Osmio WP-X20-500 User manual

User manual
SODIUM HYPOCHLORITE
ELECTROLYSIS GENERATOR
1. Product description
2. Parameters
3. Application
Disinfection for offices, public spaces, public toilets,
elevator, hotel and vehicle, etc.
Nozzle Charging cable
Salt spoon
User manual
User
manual
Bottle body
Base
Model
Input
Production time
Material
Size
Capacity
WP-X20-500
DC5V/2A
10min
Rated power 8W
PC/ABS
Φ90*256mm
500ml
1. The electrical unit is guaranteed for one year from
the date of purchase (excluding consumables). The
following consumable parts are not covered by the
warranty. If damaged, you will need to purchase
replacements: charging cable, electrode,nozzle.
2. During the warranty period, proof of purchase and
this warranty card are required for repair. Once the
product has been used customers are responsilbe
for the cost of replacing all consumable parts.
3.Do not disassemble or use this produce improperly
as ths will invalidate the warranty. We can provide
ongoing maintenance if required (call for price).
Note: 1. Please keep this card in a safe place. If
maintenance is needed, please contact your
authorised service centre with this card and receipt.
2. If your address and telephone number have
changed, please inform the service centre.
Warranty Card
Buyer
Customer Warranty Card
Date of
purchase
Contact
information
Name
Address
Product
issues
Suggestion

1. Using the spoon provided measure four spoons of the
salt (12g) into the bottle.
2. Add sufficient water to the bottle,and shake the bottle
gently to dissolve the salt completely.
3. Keep adding the water to fill the bottle and tighten the
nozzle.
4. Connect the power cable to machine, connect the USB
to the adapter, a buzzer will sound indicating that the unit
is connected.
5. The unit is powered by an DC5V/2A adapter, when
plugged into the DC power port, the red indicator light will
come on.
ɫ Select the five minute cyle to make the disinfectant:
Press the button for 1.5 second, the blue BLN control will
light up and the unit will start producing the disinfectant.
It will stop working automatically after five minutes.
This function can be cycled.
ɫ Select the ten minute cycle to make the disinfectant:
Press the button three times,the green BLN control will
light up and the unit will start making the disinfectant in
five seconds. It will stop working automatically after ten
minutes. The green indicator light will come on indicating
that disinfectant was produced.
This function can be cycled.
6.Pull the USB cable out of the unit and use the product
as required.
7.After use empty the disinfectant water from the bottle,
wash the bottle with clean water and leave to dry.
In order to avoid possible injury or property damage
to yourself or others, please pay attention to the
following safety rules.
1. If the product develops a fault, please turn off the
power immediately.
2. Do not touch the power plug with wet hands to
avoid electric shock.
3. Please keep unused disinfection water out of the
reach of children and avoid direct sunlight.
4. Sodium hypochlorite disinfection water has an
oxidizing effect on metals. Do not store it with metal
utensils. When disinfecting metal utensils, please
wash them thoroughly with water immediately and
wipe clean.
5.Do not drink the disinfection water.
6. Disinfection water has a bleaching effect on fabric.
We suggest that you do not use it on coloured or dark
clothes. Do not use it to soak silk or leather.
7. Do not touch the water in the machine during
charging.
8. After the production of disinfection water is
complete, the power plug should be removed.
9. To extend the service life, do not keep the salt
water in the bottle when not in use for long periods.
Do not store the sodium hypochlorite disinfection
water in the bottle. After use empty the bottle
immediately, rinse the inside of the bottle using clean
water and then dry.
10. The unit is not designed to work continuously and
not using as directed will invalidate the warranty.
Make sure there is at least 5 minutes between each
production cycle.
11. Do not place the bottle near naked flames or heat.
12. Do not use in the microwave oven, electric kettle,
rice cooker, electric water bottle for heating.
13. We do not accept any responsibility for the
consequences if the users do not follow these
instructions when handlling he device.
5. Descaling maintenance
4.Operation
In order to maintain the system it is recommended you
perform descaling maintenance on the device regularly
(at least once per month)
1. Add edible citric acid into the bottle, (about 2g each
time), add water, soak for 2 hours then discard the
water.
The longer the soaking time, the better the descaling
effect.
2. Add clean water into the bottle when the device is off
and press the power button for about 5 seconds. Then
the descaling process will start (the red light will
remain on). After the function is complete, the device
will stop automatically and the red light will turn off;
pour out the water and wash the bottle.
You can select either of the above methods to descale
the unit. It is recommended to use the two methods
together for the best result.
ɫDo not use volatile solvents such as detergents and
thinners to clean the inner wall of the bottle;
ɫDo not put any liquid except water into the bottle.
ɫDo not disassemble the bottom cover for maintenance
Safety precautions
6. Function of sodium
hypochlorite disinfectant
This product produces low-concentration sodium
hypochlorite disinfectant. It is not only used in
households, but also widely used in many fields for
sterilization, disinfection, algae elimination,
deodorization, etc.
Salt
amount Electrolysis
time Effective
chlorine
content
Applicable disinfection
5min 150-200mg/L
10min ı300mg/L
⭥ս٬ mv 5min=620mv/10min=880mv
Note
The data based on Joint Laboratory for Hydrogen-Rich
Technology
12g
500ml Sodium Hypochlorite Electrolysis Generator
Disinfection in the home,
office, elevator, vehicle
handrails, etc
Medical grade: sterilization of
bacteria prone items, such as
wet clothes, mops
