Osburn MATRIX INBUILT User manual

READANDKEEPTHISMANUALFORREFERENCE
45642A
PrintedinCanada28‐02‐2013
INSTALLATIONANDOPERATIONMANUAL
MATRIX
INBUILT




YOUROSBURNMATRIXINBUILT
HASBEENTESTEDWITHOUR
ORIGINALOSBURNMATRIX
ZEROCLEARANCEKIT.THE
INSTALLATIONOFANYOTHER
ZEROCLEARANCEKITWILLVOID
YOURWARRANTY.

Distributedby
GlenDimplexAustralasia
NEWZEALAND
38HarrisRoad,EastTamaki,Auckland
Ph:092748265Fax092748472
Email:[e-mail]
www.glendimplex.com.au
AUSTRALIA
Unit1,21LionelRoad
MountWaverley,Victoria3149
Ph:1300566816Fax87873570
Email:[e-mail]
www.glendimplex.com.au

Thismanualisavailableforfreedownloadonthemanufacturer’swebsite.Itisacopyrighted
document.Re‐saleisstrictlyprohibited.Themanufacturermayupdatethismanualfromtimeto
timeandcannotberesponsibleforproblems,injuries,ordamagesarisingoutoftheuseof
informationcontainedinanymanualobtainedfromunauthorizedsources.

OsburnMatrixInbuiltInstallationandOperationManual
2_______________________________________________________________________________
THANKYOUFORCHOOSINGTHISWOODINBUILT
Wewanttocongratulateyouonyourpurchaseandwishtohelpyougetmaximumsatisfaction
fromyourwoodinbuilt.Inthepagesthatfollow,wewillgiveyouadviceonwoodheatingand
controlledcombustionaswellastechnicalspecificationsregardinginstallation,operationand
maintenanceofthemodelyouhavechosen.
Theinstructionspertainingtotheinstallationofyourwoodinbuiltcomplywith
AS/NZS4012/4013(1999)andAS/NZS2918:2001standards.
Pleasereadthisentiremanualbeforeyouinstallanduseyournewwoodinbuilt.Failureto
followinstructionsmayresultinpropertydamage,bodilyinjury,orevendeath.Itisimportant
thatyoufollowtheinstallationsguidelinesexactly.
Consultyourlocalcity,boroughorshirecouncilaboutrestrictionsandinstallations
requirementsinyourareaandtheneedtoobtainapermit.
Thisheatingunitisdesignedtoserveasasupplementaryheatsource.Werecommendthata
primaryheatsourcealsobeavailableinthehome.Themanufacturercannotberesponsiblefor
costsassociatedwiththeuseofanotherheatingsystem.

KEEPTHISINSTRUCTIONMANUALFORFUTUREREFERENCE.


OsburnMatrixInbuiltInstallationandOperationManual
_______________________________________________________________________________3
Tableofcontent
PARTA‐OPERATIONANDMAINTENANCE.............................................6
1SafetyInformation...........................................................................6
1.1SummaryofOperationandMaintenanceCautionsandWarnings......................................6
2GeneralInformation........................................................................7
2.1OSBURNMatrixSpecifications..............................................................................................7
2.2ZoneHeatingandHowtoMakeitWorkforYou..................................................................9
2.3TheBenefitsofLowEmissionsandHighEfficiency...............................................................9
2.4Osburn’sCommitmenttoYouandtheEnvironment..........................................................10
2.4.1WhatisYourNewWoodinbuiltMadeOf?.....................................................................10
3Fuel...............................................................................................11
3.1MaterialsThatShouldNotbeBurned.................................................................................11
3.2HowtoPrepareorBuyGoodFirewood..............................................................................11
3.2.1WhatisGoodFirewood?.................................................................................................11
3.2.2TreeSpecies.....................................................................................................................11
3.2.3LogLength........................................................................................................................11
3.2.4PieceSize..........................................................................................................................12
3.2.5HowtoDryFirewood.......................................................................................................12
3.2.6JudgingFirewoodMoistureContent...............................................................................13
3.3ManufacturedLogs..............................................................................................................14
4OperatingYourWoodinbuilt.........................................................15
4.1Theuseofafirescreen........................................................................................................15
4.2YourFirstFires.....................................................................................................................15
4.3LightingFires........................................................................................................................16
4.3.1ConventionalFireStarting...............................................................................................16
4.3.2TheTopDownFire...........................................................................................................16
4.3.3TwoParallelLogs..............................................................................................................17
4.3.4UsingFireStarters............................................................................................................17
4.4MaintainingWoodfires.......................................................................................................17
4.4.1GeneralAdvice.................................................................................................................17
4.4.2AshRemoval.....................................................................................................................18
4.4.3RakingCharcoal................................................................................................................18
4.4.4FiringEachNewLoadHot................................................................................................19
4.4.5TurningDowntheAirSupply...........................................................................................19

OsburnMatrixInbuiltInstallationandOperationManual
4_______________________________________________________________________________
4.5FanOperation......................................................................................................................20
4.5.1BuildingDifferentFiresforDifferentNeeds....................................................................20
5MaintainingYourWoodHeatingSystem.......................................23
5.1WoodinbuiltMaintenance..................................................................................................23
5.1.1CleaningDoorGlass.........................................................................................................23
5.1.2Dooradjustment..............................................................................................................24
5.1.3ReplacingtheDoorGasket...............................................................................................25
5.1.4ReplacingtheGlassGasketand/ortheGlass..................................................................25
5.1.5CleaningandPaintingtheWoodinbuilt..........................................................................26
5.2FlueandFlueLinerMaintenance........................................................................................26
5.2.1WhyFlueSystemCleaningisNecessary..........................................................................26
5.2.2HowOftenShouldYouCleantheFlueSystem?..............................................................27
5.2.3CleaningtheFlueSystem.................................................................................................27
PARTB–INSTALLATION.......................................................................28
6Pre‐Installationrequirements........................................................28
6.1MasonryFireplace...............................................................................................................28
6.2Zero‐ClearanceKit...............................................................................................................28
7SafetyInformation.........................................................................29
7.1SummaryofInstallationCautionsandWarnings................................................................29
7.2RegulationsCoveringWoodinbuiltInstallation..................................................................30
8ClearancestoHeat‐SensitiveMaterials..........................................31
8.1LocationoftheCertificationLabel......................................................................................31
8.2PositioningtheUnit.............................................................................................................31
8.3MinimumMasonryOpening,ClearancestoCombustibles,andFloorProtector...............34
9TheFlueSystem.............................................................................36
9.1General................................................................................................................................36
9.2SuitableFlueSystems..........................................................................................................36
9.3Linerinstallation..................................................................................................................36
9.4Fluelinerinstallation...........................................................................................................37
9.4.1Ifthefluelinerdoesalignwiththewoodinbuilt’sflueoutlet,youhavetwooptions...37
9.4.2Ifthefluelinerdoesnotalignwiththewoodinbuilt’sflueoutlet..................................38
9.5MinimumFlueSystemHeight.............................................................................................39
9.6TheRelationshipBetweentheFlueSystemandtheHouse................................................40
9.6.1WhytheFlueSystemShouldPenetratetheHighestHeatedSpace................................40
9.7Airqualityinthehouse........................................................................................................40

OsburnMatrixInbuiltInstallationandOperationManual
_______________________________________________________________________________5
Appendix1:ReversingtheDoorOpeningandAdjustingtheHandle.....41
Appendix2:InstallingtheAdapterforFreshAirKit(AC01298).............43
Appendix3:FaceplateInstallation.......................................................44
Appendix4:BlowerInstallation...........................................................46
Appendix5:InstallingtheFireScreen(AC01315).................................48
Appendix6:InstallationofSecondaryAirTubesandBaffle..................49
Appendix7:Removalinstructions........................................................51
Appendix8:ExplodedDiagramandPartsList.......................................52

REGISTERYOUWARRANTYONLINE
Toreceivefullwarrantycoverage,youwillneedtoshowevidenceof
thedateyoupurchasedyourwoodinbuilt.Keepyoursalesinvoice.
Wealsorecommendthatyouregisteryourwarrantyonlineat
http://osburn‐australia.com/warranty‐registration.aspx
Registeringyourwarrantyonlinewillhelpustrackrapidlythe
informationweneedonyourwoodinbuilt.


OsburnMatrixInbuiltInstallationandOperationManual
6_______________________________________________________________________________
PARTA‐OPERATIONANDMAINTENANCE
PleaseseePartBforinstallationinstructions.
1SAFETYINFORMATION
1.1 SUMMARYOFOPERATIONANDMAINTENANCECAUTIONSANDWARNINGS
•HOTWHILEINOPERATION,KEEPCHILDREN,CLOTHINGANDFURNITUREAWAY.CONTACT
MAYCAUSESKINBURNS.GLOVESMAYBENEEDEDFORWOODINBUILTOPERATION.
•USINGAWOODINBUILTWITHCRACKEDORBROKENCOMPONENTS,SUCHASGLASSOR
FIREBRICKSORBAFFLESMAYPRODUCEANUNSAFECONDITIONANDMAYDAMAGETHE
WOODINBUILT.
•OPERATEONLYWITHDOORFULLYCLOSEDORFULLYOPENWITHFIRESCREENINPLACE.IF
DOORISLEFTPARTLYOPEN,GASANDFLAMEMAYBEDRAWNOUTOFTHEOPENING,
CREATINGRISKSFROMBOTHFIREANDSMOKE.
•OPENTHEAIRCONTROLFULLYBEFOREOPENINGFIRINGDOOR.
•THISWOODINBUILTHASBEENTESTEDFORUSEWITHANOPENDOORINCONJUNCTION
WITHAFIRESCREEN(AC01315,SOLDSEPARATELY).THEDOORMAYBEOPENORFIRE
SCREENREMOVEDONLYDURINGLIGHTINGPROCEDURESORRELOADING.ALWAYSCLOSE
THEDOORORPUTBACKTHEFIRESCREENAFTERIGNITION.DONOTLEAVETHEWOOD
INBUILTUNATTENDEDWHENTHEDOORISOPENEDWITHORWITHOUTFIRESCREEN.
•NEVERUSEGASOLINE,GASOLINE‐TYPELANTERNFUEL(NAPHTHA),FUELOIL,MOTOROIL,
KEROSENE,CHARCOALLIGHTERFLUID,ORSIMILARLIQUIDSORAEROSOLSTOSTARTOR
‘FRESHENUP’AFIREINTHISWOODINBUILT.KEEPALLSUCHLIQUIDSORAEROSOLSWELL
AWAYFROMTHEWOODINBUILTWHILEITISINUSE.
•DONOTCONNECTTOANYAIRDISTRIBUTIONDUCTORSYSTEM.
•DONOTSTOREFUELWITHINHEATERMINIMUMINSTALLATIONCLEARANCES.
•BURNONLYSEASONEDNATURALFIREWOOD.
•THEUSEOFSOMETYPESOFPRESERVATIVE‐TREATEDWOODASAFUELCANBEHAZARDOUS.
•DONOTBURN:
oGARBAGEOFANYKIND,
oCOALORCHARCOAL,
oTREATED,PAINTEDORCOATEDWOOD,
oPLYWOODORPARTICLEBOARD,
oFINEPAPER,COLOREDPAPERORCARDBOARD,
oSALTWATERDRIFTWOOD,OR
oRAILROADTIES.
•DONOTELEVATETHEFIREBYUSINGAGRATEINTHISWOODINBUILT.
•THISAPPLIANCESHOULDBEMAINTAINEDANDOPERATEDATALLTIMESINACCORDANCE
WITHTHESEINSTRUCTIONS.

OsburnMatrixInbuiltInstallationandOperationManual
_______________________________________________________________________________7
2GENERALINFORMATION
2.1 OSBURNMATRIXSPECIFICATIONS

Combustible:Wood
Heatingcapacity*195m2
Maximumaverageheatoutput–hardwood(Australia):11.1kW
Averageefficiency–hardwood(Australia):68%
Averageemissions–hardwood(Australia):1.9g/kg
ApproximateBurnTime*6to8hours
Color: Metallicblack
FlueSpigotDiameter:150mm
Fluesystem: Tripleskinorliner
MinimumFlueHeight(fromfloorprotector):4.6meters
MaximumLogLength:508mmsideways**
Logloading:Sideways
FireboxVolume:0,068m3
Weight: 228kg
BaffleMaterialC‐Cast

*Burntimeandheatingcapacitymayvarysubjecttolocationinhome,fluesystemdraft,flue
systemdiameter,locality,heatlossfactors,climate,fuelsandothervariables.
**Sideways:throughthedooryouseethesidesofthelogs.

OsburnMatrixInbuiltInstallationandOperationManual
8_______________________________________________________________________________

 
 

OsburnMatrixInbuiltInstallationandOperationManual
_______________________________________________________________________________9

2.2 ZONEHEATINGANDHOWTOMAKEITWORKFORYOU
YournewOsburnMatrixwoodinbuiltisaspaceheater,whichmeansitisintendedtoheatthe
areaitisinstalledin,aswellasspacesthatconnecttothatarea,althoughtoalowertemperature.
Thisiscalledzoneheatinganditisanincreasinglypopularwaytoheathomesorspaceswithin
homes.
Zoneheatingcanbeusedtosupplementanotherheatingsystembyheatingaparticularspace
withinahome,suchasabasementfamilyroomoranadditionthatlacksanotherheatsource.
Housesofmoderatesizeandrelativelynewconstructioncanbeheatedwithaproperlysizedand
locatedwoodinbuilt.Wholehousezoneheatingworksbestwhentheinbuiltislocatedinthepart
ofthehousewherethefamilyspendsmostofitstime.Thisisnormallythemainlivingareawhere
thekitchen,diningandlivingroomsarelocated.Bylocatingtheinbuiltinthisarea,youwillgetthe
maximumbenefitoftheheatitproducesandwillachievethehighestpossibleheatingefficiency
andcomfort.Thespacewhereyouspendmostofyourtimewillbewarmest,whilebedroomsand
basement(ifthereisone)willstaycooler.Inthisway,youwillburnlesswoodthanwithother
formsofheating.
Althoughthewoodinbuiltmaybeabletoheatthemainlivingareasofyourhousetoanadequate
temperature,westronglyrecommendthatyoualsohaveaconventionaloil,gasorelectricheating
systemtoprovidebackupheating.
Yoursuccesswithzoneheatingwilldependonseveralfactors,includingthecorrectsizingand
locationofthewoodinbuilt,thesize,layoutandageofyourhomeandyourclimatezone.Three‐
seasonvacationhomescanusuallybeheatedwithsmallerwoodinbuiltsthanhousesthatare
heatedallwinter.

2.3 THEBENEFITSOFLOWEMISSIONSANDHIGHEFFICIENCY
ThelowsmokeemissionsproducedbythespecialfeaturesinsidetheOsburnMatrixfireboxmean
thatyourhouseholdwillreleaseupto90percentlesssmokeintotheoutsideenvironmentthanif

OsburnMatrixInbuiltInstallationandOperationManual
10______________________________________________________________________________
youusedanolderconventionalwoodinbuilt.Butthereismoretotheemissioncontrol
technologiesthanprotectingtheenvironment.
Thesmokereleasedfromwoodwhenitisheatedcontainsabouthalfoftheenergycontentofthe
fuel.Byburningthewoodcompletely,yourwoodinbuiltreleasesalltheheatenergyfromthe
woodinsteadofwastingitassmokeupthefluesystem.Also,thefeaturesinsidethefireboxallow
youtoreducetheairsupplytocontrolheatoutput,whilemaintainingcleanandefficientflaming
combustion,whichbooststheefficientdeliveryofheattoyourhome.
Theemissioncontrolandadvancedcombustionfeaturesofyourwoodinbuiltcanonlywork
properlyifyourfuelisinthecorrectmoisturecontentrangeof15to20percent.SeeSection3of
thismanualforsuggestionsonpreparingfuelwoodandjudgingitsmoisture.

2.4 OSBURN’SCOMMITMENTTOYOUANDTHEENVIRONMENT
TheOsburnteamiscommittedtoprotectingtheenvironment,sowedoeverythingwecantouse
onlymaterialsinourproductsthatwillhavenolastingnegativeimpactontheenvironment.
2.4.1 WHATISYOURNEWWOODINBUILTMADEOF?
Thebodyofyourwoodinbuilt,whichismostofitsweight,iscarbonsteel.Shoulditeverbecome
necessarymanyyearsinthefuture,almosttheentirewoodinbuiltcanberecycledintonew
products,thuseliminatingtheneedtominenewmaterials.
Thepaintcoatingonyourwoodinbuiltisverythin.ItsVOCcontent(VolatileOrganicComponents)
isverylow.VOCscanberesponsibleforsmog,soallthepaintusedduringthemanufacturing
processmeetsthelatestairqualityrequirementswithregardstoVOCreductionorelimination.
Theairtubesarestainlesssteel,whichcanalsoberecycled.
TheC‐Castbaffleismadeofanaluminosilicatefibrematerialthatiscompressedwithabinderto
formarigidboard.C‐Castcanwithstandtemperaturesabove1093°C(2,000°F.)Itisnot
consideredhazardouswaste.Disposalatalandfillisrecommended.
Firebrickismainlycomposedofsilicondioxide,alsoknownassilica,aproductprocessedfroma
minedmineral.Itismostcommonlyfoundinnatureintheformofsandandclay.Disposalata
landfillisrecommended.
Thedoorandglassgasketsarefibreglasswhichisspunfrommeltedsand.Blackgasketshavebeen
dippedintoasolvent‐freesolution.Disposalatalandfillisrecommended.
Thedoorglassisa5mmthickceramicmaterialthatcontainsnotoxicchemicals.Itisbasically
madeofrawearthmaterialssuchassandandquartzthatarecombinedinsuchawaytoforma
glassathightemperatures.Ceramicglasswillnotre‐meltinthesamewayasnormalglass,soit
shouldnotberecycledwithyourregularhouseholdproducts.Disposalatalandfillis
recommended.

OsburnMatrixInbuiltInstallationandOperationManual
______________________________________________________________________________11
3FUEL
3.1 MATERIALSTHATSHOULDNOTBEBURNED
•GARBAGEOFANYKIND,
•COALORCHARCOAL,
•TREATED,PAINTEDORCOATEDWOOD,
•PLYWOODORPARTICLEBOARD,
•FINEPAPER,COLOREDPAPERORCARDBOARD,
•SALTWATERDRIFTWOOD
•MANUFACTUREDLOGSCONTAININGWAXORCHEMICALADDITIVES
•RAILROADTIES
•LIQUIDSSUCHASKEROSCENEORDIESELFUELTOSTARTAFIRE

3.2 HOWTOPREPAREORBUYGOODFIREWOOD
3.2.1 WHATISGOODFIREWOOD?
Goodfirewoodhasbeencuttothecorrectlengthforthewoodinbuilt,splittoarangeofsizesand
stackedintheopenuntilitsmoisturecontentisreducedto15to20percent.
3.2.2 TREESPECIES
Thetreespeciesthefirewoodisproducedfromislessimportantthanitsmoisturecontent.The
maindifferenceinfirewoodfromvarioustreespeciesisthedensityofthewood.Hardwoodssuch
asgums,Manukaorironbarkaredenserthansoftwoods.Hardwoodwillproducelong‐lastingcoal
bedscombinedtomoreheatandlongerburncycles.
Old,leakycastironwoodinbuiltswouldn’tholdafireovernightunlesstheywerefedlargepieces
ofhardwood.Thatisnolongertrue.Youcansuccessfullyheatyourhomebyusinglesswoodand
givetheforestabreakatthesametime.
3.2.3 LOGLENGTH
Logsshouldbecutabout25mm(1”)shorterthanthefireboxsotheyfitineasily.Piecesthatare
slightlytoolongmakeloadingthewoodinbuiltverydifficult.Themostcommonstandardlengthof
firewoodis400mm(16”).

OsburnMatrixInbuiltInstallationandOperationManual
12______________________________________________________________________________
Thepiecesshouldbeaconsistentlength,withamaximumof25mm(1”)variationfrompieceto
piece.

3.2.4 PIECESIZE
Firewooddriesmorequicklywhenitissplit.Largeunsplitroundscantakeyearstodryenoughto
burn.Evenwhendried,unsplitlogsaredifficulttoignitebecausetheydon’thavethesharpedges
wheretheflamesfirstcatch.Logsassmallas75mm(3”)shouldbesplittoencouragedrying.
 
Woodshouldbesplittoarangeofsizes,fromabout75mmto150mm(3”to6”)incrosssection.
Havingarangeofsizesmakesstartingandrekindlingfiresmucheasier.Often,thefirewood
purchasedfromcommercialsuppliersisnotsplitfinelyenoughforconvenientstoking.Itis
sometimesadvisabletoresplitthewoodbeforestackingtodry.
3.2.5 HOWTODRYFIREWOOD
Firewoodthatisnotdryenoughtoburnisthecauseofmostcomplaintsaboutwoodinbuilts.
Continuallyburninggreenorunseasonedwoodproducesmorecreosoteandinvolveslackofheat
anddirtyglassdoor.SeeSection5:Maintainingyourwoodheatingsystemforconcernsabout
creosote.

OsburnMatrixInbuiltInstallationandOperationManual
______________________________________________________________________________13

Herearesomethingstoconsiderinestimatingdryingtime:
•firewoodtakesalongtimetodry
•firewoodboughtfromadealerisrarelydryenoughtoburn,soitisadvisabletobuythewood
inspringanddryityourself
•dryinghappensfasterindryweatherthanindamp,maritimeclimates
•dryinghappensfasterinwarmsummerweatherthaninwinterweather
•smallpiecesdrymorequicklythanlargepieces
•splitpiecesdrymorequicklythanunsplitrounds
•softwoodstakelesstimetodrythanhardwoods
•hardwoodslikegums,Manukaandironbarkcantakeone,oreventwoyearstodryfully,
especiallyifthepiecesarebig
•firewooddriesmorequicklywhenstackedintheopenwhereitisexposedtosunandwind;it
takesmuchlongertodrywhenstackedinawoodshed
•firewoodthatisreadytoburnhasamoisturecontentbetween15and20%byweightandwill
allowyourwoodinbuilttoproduceitshighestpossibleefficiency
3.2.6 JUDGINGFIREWOODMOISTURECONTENT
Youcanfindoutifsomefirewoodisdryenoughtoburnbyusingtheseguidelines:
•cracksformattheendsoflogsastheydry
•asitdriesinthesun,thewoodturnsfromwhiteorcreamcolouredtogreyoryellow,
•bangtwopiecesofwoodtogether;seasonedwoodsoundshollowandwetwoodsoundsdull,
•drywoodismuchlighterinweightthanwetwood,
•splitapiece,andifthefreshfacefeelswarmanddryitisdryenoughtoburn;ifitfeelsdamp,it
istoowet,
•burnapiece;wetwoodhissesandsizzlesinthefireanddrywooddoesnot.

Youcouldbuyawoodmoisturemetertotestyour
firewood.

OsburnMatrixInbuiltInstallationandOperationManual
14______________________________________________________________________________
3.3 MANUFACTUREDLOGS
Donotburnmanufacturedlogsmadeofwaximpregnatedsawdustorlogswithanychemical
additives.Manufacturedlogsmadeof100%compressedsawdustcanbeburned,butusecaution
inthenumberoftheselogsburnedatonetime.Startwithonemanufacturedlogandseehowthe
woodinbuiltreacts.Youcanincreasethenumberoflogsburnedatatimetomakingsurethe
temperatureneverriseshigherthan246°C(475°F)onamagneticthermometerforinstallationon
woodinbuiltflue.Thethermometershouldbeplacedabout450mm(18”)abovethewoodinbuilt.
Highertemperaturescanleadtooverheatanddamageyourwoodinbuilt.


OsburnMatrixInbuiltInstallationandOperationManual
______________________________________________________________________________15
4OPERATINGYOURWOODINBUILT
•NEVEROVERFIREYOURWOODINBUILT.IFANYPARTOFTHEWOODINBUILTSTARTSTO
GLOWRED,OVERFIRINGISHAPPENING.READJUSTTHEAIRINTAKECONTROLATALOWER
SETTING.
•NEVERLOADYOURWOODINBUILTUPTOTHEBAFFLE.ALWAYSLEAVE5TO10
CENTIMETERSTOALLOWPROPERCOMBUSTIONTHROUGHSECONDARYAIROPENINGS
(NEVERPUTWOODABOVETHEFIREBRICKLININGONTHEFIREBOX).THISWILLALSO
PREVENTOVERFIRINGOFYOURWOODINBUILT.
•SHOULDTHEREBEASOOTORCREOSOTEFIREINYOURFLUESYSTEM,CLOSETHEAIR
CONTROLCOMPLETELY.IMMEDIATELYCALLTHEFIREDEPARTMENT.

4.1 THEUSEOFAFIRESCREEN.
Thiswoodinbuilthasbeentestedforusewithanopendoorinconjunctionwithafirescreen
(AC01315,soldseparately).Makesurethefirescreenisproperlysecuredonthewoodinbuiltto
avoidanyriskofsparksdamagingyourflooring.Whenthefirescreenisinuse,donotleavethe
woodinbuiltunattendedsothatyoucanrespondpromptlyintheeventofsmokespillageintothe
room.PotentialcausesofsmokespillagearedescribedinSection9TheFlueSystemofthis
manual.SeeAppendix5:InstallingtheFireScreen(AC01315)forinstallationinstructions.
OPERATINGWITHTHEFIRESCREENINCREASESPOSSIBILITIESOFGENERATINGCARBON
MONOXIDE.CARBONMONOXIDEISANODOURLESSGASTHATISHIGHLYTOXICANDWHICH
CANCAUSEDEATHATHIGHCONCENTRATIONINAIR.

4.2 YOURFIRSTFIRES
Twothingswillhappenasyouburnyourfirstfewfires;thepaintcuresandtheinternal
componentsofthewoodinbuiltareconditioned.
Asthepaintcures,someofthechemicalsvaporize.Thevaporsarenotpoisonous,buttheydo
smellbad.Freshpaintfumescanalsocausefalsealarmsinsmokedetectors.So,whenyoufirst
lightyourwoodinbuilt,bepreparedbyopeningdoorsand/orwindowstoventilatethehouse.As
youburnhotterandhotterfires,moreofthepaintedsurfacesreachthecuringtemperatureofthe
paint.Thesmellofcuringpaintdoesnotdisappearuntilyouhaveburnedoneortwoveryhot
fires.
Burnoneortwosmallfirestobeginthecuringandconditioningprocess.Thenbuildbiggerand
hotterfiresuntilthereisnolongeranypaintsmellfromthewoodinbuilt.Oncethepaintsmell
disappears,yourwoodinbuiltisreadyforseriousheating.

OsburnMatrixInbuiltInstallationandOperationManual
16______________________________________________________________________________
4.3 LIGHTINGFIRES
Eachpersonwhoheatswithwooddevelopstheirownfavoritewaytolightfires.Whatever
methodyouchoose,yourgoalshouldbetogetahotfireburningquickly.Afirethatstartsfast
produceslesssmokeanddepositslesscreosoteinthefluesystem.Herearethreepopularand
effectivewaystostartwoodinbuilts.
4.3.1 CONVENTIONALFIRESTARTING
Theconventionalwaytobuildawoodinbuilt isto
bunchup5to10sheetsofplainnewspaperandplace
theminthefirebox.Next,place10orsopiecesoffine
kindlingonthenewspaper.Thiskindlingshouldbe
verythin;lessthan25mm(1”).Next,placesome
largerkindlingpiecesonthefinekindling.Openthe
aircontrolfullyandlightthenewspaper.Ifyouhavea
tall,straightfluesystemyoushouldbeabletoclose
thedoorimmediatelyandthefirewillignite.Ifyour
fluehaselbowsoranoutsidefluesystem,youmay
needtoleavethedoorclosedbutunlatchedforafew
minutesasthenewspaperignitesandheatintheflue
systemproducessomedraft.Oncethefirehas
ignited,closethedoorandleavetheaircontrolfully
open.

Aconventionalkindlingfirewithpaper
underfinelysplitwood.
DONOTLEAVETHEWOODINBUILTUNATTENDEDWHENTHEDOORISSLIGHTLYOPENED
DURINGIGNITION.ALWAYSCLOSETHEDOORAFTERIGNITION.
Afterthekindlingfirehasmostlyburned,youcanaddstandardfirewoodpiecesuntilyouhavea
fireoftherightsizefortheconditions.
4.3.2 THETOPDOWNFIRE
Thetopdownfirestartingmethodsolvestwoproblemswiththeconventionalmethod:first,it
doesnotcollapseandsmotheritselfasitburns;andsecond,itisnotnecessarytobuildupthefire
graduallybecausethefireboxisloadedbeforethefireislit.Atopdownfirecanprovideuptotwo
hoursofheatingormore.Thetopdownmethodonlyworksproperlyifthewoodiswell‐seasoned.
Startbyplacingthreeorfourfull‐sizedsplitpiecesofdryfirewoodinthefirebox.Next,place4or5
morefinelysplitpiecesoffirewood(50mmto75mm[2”to3”]india.)onthebaselogsatright
angles(logcabinstyle).Nowplaceabout10piecesoffinelysplitkindlingonthesecondlayerat
rightangles.
Thefireistoppedwithabout5sheetsofnewspaper.Youcanjustbunchthemupandstuffthemin
betweenthekindlingandtheundersideofthebaffle.Oryoucanmakenewspaperknotsbyrolling
upsinglesheetscornertocornerandtyingaknotinthem.Theadvantageofknotsisthatthey
don’trolloffthefireastheyburn.Lightthenewspaperandwatchasthefireburnsfromtopto
bottom.

OsburnMatrixInbuiltInstallationandOperationManual
______________________________________________________________________________17
4.3.3 TWOPARALLELLOGS
Placetwospitlogsinthefirebox.Placeafewsheetsoftwistednewspaperbetweenthelogs.Now
placesomefinekindlingacrossthetwologsandsomelargerkindlingacrossthose,logcabinstyle.
Lightthenewspaper.
4.3.4 USINGFIRESTARTERS
Manypeopleliketousecommercialfirestartersinsteadofnewspaper.Someofthesestartersare
madeofsawdustandwaxandothersarespecializedflammablesolidchemicals.Followthe
packagedirectionsforuse.
Gelstartermaybeusedbutonlyiftherearenohotemberspresent.Useonlyinacoldfireboxto
startafire.
DONOTUSEFLAMMABLELIQUIDSSUCHASGASOLINE,NAPHTHA,FUELOIL,MOTOROIL,OR
AEROSOLSTOSTARTORREKINDLETHEFIRE.

4.4 MAINTAININGWOODFIRES
4.4.1 GENERALADVICE
Woodheatingwithaspaceheaterisverydifferentthanotherformsofheating.Therewillbe
variationsinthetemperatureindifferentpartsofthehouseandtherewillbevariationsin
temperaturethroughoutthedayandnight.Thisisnormal,andforexperiencedwoodburners
theseareadvantagesofzoneheatingwithwood.
Donotexpectsteadyheatoutputfromyourwoodinbuilt.Itisnormalforitssurfacetemperature
toriseafteranewloadofwoodisignitedandforitstemperaturetograduallydeclineasthefire
progresses.Thisrisingandfallingoftemperaturecanbematchedtoyourhouseholdroutines.For
example,theareatemperaturecanbecoolerwhenyouareactive,suchaswhendoinghousework
orcooking,anditcanbewarmerwhenyouareinactive,suchaswhenreadingorwatching
television.
Woodburnsbestincycles.Acyclestartswhenanewloadofwoodisignitedbyhotcoalsandends
whenthatloadhasbeenconsumeddowntoabedofcharcoalaboutthesamesizeasitwaswhen
thewoodwasloaded.Donotattempttoproduceasteadyheatoutputbyplacingasinglelogon
thefireatregularintervals.Alwaysplaceatleastthree,andpreferablymore,piecesonthefireat
atimesothattheheatradiatedfromonepiecehelpstoignitethepiecesnexttoit.Eachloadof
woodshouldprovideseveralhoursofheating.Thesizeofeachloadcanbematchedtothe
amountofheatneeded.
Whenyouburnincycles,yourarelyneedtoopenthewoodinbuilt’sloadingdoorwhilethewood
isflaming.Thisisanadvantagebecausethereismorechancethatsmokewillleakfromthewood
inbuiltwhenthedoorisopenedasafullfireisburning.
IFYOUMUSTOPENTHEDOORWHILETHEFUELISFLAMING,OPENTHEAIRCONTROLFULLYFOR
AFEWMINUTES,THENUNLATCHANDOPENTHEDOORSLOWLY.

OsburnMatrixInbuiltInstallationandOperationManual
18______________________________________________________________________________
4.4.2 ASHREMOVAL
Ashshouldberemovedfromthefireboxeverytwoorthreedaysoffulltimeheating.Donotlet
theashbuildupinthefireboxbecauseitwillinterferewithproperfiremanagement.
Thebesttimetoremoveashisafteranovernightfirewhenthewoodinbuiltisrelativelycool,but
thereisstillsomefluesystemdrafttodrawtheashdustintothewoodinbuiltandpreventitfrom
comingintotheroom.
NOTE:Thefanshouldbeturnedin“OFF”position(2)priortoashremovaltoavoidashestobe
pulledtowardstheinbuiltandthenpushedintotheroom.

Afterasheshavebeenremovedfromthewoodinbuiltandplacedinatightlycoveredmetal
container,theyshouldbetakenoutsideimmediately.Theclosedcontainerofashesshouldbe
placedonanon‐combustiblefloororonthegroundwellawayfromallcombustiblematerials
pendingfinaldisposal.Ashesnormallycontainsomelivecharcoalthatcanstayhotforseveral
days.Iftheashesaredisposedofbyburialinsoilorotherwiselocallydispersed,theyshouldbe
retainedintheclosedcontaineruntilallcindershavethoroughlycooled.Otherwasteshallnotbe
placedinthiscontainer.
NEVERSTOREASHESINDOORSORINANON‐METALICCONTAINERORONAWOODENDECK.
4.4.3 RAKINGCHARCOAL
Rekindlethefirewhenyounoticethattheroomtemperaturehasfallen.Youwillfindmostofthe
remainingcharcoalatthebackofthefirebox,furthestfromthedoor.Rakethesecoalstowards
thedoorbeforeloading.Therearetworeasonsforthisrakingofthecoals.First,itconcentrates
themnearwheremostofthecombustionairentersthefireboxandwheretheycanignitethenew
loadquickly,andsecond,thecharcoalwillnotbesmotheredbythenewloadofwood.Ifyouwere
tosimplyspreadthecharcoalout,thenewloadwillsmoulderforalongtimebeforeigniting.

Removeashfirst,andthenrakecharcoaltowardsthefrontofthefireboxbeforeloadingsothatit
willignitethenewload.

OsburnMatrixInbuiltInstallationandOperationManual
______________________________________________________________________________19
4.4.4 FIRINGEACHNEWLOADHOT
Placethenewloadofwoodonandbehindthecharcoalandnottooclosetotheglass.Closethe
doorandopentheaircontrolfully.Leavetheaircontrolfullyopenuntilthefireboxisfullof
flames,thewoodhascharredtoblackanditsedgesareglowingred.Firingeachloadofwoodhot
accomplishesafewthings:
•drivesthesurfacemoisturefromthewood,
•createsalayerofcharonthewood,whichslowsdownitsreleaseofsmoke,
•heatsthefireboxcomponentssotheyreflectheatbacktothefire,and
•heatsthefluesystemsoitcanproducestrong,steadydraftfortherestofthecycle.
Althoughitisimportanttofireeachnewloadhottoprepareforacleanburn,donotallowthefire
toburnatfullintensityformorethanafewminutes.
DONOTLEAVETHEWOODINBUILTUNATTENDEDWHILEANEWLOADISBEINGFIREDHOT.
DONOTOVERFIRE.
Whenyouburnanewloadofwoodhottoheatupthewood,thewoodinbuiltandtheflue
system,theresultwillbeasurgeofheatfromthewoodinbuilt.Thisheatsurgeiswelcomewhen
theroomtemperatureisalittlelowerthandesirable,butnotwelcomeifthespaceisalready
warm.Therefore,alloweachloadofwoodtoburndownsothatthespacebeginstocooloffalittle
beforeloading.Lettingthespacecoolbeforeloadingisoneofthesecretstocleanburningand
effectivezoneheating.
4.4.5 TURNINGDOWNTHEAIRSUPPLY
Oncethefirewood,fireboxandfluesystemarehot,youcanbegintoreducetheairsupplyfora
steadyburn.
Asyoureducetheairsupplytothefire,twoimportantthingshappen.First,thefiringrateslows
downtospreadtheheatenergyinthefueloveralongerperiodoftime.Second,theflowrateof
exhaustthroughthewoodinbuiltandflueslowsdown,whichgivesmoretimeforthetransferof
heatfromtheexhaust.Youwillnoticethatasyoureducetheairsetting,theflamesslowdown.
Thisisyourindicationthatthewoodinbuiltisburningatitspeakefficiency.
Iftheflamesgetsmallandalmostdisappearwhenyouturndowntheair,youhaveturneddown
theairtooearly,oryourfirewoodiswetterthanitshouldbe.Withgoodfuelandcorrectair
controluse,theflamesshouldslowdown,butshouldstaylargeandsteady,evenastheairsupply
isreduced.

OsburnMatrixInbuiltInstallationandOperationManual
20______________________________________________________________________________

4.5 FANOPERATION
Allowthewoodinbuilttoreachoperatingtemperature(approximatelyonehour),beforeturning
onthefan,sinceincreasedairflowfromthefanwillremoveheatandaffectthestart‐up
combustionefficiency.
Thewoodinbuilt'sfanassemblyisequippedwithaheatsensor.Therefore,youcanleavethe
switchintheautomaticposition(3).Thefanwillstartautomaticallywhenthewoodinbuiltishot
enoughanditwillstopwhenthewoodinbuilthascooleddown.Youcanalsosettheswitchtothe
manualposition(1)tooperatethefanatanytime.Selecttheposition(2)tomanuallystopthefan.

NOTE:ENSURETHEFANCORDISNOTINCONTACTWITHANYSURFACEOFTHEWOODINBUILT
TOPREVENTELECTRICALSHOCKORFIREDAMAGE.DONOTRUNCORDBENEATHTHEWOOD
INBUILT.
4.5.1 BUILDINGDIFFERENTFIRESFORDIFFERENTNEEDS
Usingtheaircontrolisnottheonlywaytomatchthewoodinbuilt’sheatoutputtotheheat
demand.YourhousewillneedfarlessheatinAprilthaninJulytobekeptatacomfortable
temperature.Ifyoufillthefireboxfullinfallweather,youwilleitheroverheatthespaceorturn
thewoodinbuiltdownsomuchthatthefirewillbesmokyandinefficient.Herearesome
suggestionsforbuildingfirestomatchdifferentheatdemand.
4.5.1.1 SmallFirestoTaketheChillOfftheHouse
Tobuildasmallfirethatwillproducealowheatoutput,usesmallpiecesoffirewoodandload
themcrisscrossinthefirebox.Thepiecesshouldbeonly75mmto100mmindiameter.After
rakingthecoals,youcanlaytwopiecesparalleltoeachothercornertocornerinthefireboxand
laytwomoreacrossthemintheotherdirection.Opentheaircontrolfullyandonlyreducetheair
afterthewoodisfullyflaming.Thiskindoffireisgoodformildweatherwhenyouarearoundto
tendthewoodinbuiltandshouldprovideenoughheatforfourhoursormore.Smallfireslikethis
areagoodtimetousesofterwoodspeciessotherewillbelesschanceofoverheatingthehouse.
