Orion TV32LB2000(H) User manual

Operating Instructions
Before operating the unit, please read this manual thoroughly.
100Hz LED-TV
Model-No.:
TV32LB2000(H)
TV42LB2000(H)
TV46LB2000(H)
TV32LB2000H
TV42LB2000H
TV46LB2000H
3DH0114B_EN.indd 13DH0114B_EN.indd 1 5/12/11 9:45:35 AM5/12/11 9:45:35 AM

2
Features
Headphone Warning
Loud music can damage your hearing irreversibly, therefore do not set the volume to a high level when
listening through headphones, particularly for extended listening periods.
Battery notice (valid in EU only)
Look after our environment - contact your local authorities for advice on how to safely dispose of exhausted
batteries.The crossed out wheelie bin symbol indicates that used batteries should not be disposed of
with your normal household waste! A separate collection system for used batteries is in place to allow the
correct treatment and recycling in accordance with current legislation. Please contact your local authority for
details on collection and recycling schemes in your area.
DVB-C notice
The DVB-C reception possibly requires an additional contract with your cable supplier. A Smartcard
for the receipt of encrypted programmes comes with the contract. Programmes that do not come with the
contract will remain encrypted and not be viewed.
You receive DVB-C programmes with a CAM module of your cable network operator. You insert the CAM
module into the CI-Slot (refer to page 10) of this TV set. You insert the Smartcard into the CAM
module.
You can possibly receive a few unencrypted DVB-C programmes at your home location even without an
additional contract and without a CAM module. However, these programmes frequently reveal a poorer
image quality than the DVB-C-HD programmes that are subject to a charge. The image quality that is
frequently poor is a feature of the respective programmes.
Information for the DVB-T function
Any function relative to the digital television (with the DVB logo) is available only within the country or area
where such signals are transmitted.Verify with the salesman if it is possible to receive a DVB-T signal in
the zone where you live.
A DVB-T antenna must be connected for DVB-T reception.
Even if the television conforms to the DVB-T specifications, the compatibility to future digital DVB-T
transmissions is not guaranteed.
Some digital television functions may not be available in some countries.
The DVB-T system present in this device is FTA (Free to air).
Waste Disposal Tip
This symbol means that your electrical and electronic equipment should be disposed at the
end of its life separately from your household waste. There are separate collection systems
for recycling in the EU. For more information, please contact the local authority or your retailer
where you purchased the product.
•
•
•
•
•
•
•
•
100Hz-16:9-FullHD-LED-TV
Panel-Resolution: 1920 x 1080
DVB-C-HDTV-Tuner with CI(+)-slot
DV B -T-Tuner
Cable-analogue-Tuner
7-band Equalizer
Sensorkeys on TV-unit
•
•
•
•
•
•
•
Mechanical mains switch for 0.0W power
consumption
Auto Power Off after 4 hours with no
operation
•
•
Equipment connected to the protective earthing of the building installation through the mains connection
or through other equipment with a connection to protective earthing – and to a cable distribution system
using coaxial cable, may in some circumstances create a fire hazard. Connection to a cable distribution
system has therefore to be provided through a device providing electrical isolation below a certain fre-
quency range.
Utstyr som er koplet til beskyttelsesjord via nettplugg og/eller via annet jordtilkoplet utstyr – og er tilkoplet
et kabel-TV nett, kan forårsake brannfare.
For å unngå dette skal det ved tilkopling av utstyret til kabel-TV nettet installeres en galvanisk isolator mel-
lom utstyret og kabel-TV nettet.
Utrustning som är kopplad till skyddsjord via jordat vägguttag och/eller via annan utrustning och samtidigt
är kopplad till kabel-TV nät kan i vissa fall medföra risk för brand.
För att undvika detta skall vid anslutning av utrustningen till kabel-TV nät galvanisk isolator finnas mellan
utrustningen och kabel-TV nätet.
3DH0114B_EN.indd 23DH0114B_EN.indd 2 5/12/11 9:45:38 AM5/12/11 9:45:38 AM

3
Contents
* DVB and the DVB logos are trademarks of the DVB project.
* Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks
of Dolby Laboratories. (TV32...H/TV42...H/TV46...H)
* THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PER-
SONAL AND NON-COMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN COMPLIANCE
WITH THE AVC STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT WAS ENCODED
BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS
OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS
GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION MAY BE
OBTAINED FROM MPEG LA, L.L.C. SEE HTTP://WWW.MPEGLA.COM
*
HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks
of HDMI Licensing LLC in the United States and other countries.
Viewing distance
Your new FullHD-TV has been designed to display high-resolution HD-signals in the very best quality.
Currently the following HD-sources are available:
1. DVB-S2-HDTV satellite receiver
2. HDTV cable receiver
3. Blu-ray player.
Only above sources offer highest-quality HD-video at top-resolution, which your new FullHD-TV lets you enjoy
now. To play such signals at full resolution, it is necessary to connect the sources by HDMI-cable (not supplied).
The recommended closest viewing-distance for such HD-signals is: 1 meter.You may also watch from greater
distance, however you might not catch all the HD-video’s details.
Standard video
All other sources offer standard-resolution of max. 576 lines, e.g. analog & digital cable-TV, MPEG-2-DVB-T, DVB-
S-satellite receiver, DVD-Player, VHS, etc.
For all 16:9-videos the analog cable-TV transmits only 432 lines. For comparison: HD-sources deliver 1080
lines. Having more than twice the amount of lines, the HD-video looks a lot more detailed compared to analog
TV. Or vice versa: analog video supplies a very poor quality if viewed on FullHD-TVs. Thus the recommended
closest viewing-distance for analog cable-TV is: 3,00 meters.You may watch from a greater distance though.
If, however, you decide to watch such poor signal from a distance closer than recommended, you will notice the
signal’s inherent poor quality.
How to improve the analog cable-TV’s picture-quality.
Actually analog cable has a 60-year history and is now quite old-fashioned. Cable supplier will not improve the
analog-video-standard any more. However, you may upgrade to digital-cable-qualtiy for relatively low cost. Please
ask your cable-supplier for more detail concerning the low-cost trial-period, free digital receiver, etc.
Features.........................................................2
Contents ........................................................3
Important safety information...........................4
Location of controls........................................7
Remote Control..............................................8
Antenna connection.....................................10
Auto setup....................................................11
Selecting the input source............................12
On-screen Language Selection ...................12
Automatic channel scan...............................12
Manual channel scan...................................12
Channel list setting ......................................12
Basic Operation ...........................................13
Teletext ........................................................14
Remarks on DVB-T system ..........................15
Password Setup (Parental lock) ...................16
EPG (Electronic Program Guide) .................16
Picture size and resolution ...........................17
Picture format...............................................18
Other convenience functions .......................19
Media Operation ..........................................22
Media Browser.............................................22
Playable File Types ......................................23
PC connection .............................................24
Connecting an HDMI or a DVI device to the
HDMI input...................................................24
Connection to other equipment....................25
Troubleshooting table...................................27
Specifications ..............................................27
3DH0114B_EN.indd 33DH0114B_EN.indd 3 5/12/11 9:45:39 AM5/12/11 9:45:39 AM

4
Important safety information
This unit has been produced according to all current safety regulations. The following safety tips should safeguard
users against careless use and the dangers connected with such use.
Although this appliance has been carefully manufactured and rigorously checked prior to leaving the factory, as
with all electrical appliances it is possible for problems to develop. If you notice smoke, an excessive build-up
of heat or any other unexpected phenomena, you should disconnect the plug from the mains power socket
immediately.
Ensure that the unit is sufficiently ventilated! Never place next to or underneath curtains!
This set should be only be connected to an AC 220~240V / 50Hz mains power supply - do not attempt to
connect it to any other type of supply.
The apparatus must be connected to a main socket outlet with a protective earthing connection.
The socket-outlet must be installed near the equipment and easily accessible.
Any repairs must be carried out by qualified service personnel only.
Do not open this unit. A non-expert attempting to repair the unit could be dangerous and potentially cause a fire
hazard.
Keep away from rodents. Rodents (and also cockatiels) enjoy biting into electric flexes.
The animal can cause a short cut (fire hazard!) and receive a fatal electric shock.
Always hold plug when pulling out plug from power mains supply system. Do not pull on flex.The flex can
become overloaded and cause a short cut.
Never wet clean. Only use a damp cloth, the same as when cleaning furniture.
Do not submerge in or under water!
Set up unit so that no one is able to trip over the flex.
This unit is recommended to be installed on shock-free benches in order to avoid any danger from falling.
Take note that toddlers can pull the unit down from the table or cupboard by means of its flex. Children can hurt
themselves when doing this.
Do not use the unit near heat sources.The casing and flex could be damaged by the impact of heat.
Watch out for kiddies copying what adults do! Do not stick any objects through the vents!
The vents must remain open! No newspapers or covers should be put on the unit!
The remote control is not a toy! Toddlers could swallow the batteries. If a battery has been swallowed, please
seek out a doctor immediately.
The screen is made of glass and can break if damage is done to it. Be careful when collecting sharp-edged
glass splitters.
You could be hurt or the unit could be damaged.
If the unit is mounted on the wall, contact the shop where you purchased the unit for advice, and leave the
installation work to experts. Incomplete installation work can cause you injuries.
Taking fall-prevention measures
- If these measures are not taken, the unit can fall and you could be injured.
- Contact the shop where you purchased the unit to obtain full details of the measures.
When a TV stand is used,
- Ensure the unit is fully on the stand and placed in the centre.
- Do not leave the stand doors open.
- You could be hurt as a result of the unit falling or breaking, or your fingers being caught or jammed. Take extra
precautions if you have children.
Avoid placing the unit on any surfaces that may be subject to vibrations or shocks.
To protect the unit during a thunder storm unplug the AC power cord and disconnect the antenna. Caution: Do
not touch the antenna connector.
When you leave your home for a long period of time, unplug the AC power cord for safety reasons.
The unit becomes warm when in operation. Do not place any covers or blankets on the unit in order to prevent
overheating. The ventilation holes are not to be blocked. Do not set up near radiators. Do not place in direct
sunshine. When placing on a shelf leave 10 cm free space around the whole unit.
Make some space around TV (Correct shelf assembly).
The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as
vases, shall be placed on the apparatus.
Liquids spilled into the unit can cause serious damage. Switch the set OFF and disconnect the mains power
supply, then consult a qualified service person before attempting to use the unit again.
Please pay attention to the following instructions in order to avoid receiving a life-threatening electric
shock:
Protect against moisture. Never use in the bath or sauna.
Never use near a bath, shower or swimming pool.
Never use the unit if it has got wet. This can also mean condensation moisture, which occurs in the winter when
the cold unit is brought into a heated flat. Wait before operating the unit especially after it has been transported
in the winter, until the cold unit has adjusted to the room temperature.
Do not place any heavy objects on the flex. Electrical isolation could be damaged.
Never wrap insulating tape around damaged flexes or on damaged plugs. These should be repaired or replaced
by qualified service personnel.
Never use this unit if the cabinet is defective. Do not make provisional repairs if the cabinet is damaged - this
should be replaced by a new cabinet if necessary.
Unplug the unit from the mains power supply prior to the cleaning of the unit.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
3DH0114B_EN.indd 43DH0114B_EN.indd 4 5/12/11 9:45:39 AM5/12/11 9:45:39 AM

5
Important safety information
How to attach the stand
NOTE:
• Unplug the AC cord from the AC Outlet terminal.
• Before beginning this process, assure that TV is laid on a clean, safe, and cushioned space to avoid any
damage to the unit.
• Do not touch or press the TV-screen, glass might break under pressure.
• Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.
1) Place the TV on its front onto a table.
2) Align the stand’s bottom-plate (supplied) as seen here.
It will fit in only one direction.
3) Hold the unit and attach the stand slowly. Finally secure the bottom-plate with screws(included).
Dismantling the base
For wall mounting, the base must be dismantled. To do this, remove screws (N, see page 10) from the back.
Take off the base entirely.
NOTE:
To detach the stand, perform these steps in reverse order.•
TV32... TV42... / TV46...
Warning (TV46...)
To prevent injury, this apparatus should be securely attached to the floor/wall in accordance with
the installation instructions.
1. Please use two strong strings of the same length as distance (A) between the back of the unit and the wall.
2. Please tie the string to the place in the figure below.
A
Screw
Clamp
String
String
3DH0114B_EN.indd 53DH0114B_EN.indd 5 5/12/11 9:45:40 AM5/12/11 9:45:40 AM

6
WARNING
To prevent fire, never place any type of candle or open flame
on the top or near the TV set.
Moving the unit or carrying by hand
When the unit is moved a long way, unplug the power cord and disconnect the antenna, connecting
cables and any fall-prevention apparatus.
• Moving without doing so could result in damage to the power cord, a fire, electric shocks or injuries from
dropping the unit.
Ensure that unpacking and transfer of the unit is carried out by two or more people and that the unit
stays upright when doing this.
When the TV stand has casters, remove caster cups from the stand and push it while supporting the
unit.
• Ensure that you support the unit when the stand is pushed, as this can cause the unit to fall and you could
be injured.
• The appliance could leave indentations in wooden tables with extremely soft wooden surfaces due to its
heavy weight.
• Furniture polish could corrode and dissolve rubber feet. Black imprints could be visible on the table.You
should therefore only use TV benches, which have been constructed for this specific purpose.
Secure the casters when the unit is installed on a TV stand with casters.
• The stand can move and you could be hurt if the casters are not secured.
Remove casters when the stand is placed on a soft surface such as a mat and carpet.
The distance between eyes and the screen should be about 3 ~ 4 times as long as height of the screen.
• Viewing from too close a distance can cause strain for your eyes.
When installing the Monitor on a table, be careful not to place the edge of its stand.
• This may cause the Monitor to fall, causing serious injury to a child or adult, and serious damage to the
Monitor.
Possible Adverse Effects on LCD Screen: If a fixed (non-moving) pattern remains on the LCD screen for long
periods of time, the image can become permanently engrained in the LCD TV panel and cause subtle but perma-
nent ghost images.This type of damage is NOT COVERED BY YOUR WARRANTY. Never leave your TV on for
long periods of time while it is displaying the following formats or images:
• Fixed Images, such as stock tickers, video game patterns, TV station logos, and websites.
• Special Formats that do not use the entire screen.For example, viewing letterbox style (16:9) media on a normal
(4:3) display (Black bars at top and bottom of screen); or viewing normal style (4:3) media on a widescreen
(16:9) display (Black bars on left and right sides of screen).
Attention!
Cleaning instructions for your LCD TV.
Safety note:
Before you start to clean, switch the set’s power off completely and disconnect the plug from the mains power supply.
Be careful not to scratch the plastic coated front panel - it is highly vulnerable to accidental scratching (e.g. by
fingernails or other sharp items). (While cleaning, do not wear jewelry) that could cause surface scratching (such
as rings, wrist-watch, etc.). Use a lint-free cloth and pure water to clean with, but make sure the cloth is thoroughly
wrung out so that it is just damp and not soaking wet - also make sure that the cloth is free from any dirt that could
cause scratching to the surface.
Wipe the set clean using minimal pressure.
Do not use standard window cleaning fluid. Its alcohol / ammonia will dissolve the front window’s coating.
Never use solvent or thinner. Never use special cleaners which are designed for cleaning PC Monitors or CRT TVs.
Finally carefully rub dry with a clean dry lint-free cloth.
Do not use paper towels or tissues to clean the set - paper can disintegrate when wet or may leave a trail of dust
behind. Some paper can also be abrasive and scratch your screen.
Saving electricity
The backlight’s brightness (power) can be set manually to match the surrounding illumination. At bright daylight
the backlight’s full power is required to perform a brillant result. During lower illumination, e.g. at night, you set
a lower backlight-brightness (see p. 21). Figures lower than 10 reduce the brightness, save energy and offer
a dazzlefree fatigueless watching at night.
•
Important safety information
3DH0114B_EN.indd 63DH0114B_EN.indd 6 5/12/11 9:45:44 AM5/12/11 9:45:44 AM

7
Location of controls
Description of Indicators and Controls
1. Loudspeakers
2. (Standby/On) indicator: The LED indicator lights up red in standby mode, and blue in the power
ON mode.
3. Remote sensor
4. (Power)-key: Enter standby mode or turn on the power. Preparation: Connect power-cable to
AC220~240V/50Hz.Then turn on mains switch (9).
5. INPUT/ENTER button: Select input mode for TV/AV/COMPONENT/HDMI/PC. In Menu : Using as
ENTER button.
6. MENU button: To display the menu screen.
7. P (Channel) +/–/▲/▼buttons: Press +to change to a higher numbered channel set into memory.
Press –to change to a lower numbered channel set into memory. In Menu: Setting.
8. (Volume) +/–/◀/▶buttons / In Menu: Setting.
9.
Mains switch: Switch on/off power supply completely.
For complete disconnection from the mains power supply, remove the supplied power cable from the
socket.
To adjust the TV angle (TV42.../TV46...) :
You can adjust the TV angle of the TV-screen for 30° from horizontal angle. Hold the base of the TV while
adjusting the angle.
5
1
678
3
4
2
9 (TV42.../TV46...)9 (TV32...)
3DH0114B_EN.indd 73DH0114B_EN.indd 7 5/12/11 9:45:45 AM5/12/11 9:45:45 AM

8
Remote Control
Function Page
Enter standby mode or turn on the power 11
Display program information 13
Select an input source 12
Select picture format 18
Select channel
Select Teletext page
Enter password
13
14
16
Select between the available broadcast
audio
13
Display the EPG (Electronic Progr. Guide) 16
Activate menu 11
In menu, return 1 step / exit menu
Cursor buttons
Memorize
Channel List 13
Turn the sound on/off 13
Display the subtitle 13
Volume
Still picture
Hold the text page
13
14
Switches between the present channel and
the last selected channel
Sub Page selection
13
14
Change the TV channel or Teletext page up
or down
13
Teletext ON / TV+text / OFF 14
Reveal quiz page answers 14
Teletext enlargement 14
Sort channel 13
To enter Media Browser 22
This button is not effective to this product
Control buttons for USB - playback 22
Fastext/TOPtext buttons 14
3DH0114B_EN.indd 83DH0114B_EN.indd 8 5/12/11 9:45:45 AM5/12/11 9:45:45 AM

9
Remote Control
Install the batteries
Use batteries type UM4 (AAA-Size).
Do not use old or weak batteries.The remote control may not work properly with a weak voltage from such
batteries. Replace exhausted batteries with new ones. Never try to recharge normal batteries - this could
cause an explosion.
Note:
Exhausted batteries can leak corrosive electrolyte, which may cause damage to the remote
control - therefore remove exhausted batteries immediately.
Batteries should not be exposed to excessive heat such as sunshine, fire or the like.
1Open the battery
compartment. 2Install the batteries as shown below, ensuring the correct
polarity.
3Close the battery
compartment.
•
•
The remote control handset will not work properly in the following cases:
a) If bright sunlight directly beams onto the unit front. b) If an obstacle is placed between the unit and the
handset.
Z
Z
Z
Z
Z
Z
c) If the batteries have not been installed
according to their polarities.
d) If the batteries are weak.
Distance of Remote Control Operation
Transmitter window
Maximum distance approx. 5m
Remote sensor
Point the remote control
directly at the remote sensor. 30 30
3DH0114B_EN.indd 93DH0114B_EN.indd 9 5/12/11 9:45:49 AM5/12/11 9:45:49 AM

10
Antenna connection
Note: Before you connect other appliances:
To avoid potentially damaging your set, make sure all items are switched off and disconnected from the
mains power when you make the connections.
Arrange the desired connection.
When you have finished making the connections, reconnect the mains power to the unit and switch it
back on.
Connect your antenna as shown below (A). Connections to other equipment is explained further on
P.25,26. If you have problems with reception, consult a specialist of antenna.
•
•
•
CAM
(K) (N)
(H)
(I)
(J)
(E)
(F)
(M)
Back Side
(A) Antenna: Connect a DVB-T or DVB-C antenna if DVB-T or DVB-C is already available in your transmission
area. Or connect to an analogue cable connection.
The built-in tuner receives all analogue cable programmes and DVB-T/-C channels.
(B) HDMI/DVI1/HDMI2/3/4 input: See P.24.
(C) PC/DVI AUDIO input: See P.24.
(D) Scart socket: For the connection of scart cables. See P.25, 26.
(E) DIGITAL AUDIO output: digital output for DVB-T/-C sound (see page 26).
(F) C.I. slot: for DVB-T/-C-PayTV (if PayTV-provider supports this)
Note: Be sure to turn off the TV before inserting the CAM card into the C.I. slot.
(G) USB input: See page 22.
(H) HEADPHONE jack: Plug headphones with a mini plug (3.5 mm) into this jack.
(I) AV input: Input for analogue AV-Signal (Composite) See P.26.
Note: AV-AUDIO input is sharing with COMPONENT AUDIO input.
(J) COMPONENT input: See P.26.
(K) PC-INPUT: See P.24.
(L)
Power supply: Connect the supplied power cable to an AC 220-240V/50Hz mains power supply only - do
not attempt to connect it to any other type of supply. Never try to repair a damaged AC power cord with
isolation-tape - this should be repaired by a specialist or replaced. Do not let your pet loose near the cable.
Animals biting into the cable could receive a fatal electric shock, and could cause a hazard to others.
(M) Bracket holes: Fix a wall mounting bracket (not supplied) here.
(N) To hang the television on a wall, remove these screws and then remove a stand.
Before performing work spread cushioning over the base area to lay the TV on.
(O) Woofer: (TV42.../TV46...)
(C) (A)
(D) (B)
(G)
(B)
(L)
(O)
3DH0114B_EN.indd 103DH0114B_EN.indd 10 5/12/11 9:45:50 AM5/12/11 9:45:50 AM

11
Auto setup
The built-in tuner receives DVB-C, DVB-T and Cable-
analogue. At the first time you operate after the
purchase, “First time installation” menu will appear.
Preparation:
Turn on TV-unit (see P.7) and connect antenna.
1First time installation menu will appear.
Press or to select desired language.
Then press ENTER.
Welcome please select your language!
Bienvenue ! Veuillez choisir une langue.
Willkommen! Bitte wählen Sie Ihre Sprache.
Benvenuti.Selezionare la lingua.
Bienvenido, seleccione un idioma
Hoş geldiniz, lütfen dilinizi seçin!
Vitajte, vyberte prosím svoj jazyk!
Välkommen, välj ditt språk!
Bem-vindo, escolha o seu idioma!
Tervetuloa! Valitse kielesi.
Velkommen! Vennligst velg ønsket språk!
Vítejte! Vyberte jazyk!
Wbi ójj k!
English
Français
Deutsch
Italiano
Español
Türkçe
Slovenčina
Svenska
Português
Suomi
Norsk
Česky
Plki
First time installation Language Setting
2Press ◀or ▶to select your country. Then press
▼and select Scan Encrypted setting with ◀or
▶. Then press ENTER.
Country
Scan Encrypted
Welcome!
UK
Yes
First time installation
><
3Press or to select Home.
Then press ENTER.
Please select where the TV will be placed.
The picture will be optimised for the location.
Home
Store
First time installation TV Location
4If you cancel Auto Power Off (see page 21),
press or to select Off. Then press ENTER.
Your TV has been set to power off
after 4 hours of continuous viewing
If you want to change this settings, please choose Off.
This settings can also be changed in the MENU.
On
Off
First time installation Auto Power Off
5TV will search for Digital cable TV-channels at
first. Connect your DVB-C antenna now.
Select “Yes” and press ENTER to start an
automatic DVBC channel scan.
The tuning’s progress will be displayed for
confirmation.
Do you want to start an automatic DVBC
channel scan?
Yes No
Note:
Please be patient - the Auto Tuning process
can take several minutes to complete.
•
6When the tuning for Digital cable TV-channels
is completed, you will be asked if you want to
proceed to autotuning for Digital TV-channels. If
you wish to start autotune Digital TV-channels,
connect your DVB-T antenna. Then Select “Yes”
and press ENTER.
Do you want to start an automatic DVBT
channel scan?
Yes No
7When the tuning for Digital TV-channels is
completed, you will be asked if you want
to proceed to autotuning for Analog TV-
channels. If you wish to start autotune Analog
TV-channels, connect your Analog cable-TV
antenna. Then select “Yes” and press ENTER.
Do you want to start an automatic Analog
channel scan?
Yes No
8When the tuning is completed, Edit Channel
List will appear. Then press MENU to watch a
normal TV-screen.
Note:
To cancel the auto tuning, press RETURN during
the process.
You would like to repeat First time installation?
So, you proceed:
1. Press MENU.
2. Select “Installation”. Press ENTER.
3. Select “Reset TV Setting”. Press ENTER.
4. Select “Yes”. Press ENTER.
The TV-unit will turn off.
Now, you can start from the beginning.
•
•
3DH0114B_EN.indd 113DH0114B_EN.indd 11 5/12/11 9:45:52 AM5/12/11 9:45:52 AM

12
Selecting the input source
Press INPUT SELECT to view a signal from
another device connected to your TV, such as a
VCR or DVD player.You can select each input
source depending on which input jacks you used to
connect your devices.
To select the video input source, press INPUT
SELECT or / , then press ENTER.
On-screen Language Selection
1Select Settings (unless you have already
selected when the set was first switched
on) then press ENTER. Then press or to
select Language, then press ENTER.
Language
Parental
Conditional Access
Timer
Setup
2Press or to select Menu, then press ◀or
▶to select the desired language.
Preferred
- Audio
- Audio 2nd
- Subtitle
- Subtitle 2nd
English
English
English
English
Menu English ><
Language settings
3Press MENU to exit the menu.
Automatic channel scan
Warning! All previously saved channels are
deleted in Step 3. A new channel search then
starts automatically.
Preparation:
Make sure your antenna is connected to the antenna input
(see P.10). Select TV (see above). Then press MENU.
1Select Automatic channel scan option in
Installation menu
, then press ENTER.
2Select desired scan option, then press ENTER.
Digital Air
Analogue Air & Cable
Digital Cable
Guided Installation
Auto channel scan
3Confirmation screen will appear. If you start
automatic scanning, check your antenna
connection. Then select “Yes” and press
ENTER.
4When the scanning is completed, Edit Channel
List will appear. Then press MENU to watch a
normal TV-screen.
Manual channel scan
1Select Manual channel scan option in
Installation menu
, then press ENTER.
2Select desired Search Type in first line, then set
up other options and press ENTER to start the
scanning.
Search Type
Channel
Frequency
Signal quality:
Signal level:
100%
100%
Digital Air Scan
25
506000
Manual Search
><
Note:
If you need, perform Analog fine tune in Installation
menu.
•
Channel list setting
1Select Channel list menu, then press ENTER.
2Select desired option, then press ENTER.
Favourites
Active channel list
Edit Channel List
Channel list
< Edit Channel List >
Tag/Untag channel Tag/Untag All
Enter channel number Function
Filter
Select channel Return to previous menu Exit
Edit Channel List
OK
671. MNO
672. PQR
673. STU
674.TCM
679.VWXYZ
800. FRATV1
900. S42
901. S10
902. C11
903. C12
Move Delete Edit name Lock
Delete
0...9
RETURN MENU
◀▶
◀ ▶
ENTER
1 2 3 4
8 76
5
1Watch the selected channel
2In the right pop up window, input the channel
number that you want to move the selected
channel to.
3Delete the selected channel
4Change the name of the selected channel. In the
right pop up window, move the cursor with ◀or ▶,
then change the character with ▲or ▼.
5Lock the selected channel. Enter the pin code.
(0000 is the default pin code)
6You can sort the channel. Set up the filter options
appears in the right pop up window.
7Each time you press green button, you can tag or
untag all channels.
8Each time you press yellow button, you can tag or
untag the selected channel.
3DH0114B_EN.indd 123DH0114B_EN.indd 12 5/12/11 9:45:52 AM5/12/11 9:45:52 AM

13
Information display
Press . The program information will appear.To
cancel the program information, press again.
The following figure is an example of DVB-channel
reception.
1 FRATV1 00:00
Now: 00:00-01:00
FRATV1_MovingPicture
Next: 01:00-02:00
FRATV1_MovingPicture
▶◀ TV
█
/
▌▌
123
45
1Channel number/Channel name
2The icon that shows the content of the received
broadcasting is displayed.
3Current time
4Next event information of selected service
5Event information of selected service
Note:
If the current watching channel has more than
one audio language, you can change them with
AUDIO I/II.
You can select Subtitles ON or OFF with .
TV32...H/TV42...H/TV46...H: When a DVB-channel
with HE-AAC
audio is selected, the sound will
be output as PCM audio from DIGITAL AUDIO
COAXIAL output jack.
In case of bad reception, the stereo sound also
can be disturbed.
QuickView
button allows you to go back to the last
selected TV channel.
MUTE
Press . The sound will be cut off.
The muting can be released by pressing again
or +.
Still picture
Press FREEZE to make a still picture. To cancel the
still picture, press FREEZE again.
Note:
During still picture mode, PICTURE SIZE feature
is not available.
Note:
If the built-in tuner does not receive anything (e.g.
if no antenna is connected) during TV-operation,
then the TV-unit will change to standby after approx. 15
minutes.
•
•
•
•
•
•
< Favourites >
Favourite
671. MNO
672. PQR
673. STU
674.TCM
679.VWXYZ
800. FRATV1
900. S42
901. S10
902. C11
903. C12
Favourite List
Return to previous menu Tag/Untag All
Add/RemoveSelect channel
0...9
RETURN MENU
ENTER
Enter channel number
Exit
◀ ▶
Filter
Tag/Untag channel
Select a channel and press ENTER. A symbol
appears to the right next to the channel.The
channels desigated in the favourites’ list only
appear in this way.
< Active Channel list >
Active channel list
Digital only
Analogue only
Radio only
Text only
Favourites
TV only
Show all
Select an option and press ENTER. Press MENU
in order to leave the menu. Press ENTER.
The Channel list will be shown with the
selected option.
Basic Operation
Channel selection
Preparation:
You can sort the channel beforehand.
Press TV and then select desired sorting option.
Then press ENTER.
With the numbered buttons.
Example:
No. 2: Press 2.
No. 29: Press 2and within 2 seconds, press 9.
No. 929: Press 9, 2, 9same as above.
Press P + or –to change up or down a channel. This
takes approx. 3-4 seconds. If the auto search only
stored 5 stations, only these 5 will appear.
Channel List
The Channel List shows a list of all receivable
programmes.
Note:
You can sort the channel in Channel List beforehand.
(see Active Channel list above)
Press CH LIST to display the Channel List.
Press or to select the desired channel.
Press CH LIST to display the selected channel.
•
•
•
•
•
3DH0114B_EN.indd 133DH0114B_EN.indd 13 5/12/11 9:45:53 AM5/12/11 9:45:53 AM

14
Teletext
Teletext is sent page by page. This unit is able to
automatically store up to 1000 pages, but they can
only be accessed once they have been stored.This
can take a few moments.
The TELETEXT menu allows the installation of
the teletext language.
The languages displayed are only those
supported by the channel. In Germany this is
usually GERMAN.
Fastext/TOPtext
The Fastext/TOPtext is teletext with a special
directory.
On the lower part of the screen there are four
different coloured fields (red, green, yellow and
blue). These fields lead directly to the pages
shown within.The coloured buttons on the remote
control correspond to the coloured fields. Press the
appropriate coloured button in order to activate the
desired colour field.
Switch on / off Teletext
Teletext is not transmitted by all channels.
Select a channel that shows teletext.
Press .You will now see a teletext page.
(If “100” is shown without any text information, it
may mean that the channel you have selected does
not support teletext.)
Press again. The TV-screen will be split into two
and both Teletext information and actual broadcast
will be displayed at the same time.
Press again in order to switch off teletext.
Press again in order to switch on teletext again.
The last page which was stored is now shown.
Note:
You cannot select any other channels as long as
teletext is switched on. Switch teletext off when
you want to switch over to another channel.
•
Select Page
Press P+or –until the page you desire appears. Or
... enter the requested page number by using the 10
Number Buttons.
And if you mistype something, just enter the
complete 3-digit wrong page number then enter
the desired number again. Or ... press one of the
coloured teletext buttons so that a page from
Fastext/TOPtext is shown.
Hold Pages
Some pages are divided up into subpages by the
channel.
Subpages are automatically shown in turn, as they
are transmitted. In order to hold the page, press .
Press again in order to display the next subpage.
Directly Select Subpages
You can directly select the subpages if required.You
may use one of two operations.
Each time you press , the subpage will
advance.
Enlargement
In order to enlarge the display, press .
Either the upper or lower half of the screen is
enlarged.
Each time you press you switch between the
display of the upper or lower half of the screen or
the full picture.
Answering Quiz Questions
Some pages contain quiz questions with concealed
answers.
Press in order to show the answers.
3DH0114B_EN.indd 143DH0114B_EN.indd 14 5/12/11 9:45:53 AM5/12/11 9:45:53 AM

15
Remarks on DVB-T system
DVB-T is at present still being developed.You can get information regarding the current stage of development
on http://www.ueberall-tv.de or from your specialist retailer.
As a digital service DVB-T basically works differently to previous analogue TV reception.
Reception Possibilities:
In contrast to cable TV, DVB-T is received via room or roof antennas. A room antenna is sufficient for reception
within the reception area of a DVB-T transmitter. A roof antenna may perhaps be necessary for reception in a
fringe area. Existing roof antennas may have to be turned in a different direction.
Contact your specialist retailer or go to http://www.ueberall-tv.de to find out about the location of the reception
areas or fringe areas.You cannot get DVB-T reception outside the fringe area. Ask a certified antenna specialist
for advice on interference with reception.The tuner of this appliance cannot provide active room antennas with
operating voltage. Active room antennas have to be equipped with a separate power supply.
Reception Quality:
DVB-T reception principally either works really well or not at all.There is not a smooth transition with a constant
reduction in reception quality. Digital interference occurs at maximum reception range:
the image freezes, the picture becomes blocky, the sound breaks up or reception cuts out altogether at times. If
you notice interference with DVB-T reception then this is usually not due to a fault on the TV appliance. Please
contact an antenna specialist if you have interference with reception.Inspection of the quality of DVB-T reception
is not included in the free warranty to be provided by the manufacturer of the TV appliance.
Image and Sound Quality:
An individual transmitter transmits up to 4TV channels on one transmission frequency.This is possible through
compression in accordance with the MPEG standard, which is similar to digital data storage on a DVD. The
data rate of DVB-T is just a lot lower; at present the max. video bit rate is approx. 4Mbps and the max. audio bit
rate is at 256kbps.Visible interference (e.g.blocky picture) can result at extremely low data rates despite there
being excellent reception quality within vicinity of the transmitter. Blocky pictures are no fault of the receiver.
They are the result of the low data rate transmitted. The digital DVB-T sound can be transmitted to the digital
amplifier via the digital output of your TV set.
Image Format
Images are transmitted in 4:3 format, 4:3 letterbox format (with black bars above and below the picture) and
anamorphic 16:9 format (without black bars).The max. transmitted resolution at present is 704x576.
Encryption
Encryption is basically possible, but no DVB-T channels are as yet encrypted. A CAM module and an access
card are necessary to receive encrypted channels.You can get CAM modules from your specialist retailer and
access cards from the respective broadcasting company. The CI slot in this appliance accepts CAM modules
and therefore allows for the reception of encrypted channels. Please note: Pay TV providers are basically free
to choose their encryption system. Although this TV set is manufactured according to DVB standards, it can
be that a set-top box is nevertheless required to receive the desired pay TV channels. These are available
from the pay TV provider.
Child Lock
Like DVDs, DVB-T offers can also provide age-restricted access. At the moment, no channels are equipped
with this restriction.This appliance does, however, already offer the feature of setting up password protected
age restrictions, which only work when the respective programmes are broadcast.
DVB-T Update
The DVB-T norm earmarks the transfer of firmware updates. The transfer of firmware updates is called Over
Air Download or OAD for short.
If this product happens to require a firmware update in future, this update could be received via DVB-T. If the
available software for updating is detected, the confirmation message whether start the software to download
is displayed. The rest please proceed to download-operation according to the directions of a TV screen.
EPG (Electronic Program Guide)
EPG is part of the DVB-signal with 8-days-schedule. This TV can receive and display the EPG-information
included into DVB. This TV’s EPG-Decoder will not work with Satellite-TV.
3DH0114B_EN.indd 153DH0114B_EN.indd 15 5/12/11 9:45:54 AM5/12/11 9:45:54 AM

16
Password Setup (Parental lock)
Parental lock is a function of the channel
provider. If it is not supported by the channel,
parental lock is without function. Currently there
are no channels supporting parental lock.
1Press MENU. Select Parental option in Settings
menu, then press ENTER.
2PIN code entering screen will appear. Press ‘0
0 0 0’ using the Number buttons (0-9). (This
is the default PIN code.)
3Select the desired option.
Menu lock: Press ◀or ▶to select desired lock
option.
Maturity Lock: Press ◀or ▶to select desired
parental rating.
Set PIN: Press ENTER to set PIN code.
New PIN
Enter your chosen new PIN code (please
call Service, if you have forgotten the new
number).
Confirm
After you have entered the new PIN code,
you need to enter the same PIN code again
for confirmation.
•
•
4Press MENU to return to the normal screen.
While toggling between channels, if a service which
has a parental rating (higher than your setting) is
selected, the channel will be locked.The PIN code
entering screen will appear. Then enter the PIN
code to view that channel.
EPG (Electronic Program Guide)
The Guide menu shows the available
programme listings for the next 8 days only,
including today.
1Press GUIDE (EPG) to display the Guide
menu.
Programme guide Sat 01/01 00:01
Channels Current Event Next Event
FilterTimeline ScheduleList Schedule
Details
INFO
Navigate Options
ENTER
1
2
673. STU
674.TCM
679.VWXYZ
800. FRATV1
900. S42
901. S10
902. C11
903. C12
904. S41
905. C21
906. C23
907. C29
673_STU_SDTV Moving_0820_0002_0003
No Information
679_VWXYZ_Monosco_0820_0002_0003
No Information
No Information
No Information
No Information
No Information
No Information
No Information
No Information
No Information
673_STU_SDTV Moving_0820_0003_0...
No Information
679_VWXYZ_Monosco_0820_0003_0004
No Information
No Information
No Information
No Information
No Information
No Information
No Information
No Information
No Information
0...9
Enter channel number
1Service list :
Lists all the services that are currently available.
As you scroll through the service list by
pressing or , the Event list will be refreshed
accordingly.
2Events list :
List the events in a grid of rows.
You can press / or ◀/▶to navigate through
the rest of the events.
Press ENTER x 2 to watch the selected event
or service.
You can use List Schedule (Green button),
Timeline Schedule (Yellow button) and Filter
(Blue button) options.
2From within the Events list, you can open
the Event detail for the currently highlighted
programme by pressing .
The Event detail shows the extended event
description of an event.
To return to the Events list, press .
To clear the menu screen, press MENU or
RETURN.
3DH0114B_EN.indd 163DH0114B_EN.indd 16 5/12/11 9:45:54 AM5/12/11 9:45:54 AM

17
Resolution and picture quality
Broadcast wide screen films in different resolutions. The following table shows the resolution options for
wide screen film broadcast media.
Broadcast media
Resolution of the wide
screen signal
Analogue
cable TV
Digital
cable TV
DVB-T Satellite
(DVB-S)
DVD HDTV
Satellite
(DVB-S2)
Blu-ray-
Disc
432i x 768 (Letterbox) Yes Yes Yes Yes Yes Yes No
576i x 768 (anamorphic) No Yes Yes Yes Yes Yes No
720 x 1280 (HD) No Yes No No No Yes Yes
1080i x 1920 (HD) No Yes No No No Yes Yes
1080p x 1920 (HD) No No No No No No Yes
Picture quality and black bars
Wide screen films come in different formats.The format is the relationship
between the width and height of the picture. For example, with a 16:9 film
the width to height ratio is 16:9 or 1.78:1. Only 16:9 films can fill a HD-
ready screen without black bars. Therefore, black bars are always visible
when a format other than 16:9 is received. E.g. 4:3, A 4:3 displays vertical
black bars to the right and left.
If a 4:3 picture is increased to 16:9 format then it either appears distorted
(see illustration) or some parts of the picture are cropped off at the top and
the bottom. This is completely normal and is not a fault in the wide screen
TV.
Super Cinemascope films are wider than 16:9 films.They are in the format
2.4:1 or 22:9, for example.This is clearly wider than16:9. Therefore, Super
Cinemascope films display black bars at the top and bottom on any HDTV
set.
Picture format and resolution
There is no connection between the picture format and the resolution received. For example, the Super
Cinemascope format can be received in all resolutions, even in the HD resolution1080ix1920. For HDTV
reception too an HDTV set may display black bars at the top and bottom.
4:3 picture 1:1 on
16:9 screen
4:3 picture zoomed on
16:9 screen
Picture size and resolution
Best picture quality is achieved when the input signal has a resolution of 1920 x 1080i. If a signal with a lower
resolution is input (e.g. analogue cable TV), there is a visibly poorer picture quality.
This is understandable as, if the same picture quality were available at a lower resolution, the broadcasting
companies would not need to take the trouble to send the signal at the higher resolution.
Why are there different resolutions?
Analogue cable TV uses a standardised TV signal. Each analogue 4:3- tube TV, however old it is, can process
this signal. That is the advantage of standardisation. The disadvantage is that the resolution has not changed
since the end of the Second World War.The resolution has been max. 576 x 768 for over 60 years.
For comparision: today’s TVs feature a FullHD-resolution of 1080 x 1920.
The analog cable-network offers the 16:9-format at a low resolution of only 432 x 768.This input covers only 16%
of a FullHD-screen’s area. 84% of the screen would stay black, if the TV would not make up the rest by some
special mathematics. 84% of what you see had been made up artificially by magnifying the tiny input-signal to
full-screen-size. That’s the reason for the analog cable-network’s low picture-quality seen on every FullHD-TV.
3DH0114B_EN.indd 173DH0114B_EN.indd 17 5/12/11 9:45:54 AM5/12/11 9:45:54 AM

18
Picture Size
The required picture format can be set by pressing
the PICTURE SIZE button. Press PICTURE SIZE
until the required format is displayed.
You move through the following formats when you
press the button: Auto, 4:3, 16:9, 14:9, Cinema,
Real (DTV/HDMI/PC mode only).
Auto
The picture is automatically only then shown in
a format-filling display when a WSS-TV signal is
received.
Note:
Auto is not available in Component mode.
Example:
If the analogue tuner receives a letterbox image with WSS
signal then the resulting image looks like this:
illustration 1:
Letterbox image is increased
WSS:
Public broadcasters include 16:9 identification,
the WSS signal (WideScreenSignalling), during
transmission in order to ensure automatic
conversion to 16:9.
Some private broadcasters do not transmit a WSS
signal. Automatic does not recognise anything
without WSS signal and does not automatically alter
the picture size. Use the PICTURE SIZE button to
set the required picture size for private channels.
•
Other formats
Press PICTURE SIZE until the desired size is
reached.
4:3
The picture is displayed in 4:3
format with black bars to the
right and left.
16:9
The width of the picture will be zoomed evenly.
16:9 is particularly suitable for DVD players, DVB-T,
DVB-C and satellite receivers, which can transmit
and show 16:9 feature films without black bars. In
the set-up menu of the set, adjust it to show that a
16:9 TV set is connected.
14:9
The picture is increased somewhat but not up to the
full screen width. Black bars remain on the right and
left and also at the top and bottom.
Cinema
Use Cinema to increase a small 4:3 letterbox signal.
How do you recognise whether the broadcasting
station / the set operating is using a 4:3 letterbox
signal that is too low? Press the PICTURE SIZE
button on the remote control until the 4:3 format
appears. If the picture is surrounded by a black
border as in the illustration, this is a 4:3 letterbox
signal. Limited by the broadcasting station / the
set operating, this signal is much too low for a
16:9 HD screen. Cinema increases this picture
that is too small as far as possible. Natural visible
poor focus emerges, rather as if a postcard were
being increased to poster size. This unfocused
appearance is conditioned by input signals that are
too low and is in no way a production fault in this TV
set.
4:3 Letterbox picture increased to Cinema format.
Real (DTV/HDMI/PC mode only)
All images are displayed on the
TV screen of 16:9 ratio without
overscanning.
Note:
In PC mode, the picture size feature is available
only for 16:9-, 4:3- or Real-format.
External receivers can automatically adjust the
picture size via a SCART cable. Please read the
instructions for the external receiver.
If you select Real, the image might become a
horizontal expansion according to the signal
format.
In this case, select an appropriate aspect with
PICTURE SIZE.
Cinema might not work with HDMI at 1080p24.
The picture might look distorted.
•
•
•
•
Picture format
3DH0114B_EN.indd 183DH0114B_EN.indd 18 5/12/11 9:45:55 AM5/12/11 9:45:55 AM

19
Other convenience functions
Selected Items Setup hint
Mode
Natural Recommended for viewing under normal ambient room
lighting conditions.
Cinema Recommended for watching movies in a darkened room
producing a cinema-like picture.
Dynamic Provides enhanced picture contrast and sharpness when
viewing in a bright room.
Contrast / Brightness / Sharpness / Colour You can adjust the picture to your preference.
Colour Temp
(available only when you selected the Mode except
“Cinema”)
Cool (Bluish) / Normal (Neutral) / Warm (Reddish)
Noise Reduction To set the level of decreasing noises included in the video
signal.
Off / Low / Medium / High
Film Mode You can set the TV to automatically detects the movie film
material and faithfully reproduces the original film image.
(Not available if Motion 100Hz is on (Low/Medium/High))
On / Off
FAROUDJA
(available only when you selected “Cinema” at Mode)
Active Contrast This function dynamically enhances contrast by analyzing
the several previous frames of input image.
Off/Low/Medium/High
Active Color 3D This item is to change the performance of advanced color
management feature. The gain and offset of hue, saturation
and luminance is adjusted by this feature.
Off/Low/Medium/High
Mpeg Noise Reduction This setting is the level of decreasing noises with preventing
degradation of image quality.
Off/Low/Medium/High
WB-Red / -Green / -Blue Gain To set manually the gain of R/G/B signal in video.
WB-Red / -Green / -Blue Bias To set manually the bias of R/G/B signal in video.
WB-Reset To reset the setting in FAROUDJA.
PC Position
Autoposition Automatic adjustment of VGA for optimal picture.
H Position (1360x768 /
1280x1024)
To adjust the horizontal placing of the image.
V Position To adjust the vertical placing of the image.
Dot Clock Eliminates the vertical (CLOCK) interfering lines.
Phase Eliminates the horizontal (PHASE) interfering lines.
Reset Select “Reset” to reset Picture options (except “Mode”) to
the factory preset values.
Sound
Equalizer You can choose a basic equalizer mode. Depending on this
setting, the following detail setting is set to default value of
each mode.
Music / Movie / Speech / Flat / Classic
/ User
100 ~ 10,000Hz
(available only when you selected
“User”.)
The setting of this item adjusts the audio level of its
frequency corresponding to each setting.
Balance You can adjust the Balance.
Headphone You can adjust the sound of headphone.
Volume / Balance / Bass / Treble
Sound Mode To change which of the left or right in the audio stream is
output.
Mono / Stereo / Dual I / Dual II
Surround To activate surround sound when receiving stereo
signals.
On / Off
Loudness This will automatically adjust volume.
On / Off
Reset Select “Reset” to reset Sound options to the factory preset
values.
3DH0114B_EN.indd 193DH0114B_EN.indd 19 5/12/11 9:45:55 AM5/12/11 9:45:55 AM

20
Other convenience functions
Selected Items Setup hint
Settings
Conditional Access You can access the Common Interface module
information from this menu option.
Language
Menu See page 12.
Preferred-Audio Select preferred audio language, if the current watching
DVB channel has more than one audio language.
This option is not available for analogue channel.
•
Preferred-Audio 2nd Select second preferred audio language, if the current
watching DVB channel does not have the language set
in Preferred-Audio option above. If the Preferred-Audio
2nd set here is not transmitted in the channel, the first
language included in the channel is selected.
Preferred-Subtitle Select preferred subtitle language, if the current
watching DVB channel has more than one subtitle
language.
Preferred-Subtitle 2nd Select second preferred subtitle language, if the current
watching DVB channel does not have the language
set in Preferred-Subtitle option above. If the Preferred-
Subtitle 2nd set here is not transmitted in the channel,
the first language included in the channel is selected.
Preferred-Analog Teletext Language First preferred Videotext area can be set here, which is
used in case that the currently viewed analogue channel
has more than one Videotext areas.
If the channel does not have the Videotext area set in
Preferred-Analog Teletext Language, the Videotext area
is displayed with first receiving area.
Preferred-Digital Teletext Language First preferred Videotext language can be set here,
which is used in case that the currently viewed DVB
channel has more than one Videotext Languages.
If the channel does not have the Videotext language set
in Preferred-Digital Teletext Language, the Videotext
language is displayed with first receiving language.
Current-Audio The audio language in current signal can be selected.
Current-Subtitle The subtitle language in current signal can be selected.
Current-Teletext The Teletext language in current signal can be selected.
Parental See page 16.
Timer Sleep timer switches the TV to standby after a defined
period of time.
To cancel the Sleep Timer, set to “Off”.
Sleep Timer
Off
10~120 minutes
3DH0114B_EN.indd 203DH0114B_EN.indd 20 5/12/11 9:45:55 AM5/12/11 9:45:55 AM
