Osprey Ozone 28/80L User manual

OZONE SERIES
Size Capacity Weight
28”/ 80 l / One Size 4882 cu.in. / 80 l 5 lb 0 oz / 2.27 kg
External Dimensions 28”h x 14”w x 14”d / 72h x 35.5w x 35d CM
*22”/ 46 l / One Size 2807 cu.in. / 46 l 4 lb 7 oz / 2.02 kg
External Dimensions 22”h x 14”w x 9”d / 56h x 35.5w x 23d CM
*18”/ 36 l / One Size 2197 cu.in. / 36 l 4 lb 4 oz / 1.92 kg
External Dimensions 18”h x 14”w x 8”d / 46h x 35.5w x 20d CM
Key Fabrics
• 210D Nylon Shadow Box
• 210D Nylon Velocity
* Meets U.S. maximum legal carry-on guidelines
OZONE SERIES SHARED FEATURES
The Ozone Series of ultra-light wheeled travel packs
utilizes Osprey’s proprietary High Road LT™ Chassis
suspension system.
It features:
• An ergonomic, single tube retractable
handle with integrated venting
• A 6001 T6 aluminum frame
• An ultra-durable and ultra-lightweight injection
molded high clearance ABS base with integrated
foot bar/grab handle and large, high traction
polyurethane wheels with sealed bearings
Grab Handles
Fully padded, reinforced top and side, low
profi le grab handles along with the foot
bar/grab handle provide several comfortable
carry options.
Zippered Top Pocket
An easily accessed, zippered top accessory pocket is ideal
for toiletries, liquids or other frequently needed items.
www.ospreypacks.com/PackTech/OwnersManuals
에서 사용자 설명 서를다운로드하세요
KR
Ozone/Shuttle Series
Owner’s Manual
Congratulations on your purchase of an Osprey Ozone
or Shuttle Series wheeled travel pack. Our obsession with
detail rewards you with a truly full-featured pack and we
want to be sure that you understand and utilize your new
Osprey completely. Here’s a full tour of your pack from
the ground up.
11.1V
Printed on recycled content paper
OSPREY ADDONS™
Customize and protect your pack with Osprey’s
full line of AddOns.™ For the full lineup, please
visit your local Osprey retailer or visit our web site
www.ospreypacks.com.
PACK CARE
Osprey recommends Nikwax® products for pack care.
For complete instructions on cleaning your pack,
visit:www.ospreypacks.com/PackTech/
CARRY-ON LUGGAGE
The Ozone 22”/ 46L, the Ozone 18”/36L and the
Shuttle 22”/ 40L all comply with the maximum
carry-on luggage size specifi cations as required
by most U.S. airlines. TIP: When placing these bags in the
overhead compartment, stow retractable handle fi rst as
advised by most U.S. airlines (not wheels fi rst).
GUARANTEE
At Osprey, sustainability is designed into
our packs, which are built to last a lifetime and backed by a
superb guarantee, no matter how hard you are on your gear.
Visit www.ospreypacks.com for details.
QUESTIONS?
Contact Osprey Customer Service. Real help from
real people. Scroll over the customer service tab at
www.ospreypacks.com.
OSPREY PACKS, INC.
115 PROGRESS CIRCLE
CORTEZ, CO 81321 USA
866-284-7830
WWW.OSPREYPACKS.COM
Ozone Shuttle
28”/80L 22”/46L 18”/36L
Panel Load Main Compartment
A dual lockable zippered panel provides access to
the main compartment. Once inside, the internal
organization consists of dual internal compression
straps to hold clothes securely, with internal
organization consisting of a full length, zippered
mesh pocket on the front panel with a single,
zippered fabric pocket and one zippered mesh
pocket along the sides.
External Compression
Dual external compression straps help to secure
and compress loads while protecting the Ozone’s
zippers.
Vertical Zippered Pockets
Dual vertical zippered full length front panel
pockets provide additional organizational options
and easy storage of longer items.
Rear Panel Access
A zippered, rear panel compartment with an
internal, mesh zippered pocket off ers ideal
magazine storage and handy access to smaller
items.
Handle-It™ Accessory Bag Attachment System
The Ozone Series accessory bags (sold
separately) use Osprey’s innovative Handle-It™
attachment system to quickly connect to our
High Road LT™ Chassis handle or any similar
size, single-tube handle. The key element is an
open slot that folds down against the accessory
bag backpanel when not in use. Flip the panel
up and slip the slot over the extended handle
on the roller to hang the bag for a very stable,
secure connection. Compared to traditional
sleeve attachment designs which place the
additional weight of an accessory bag high on
the handle making the roller feel heavier and
less stable, the Osprey Handle-It™ design keeps
the additional load well-balanced and directly
over the wheels.

Size Capacity Weight
32” / 110 L / One Size 6713 cu.in. / 110 L 8 Lb 13 Oz / 4.01 kg
External Dimensions 32”H X 16”W X 12”D / 82H X 40.5W X 31D CM
28” / 80 L / One Size 4882 cu.in./ 80 L 7 Lb 3 Oz / 3.26 kg
External Dimensions 28”H X 14”W X 12”D / 72H X 35.5W X 30D CM
*22” / 40 L / One Size 2440 cu.in. / 40 L 5 Lb 15 Oz / 2.68 kg
External Dimensions *22”H X 14”W X 9”D / 56H X 35.5W X 23D CM
Key Fabrics
• 420D HD Nylon Pack Cloth
• 1680D Ballistic
• 210D Nylon
* Maximum legal carry-on size
* Shuttle 22”/40L available in select markets only
SHUTTLE SERIES SHARED FEATURES
Modified High Road™Chassis
The Shuttle Series utilizes Osprey’s proprietary
High Road™ Chassis. (Shuttle 32” / 110L utilizes
a modifi ed 16” / 40.5CM wide version) Features
include an ergonomic, retractable handle with
integrated vent fi ns, a 6061 T6 aluminum frame,
ultra durable and lightweight injection molded
high clearance ABS base with integrated foot/grab
handle, oversized, high traction polyurethane wheels
with sealed bearings and a high clearance design.
Lockable Main Compartment
Dual oversized lockable zippers provide panel
load access to the main compartment.
Liquids/Accessory Pocket
An easy access zippered liquids/accessory pocket
at the top of the Shuttle Series provides quick
access to liquids when passing through airport
security.
32”/110L 28”/80L *22”/40L
SHUTTLE SERIES SHUTTLE UNIQUE FEATURES
Bellows Pocket (32”/110L, 28”/80L)
The main compartment in the Shuttle 32”/110L
and 28”/80L features a zippered, expandable
bellows divider to help organize large loads.
Full-length Side Pocket (32”/110L)
A single, full-length vertical zippered side
pocket provides organization and additional
storage for longer items.
Front Panel Top Pocket
(28”/80L, 22”/40L)
A front panel zippered slash pocket with
internal key clip is ideal for quick access
and additional organization.
Backpanel Compartment
(28”/80L, 22”/40L)
The backpanel compartment on the Shuttle
28”/80L and 22”/40L is accessed via a
hook-and-loop fl ap and off ers ideal storage
for magazines, documents and other needed
items.
Courier Bag Attachment
An integrated, hideaway courier bag attachment strap
provides quick and secure courier carry.
Name Tag Holder
A concealed name tag holder located on the Shuttle
backpanel delivers quick, protected identifi cation.
Grab Handles
Each Shuttle can be carried with a padded top or side
grab handle. The Shuttle 32’’/110L has dual side grab
handles due to its overall load capacity.
Front Panel Pocket
A vertical zippered front panel slash pocket is ideal
for easy access storage options.
StraightJacket™Compression
Osprey’s StraightJacket™ Compression System and
foam padded sidewalls allows you to further compress
loads. Two extra female buckles on the right side of your
Shuttle allow you to StraightJacket™ your pack when
carrying a minimal load. Connect the straps to the two
female buckles at the edge of the backpanel and adjust
to desired tension as required by the load.
AddOns™Attachment
The Shuttle Series are Osprey AddOns™ compatible and
allow the added versatility and capacity provided by
the Daylite attachment pack.
The sliders along the sides of the Daylite AddOns™button
through the attachment D-Rings found on the front
panel of the Shuttle. Push the slider through the D-Ring
from underneath and tug on the straps to tighten.
Reverse to remove.
Internal Organization
The internal organization of the Shuttle 32”/110L
and 28”/80L main compartments consists of dual
front panel zippered mesh pockets, dual side zippered
mesh pockets, (the Shuttle 22”/40L features single
front zippered and side zippered mesh pockets) and
dual compression straps to prevent migration of
clothing.
OZONE DAY PACK (Sold separately)
The Ozone Day Pack is an ultra-lightweight,
full featured travel daypack featuring Osprey’s
innovative Handle-It™ System for quick, stable
attachment to our HighRoad LT™ Chassis handle,
or any similar single-tube style handle.
Unique Features
• Handle-It™ attachment slot quickly connects
to most single tube roller handles
• Zippered access to internal padded laptop sleeve
and zippered fl eece lined tablet/eReader sleeve
(Fits laptops to 15”/38CM)
• Large zippered front organizer pocket with
internal key clip
SPECS ONE SIZE
Cubic Inches 1465
Liters 24
Lbs/Ounces 1/6
Kilograms 0.61
Inches 18H x 12W x 8D
Centimeters 45H x 30W x 20D
OZONE COURIER (Sold separately)
The Ozone Courier is an ultra-lightweight,
full featured travel courier featuring Osprey’s
innovative Handle-It™ System for quick, stable
attachment to our HighRoad LT™ Chassis handle,
or any similar single-tube style handle.
Unique Features
• Handle-It™ attachment slot quickly connects to
most single tube roller handles
• Zippered access to internal padded laptop sleeve
and zippered fl eece lined tablet/eReader sleeve.
(Fits laptops to 15”/38CM)
• Large zippered front organizer pocket with
internal key clip
SPECS ONE SIZE
Cubic Inches 1220
Liters 20
Lbs/Ounces 1/4
Kilograms 0.57
Inches 13H x 6W x 7D
Centimeters 32H x 41W x 17D
OZONE DAY / COURIER KEY
FABRICS
+ 210D nylon shadow box
+ 210D nylon velocity
