual
-
Firmware 3.X
4
2.3.3
Connecting and configuring sensor........................................................................... 27
2.3.3.1 Specification .......................................................................................................... 27
2.3.3.2 Connecting relay and setting ................................................................................. 28
2.3.3.3 Connecting serial port............................................................................................ 29
2.3.3.4 Connection to external device via Serial port ........................................................ 32
2.3.3.5 USB Device Connection ........................................................................................ 34
2.3.3.6 Video In/Out connection ........................................................................................ 36
2.3.3.7 Audio In/Out connection ........................................................................................ 36
2.3.4 HDD........................................................................................................................... 36
2.3.4.1 HDD registration and format.................................................................................. 37
2.3.4.2 HDD Replacement................................................................................................. 37
2.3.5 Remote monitor and control...................................................................................... 38
2.3.5.1 Ethernet connection............................................................................................... 38
2.3.5.2 Network configuration ............................................................................................ 39
2.3.6 External device connection ....................................................................................... 40
2.3.6.1 eSATA Device Connection..................................................................................... 40
USER MANUAL .......................................................................................................................... 41
3 MENU USE ........................................................................................................................... 41
3.1 Menu Structure ............................................................................................................. 41
3.2 Function Menu .............................................................................................................. 41
3.3 Factory Reset................................................................................................................ 42
4 MONITORING ....................................................................................................................... 47
4.1 Basic Screen ................................................................................................................. 47
4.2 Single Full Screen Mode............................................................................................... 47
4.3 Multi Screen Mode ........................................................................................................ 47
4.4 Screen Description........................................................................................................ 47
4.5 Auto Switch Mode ......................................................................................................... 47
4.5.1 System Standard Mode............................................................................................. 48
4.5.2 User Sequence Mode................................................................................................ 48
4.6 Event Screen ................................................................................................................ 49
4.7 Zoom Screen Mode ...................................................................................................... 50
4.8 Pause/Freeze Live Screen............................................................................................ 50
4.9 PTZ Control................................................................................................................... 50
4.9.1 Pan/Tilt ...................................................................................................................... 52
4.9.2 Zoom/Focus .............................................................................................................. 52
4.9.3 Load Preset ............................................................................................................... 52
4.9.4 Save Preset............................................................................................................... 52

OSD-400/OSD-800/OSD-1600
Install & User Manual
-
Firmware 3.X
5
4.9.5
Auxiliary On ............................................................................................................... 52
4.9.6 Auxiliary Off ............................................................................................................... 52
4.9.7 Menu.......................................................................................................................... 53
5 PLAYBACK........................................................................................................................... 54
5.1 Playback Mode ............................................................................................................. 54
5.1.1 Playback on Standard monitor (16 / 9 division) ........................................................ 54
5.1.2 Playback function ...................................................................................................... 54
5.2 Search Mode................................................................................................................. 54
5.2.1 Time Search .............................................................................................................. 55
5.2.2 Schedule Search ....................................................................................................... 55
5.2.3 Event Search............................................................................................................. 56
5.2.4 Thumbnail Search ..................................................................................................... 57
5.3 Copy.............................................................................................................................. 58
5.3.1 CD/DVD..................................................................................................................... 58
5.3.2 RE4............................................................................................................................ 59
5.3.3 AVI ............................................................................................................................. 60
6 CONFIGURATION ................................................................................................................ 62
6.1 Recording Structure ...................................................................................................... 62
6.2 System Setup................................................................................................................ 62
6.2.1 Date/Time .................................................................................................................. 62
6.2.1.1 Time Setup............................................................................................................. 63
6.2.1.2 NTP Setup ............................................................................................................. 64
6.2.2 Disk............................................................................................................................ 65
6.2.2.1 Disk Manager......................................................................................................... 66
6.2.2.2 Disk Status............................................................................................................. 67
6.2.3 User Setup ................................................................................................................ 68
6.2.4 Utility.......................................................................................................................... 70
6.3 Network ......................................................................................................................... 74
6.3.1 xDSL.......................................................................................................................... 75
6.3.2 WRS .......................................................................................................................... 76
6.3.3 Radius ....................................................................................................................... 77
6.4 Device Setup................................................................................................................. 77
6.4.1 Camera Setup ........................................................................................................... 78
6.4.1.1 Title ........................................................................................................................ 78
6.4.1.2 Using Channel ....................................................................................................... 78
6.4.1.3 PTZ ........................................................................................................................ 79
6.4.1.4 AGC (Auto Gain Control) ....................................................................................... 79

OSD-400/OSD-800/OSD-1600
Install & User Manual
-
Firmware 3.X
6
6.4.1.5
Brightness/Contrast ............................................................................................... 79
6.4.1.6 Privacy ................................................................................................................... 79
6.4.2 Monitor Setup ............................................................................................................ 80
6.4.3 Audio Setup............................................................................................................... 81
6.4.4 Text Setup ................................................................................................................. 82
6.4.5 Serial Setup............................................................................................................... 84
6.4.5.1 PTZ Setup.............................................................................................................. 84
6.5 Event Setup .................................................................................................................. 85
6.5.1 Event Check .............................................................................................................. 85
6.5.2 Sync Event ................................................................................................................ 87
6.5.3 Motion Detection ....................................................................................................... 92
6.5.4 Sensor ....................................................................................................................... 93
6.5.5 Preset ........................................................................................................................ 93
6.6 Recording setup............................................................................................................ 94
6.6.1 Program setup........................................................................................................... 94
6.6.2 Manual/Schedule recording setup............................................................................. 96
6.6.2.1 Manual Recording.................................................................................................. 96
6.6.2.2 Schedule Setup ..................................................................................................... 96
6.6.2.3 Event recording setup............................................................................................ 98
7 WEB VIEWER ACTIVEX .................................................................................................... 101
7.1 System requirement.................................................................................................... 101
7.2 Login ........................................................................................................................... 101
7.3 User Setup .................................................................................................................. 102
7.4 Browser available........................................................................................................ 103
7.5 Monitor ........................................................................................................................ 103
7.5.1 Screen division and changing video position .......................................................... 103
7.5.2 Move to Playback .................................................................................................... 104
7.5.3 Channel On/Off ....................................................................................................... 105
7.5.4 Sensor Indication..................................................................................................... 105
7.5.5 Relay operation ....................................................................................................... 105
7.5.6 Using microphone ................................................................................................... 105
7.5.7 Event data ............................................................................................................... 106
7.5.8 Video Recording & Save saving.............................................................................. 106
7.5.8.1 Video Recording .................................................................................................. 106
7.5.8.2 Saving Video........................................................................................................ 106
7.5.9 Using PTZ ............................................................................................................... 107
7.5.10 Using Audio.......................................................................................................... 108

OSD-400/OSD-800/OSD-1600
Install & User Manual
-
Firmware 3.X
7
7.5.11
Closing Video Channel............................................................................................ 108
7.6 Playback...................................................................................................................... 109
7.6.1 Video Division & Changing Channel ....................................................................... 109
7.6.2 Image recording ...................................................................................................... 109
7.6.3 Printing .................................................................................................................... 110
7.6.4 Backup .................................................................................................................... 110
7.6.5 Web Monitor ............................................................................................................ 110
7.6.6 Channel On/Off ........................................................................................................111
7.6.7 Saving time & Checking Rec. Capacity....................................................................111
7.6.8 Searching Calendar..................................................................................................111
7.6.9 Functional function at the button of monitor............................................................ 112
8 JAVA WEB VIEWER........................................................................................................... 113
9 USER MANUAL FOR MOBILE VIEWER........................................................................... 114
9.1 Log-In page ................................................................................................................. 114
9.2 Monitoring page .......................................................................................................... 114
10 TROUBLE SHOOTING .................................................................................................. 116
11 AVAILABLE HDD........................................................................................................... 119
12 COMPATIBLE CD/DVD LIST......................................................................................... 119
13 SPECIFICATION ............................................................................................................ 119
14 PRODUCT SIZE ............................................................................................................. 122

OSD-400/OSD-800/OSD-1600
Install & User Manual
-
Firmware 3.X
8
KEY FEATURES
Monitoring Screen
Supports real live video with high resolution for each channel and variable display mode.
oReal H.264 Video
oVariable display mode
OSD-1600: 1/4/9/16 channel mode
OSD-800: 1/4/9 channel mode
OSD-400: 1/4 channel mode
oAuto Switching
OSD-1600: Composite x 2, VGA x 1
OSD-800: Composite x 2, VGA x 1
OSD-400: Composite x 2, VGA x 1
Audio Recording
Supports real-time audio input and recording
oSimultaneous 4ch audio input & recording available
oInput: 4Ch, Output: 1ch (Rear)
oSimultaneous audio recording and playback available
Recording
It supports 400ips recording at High-Resolution (4CIF) and available to record max. 5 seconds
before triggering an event. Also, convert function is available protecting privacy.

OSD-400/OSD-800/OSD-1600
Install & User Manual
-
Firmware 3.X
9
oH.264 Video recording with High-Quality
OSD-1600: CIF(360x240) 400ips
OSD-800: 2CIF(360x240) 240ips
OSD-400: 4CIF(360x240) 100ips
oSupprots manual & schedule recording
oVideo loss detection
oSupprots archiving event list event (Sensor, Video Loss, Motion detection,
Text)
oAvailable record Max 5 seconds before triggering an event per each channel
Search/ Playback
It supports variable and convenient functions for search & playback
oPlay back by time, date, Channel
oEasy and convenient search using mouse
oPre/post search from a freeze frame
oPlay back by Event (Sensor, Video Loss, Motion Detection, Text)
oEasy & convenient search using Remote Controller & Jog/Shuttle
Back up device
It is available to back up to DVD-R, CD-R, USB memory by user’s choice.
oSupprots various back up device: DVD-R, CD-R, USB memory
Network
It supports variable network like LAN, XDSL and easily control from remote site using PC client
viewer.

OSD-400/OSD-800/OSD-1600
Install & User Manual
-
Firmware 3.X
10
oE-mail notification through TCP/IP, DHCP in case of triggering an event
oLive monitoring form remote site (Whole screen or available to select quad
screen)
oAvailable to playback, recording, search and DVR management through
network viewer in PC.
oAvailable to record, search & playback by time from remote site.
oSupprots 10/100Mbps Ethernet/xDSL
oMultiple DVR connection
Etc.
oSupports User friendly GUI and mouse function
oEasy and simple firmware upgrade through USB memory
oRecorded data back up through USB port
oPTZ Control (SPEED DOME), PRESET fucntion
oAvailable to control up to 16 DVRs with one remote controller

OSD-400/OSD-800/OSD-1600
Install & User Manual
-
Firmware 3.X
11
Install Manual
1 Feature
1.1 Supplied Accessories
Unpack and check all the items as below

OSD-400/OSD-800/OSD-1600
Install & User Manual
-
Firmware 3.X
12
1.2 Description & Function
1.2.1 Front
Item Description
1 DVD-Multi (For
Back up)
Back up use for recorded data by DVD/CD media
2 Channel Button To select video input channel
3 Jog/ Shuttle STEP function control, Playback direction change,
Playback speed control
4
REC LED Displays recording status
COPY LED Displays copy status
HDD LED Displays HDD running.
NETWORK LED Displays network connection
EVENT LED Displays event detection
5 Power Turn on/ off power
6 MENU To enter menu
7 ESC To escape from menu or close pop-up window
8 REC To start or stop manual recording
9 MULTI To change DVISION in live or playback mode
10 SEQ To run or stop user sequence
11 COPY To enter copy mode
12 SEARCH To enter search mode
13 PTZ To start PTZ function or stop
14
FUNC To enter function mode
15 RELAY Manual On/Off button for relay

OSD-400/OSD-800/OSD-1600
Install & User Manual
-
Firmware 3.X
13
16 MON To change Monitor/ Stop
17 ◀ /REW To move or select in menu and change replay speed to
reverse direction in playback mode
18 ▼/STOP To stop replay in playback mode
19 ▶ /FWD To move or select in menu and change replay speed to
forward direction in playback mode
20 ▲/PAUSE To move or select in menu and pause live/ replay video
21 Enter/Play To enter playback mode or select menu
21 USB port Use connecting USB memory or Mouse
1.2.2 REAR
No. Input/ Output name Description
1 Power connector Socket for AC100V~AC240V power cord
2 CH1~16(8/4) BNC input for camera connection
OSD-1600: 16EA, OSD-800: 8EA, OSD-400: 4EA
3 Loop out BNC output(Loop) for camera connection
4 Monitor/ Spot BNC connection for monitor output
5 Audio Input(RCA) RCA connection for Audio input
6 Audio Output Speaker output terminal
7 Ground Ground between DVR & external device
8 Ethernet For network connection (RJ-45)
9 RS-232C RS-232C D-SUB

OSD-400/OSD-800/OSD-1600
Install & User Manual
-
Firmware 3.X
14
No. Input/ Output name Description
10 VGA OUTPUT Output for PC connection
11 Termination Ohm Termination Ohm for Com2, Com3
12 Relay/Serial Connection for Relay and Serial(RS-485)
13 Sensor IN Input for external sensor
14 eSATA External device connection (eSATA)
1.2.3 REMOTE CONTROLLER
It is available to use all functions of DVR. If several DVR are set with unique ID numbers, they
can be controlled with one remote controller. To use remote controller, it is necessary to set ID
first which want use. Keep pressing ID button repeatedly (Up to Max. 16 times) and use it
matching DVR & ID.
No. Item Description
1 ID To select Remote Controller ID
2 LOCK Not use

OSD-400/OSD-800/OSD-1600
Install & User Manual
-
Firmware 3.X
15
3 COPY To indicate copy menu, copy recorded data to USB
4 BACKUP Not use
5 RELAY ON To manually ON
6 RELAY OFF To manually OFF
7 SEQ Auto sequencing
8 MULTI To change division
9 ZOOM To run digital zoom
10 SEARCH To indicate search menu
11 CHANNEL BUTTON To select channel
12 SELECT Not use
13 +10 In case of selecting over 10
(+10 + 1)
14 MON Monitor
15 REC Recording
16 MENU Covert to menu screen
17 HELP Not use
18 ◀ /REW Move setting menu to left direction/REW
19 ▶ /FWD Move setting menu to right direction/FWD
20 ▲/PAUSE Move setting menu to top direction/PAUSE
21 ▼Move setting menu to bottom direction/STOP
22 ENTER/PLAY Menu selection/Playback
23 ENTER To select menu
24 EXIT To cancel setting, escape from menu
25 FAST REWIND( ◀◀ ) Speedy replay to reverse direction
26 REWIND PLAY( ◀ ) Replay to reverse direction
27 FORWARD PLAY( ▶ ) Replay to forward direction
28 FAST FORWARD
( ▶▶ )
Speedy replay to forward direction
29 STOP( ) To stop replay
30 STEP REVERSE( ◀ l) Replay to reverse direction by each frame
31 STEP FORWARD (l ▶ )
Replay to forward direction by each frame
32 PAUSE(ll) To freeze playback
33 P/T PAN/TILT Control
34 LOAD PRESET To read preset
35 AUX ON Auxiliary ON

OSD-400/OSD-800/OSD-1600
Install & User Manual
-
Firmware 3.X
16
2 Installation
2.1 Installation and Connection
2.1.1 Connecting & Running
2.1.1.1 Connecting camera
Connect CCTV camera to DVR with BNC cable as below
•The video type for all channels should be either NTSC or PAL, not be combined both
•DVR sets video signal’s impedance (75Ω) automatically. Impedance is set as 75 Ωbasically.
If connecting a device to video output, impedance will be “Hi-z” status.
•Video Type (NTSC/PAL) should be changed after booting DVR. The order of camera
recognition follows ch1 through Ch16 camera and 1st recognized camera type leads other
camera type.
2.1.1.2 Connecting monitor
Connect CCTV monitor to DVR with BNC cable as below;

OSD-400/OSD-800/OSD-1600
Install & User Manual
-
Firmware 3.X
17
2.1.1.3 Connecting Audio
Connect audio signal to DVR with using RCA cable or D-SUB as below;
2.1.1.4 Supplying Power
Connect power cable as below;
•When supplying power, DVR starts booting automatically.
•In order to cut off power, press power switch on DVR front during 5 seconds, then select
“YES” after appearing a pop-up window.
•For supplying power again, push the Power button.

OSD-400/OSD-800/OSD-1600
Install & User Manual
-
Firmware 3.X
18
2.2 Running OSD menu
2.2.1 OSD menu configuration
Press [MENU] in keypad of front to open the main menu;
Select one of menus to enter the configuration menu as below:
1. Main Menu: The selected tab is show in bright colour and the related sub-menu will be shown
left- below the tab. To move to the previous/next tab, use the [ ◀ / ▶ ] arrow buttons. To move to
a sub-menu press the [Enter] key.
2. Sub-menu: The selected sub-menu is shown as tab title and the related setting will be shown.
To move to the previous/next tab, use the [ ◀ / ▶ ▲/▼] arrow buttons. To move to the related
setting press [Enter]. To move to upper main menu, press [ESC] button.
3. Setting page: The selected tab is shown as orange, To move to the previous/next tab, use the
[ ◀ / ▶ ] or [▲/▼] arrow button and press [Enter] key for value setting. When setting value is a
word, a dialogue box to edit the word will be open. When setting value is number, it should be
Main
Sub Menu
Configuration

OSD-400/OSD-800/OSD-1600
Install & User Manual
-
Firmware 3.X
19
set with using [
◀ / ▶ ] or [▲/▼]. Press [ESC] button when the value is set and also [ESC]
button is available to upper sub-menu.
2.2.1.1 Dialogue box to edit a word
Dialogue box to edit a word is image shown as below; it is available to input both word and bumper.
.
Keep pressing [▲/▼], [ ◀ / ▶ ] arrow button until the word is looking for and press Enter. In case of
deleting input word press [], spacing words press [] button. To exit from dialogue box, press [Enter]
after finishing word input.
2.2.2 Setting remote controller
2.2.2.1 Setting ID of DVR
When controlling several DVRs with one remote controller, set Remote Control ID as follows;
1. Press the [MENU] button
2. [ ▶ ] Select “system” with using [ ▶ ] arrow button and press [Enter] or [▼] button
3. [▼] Select “Utility” with using [ ▶ ] arrow button and press [Enter] button.
4. Select “Remote Control ID” and press [Enter]
5. [ ◀ / ▶ ] Select a value using [ ◀ / ▶ ] arrow buttons and press [ESC]
6. Press the [ESC] button to return to the monitor mode.
