Orion OPE-11701 User manual

• 2012.11.20
Thank you for purchasing our MPDP.
Please read through this user's manual for safety before installing this product.
This product is manufactured for Multi Plasma display model only.
User’s Manual
OPE-11701
Orion e-Board Solutions
Innovative e-Board of New Conception
Address: 257-6, Gongdan-dong, Gumi-si, Gyeongsangbuk-do, Korea
Tel : [phone], Fax: [phone]
ORION CO., LTD.
www.oriondisplay.net
Innovative e-Board of New Conception
Orion e-Board Solutions

- 1 -
STAND UNITWALL UNITSCREEN CONFIG'GRAPHIC CONFIG'FRAME INSTALL'SENSOR CONFIG'OPERATION
If you fail to comply with the regulations for safety and proper use, fire
or injury may be caused.
Warning
Thank you for purchasing our e-Board.
This manual describes how to use the product and notes in use.
Please read the manual carefully before using it.
After reading this manual, please retain for future reference.
If you have any questions or a problem occurs, please contact either the company you purchased this product
from or an authorized service center.
※
Displaying static picture for an extended period of time may cause an burn-in effect.
To prevent electric shock, Do not remove cover.
No user serviceable part inside
Refer servicing to qualified service personal.
Guide Pin (4pcs)
Handle (2pcs)
RS-232C cable
Bolt (4pcs)
DVI-D cable Power cable
User's Manual Multi-Screen Control
System(MSCS)
Ferrite Core (1pc)
▶ The combination of Large Screen Display and Precise Touch Function realizes the Large
e-Board system.
▶ Every work you have to do with a mouse can be done by simple and easy touch actions.
▶ Your classroom will be turned into the cutting-edge digital classroom with variety of
multimedia.
The Features of e-Board
Supplied Accessories ( MPDP 1set)
※The ferrite core is used to shield the power cable from interference.
※When connecting a cable, open the ferrite core and clip it around the cable near the plug.
※The parts or the specications of the product may be changed for better quality without prior notice.
MAIN FRAME PC
(3Channel Output Port)
STAND
Optional Accessories
Warning
Innovative e-Board of New Conception e-Board
MPDP 1set
Supplied Accessories of e-Board
Frame Bottom (1ea)
Frame Top (1ea)
Frame Left (1ea) Frame Right (1ea)
Glass (1ea)
IR Bar (3ea)
Power cableUSBcable
Camera Module
Left Right
Pen
M8*10 bolt
(20ea)
M4*10bolt
(32ea)
Adhesive tape for
IR Bar (8ea)
Ball Driver + Driver
T-Wrench
Washer
(20ea)
Accessory Box Mask Cover Top Right (1ea)
Mask Cover Top Left (1ea)
Mask Cover Left (1ea)
Mask Cover Right (1ea)
Mask Cover Bottom Left (1ea)
Mask Cover Bottom Right (1ea)
REMOTECONTROL
ON OFF
INFO
A
SET
F1 F2 F3 F4
VIDEO
DVI PC 117" 84"
B
BROADCAST
IDSETTING
ON
OFF
1 2 3
4 5 6
7 8
0
9
MODEL
SELECT
MODESELECT
INPUTSELECT E-BOARD
CD Remote Controller

- 2 - - 3 -
STAND UNITWALL UNITSCREEN CONFIG'GRAPHIC CONFIG'FRAME INSTALL'SENSOR CONFIG'OPERATION
Notice to users
Class A digital device
It is a device designed for business purpose with a safety certicate for electromagnetic interference,
which user should be mindful of.
" Important Safety Instructions"
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including ampliers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your safety. If the provided plug does not t
into your outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specied by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long
periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate normally, or has been dropped.
The symbol in gure 21 shall be shown adjacent to the text of item 12 above.
NOTICE
1. To disconnect the apparatus from the mains, the plug must be pulled out from the mains socket,
therefore the mains plug shall be readily operable
2. WARNING - To reduce the risk of re or electric shock, do not expose this appliance to rain or moisture.
3. Apparatus shall not be exposed to dripping or splashing and no objects lled with liquids, such as
vases, shall be placed on the apparatus.
4. Use only a properly grounded plug and receptacle
5. "Warning" CAUTION – These servicing instructions are for use by qualied service personnel only.
To reduce the risk of electric shock, do not perform any servicing other than that contained in the
operating instructions unless you are qualied to do so.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol is intended to alert the user to the presence of uninsulated "dangerous
voltage" within the product's enclosure that may be of sufcient magnitude to
constitute a risk of electric shock to persons.
This symbol is intended to alert the user to the presence of important operating and
maintenance(servicing) instructions in the literature accompanying the appliance.
OPE-11701 Innovative e-Board of New Conception
e-Board

- 4 - - 5 -
STAND UNITWALL UNITSCREEN CONFIG'GRAPHIC CONFIG'FRAME INSTALL'SENSOR CONFIG'OPERATION
Contents
WARNING
※Please keep following instruction for panel protection without exception.......................................................8
※Handle with Caution.......................................................................................................................................................................9
※nstallation Cautions for e-Board............................................................................................................................................ 10
※Clearance for Ventilation ........................................................................................................................................................... 11
※Do not cover the vent hole for the fan................................................................................................................................ 12
※Cleaning and Maintenance....................................................................................................................................................... 12
※Open Structure ............................................................................................................................................................................... 13
※Caution for Installation work................................................................................................................................................... 13
※Safety Precautions ........................................................................................................................................................................ 14
※How to Install .................................................................................................................................................................................. 16
01_STAND UNIT
1. Safety notice for Stand installation...................................................................................................................................... 22
2. Stand & MAIN FRAME Assembly ........................................................................................................................................... 24
2.1. Assemble STAND FOOT and STAND COLUMN..................................................................................................................... 24
2.2. Assemble STAND COLUMN and STAND SUPPORT. ............................................................................................................ 25
2.3. Assemble the first MAIN FRAME for the lower row............................................................................................................. 26
2.4. Assemble the second MAIN FRAME for the lower row. ..................................................................................................... 28
2.5. Assemble the third MAIN FRAME for the lower row........................................................................................................... 29
2.6. Remove M6*70 bolt for temporary attachment. ................................................................................................................ 30
2.7. Assemble the first MAIN FRAME for the upper row............................................................................................................ 31
2.8. Assemble the second MAIN FRAME for the upper row...................................................................................................... 32
2.9. Assemble the third MAIN FRAME for the upper row.......................................................................................................... 34
2.10. Check the contacting surfaces of MAIN FRAMEs.............................................................................................................. 36
2.11. Remove the supporting plate of MAIN FRAMEs in the left and right columns.......................................................... 37
2.12. Fix the MAIN FRAMEs of the upper and lower rows with "Y-Axis Link." ....................................................................... 38
3. MPDP Installation. ....................................................................................................................................................................... 39
3.1. Check the height of ADJUSTER............................................................................................................................................... 39
3.2. Assemble the PEG and GUIDE PIN to the MPDP. ................................................................................................................ 40
3.3. Install the first MPDP set........................................................................................................................................................... 41
3.4. Install the second MPDP set .................................................................................................................................................... 42
3.5. Position the first and the second MPDP sets closely. ......................................................................................................... 43
3.6. Install the third MPDP set......................................................................................................................................................... 44
3.7. Install the fourth MPDP set. ..................................................................................................................................................... 45
3.8. Position the third and fourth MPDP sets closely. ................................................................................................................ 46
3.9. Install the fifth and sixth MPDP sets. ..................................................................................................................................... 47
3.10. Assemble the GUIDE PINs on the side of MPDP sets........................................................................................................ 48
4. MPDP Aignment ............................................................................................................................................................................ 49
4.1. Adjust the horizontality of the Fixed Center Column. ....................................................................................................... 49
4.2. Move the MPDP sets in the Left Column. ............................................................................................................................. 50
4.3. Move the MPDP sets in the Right Column............................................................................................................................ 51
4.4. Fix MPDP sets with FIX BRACKET UNIT.................................................................................................................................. 52
02_WALL UNIT
1. Safety notice for Wall installation ......................................................................................................................................... 56
2. Checking the location for installation. ............................................................................................................................... 58
3. Fixing Anchor and Bolt............................................................................................................................................................... 59
4. Installing the Wall Bracket ....................................................................................................................................................... 60
4.1. Install the Wall Bracket on the wall. ....................................................................................................................................... 60
4.2. Assemble the first MAIN FRAME for the lower row............................................................................................................. 61
4.3. Assemble the second MAIN FRAME for the lower row. ..................................................................................................... 63
4.4. Assemble the third MAIN FRAME for the lower row........................................................................................................... 64
4.5. Remove M6*70 bolt for temporary attachment. ................................................................................................................ 65
4.6. Assemble the first MAIN FRAME for the upper row............................................................................................................ 66
4.7. Assemble the second MAIN FRAME for the upper row...................................................................................................... 67
4.8. Assemble the third MAIN FRAME for the upper row.......................................................................................................... 69
4.9. Check the contacting surfaces of MAIN FRAMEs ................................................................................................................ 71
4.10. Remove the supporting plate of MAIN FRAMEs in the left and right columns.......................................................... 72
4.11. Fix the MAIN FRAMEs of the upper and lower rows with "Y-Axis Link." ....................................................................... 73
5. MPDP Installation. ....................................................................................................................................................................... 74
5.1. Check the height of ADJUSTER............................................................................................................................................... 74
5.2. Assemble the PEG and GUIDE PIN to the MPDP. ................................................................................................................ 75
5.3. Configure MPDP ID and make connections for all the necessary external devices and power................................ 76
5.4. Install the first MPDP set........................................................................................................................................................... 77
5.5. Install the second MPDP set .................................................................................................................................................... 78
5.6. Position the first and the second MPDP sets closely. ......................................................................................................... 79
5.7. Install the third MPDP set......................................................................................................................................................... 80
5.8. Install the fourth MPDP set. ..................................................................................................................................................... 81
5.9. Position the third and fourth MPDP sets closely. ................................................................................................................ 82
5.10. Install the fifth and sixth MPDP sets. ................................................................................................................................... 83
5.11. Assemble the GUIDE PINs on the side of MPDP sets........................................................................................................ 84
6. MPDP Alignment........................................................................................................................................................................... 85
6.1. Adjust the horizontality of the Fixed Center Column. ....................................................................................................... 85
6.2. Move the MPDP sets in the Left Column. ............................................................................................................................. 86
6.3. Move the MPDP sets in the Right Column............................................................................................................................ 87
6.4. Fix MPDP sets with FIX BRACKET UNIT.................................................................................................................................. 88
7. MAIN FRAME SPECIFICATION.................................................................................................................................................. 89
03_SCREEN CONFIGURATION
1. Input/Output Terminals ............................................................................................................................................................. 92
2. Set ID Switch Setting................................................................................................................................................................... 93
3. Control Signal Cable Connection .......................................................................................................................................... 94
3.1. Connection of RS-232C Cable................................................................................................................................................. 94
4. Setting and operation of MSCS software.......................................................................................................................... 95
4.1. MSCS Installation ....................................................................................................................................................................... 95
4.2. Start MSCS................................................................................................................................................................................... 96
4.3. Setting of COM Port .................................................................................................................................................................. 97
4.4. "New design/Last design" setting .......................................................................................................................................... 98
OPE-11701 Innovative e-Board of New Conception
e-Board

- 6 - - 7 -
STAND UNITWALL UNITSCREEN CONFIG'GRAPHIC CONFIG'FRAME INSTALL'SENSOR CONFIG'OPERATION
4.5. Multi-screen configuration...................................................................................................................................................... 99
4.6. Selecting the command transmission method................................................................................................................... 99
4.7. Screen Information.................................................................................................................................................................. 100
4.8. Power On/Off............................................................................................................................................................................ 101
4.9. Screen Formation.....................................................................................................................................................................102
04_GRAPHIC CONFIGURATION
1. Graphic card Configuration for batter image quality ...............................................................................................108
2. Hardware connection................................................................................................................................................................109
2.1. Daisy-Chain .............................................................................................................................................................................. 109
2.2. Graphic card connection ....................................................................................................................................................... 110
3. S/W Configuration ...................................................................................................................................................................... 110
3.1. Execute "NVIDIA Control Panel" ........................................................................................................................................... 110
3.2. Surround Configuration ........................................................................................................................................................ 113
3.3. Bezel Correction.......................................................................................................................................................................116
3.4. Change Resolution ................................................................................................................................................................. 119
3.5. Desktop configuration........................................................................................................................................................... 123
05_FRAME INSTALLATION
1. Check the parts information.................................................................................................................................................. 128
2. Installation...................................................................................................................................................................................... 129
3. Fix "Frame Bottom" to the bottom side........................................................................................................................... 130
4. Fix "Frame Right"......................................................................................................................................................................... 131
5. Front glass installation.............................................................................................................................................................132
5.1. Slide the front glass toward the right end.......................................................................................................................... 133
6. Fix "Frame Left" ............................................................................................................................................................................ 134
7. Fix "FrameTop"............................................................................................................................................................................. 135
8. Fix "IR Bar"....................................................................................................................................................................................... 136
9. Fix "Camera Module"................................................................................................................................................................. 137
10. Connector connection ...........................................................................................................................................................138
10.1. e-Board Connection Diagram.............................................................................................................................................138
10.2. Connecting the right Camera Module. ............................................................................................................................139
10.3. Connecting the left Camera Module................................................................................................................................. 140
10.4. Connecting the extension connectors. ............................................................................................................................141
10.5. Connecting IR Bar Right ...................................................................................................................................................... 142
10.6. Connecting IR Bar Left ......................................................................................................................................................... 143
10.7. Connecting Adapter Power Cord.......................................................................................................................................144
10.8. Connecting USB Cable .........................................................................................................................................................145
10.9. Connecting RS-232C Cable ................................................................................................................................................. 146
10.10. Connecting PC Power Control Connector .....................................................................................................................147
11. Fix Mask Cover (Bottom, Left and Right) ......................................................................................................................148
12. Touch Sensor Configuration................................................................................................................................................ 149
13. Fix Mask Cover Top...................................................................................................................................................................149
14. Front Panel...................................................................................................................................................................................150
06_SENSOR CONFIGURATION
1. Introduction .................................................................................................................................................................................. 152
1.1. Program Features ...................................................................................................................................................................153
2. Sideview...........................................................................................................................................................................................154
2.1. Selection of Camera ................................................................................................................................................................155
2.2. Aligning the Camera Tilt.........................................................................................................................................................155
2.3. Positioning the Light Bar........................................................................................................................................................ 158
2.4. Saving the Sideview Data ......................................................................................................................................................158
3. Detection......................................................................................................................................................................................... 159
3.1. Threshold...................................................................................................................................................................................159
3.2. Detection Range ......................................................................................................................................................................160
3.3. Auto Correction: Detection Line........................................................................................................................................... 166
3.4. Simple Detection .....................................................................................................................................................................166
3.5. Invert Detection ....................................................................................................................................................................... 167
3.6. Detection Sensitivity Measurement Graph........................................................................................................................168
3.7. Saving the Detection Data..................................................................................................................................................... 169
3.8. Additional function of Detection Graph.............................................................................................................................169
4. Bent Adjustment..........................................................................................................................................................................170
4.1. Bent Adjustment Process.......................................................................................................................................................171
4.2. Saving the Bent Adjustment Data........................................................................................................................................ 173
5. Touch Setting................................................................................................................................................................................. 173
5.1. Touch Area Margin...................................................................................................................................................................174
5.2. Touch Tap Timing .....................................................................................................................................................................174
5.3. Sensitivity of the Mouse Wheel / Zoom..............................................................................................................................175
5.4. Touch input mode setting......................................................................................................................................................176
5.5. Touch Area.................................................................................................................................................................................177
5.6. Saving the Touch Setting Data..............................................................................................................................................179
07_OPERATION
1. Flick Configuration on Desktop...........................................................................................................................................182
2. PC Bracket Connection.............................................................................................................................................................184
2.1. PC Bracket Connection Diagram ......................................................................................................................................... 184
2.2. Install PC Bracket ...................................................................................................................................................................184
2.3. Power Switch Connection......................................................................................................................................................185
2.4. Power Connector Connection...............................................................................................................................................186
2.5. RS-232C Connection .............................................................................................................................................................. 186
3. Remote Controller ..................................................................................................................................................................... 187
3.1. Button Names........................................................................................................................................................................... 187
3.2. How to use the Remote Controller ......................................................................................................................................188
4. MPDP Trouble shooting ..........................................................................................................................................................189
3.3. Before calling for service ........................................................................................................................................................ 189
4.1. About Plasma display panel .................................................................................................................................................. 190
5. Specification.................................................................................................................................................................................. 191
OPE-11701 Innovative e-Board of New Conception
e-Board

- 8 - - 9 -
WARNING
WARNING
PANEL
CUSHION
PANEL
•If you need to stand PDP, you must
use handles on the back and lean
over the PDP to avoid panel touches
ground or oor.
•If you need to lay down PDP as
face down position, please use
shock-absorbing pads under the
PDP.
•If you need to lay down PDP as face
up position, please be cautious for
falling objects on the surface of the
PDP.
※Please keep following
instruction for panel
protection without exception.
- This product can be damaged even with
minor impact for its nature.
Please keep following instruction to carry or
store the products.
Warning
PANEL PANEL PANEL
※Handle with Caution.
-Shock/Impact on the set's sides will result in
internal circuit damages.
-The edge/bottom of the panel are fragile.
Use shock-absorbing pads or rugs for laying
down the product.
•Please do not stand PDP alone. It
may fall or slip off and Panel can be
broken or damaged.
•Please do not lean over the PDP.
It may damage the bottom part of
the PDP.
•Please do not lean over the PDP
toward the edge part. It may damage
the edge part of the PDP.
Warning
WARNING
OPE-11701 Innovative e-Board of New Conception
e-Board

※Installation Cautions for e-Board.
Installation Cautions for e-Board
•The installation of e-Board requires extra caution, because the panels of e-Board can be
easily damaged even by minor impact.
•Minimum 20cm clearance from walls or ceiling must be secured for smooth ventilation
and the product must not be under air tight condition.
If it is installed at the air tight or near air tight places, improper ventilation causes
malfunctions and may shorten the product lifetime by rapid internal temperature rise.
•If it has to be installed at the place of improper ventilation, additional ventilation
openings or fans must be provided to maintain the internal temperature between 0~
35℃.
•For ground of e-Board and application devices, it should be connected as frame ground.
•Considering Max power consumption of e-Board, check the main electricity capacity.
Consideration for easier service
•When you design the exterior design for MPDP system, consider easier disassembly for
possible service occasion in the future.
•The sliding Universal Unit of ORION is recommended for easier service.
•If service people can step into the backside of MPDP system, it can greatly reduce time
and eort for service.
•In case of higher locations, consider the installation location and exterior design for
easier service.
- 10 - - 11 -
WARNING
WARNING
•When you install MPDP, make sure there is at least 20cm clearance for eective
ventilation and do not seal o MPDP sets.
If MPDP sets are installed at the locations of bad ventilation, the inner
temperature can be raised rapidly and it can cause frequent malfunctions and
rapid reduction of the product life.
※Ventilation space in front of MPDP must be furnished for heat dispersion.If the front space of MPDP
has to be sealed, there must be consideration for the heat dispersion in the rear side of MPDP.
※Clearance for Ventilation
OPE-11701 Innovative e-Board of New Conception
e-Board

- 12 - - 13 -
WARNING
WARNING
•Carefully install MPDP not to cover the fan air holes with any structural object.
If the holes are covered with anything, the inner temperature can be raised
rapidly and it can cause malfunctions.
•Regularly clean o the vent holes in the back of MPDP sets.
If the vent holes and the fan air holes are clogged with dust, it prevents the air
ow inside of MPDP sets.
It can cause rapid increase of the inner temperature and may cause
malfunctions.
Clean o the vent holes and the fan air holes with a vacuum cleaner regularly.
•The edges of the parts may be sharp. Please be careful not to hurt your head,
hand, or back during the installation work.
※Do not cover the vent hole for the fan
※Cleaning and Maintenance ※Caution for Installation work
Installation structure
DOWN
UP
IDSELECT
FANSTB PWRON
VIDEO
IN OUT
DVI-D
IN OUT
RS-232C
IN OUT
PC
IN OUT
SVCLAN
• Model Name : OPE-11701
• Voltage : AC~100 - 240V
• Current : Max. 4A
• Frequency : 50/60Hz
• Serial No :
MPDP
FCCVerified: Class "A"
Thisdevicecomplieswiththe Part 15 of the FCC Rules.
Operationissubjecttothe following two conditions :
1)Thisdevicemaynot cause harmful interference, and
2)Thisdevicemustaccept any interference received,
including interference that may cause undesired operation.
Topreventelectric shock,
Donotremove cover.
Nouserserviceable part inside Refer
servicingtoqualified service personal.
RISKOFELECTRICSHOCK
DONOTOPEN
CAUTION
CO.,LTD.
MadeinKorea
BZ03
FAN
Vacuum Cleaner
※Open Structure
It has to be handled with
care, because the panel
glass substrate is exposed
without side cover.
PANEL
MASTER FRAME
•Unlike consumer PDP product, the panel of MPDP is exposed without
any protective chassis.
•It needs extra caution to carry or install to prevent any impact.
OPE-11701 Innovative e-Board of New Conception
e-Board

- 14 - - 15 -
WARNING
WARNING
※Safety Precautions
yIf it operates abnormally, stop using it
immediately.
yDo not place any liquid-containing
container on it. If the inside is wet, it may
cause electric shock or fire.
yDo not put any foreign material into the
product. It may cause a failure or shorten
the life span.
yPlease refer to a specialized construction
company for installing stand or wall mount
unit. Otherwise, damage or injury may be
caused.
yDo not touch the device when lightning
strikes.
yDo not install in an unstable location
It may cause injury.
yAvoid any action to damage the power cord
or power plug. It may cause fire or electric
shock.
yDo not pull out the power plug with a wet
hand. It may cause electric shock.
yDo not exceed ratings of AC outlet
or extension cords. It may cause failure.
yDo not alter (or disassemble) the product. It
may cause electric shock since high voltage
is flowing inside.
yDo not install the product where it may
be exposed to direct sunlight or near any
heating device. It may shorten the product's
life span or cause failure.
yMake sure the product is not covered with
any object. If the ventilation hole is blocked,
the inside temperature may rise to cause
overheating resulting in fire.
yDo not pull out or hang down the
connection cable. It may damage the cord
to cause fire or electric shock.
yDo not lean against the product or keep it
leaned. It may cause injury or failure.
yDo not put it at any place with much
humidity, dust, oil, smoke or steam. It may
cause failure.
yPull out the power plug by holding the plug.
Otherwise, it may damage the power cord
to cause fire or electric shock.
yIf you do not want to use the product for a
long time, keep the power plug unplugged
to save electricity.
yThe socket-outlet should be installed near
the equipment and be easily accessible.
yDo not put any heavy object on it.
It may cause failure.
yDo not ride or step on the product It may
cause breakage when fallen down.
yWhen moving it, disconnect the connecting
cable. Otherwise, it may damage the cable
to cause fire or electric shock.
yInstall the product on safe and flat surface.
yDo not put candles on the product. If the
liquid flows inside the product. It may
cause electric shock or fire.
yDo not touch product’s front surface with
hand. Otherwise, the image quality can be
lowered.
yDo not poke the front screen with sharp
material. It may damage the screen and may
cause malfunction of the product.
OPE-11701 Innovative e-Board of New Conception
e-Board
※Please read and understand this manual fully before installation.
※Please hand over this manual to customers after installation and ask to read and keep this
manual for future use.

- 16 - - 17 -
WARNING
WARNING
※How to Install
How to assemble handles
1. Product is packed in a box as shown in Figure 1.
2. Please carefully remove the Packing Bag with a knife or a pair of scissors.
- Please check front and rear side before you cut the bag to prevent any damages on panel or set.
3. Please assemble handles with the bolts that are in the accessory box to the rear
side as shown in the figure.
Handles
Packing Bag
<Figure1>
<Figure3>
<Figure2>
<Figure4>
Panel protection
Panel
Master frame
MPDP
How to move MPDP
1. 2people hold each handle on product's back side.
2. It needs two people to carry or install this product.
- Please do not grab the panel, but grab bottom of master frame when you carry or install the products.
- Please use gloves when you carry or install the products.
※Attention :
-Do not remove the panel protection pad until a set is completely installed on a stand or a wall
hanger. Please carefully remove Panel protection pad to prevent any damages on the product .
-Please make sure to use panel protection when you move, carry or rent MPDP.
Handles
Panel protection
Panel protection
OPE-11701 Innovative e-Board of New Conception
e-Board
