ORTOLED QB-150W User manual

Instruction Manual
1. Delivery contents
- 1 x LED Grow Light Panel
- 1 x LED Driver Box
- 1 x Power Cable
- 2 x Hanging Kits
Please keep the instruction manual and desist from throwing it away. It might come in handy with
future troubleshooting.
Product Identification
150w Quantum Board
240w Quantum Board
320w Quantum Board

2. Product Structure
Knob Dimmer
LED Driver Box
Power In
p
ut
PCB
SMD LEDs

3. Product Datasheet:
3.1 Product specifications
Item QB-150W QB-240W QB-320w
AC Input AC 100-277V/50-60HZ
LED Source Seoul SMD2835 + SMD3535 LEDs
Driver Brand
Inventronic/Meanwell
LED Driver
True Power
Consumption 150w 240w 320w
PPF Efficiency 2.5 umol/J
Control 0-10V Dimming
Waterproof Level IP 65
Product Size 382*379*68.5mm 477*477*68.5mm 532*537.5*68.5mm
Net Weight 2.8 kg 4.0 kg 5.0kg
Working Tempt. -20°~ 40°
Working
Environment Damp Location Available
Warranty 3 Years Warranty

3.2 Spectrum
3. Application examples
•Grow farm •Greenhouse •Research
•Home grow •Warehouse •grow tent
4. Preparation
•Transportation
Improper transportation may harm or can even cause damage to LED lamp and power housing box). In case
of obvious damage or incomplete scope of supply, please refer to your vendor and Haulage company
immediately.
•Unboxing
Please handle and unbox the LED lamp with care! Check the delivery contents for completeness first. A
detailed list of the product range is contained on the inner cover in this manual.
Through transport or due to a long storage time, the LED-modules might get a little polluted. Therefore
we recommend to clean the modules before each use with a dry and soft tissue.

6. Operation
6.1 Safety measures & precaution
Warning! This LED fixture is powered with electricity (AC100-250V)! To prevent injury, we ask you to
desist from improper use!
•• Never open the case of the device! Health hazards await the consumer and the warranty of the device
expires.
6.2 Putting into service
Operate the LED fixture only horizontally, while hanging or slightly angled (approx. about 20°). Deploy the
LED lamp fixture about 15-50cm (at least 10cm!) above the top of the plants;
6.3 Proper use
Do not use the LED fixture vertically or as illumination device upside-down (direct eye contact and long
exposure over time may cause permanent damage to your eyesight!).
We don’t advise you to deploy the device as a room illuminant. It is exclusively designed and developed for
plant breeding, cultivation and hibernation. Please ensure that the LED fixture is being operated out of sight
and out of reach of children and animals to protect their eyes!
