Osburn Matrix User manual

READANDKEEPTHISMANUALFORREFERENCE

45641A

PrintedinCanada07‐05‐2014

INSTALLATIONANDOPERATIONMANUAL

MATRIX







  

Distributedby

GlenDimplexAustralasia

NEWZEALAND

38HarrisRoad,EastTamaki,Auckland

Ph:092748265Fax092748472

Email:sales@glendimplex.co.nz

www.glendimplex.com.au

AUSTRALIA

Unit1,21LionelRoad

MountWaverley,Victoria3149

Ph:1300554155Fax87873570

Email:sales@glendimplex.com.au

www.glendimplex.com.au



Thismanualisavailableforfreedownloadonthemanufacturer’swebsite.Itisacopyrighted

document.Re‐saleisstrictlyprohibited.Themanufacturermayupdatethismanualfromtimeto

timeandcannotberesponsibleforproblems,injuries,ordamagesarisingoutoftheuseof

informationcontainedinanymanualobtainedfromunauthorizedsources.

OsburnMatrixInstallationandOperationManual

2_______________________________________________________________________________

THANKYOUFORCHOOSINGTHISWOODFIRE

Wewanttocongratulateyouonyourpurchaseandwishtohelpyougetmaximumsatisfaction

fromyourwoodfire.Inthepagesthatfollow,wewillgiveyouadviceonwoodheatingand

controlledcombustionaswellastechnicalspecificationsregardinginstallation,operationand

maintenanceofthemodelyouhavechosen.

Theinstructionspertainingtotheinstallationofyourwoodfirecomplywith

AS/NZS4012/4013(1999)andAS/NZS2918:2001standards.

Pleasereadthisentiremanualbeforeyouinstallanduseyournewwoodfire.Failuretofollow

instructionsmayresultinpropertydamage,bodilyinjury,orevendeath.Itisimportantthatyou

followtheinstallationsguidelinesexactly.

Consultyourlocalcity,boroughorshirecouncilaboutrestrictionsandinstallations

requirementsinyourareaandtheneedtoobtainapermit.



KEEPTHISINSTRUCTIONMANUALFORFUTUREREFERENCE.



OsburnMatrixInstallationandOperationManual

_______________________________________________________________________________3

Tableofcontent

PARTA‐OPERATIONANDMAINTENANCE.............................................6

1SafetyInformation...........................................................................6

1.1SummaryofOperationandMaintenanceCautionsandWarnings......................................6

2GeneralInformation........................................................................7

2.1OSBURNMatrixSpecifications..............................................................................................7

2.2ZoneHeatingandHowtoMakeitWorkforYou..................................................................9

2.3TheBenefitsofLowEmissionsandHighEfficiency.............................................................10

2.4Osburn’sCommitmenttoYouandtheEnvironment..........................................................10

2.4.1WhatisYourNewWoodfireMadeOf?..........................................................................10

3Fuel...............................................................................................12

3.1MaterialsThatShouldNotbeBurned.................................................................................12

3.2HowtoPrepareorBuyGoodFirewood..............................................................................12

3.2.1WhatisGoodFirewood?.................................................................................................12

3.2.2TreeSpecies.....................................................................................................................12

3.2.3LogLength........................................................................................................................13

3.2.4PieceSize..........................................................................................................................13

3.2.5HowtoDryFirewood.......................................................................................................14

3.2.6Wheretostorewood.......................................................................................................15

3.2.7JudgingFirewoodMoistureContent...............................................................................15

3.3ManufacturedLogs..............................................................................................................16

4OperatingYourWoodfire..............................................................17

4.1Theuseofafirescreen........................................................................................................17

4.2YourFirstFires.....................................................................................................................17

4.3LightingFires........................................................................................................................18

4.3.1ConventionalFireStarting...............................................................................................18

4.3.2TheTopDownFire...........................................................................................................18

4.3.3TwoParallelLogs..............................................................................................................19

4.3.4UsingFireStarters............................................................................................................19

4.4MaintainingWoodFires......................................................................................................19

4.4.1GeneralAdvice.................................................................................................................19

4.4.2AshRemoval.....................................................................................................................20

4.4.3RakingCharcoal................................................................................................................20

4.4.4FiringEachNewLoadHot................................................................................................21

OsburnMatrixInstallationandOperationManual

4_______________________________________________________________________________

4.4.5TurningDowntheAirSupply...........................................................................................21

4.4.6BuildingDifferentFiresforDifferentNeeds....................................................................22

5MaintainingYourWoodHeatingSystem.......................................24

5.1WoodfireMaintenance.......................................................................................................24

5.1.1CleaningDoorGlass.........................................................................................................24

5.1.2Dooradjustment..............................................................................................................25

5.1.3ReplacingtheDoorGasket...............................................................................................26

5.1.4ReplacingtheGlassGasketand/ortheGlass..................................................................26

5.1.5CleaningandPaintingtheWoodfire...............................................................................27

5.2FlueandFlueSystemMaintenance.....................................................................................27

5.2.1WhyFlueSystemCleaningisNecessary..........................................................................27

5.2.2HowOftenShouldYouCleantheFlueSystem?..............................................................28

5.2.3CleaningtheFlueSystem.................................................................................................28

PARTB–INSTALLATION.......................................................................29

6SafetyInformation.........................................................................29

6.1SummaryofInstallationCautionsandWarnings................................................................29

6.2RegulationsCoveringWoodfireInstallation.......................................................................30

7ClearancestoHeat‐SensitiveMaterials..........................................31

7.1LocationoftheCertificationLabel......................................................................................31

7.2ClearancestoWallsandCeiling...........................................................................................31

7.3FloorProtector.....................................................................................................................32

7.4ReducingWallandCeilingClearancesSafely......................................................................33

8TheFlueSystem.............................................................................35

8.1General................................................................................................................................35

8.2SuitableFlueSystems..........................................................................................................35

8.2.1FactorybuiltInsulatedFlueKits.......................................................................................35

8.2.2MasonryFlueSystems.....................................................................................................36

8.3MinimumFlueSystemHeight.............................................................................................37

8.4TheRelationshipBetweentheFlueSystemandtheHouse................................................38

8.4.1WhyInsideFlueSystemsarePreferred...........................................................................38

8.4.2WhytheFlueSystemShouldPenetratetheHighestHeatedSpace................................39

8.5InstallingtheflueConnector...............................................................................................39

OsburnMatrixInstallationandOperationManual

_______________________________________________________________________________5

Appendix1:ReversingtheDoorOpeningandAdjustingtheHandle.....42

Appendix2:InstallingtheDecorativePanels........................................44

Appendix3:InstallingtheFreshAirKit.................................................47

Appendix4:InstallingtheFireScreen(AC01315).................................48

Appendix5:InstallationandUseoftheAirCirculationFanand

Thermodisc..........................................................................................49

Appendix6:InstallationofSecondaryAirTubesandBaffle..................51

Appendix7:ExplodedDiagramandPartsList.......................................53



Toreceivefullwarrantycoverage,youwillneedtoshowevidenceof

thedateyoupurchasedyourwoodfire.Keepyoursalesinvoice.We

alsorecommendthatyouregisteryourwarrantyonlineat

http://osburn‐australia.com/warranty‐registration.aspx

Registeringyourwarrantyonlinewillhelpustrackrapidlythe

informationweneedonyourwoodfire.



OsburnMatrixInstallationandOperationManual

6_______________________________________________________________________________

PARTA‐OPERATIONANDMAINTENANCE

PleaseseePartBforinstallationinstructions.

1SAFETYINFORMATION

1.1 SUMMARYOFOPERATIONANDMAINTENANCECAUTIONSANDWARNINGS

•HOTWHILEINOPERATION,KEEPCHILDREN,CLOTHINGANDFURNITUREAWAY.CONTACT

MAYCAUSESKINBURNS.GLOVESMAYBENEEDEDFORWOODFIREOPERATION.

•USINGAWOODFIREWITHCRACKEDORBROKENCOMPONENTS,SUCHASGLASSOR

FIREBRICKSORBAFFLESMAYPRODUCEANUNSAFECONDITIONANDMAYDAMAGETHE

WOODFIRE.

•OPENTHEAIRCONTROLFULLYBEFOREOPENINGFIRINGDOOR.

•THISWOODFIREHASBEENTESTEDFORUSEWITHANOPENDOORINCONJUNCTIONWITHA

FIRESCREEN(AC01315,SOLDSEPARATELY).THEDOORMAYBEOPENORFIRESCREEN

REMOVEDONLYDURINGLIGHTINGPROCEDURESORRELOADING.ALWAYSCLOSETHEDOOR

ORPUTBACKTHEFIRESCREENAFTERIGNITION.DONOTLEAVETHEWOODFIRE

UNATTENDEDWHENTHEDOORISOPENEDWITHORWITHOUTFIRESCREEN.

•NEVERUSEGASOLINE,GASOLINE‐TYPELANTERNFUEL(NAPHTHA),FUELOIL,MOTOROIL,

KEROSENE,CHARCOALLIGHTERFLUID,ORSIMILARLIQUIDSORAEROSOLSTOSTARTOR

‘FRESHENUP’AFIREINTHISWOODFIRE.KEEPALLSUCHLIQUIDSORAEROSOLSWELLAWAY

FROMTHEWOODFIREWHILEITISINUSE.

•DONOTCONNECTTOANYAIRDISTRIBUTIONDUCTORSYSTEM.

•DONOTSTOREFUELWITHINHEATERMINIMUMINSTALLATIONCLEARANCES.

•BURNONLYSEASONEDNATURALFIREWOOD.

•THEUSEOFSOMETYPESOFPRESERVATIVE‐TREATEDWOODASAFUELCANBEHAZARDOUS.

•DONOTBURN:

oGARBAGEOFANYKIND,

oCOALORCHARCOAL,

oTREATED,PAINTEDORCOATEDWOOD,

oPLYWOODORPARTICLEBOARD,

oFINEPAPER,COLOREDPAPERORCARDBOARD,

oSALTWATERDRIFTWOOD,OR

oRAILROADTIES.



•DONOTELEVATETHEFIREBYUSINGAGRATEINTHISWOODFIRE.

•THISAPPLIANCESHOULDBEMAINTAINEDANDOPERATEDATALLTIMESINACCORDANCE

WITHTHESEINSTRUCTIONS.

OsburnMatrixInstallationandOperationManual

_______________________________________________________________________________7

2GENERALINFORMATION

2.1 OSBURNMATRIXSPECIFICATIONS



Combustible:Wood

Heatingcapacity*195m2

Maximumaverageheatoutput–hardwood(Australia):11.1kW

Averageefficiency–hardwood(Australia):68%

Averageemissions–hardwood(Australia):1.9g/kg

ApproximateBurnTime*6to8hours

Color: Metallicblack

FlueSpigotDiameter:150mm

Fluesystem: UniversalFlueKitor

AcorninsulatedFlueKit

MinimumFlueHeight(fromfloorprotector):4.6meters

MaximumLogLength:508mmsideways**

Logloading:Sideways

FireboxVolume:0,068m3

Weight: 243kg

BaffleMaterialC‐cast



*Burntimeandheatingcapacitymayvarysubjecttolocationinhome,fluesystemdraft,flue

systemdiameter,locality,heatlossfactors,climate,fuelsandothervariables.

**Sideways:throughthedooryouseethesidesofthelogs.

OsburnMatrixInstallationandOperationManual

8_______________________________________________________________________________



OsburnMatrixInstallationandOperationManual

_______________________________________________________________________________9





2.2 ZONEHEATINGANDHOWTOMAKEITWORKFORYOU

YournewOsburnMatrixwoodfireisaspaceheater,whichmeansitisintendedtoheattheareait

isinstalledin,aswellasspacesthatconnecttothatarea,althoughtoalowertemperature.Thisis

calledzoneheatinganditisanincreasinglypopularwaytoheathomesorspaceswithinhomes.

Zoneheatingcanbeusedtosupplementanotherheatingsystembyheatingaparticularspace

withinahome,suchasabasementfamilyroomoranadditionthatlacksanotherheatsource.

OsburnMatrixInstallationandOperationManual

10______________________________________________________________________________

Housesofmoderatesizeandrelativelynewconstructioncanbeheatedwithaproperlysizedand

locatedwoodfire.Wholehousezoneheatingworksbestwhenthewoodfireislocatedinthepart

ofthehousewherethefamilyspendsmostofitstime.Thisisnormallythemainlivingareawhere

thekitchen,diningandlivingroomsarelocated.Bylocatingthewoodfireinthisarea,youwillget

themaximumbenefitoftheheatitproducesandwillachievethehighestpossibleheating

efficiencyandcomfort.Thespacewhereyouspendmostofyourtimewillbewarmest,while

bedroomsandbasement(ifthereisone)willstaycooler.Inthisway,youwillburnlesswoodthan

withotherformsofheating.

Althoughthewoodfiremaybeabletoheatthemainlivingareasofyourhousetoanadequate

temperature,westronglyrecommendthatyoualsohaveaconventionaloil,gasorelectricheating

systemtoprovidebackupheating.

Yoursuccesswithzoneheatingwilldependonseveralfactors,includingthecorrectsizingand

locationofthewoodfire,thesize,layoutandageofyourhomeandyourclimatezone.Three‐

seasonvacationhomescanusuallybeheatedwithsmallerwoodfiresthanhousesthatareheated

allwinter.

2.3 THEBENEFITSOFLOWEMISSIONSANDHIGHEFFICIENCY

ThelowsmokeemissionsproducedbythespecialfeaturesinsidetheOsburnMatrixfireboxmean

thatyourhouseholdwillreleaseupto90percentlesssmokeintotheoutsideenvironmentthanif

youusedanolderconventionalwoodfire.Butthereismoretotheemissioncontroltechnologies

thanprotectingtheenvironment.

Thesmokereleasedfromwoodwhenitisheatedcontainsabouthalfoftheenergycontentofthe

fuel.Byburningthewoodcompletely,yourwoodfirereleasesalltheheatenergyfromthewood

insteadofwastingitassmokeupthefluesystem.Also,thefeaturesinsidethefireboxallowyouto

reducetheairsupplytocontrolheatoutput,whilemaintainingcleanandefficientflaming

combustion,whichbooststheefficientdeliveryofheattoyourhome.

Theemissioncontrolandadvancedcombustionfeaturesofyourwoodfirecanonlyworkproperly

ifyourfuelisinthecorrectmoisturecontentrangeof15to20percent.SeeSection3ofthis

manualforsuggestionsonpreparingfuelwoodandjudgingitsmoisture.

2.4 OSBURN’SCOMMITMENTTOYOUANDTHEENVIRONMENT

TheOsburnteamiscommittedtoprotectingtheenvironment,sowedoeverythingwecantouse

onlymaterialsinourproductsthatwillhavenolastingnegativeimpactontheenvironment.

2.4.1 WHATISYOURNEWWOODFIREMADEOF?

Thebodyofyourwoodfire,whichismostofitsweight,iscarbonsteel.Shoulditeverbecome

necessarymanyyearsinthefuture,almosttheentirewoodfirecanberecycledintonew

products,thuseliminatingtheneedtominenewmaterials.

OsburnMatrixInstallationandOperationManual

______________________________________________________________________________11

Thepaintcoatingonyourwoodfireisverythin.ItsVOCcontent(VolatileOrganicComponents)is

verylow.VOCscanberesponsibleforsmog,soallthepaintusedduringthemanufacturing

processmeetsthelatestairqualityrequirementswithregardstoVOCreductionorelimination.

Theairtubesarestainlesssteel,whichcanalsoberecycled.

TheC‐Castbaffleismadeofanaluminosilicatefibrematerialthatiscompressedwithabinderto

formarigidboard.C‐Castcanwithstandtemperaturesabove1093°c.Itisnotconsidered

hazardouswaste.Disposalatalandfillisrecommended.

Firebrickismainlycomposedofsilicondioxide,alsoknownassilica,anearthderivedproduct.Itismost

commonlyfoundinnatureintheformofsandandclay.Disposalatalandfillisrecommended.

Thedoorandglassgasketsarefibreglasswhichisspunfrommeltedsand.Blackgasketshavebeen

dippedintoasolvent‐freesolution.Disposalatalandfillisrecommended.

Thedoorglassisa5mmthickceramicmaterialthatcontainsnotoxicchemicals.Itisbasicallymadeof

rawearthmaterialssuchassandandquartzthatarecombinedinsuchawaytoformaglassathigh

temperatures.Ceramicglasswillnotre‐meltinthesamewayasnormalglass,soitshouldnotbe

recycledwithyourregularhouseholdproducts.Disposalatalandfillisrecommended.

OsburnMatrixInstallationandOperationManual

12______________________________________________________________________________

3FUEL

3.1 MATERIALSTHATSHOULDNOTBEBURNED

•GARBAGEOFANYKIND,

•COALORCHARCOAL,

•TREATED,PAINTEDORCOATEDWOOD,

•PLYWOODORPARTICLEBOARD,

•FINEPAPER,COLOREDPAPERORCARDBOARD,

•SALTWATERDRIFTWOOD

•MANUFACTUREDLOGSCONTAININGWAXORCHEMICALADDITIVES

•RAILROADTIES

•LIQUIDSSUCHASKEROSCENEORDIESELFUELTOSTARTAFIRE



3.2 HOWTOPREPAREORBUYGOODFIREWOOD

3.2.1 WHATISGOODFIREWOOD?

Goodfirewoodhasbeencuttothecorrectlengthforthewoodfire,splittoarangeofsizesand

stackedintheopenuntilitsmoisturecontentisreducedto15to20percent.

3.2.2 TREESPECIES

Thetreespeciesthefirewoodisproducedfromislessimportantthanitsmoisturecontent.The

maindifferenceinfirewoodfromvarioustreespeciesisthedensityofthewood.Hardwoodssuch

asgums,Manukaorironbarkaredenserthansoftwoods.Hardwoodwillproducelong‐lastingcoal

bedscombinedtomoreheatandlongerburncycles.

Old,leakycastironwoodfireswouldn’tholdafireovernightunlesstheywerefedlargepiecesof

hardwood.Thatisnolongertrue.Youcansuccessfullyheatyourhomebyusinglesswoodand

givetheforestabreakatthesametime.

OsburnMatrixInstallationandOperationManual

______________________________________________________________________________13

3.2.3 LOGLENGTH

Logsshouldbecutabout25mm(1”)shorterthanthefireboxsotheyfitineasily.Piecesthatare

slightlytoolongmakeloadingthewoodfireverydifficult.Themostcommonstandardlengthof

firewoodis400mm(16”).

Thepiecesshouldbeaconsistentlength,withamaximumof25mm(1”)variationfrompieceto

piece.



3.2.4 PIECESIZE

Firewooddriesmorequicklywhenitissplit.Largeunsplitroundscantakeyearstodryenoughto

burn.Evenwhendried,unsplitlogsaredifficulttoignitebecausetheydon’thavethesharpedges

wheretheflamesfirstcatch.Logsassmallas75mm(3”)shouldbesplittoencouragedrying.

 

Woodshouldbesplittoarangeofsizes,fromabout75mmto150mm(3”to6”)incrosssection.

Havingarangeofsizesmakesstartingandrekindlingfiresmucheasier.Often,thefirewood

purchasedfromcommercialsuppliersisnotsplitfinelyenoughforconvenientstoking.Itis

sometimesadvisabletoresplitthewoodbeforestackingtodry.

OsburnMatrixInstallationandOperationManual

14______________________________________________________________________________

3.2.5 HOWTODRYFIREWOOD

Firewoodthatisnotdryenoughtoburnisthecauseofmostcomplaintsaboutwoodfires.The

complaintsusuallyinvolvealackofheatanddirtydoorglass.



Herearesomethingstoconsiderinestimatingdryingtime:

•firewoodtakesalongtimetodry

•firewoodboughtfromadealerisrarelydryenoughtoburn,soitisadvisabletobuythewood

inspringanddryityourself

•dryinghappensfasterindryweatherthanindamp,maritimeclimates

•dryinghappensfasterinwarmsummerweatherthaninwinterweather

•smallpiecesdrymorequicklythanlargepieces

•splitpiecesdrymorequicklythanunsplitrounds

•softwoodstakelesstimetodrythanhardwoods

•hardwoodslikegums,Manukaandironbarkcantakeone,oreventwoyearstodryfully,

especiallyifthepiecesarebig

•firewooddriesmorequicklywhenstackedintheopenwhereitisexposedtosunandwind;it

takesmuchlongertodrywhenstackedinawoodshed

•firewoodthatisreadytoburnhasamoisturecontentbetween15and20%byweightandwill

allowyourwoodfiretoproduceitshighestpossibleefficiency

OsburnMatrixInstallationandOperationManual

______________________________________________________________________________15

3.2.6 WHERETOSTOREWOOD

Thiswoodfirehasbeencertifiedtostorelogsinthepedestalprovidedthatthefollowing

requirementsaremet:

Thelogsmustnotexceedtheinsideedge

(A)ofthepedestal.

Theheatshieldbaffle(B)underthefirebox

mustneverberemoved.

Nocombustiblematerialcanbeplaced

abovetheheatshieldbaffle.



3.2.7 JUDGINGFIREWOODMOISTURECONTENT

Youcanfindoutifsomefirewoodisdryenoughtoburnbyusingtheseguidelines:

•cracksformattheendsoflogsastheydry

•asitdriesinthesun,thewoodturnsfromwhiteorcreamcolouredtogreyoryellow,

•bangtwopiecesofwoodtogether;seasonedwoodsoundshollowandwetwoodsoundsdull,

•drywoodismuchlighterinweightthanwetwood,

•splitapiece,andifthefreshfacefeelswarmanddryitisdryenoughtoburn;ifitfeelsdamp,it

istoowet,

•burnapiece;wetwoodhissesandsizzlesinthefireanddrywooddoesnot.



Youcouldbuyawoodmoisturemetertotestyour

firewood.



OsburnMatrixInstallationandOperationManual

16______________________________________________________________________________

3.3 MANUFACTUREDLOGS

Donotburnmanufacturedlogsmadeofwaximpregnatedsawdustorlogswithanychemical

additives.Manufacturedlogsmadeof100%compressedsawdustcanbeburned,butusecaution

inthenumberoftheselogsburnedatonetime.Startwithonemanufacturedlogandseehowthe

woodfirereacts.Youcanincreasethenumberoflogsburnedatatimetomakingsurethe

temperatureneverriseshigherthan246°C(475°F)onamagneticthermometerforinstallationon

woodfireflue.Thethermometershouldbeplacedabout450mm(18”)abovethewoodfire.

Highertemperaturescanleadtooverheatanddamageyourwoodfire.



OsburnMatrixInstallationandOperationManual

______________________________________________________________________________17

4OPERATINGYOURWOODFIRE

•NEVEROVERFIREYOURWOODFIRE.IFANYPARTOFTHEWOODFIRESTARTSTOGLOW

RED,OVERFIRINGISHAPPENING.READJUSTTHEAIRINTAKECONTROLATALOWER

SETTING.

•NEVERLOADYOURWOODFIREUPTOTHEBAFFLE.ALWAYSLEAVE5TO10CENTIMETERS

TOALLOWPROPERCOMBUSTIONTHROUGHSECONDARYAIROPENINGS(NEVERPUTWOOD

ABOVETHEFIREBRICKLININGONTHEFIREBOX).THISWILLALSOPREVENTOVERFIRINGOF

YOURWOODFIRE.

•SHOULDTHEREBEASOOTORCREOSOTEFIREINYOURFLUESYSTEM,CLOSETHEAIR

CONTROLCOMPLETELY.IMMEDIATELYCALLTHEFIREDEPARTMENT.



4.1 THEUSEOFAFIRESCREEN.

Thisstovehasbeentestedforusewithanopendoorinconjunctionwithafirescreen(AC01315,

soldseparately).Makesurethefirescreenisproperlysecuredonthestovetoavoidanyriskof

fire.Whenthefirescreenisused,itisimportantnottoleavethestoveunattendedtorespond

promptlyintheeventofsmokespillageintotheroom.Potentialcausesofsmokespillageare

describedinsectionheightofthismanual.SeeAppendix4:InstallingtheFireScreen(AC01315)

forinstallationinstructions.



4.2 YOURFIRSTFIRES

Twothingswillhappenasyouburnyourfirstfewfires;thepaintcuresandtheinternal

componentsofthewoodfireareconditioned.

Asthepaintcures,someofthechemicalsvaporize.Thevaporsarenotpoisonous,buttheydo

smellbad.Freshpaintfumescanalsocausefalsealarmsinsmokedetectors.So,whenyoufirst

lightyourwoodfire,bepreparedbyopeningdoorsand/orwindowstoventilatethehouse.Asyou

burnhotterandhotterfires,moreofthepaintedsurfacesreachthecuringtemperatureofthe

paint.Thesmellofcuringpaintdoesnotdisappearuntilyouhaveburnedoneortwoveryhot

fires.

Burnoneortwosmallfirestobeginthecuringandconditioningprocess.Thenbuildbiggerand

hotterfiresuntilthereisnolongeranypaintsmellfromthewoodfire.Oncethepaintsmell

disappears,yourwoodfireisreadyforseriousheating.



OsburnMatrixInstallationandOperationManual

18______________________________________________________________________________

4.3 LIGHTINGFIRES

Eachpersonwhoheatswithwooddevelopstheirownfavoritewaytolightfires.Whatever

methodyouchoose,yourgoalshouldbetogetahotfireburningquickly.Afirethatstartsfast

produceslesssmokeanddepositslesscreosoteinthefluesystem.Herearethreepopularand

effectivewaystostartwoodfires.

4.3.1 CONVENTIONALFIRESTARTING

Theconventionalwaytobuildawoodfireistobunch

up5to10sheetsofplainnewspaperandplacethem

inthefirebox.Next,place10orsopiecesoffine

kindlingonthenewspaper.Thiskindlingshouldbe

verythin;lessthan25mm(1”).Next,placesome

largerkindlingpiecesonthefinekindling.Openthe

aircontrolfullyandlightthenewspaper.Ifyouhave

atall,straightfluesystemyoushouldbeabletoclose

thedoorimmediatelyandthefirewillignite.Ifyour

fluehaselbowsoranoutsidefluesystem,youmay

needtoleavethedoorclosedbutunlatchedforafew

minutesasthenewspaperignitesandheatintheflue

systemproducessomedraft.Oncethefirehas

ignited,closethedoorandleavetheaircontrolfully

open.

Aconventionalkindlingfirewithpaper

underfinelysplitwood.

DONOTLEAVETHEWOODFIREUNATTENDEDWHENTHEDOORISSLIGHTLYOPENEDDURING

IGNITION.ALWAYSCLOSETHEDOORAFTERIGNITION.

Afterthekindlingfirehasmostlyburned,youcanaddstandardfirewoodpiecesuntilyouhavea

fireoftherightsizefortheconditions.

4.3.2 THETOPDOWNFIRE

Thetopdownfirestartingmethodsolvestwoproblemswiththeconventionalmethod:first,it

doesnotcollapseandsmotheritselfasitburns;andsecond,itisnotnecessarytobuildupthefire

graduallybecausethefireboxisloadedbeforethefireislit.Atopdownfirecanprovideuptotwo

hoursofheatingormore.Thetopdownmethodonlyworksproperlyifthewoodiswell‐seasoned.

Startbyplacingthreeorfourfull‐sizedsplitpiecesofdryfirewoodinthefirebox.Next,place4or5

morefinelysplitpiecesoffirewood(50mmto75mm[2”to3”]india.)onthebaselogsatright

angles(logcabinstyle).Nowplaceabout10piecesoffinelysplitkindlingonthesecondlayerat

rightangles.

OsburnMatrixInstallationandOperationManual

______________________________________________________________________________19

Thefireistoppedwithabout5sheetsofnewspaper.Youcanjustbunchthemupandstuffthemin

betweenthekindlingandtheundersideofthebaffle.Oryoucanmakenewspaperknotsbyrolling

upsinglesheetscornertocornerandtyingaknotinthem.Theadvantageofknotsisthatthey

don’trolloffthefireastheyburn.Lightthenewspaperandwatchasthefireburnsfromtopto

bottom.

4.3.3 TWOPARALLELLOGS

Placetwospitlogsinthefirebox.Placeafewsheetsoftwistednewspaperbetweenthelogs.Now

placesomefinekindlingacrossthetwologsandsomelargerkindlingacrossthose,logcabinstyle.

Lightthenewspaper.

4.3.4 USINGFIRESTARTERS

Manypeopleliketousecommercialfirestartersinsteadofnewspaper.Someofthesestartersare

madeofsawdustandwaxandothersarespecializedflammablesolidchemicals.Followthe

packagedirectionsforuse.

Gelstartermaybeusedbutonlyiftherearenohotemberspresent.Useonlyinacoldfireboxto

startafire.

DONOTUSEFLAMMABLELIQUIDSSUCHASGASOLINE,NAPHTHA,FUELOIL,MOTOROIL,OR

AEROSOLSTOSTARTORREKINDLETHEFIRE.



4.4 MAINTAININGWOODFIRES

4.4.1 GENERALADVICE

Woodheatingwithaspaceheaterisverydifferentthanotherformsofheating.Therewillbe

variationsinthetemperatureindifferentpartsofthehouseandtherewillbevariationsin

temperaturethroughoutthedayandnight.Thisisnormal,andforexperiencedwoodburners

theseareadvantagesofzoneheatingwithwood.

Donotexpectsteadyheatoutputfromyourwoodfire.Itisnormalforitssurfacetemperatureto

riseafteranewloadofwoodisignitedandforitstemperaturetograduallydeclineasthefire

progresses.Thisrisingandfallingoftemperaturecanbematchedtoyourhouseholdroutines.For

example,theareatemperaturecanbecoolerwhenyouareactive,suchaswhendoinghousework

orcooking,anditcanbewarmerwhenyouareinactive,suchaswhenreadingorwatching

television.

Woodburnsbestincycles.Acyclestartswhenanewloadofwoodisignitedbyhotcoalsandends

whenthatloadhasbeenconsumeddowntoabedofcharcoalaboutthesamesizeasitwaswhen

thewoodwasloaded.Donotattempttoproduceasteadyheatoutputbyplacingasinglelogon

thefireatregularintervals.Alwaysplaceatleastthree,andpreferablymore,piecesonthefireat

atimesothattheheatradiatedfromonepiecehelpstoignitethepiecesnexttoit.Eachloadof

woodshouldprovideseveralhoursofheating.Thesizeofeachloadcanbematchedtothe

amountofheatneeded.

OsburnMatrixInstallationandOperationManual

20______________________________________________________________________________

Whenyouburnincycles,yourarelyneedtoopenthewoodfire’sloadingdoorwhilethewoodis

flaming.Thisisanadvantagebecausethereismorechancethatsmokewillleakfromthewood

firewhenthedoorisopenedasafullfireisburning.Thisisespeciallytrueiftheflueconnectorhas

90degreeelbowsandifthefluesystemrunsuptheoutsidewallofthehouse.

IFYOUMUSTOPENTHEDOORWHILETHEFUELISFLAMING,OPENTHEAIRCONTROLFULLYFOR

AFEWMINUTES,THENUNLATCHANDOPENTHEDOORSLOWLY.

4.4.2 ASHREMOVAL

Ashshouldberemovedfromthefireboxeverytwoorthreedaysoffulltimeheating.Donotlet

theashbuildupinthefireboxbecauseitwillinterferewithproperfiremanagement.

Thebesttimetoremoveashisafteranovernightfirewhenthewoodfireisrelativelycool,but

thereisstillsomefluesystemdrafttodrawtheashdustintothewoodfireandpreventitfrom

comingintotheroom.

Afterasheshavebeenremovedfromthewoodfireandplacedinatightlycoveredmetal

container,theyshouldbetakenoutsideimmediately.Theclosedcontainerofashesshouldbe

placedonanon‐combustiblefloororonthegroundwellawayfromallcombustiblematerials

pendingfinaldisposal.Ashesnormallycontainsomelivecharcoalthatcanstayhotforseveral

days.Iftheashesaredisposedofbyburialinsoilorotherwiselocallydispersed,theyshouldbe

retainedintheclosedcontaineruntilallcindershavethoroughlycooled.Otherwasteshallnotbe

placedinthiscontainer.

NEVERSTOREASHESINDOORSORINANON‐METALICCONTAINERORONAWOODENDECK.

4.4.3 RAKINGCHARCOAL

Rekindlethefirewhenyounoticethattheroomtemperaturehasfallen.Youwillfindmostofthe

remainingcharcoalatthebackofthefirebox,furthestfromthedoor.Rakethesecoalstowards

thedoorbeforeloading.Therearetworeasonsforthisrakingofthecoals.First,itconcentrates

themnearwheremostofthecombustionairentersthefireboxandwheretheycanignitethenew

loadquickly,andsecond,thecharcoalwillnotbesmotheredbythenewloadofwood.Ifyouwere

tosimplyspreadthecharcoalout,thenewloadwillsmoulderforalongtimebeforeigniting.



Removeashfirst,andthenrakecharcoaltowardsthefrontofthefireboxbeforeloadingsothatit

willignitethenewload.

Other manuals for MATRIX

Table of contents

Other Osburn Indoor Fireplace manuals

Popular Indoor Fireplace manuals by other brands

Miles Industries

Miles Industries HORIZON 535XAN Installation & operating instructions

Modern Flames

Modern Flames Landscape Pro Multiview Series Installation and owner's manual

Logaire

Logaire Micros Ash Hearth Assembly

CrownFlame

CrownFlame MT321C Assembly instructions

kozy heat

kozy heat 55801 Installation & operating manual

Ecoflam

Ecoflam BLU 1500.1 LN PR Technical data, Operating Instructions, Electric Diagrams, Spare Parts List

Empire Comfort Systems

Empire Comfort Systems MILLIVOLT DVCD32FP30N-4 Homeowner's manual

Lennox Hearth Products

Lennox Hearth Products LENNOX MPE-33R Installation and operating instructions

Continental Fireplaces

Continental Fireplaces BCDV36CFGN Installation and operating instruction

livin flame

livin flame Lugano Installation instructions & operating manual

Valcourt

Valcourt FG00010 owner's manual

EdilKamin

EdilKamin SOLEIL plus Installation, use and maintenance

Travis Industries

Travis Industries 1250 Insert owner's manual

Heatilator

Heatilator Wood Burning Fireplace EL42 Series owner's manual

Desa

Desa P325 OWNER'S OPERATION AND INSTALLATION MANUAL

Firenzo

Firenzo KOMPACT RU Installation and operator's handbook

Valcourt

Valcourt Manoir FP1 Installation and operation manual

Appalachian Stove & Fabricators

Appalachian Stove & Fabricators 52-Bay Installation and operation procedures

Osburn MATRIX User manual

Popular Indoor Fireplace manuals by other brands
