Ossila UNIT-X200 User manual

USERMANUAL
Manual Version: 2.0.E
Product Code: P2005A
Product Version: 2.0
Firmware Version: 2.4
Software Version: 1.2
SOURCE MEASURE
UNIT–X200

Contents
1. Overview ...................................................................................................4
1.1 Features.......................................................................................................4
2. EU Declaration of Conformity (DoC).................................................5
3. Safety..........................................................................................................8
3.1 Warning........................................................................................................8
3.2 Use of Equipment.....................................................................................8
3.3 Hazard Icons...............................................................................................8
3.4 General Hazards.......................................................................................8
3.5 Power Cord Safety....................................................................................9
3.6 Servicing.......................................................................................................9
3.7 Health and Safety – Servicing................................................................9
4. Software Requirements.......................................................................9
5. Unpacking.............................................................................................. 10
5.1 Packing List ...............................................................................................10
5.2 Damage Inspection................................................................................10
6. Specications........................................................................................ 10
6.1 Specication Conditions.......................................................................10
6.2 Source Measure Units (SMU 1 and SMU 2) ...................................11
6.3 Voltmeter (Vsense1 and Vsense2) ....................................................14
6.4 Measurement Non-Linearity..............................................................14
6.5 Shutter/Trigger.........................................................................................14
6.6 Physical Specications...........................................................................15
7. System Components.......................................................................... 15
8. Installation............................................................................................. 17
8.1 Power On...................................................................................................17
8.2 USB Driver Installation...........................................................................17
8.3 Connecting to a Network.....................................................................18
8.4 Front Panel Software Installation.......................................................18

9. Front Panel Software.......................................................................... 19
9.1 Connection Controls..............................................................................19
9.2 Utility Controls..........................................................................................20
9.3 Front Panel................................................................................................21
9.4 Data Plots...................................................................................................23
9.5 Logged Data .............................................................................................25
9.6 IV Curve......................................................................................................26
10. Advanced Measurements.............................................................. 29
11. Troubleshooting................................................................................ 30
12. Related products............................................................................... 31
12.1 Related Consumables.........................................................................31
12.2 Related Equipment..............................................................................31

4
1. Overview
The Ossila Source Measure Unit (SMU) incorporates two voltage sources for measuring current and two
voltage meters for measuring voltage. With it, you can measure a wide range of research devices including
photovoltaics, LEDs and OLEDs, transistors, and more.
The ability to control instruments is a key skill for experimental scientists and engineers. We have designed
the SMU so that no matter what your skill level is, you can access aordable, precise instrumentation.
1.1 Features
• Dual Source Measure (SMU) channels
• Dual Voltmeter channels
• ±10 V source
• Up to ±200 mA source/sink current per channel
• Five software controlled current ranges (10 nA – 200 mA)
• Shutter control or trigger input
• Serial and I2C extension
• PC software front panel
• USB & Network control
• Simple text-based interface

5
2. EU Declaration of Conformity (DoC)
We
Company Name: Ossila Limited
Postal Address: Solpro Business Park, Windsor Street.
Postcode: S4 7WB
City: Sheeld
Telephone number: [phone]
Email Address: [email protected]
declare that the DoC is issued under our sole responsibility
and belongs to the following product:
Product: Source Measure Unit – X200 (P2005A2)
Serial number: P2005A2-xxxx
Object of declaration:
Source Measure Unit – X200 (P2005A2)
The object of declaration described above is in conformity
with the relevant Union harmonisation legislation:
EMC Directive 2014/30/EU
RoHS Directive 2011/65/EU
Signed:
Name: Dr James Kingsley
Place: Sheeld
Date: 01/10/2018

6
[Декларация] за съответствие на ЕС
Производител: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, Великобритания
Декларира с цялата си отговорност, че посоченото оборудване съответства на приложимото законодателство на ЕС за
хармонизиране, посочено на предходната(-ите) страница(-и) на настоящия документ.
[Čeština] Prohlášení o shodě EU
Výrobce: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, Spojené Království
Prohlašujeme na vlastní odpovědnost, že uvedené zařízeni je v souladu s příslušnými harmonizačními předpisy EU uvedenými na
předchozích stranách tohoto dokumentu.
[Dansk] EU-overensstemme lseserklærin g
Producent: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, UK
Erklærer herved, at vi alene er ansvarlige for, at det nævnte udstyr er i overensstemmelse med den relevante EU-
harmoniseringslovgivning, der er anført på den/de foregående side(r) i dette dokument.
[Deutsch] EU-Konformitätserklärung
Hersteller: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, Vereinigtes Königreich
Wir erklären in alleiniger Verantwortung, dass das aufgeführte Gerät konform mit der relevanten EU-Harmonisierungsgesetzgebung
auf den vorangegangenen Seiten dieses Dokuments ist.
[Eesti keel] ELi vastavusavaldus
Tootja: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, UK
Kinnitame oma ainuvastutusel, et loetletud seadmed on kooskõlas antud dokumendi eelmisel lehelküljel / eelmistel lehekülgedel ära
toodud asjaomaste ELi ühtlustamise õigusaktidega.
[Ελληνικά] Δήλωση πιστότητας ΕΕ
Κατασκευαστής: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, Ηνωμένο Βασίλειο
Δηλώνουμε υπεύθυνα όn ο αναφερόμενος εξοπλισμός συμμορφώνεται με τη σχεnκή νομοθεσία εναρμόνισης της ΕΕ που υπάρχει
σnς προηγούμενες σελίδες του παρόντος εγγράφου.
[Español] Declaración de conformidad UE
Fabricante: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, Reino Unido
Declaramos bajo nuestra única responsabilidad que el siguiente producto se ajusta a la pertinente legislación de armonización de la
UE enumerada en las páginas anteriores de este documento.
[Français] Déclaration de conformité UE
Fabricant: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, Royaume-Uni
Déclarons sous notre seule responsabilité que le matériel mentionné est conforme à la législation en vigueur de l’UE présentée sur la/
les page(s) précédente(s) de ce document.
[Hrvatski] E.U izjava o sukladnosti
Proizvođač: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, Velika Britanija
Izjavljujemo na vlastitu odgovornost da je navedena oprema sukladna s mjerodavnim zakonodavstvom EU-a o usklađivanju koje je
navedeno na prethodnoj(nim) stranici(ama) ovoga dokumenta.
[Italiano] Dichiarazione di conformità UE
Produttore: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, UK
Si dichiara sotto la propria personale responsabilità che l’apparecchiatura in elenco è conforme alla normativa di armonizzazione UE
rilevante indicata nelle pagine precedenti del presente documento.
[Latviešu] ES atbils tības deklarācija
Ražotājs: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, UK
Ar pilnu atbilclību paziņojam, ka uzskaitītais aprīkojums atbilst attiecīgajiem ES saskaņošanas tiesību aktiem, kas minēti iepriekšējās šī
dokumenta lapās.

7
[Lietuvių k.] ES atitikties deklaracija
Gamintojas: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, UK
atsakingai pareiškia, kad išvardinta įranga atitinka aktualius ES harmonizavimo teisės aktus, nurodytus ankstesniuose šio dokumento
[Magyar] EU-s megfelelőségi nyilatkozat
Gyártó: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, UK
Kizárólagos felelősségünk mellett kijelentjük, hogy a felsorolt eszköz megfelel az ezen dokumentum előző oldalán/oldalain található
EU-s összehangolt jogszabályokra vonatkozó rendelkezéseinek.
[Nederlands] EU-Conformiteitsverklaring
Fabrikant: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, UK
Verklaart onder onze uitsluitende verantwoordelijkheid dat de vermelde apparatuur in overeenstemming is met de relevante
harmonisatiewetgeving van de EU op de vorige pagina(‘s) van dit document.
[Norsk] EU-samsvarserklæ ring
Produsent: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, UK
Erklærer under vårt eneansvar at utstyret oppført er i overholdelse med relevant EU-harmoniseringslavverk som står på de(n) forrige
siden(e) i dette dokumentet.
[Polski] Deklaracja zgodności Unii Europejskiej
Producent: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, UK
Oświadczamy na własną odpowiedzialność, że podane urządzenie jest zgodne ze stosownymi przepisami harmonizacyjnymi Unii
Europejskiej, które przedstawiono na poprzednich stronach niniejszego dokumentu.
[Por tuguês] Declaração de Conformidade UE
Fabricante: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, Reino Unido
Declara sob sua exclusiva responsabilidade que o equipamento indicado está em conformidade com a legislação de harmonização
relevante da UE mencionada na(s) página(s) anterior(es) deste documento.
[Română] Declaraţie de conformitate UE
Producător: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, Regatul Unit
Declară pe proprie răspundere că echipamentul prezentat este în conformitate cu prevederile legislaţiei UE de armonizare aplicabile
prezentate la pagina/paginile anterioare a/ale acestui document.
[Slovensky] Vyhlásenie o zhode pre EÚ
Výrobca: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, Spojené kráľovstvo
Na vlastnú zodpovednosť prehlasuje, že uvedené zariadenie je v súlade s príslušnými právnymi predpismi EÚ o harmonizácii
uvedenými na predchádzajúcich stranách tohto dokumentu.
[Slovenščina] Izjava EU o skladnosti
Proizvajalec: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, UK
s polno odgovornostjo izjavlja, da je navedena oprema skladna z veljavno uskladitveno zakonodajo EU, navedeno na prejšnji strani/
prejšnjih straneh tega dokumenta.
[Suomi] EU-vaatimustenm ukaisuusvakuutus
Valmistaja: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, UK
Vakuutamme täten olevamme yksin vastuussa siitä, että tässä asiakirjassa luetellut laitteet ovat tämän asiakirjan sivuilla edellisillä
sivuilla kuvattujen olennaisten yhdenmukaistamista koskevien EU-säädösten vaatimusten mukaisia.
[Svenska] EU-försäkran om överensstämmelse
Tillverkare: Ossila Ltd., Solpro Business Park, Windsor Street, S4 7WD, Storbritannien
Vi intygar härmed att den utrustning som förtecknas överensstämmer med relevanta förordningar gällande EU-harmonisering som
fmns på föregående sidor i detta dokument.

8
3. Safety
3.1 Warning
• Do NOT connect external voltage sources to either SMU channel.
• The absolute maximum input voltage for the Vsense channels is ±12 V. DO NOT apply
input while not powered.
3.2 Use of Equipment
The Ossila Source Measure Unit is designed to be used as instructed. It is intended for use under the
following conditions:
• Indoors in a laboratory environment (Pollution Degree 2)
• Altitudes up to 2000m
• Temperatures of 5°C to 40°C; maximum relative humidity of 80% up to 31°C.
The unit is supplied with a 24 VDC / 2A power adapter with a power cord for the country of purchase, in
accordance with European Commission regulations and British Standards. Use of any other electrical power
cables, adaptors, or transformers is not recommended.
3.3 Hazard Icons
The following symbols can be found at points throughout the manual. Note and read each warning before
attempting any associated operations associated with it:
Table 3.1. Hazard warning labels used in this manual.
Symbol Associated Hazard
Electrical shock
3.4 General Hazards
Before installing or operating the Ossila Source Measure Unit, there are several health and safety
precautions which must be followed and executed to ensure safe installation and operation.

9
3.5 Power Cord Safety
3.7 Health and Safety – Servicing
4. Software Requirements
3.6 Servicing
Table 4.1. Ossila Front Panel requirements.
Emergency power disconnect options: use the power cord as a disconnecting method
and remove from wall. To facilitate disconnect, make sure the power outlet for this cord is
readily accessible to the operator.
Servicing should only be performed by an Ossila engineer. Any modication or
alteration may damage the equipment, cause injury, or death. It will also void your
equipment’s warranty.
If servicing is required, please return the unit to Ossila Ltd. The warranty will be invalidated if:
• Modication or service has been carried out by anyone other than an Ossila engineer.
• The unit has been subjected to chemical damage through improper use.
• The unit has been operated outside the usage parameters stated in the user documentation
associated with the unit.
• The unit has been rendered inoperable through accident, misuse, contamination, improper
maintenance, modication, or other external causes.
The Ossila SMU is compatible with our Front Panel software which is included with the system. It allows for
simple operation of the SMU and precision voltmeter channels.
Table 4.1 details the minimum computer specications for the Ossila Front Panel software
Operating System Windows 10
CPU Dual-core 2 GHz
RAM 2 GB
Hard Drive Space 100 MB
Connectivity USB 2.0 or newer, Ethernet

10
5.1 Packing List
The standard items included with the Ossila Source Measure Unit are:
• The Ossila Source Measure Unit.
• 24 VDC / 2 A DC power adapter with a cord set specically for country of operation
(plug type A, F, G, or I).
• USB-B cable.
• USB memory stick pre-loaded with the user manual, USB drivers, QC data, and software
Front Panel installer.
• Printed copy of the user manual.
The Ossila Source Measure Unit contains four channels: two source measure units (SMUs) and two precision
voltmeters. There is also a general-purpose shutter/trigger to allow other instruments to be controlled or
control the unit.
6. Specications
5. Unpacking
5.2 Damage Inspection
6.1 Specication Conditions
Examine the components for evidence of shipping damage. If damage has occurred, please contact Ossila
directly for further action. The shipping packaging will come with a shock indicator to show if there has been
any mishandling of the package during transportation.
The specications and information in this document are for the Ossila Source Measure Unit. All units meet
these standard specications when dispatched to the end-user.
The accuracy of both source and measurement of the unit are specied under the following conditions:
• Ambient temperature of 23 °C ± 5 °C, < 60% relative humidity.
• After a 30-minute warm-up period.
• Default measurement speed (OSR 5) unless specied.
• No lter.

11
6.2 Source Measure Units (SMU 1 and SMU 2)
The source measure units output a voltage and then measure both the voltage and current. The output
voltage is always measured at the output of the BNC (rather than assuming it is at the set voltage) in case of
any load eects (for example short circuiting the output or low impedances causing a small drop in voltage).
Each source measure unit has manually selectable ranges so that both high and low currents can be
measured accurately.
6.2.1 Power Specications
The unit is specied for a maximum operation power as in Table 6.1. Figure 6.1 shows the four-quadrant
safe operation zone of the unit.
Table 6.1. DC power specication.
Figure 6.1. The four-quadrant safe operation zone.
Power per SMU channel (continuous)
Four-quadrant Operation Source / Sink 2W (± 10 V at ±200 mA)

12
Table 6.2. Measurement speed modes.
OSR 1
Index
ADC
mode
ADC
(samples/
data point)
ADC 2 RMS
Noise
SMU 1/2 3(data
points/sec)
Vsense 1/2 3
(data points/
sec)
0x1 64 23 μV N / A N / A
1x1 128 3.5 μV 525 785
2x1 256 2 μV 276 414
3x1 512 1.4 μV 142 213
4x1 1024 1 μV 72 108
5x1 2048 750 nV 36 55
6x1 4096 510 nV 18 27
7x1 8192 375 nV 912
8x1 16384 250 nV 4.5 6
9x1 32768 200 nV 2.2 3
There is some allowance for being beyond these limits (± 10 V and ±200 mA). The unit has internal voltage
and current limits set at ±10.5 V and ±225 mA. If a voltage or current greater than these values is measured
on either SMU, the red error LED next to the SMU will turn on and the output voltage of the SMU will be set
to 0 V. This is a measure to reduce the possibility of damaging the unit due to excessive voltages or currents.
The voltage and current limits can be changed programmatically, but they should not be increased past the
default values as this will increase the possibility of damaging the unit.
6.2.2 Measurement Speed
The Ossila Source Measure Unit utilises a high-speed, 24-bit no Latency ∆Σ™ ADC. It provides ten speed/
resolution combinations (6.9 Hz/200 nV RMS noise to 3.5 kHz/25 µV RMS noise) which can be selected,
with no latency between conversion results. Additionally, a double-speed mode can be selected, enabling
output rates up to 7 kHz with one cycle latency. These modes are linked to a single variable called OSR
(Oversampling Rate) which is used to program the unit and take the measurement. Table 6.2 lists the various
speed settings of the unit, with maximum measurement rates for both SMU and voltmeter channels.

13
Table 6.3. Voltage measurement specications.
Mode OSR Range Accuracy Noise Resolution
Sourcing N / A ± 10 V ± 10 mV 333 μV 1.7E-4
Measuring 1 to 4 ± 10 V ± 10 mV 100 μV 1.0E-4
5 to 9 ± 10 V ± 10 mV 50 μV 1.0E-5
1OSR 10-19 will set the ADC in 2x mode with the same parameters of OSR 0-9, this will approximately double
the unit’s measurement rate.
2 ADC noise increases by approximately √2 when OSR is decreased. Note that this is not the unit
measurement noise levels.
3Values based on 1000 data points per measurement.
6.2.3 Voltage Source and Measurement Specications
Warning: Do NOT attach external voltage sources to either SMU module as this may result in
damage to the unit.
6.2.4 Current Measurement Specications
The current measurement of the Ossila Source Measure Unit is spread over 5 ranges. Each range has
a dierent maximum current, accuracy, and resolution. As the range number increases, the maximum
measurable current decreases, but the accuracy and resolution increase.
Table 6.4. Current measurement specications.
Range Max current Accuracy1Noise2Resolution Burden
1± 200 mA ± 500 μA 10 μA 1 μA < 10mV
2± 20 mA ± 10 μA 1 μA 100 nA < 10mV
3± 2 mA ± 1 μA 100 μA 10 nA < 10mV
4± 200 μA ± 100 nA 10 nA 1 nA < 10mV
5± 20 μA ± 10 nA 1 nA 100 pA < 10mV
1Accuracy has been measured at the maximum current of that range.
2Noise measurement at the highest OSR (9).

14
Table 6.5. Voltmeter specications.
OSR Range Accuracy Noise Resolution
1 to 4 1 to 5 ± 10 mV 100 μV 1.0E-4
5 to 9 1 to 5 ± 10 mV 50 μV 1.0E-5
6.3 Voltmeter (Vsense1 and Vsense2)
6.4 Measurement Non-Linearity
6.5 Shutter/Trigger
The Ossila Source Measure Unit has two additional voltage measurement channels marked as Vsense1 and
Vsense2. They are designed to accurately detect small voltages while simultaneously having a wide dynamic
range of ±10 V. Table 6.5 lists the specications of these additional channels.
The non-linearity in the measurement of the Ossila Source Measure Unit is kept well below the
measurement accuracy of every range. Such non-linearity is common due to dierent amplication stages
and analogue digital conversion processes.
The Shutter/Trigger can be used either as an input or an output. It can be used to send a trigger signal to
other instruments or congured to wait for a trigger from other instruments. The voltage level of the Shutter/
Trigger is 5 volts and can source and sink up to 30 mA of current; higher currents may result in damage to
the unit.
Warning: Do NOT apply currents to a SMU that are greater than the maximum current of the range
that is active, as this may result in damage to the unit.
Note: the Vsense module shares a ground plane with the SMU module of the same number (i.e.
Vsense 1 shares a ground plane with SMU 1) and hence is not isolated.

15
Table 6.6. Physical specications of the Source Measure Unit.
Channels (BNC connectors)
2 x source measure units (SMU)
2 x voltmeters (Vsense)
1 x shutter/trigger
Connectivity USB and Ethernet
Dimensions
Width: 125 mm
Height: 55 mm
Depth: 185 mm
Weight 0.55 kg
Power supply 24VDC/2A
6.6 Physical Specications
7. System Components
The Ossila Source Measure Unit P2005A comprises three items: the Ossila Source Measure Unit (Figure 7.1),
power adapter (Figure 7.2), and the Ossila Front Panel software (Figure 7.3).
Figure 7.1. Source Measure Unit.

16
Figure 7.3. The Ossila Front Panel PC software.
Figure 7.2. The 24 VDC power adapter

17
1. Connect the power supply rst to the mains outlet, and secondly to the unit.
I. The red and green power LED (at the back of the unit) and the fan will both switch on.
2. Leave for 30 minutes to warm up before performing any measurements.
1. Connect the unit to the computer using a USB cable.
2. On computers running Windows 10, the USB drivers will be installed automatically.
I. The unit will appear in the Device Manager under the Ports (COM & LTP) section as USB Serial
Device (COMX) as shown in Figure 8.1.
Figure 8.1. Ossila Source Measure Unit in the Device Manager.
8. Installation
8.1 Power On
8.2 USB Driver Installation
3. Alternatively, the USB drivers can be installed by running the 32-bit or 64-bit installation le found on
the USB memory stick provided with the unit.

18
The Ossila Source Measure Unit is designed to work with any network that supports DHCP. When the
ethernet cable is plugged in, the unit will automatically detect and identify the network and register itself
within a few seconds.
For most networks, the unit will need no further work – simply plug in and wait for the DHCP to work, and it is
ready to go. However, there are two situations where more steps are required:
(I) Networks Requiring Registering Devices
Some large corporate networks (such as universities) have increased security levels and will only allow
“known/registered” devices onto the network. If this is the case for your network, you will need to register
the MAC address rst. After this, the unit should be allowed on the network and will work as normal via
DHCP (fully automatically from this point with no intervention). Many institutions have their own registration
systems for computers and printers, and usually have online instructions on how to register a device. If
needed, the MAC address of the unit can be obtained by connecting to it with the Front Panel software
over USB.
(II) Static IP Networks
For a network without DHCP support, a static IP address must be set manually. This can be done by following
these steps:
1. Connect the Source Measure Unit to a PC using a USB cable.
2. Disable the DHCP client of the device using the command “eth0 set dhcp false”.
3. Set the IP address and other network parameters using the command “eth0 set network ip-address
subnet-mask gateway-ip dns-ip”.
4. Save the changes to the board so that they are loaded when the device powers on using the
command “eth0 save network”.
5. Disconnect the USB cable, then connect the Ethernet cable and the device should connect after
a few seconds.
Alternatively, an external network router that supports DHCP can be used to connect to a static IP network.
1. Run the le ‘Ossila-Front-Panel-Installer-vX-X-X-X.exe’ on the USB memory stick provided.
2. Follow the on-screen instructions to install the software.
8.3 Connecting to a Network
8.4 Front Panel Software Installation

19
9.1 Connection Controls
Note: The Ossila Front Panel and Source Measure Unit USB drivers can also be downloaded from
ossila.com/pages/software-drivers
9. Front Panel Software
1. Start the program “Ossila Front Panel” and the window shown in Figure 7.3 will open.
2. There are 6 main areas of the UI which are detailed below:
I. Connection controls
II. Utility controls
III. Front Panel tab
IV. Data Plot tab
V. Logged Data tab
VI. IV Curve tab
Figure 9.1. Connection controls before and after connecting to a Source Measure Unit.
(I) Connected SMUs
• Select the connected Source Measure Unit that you want to use.
I. This box will be populated automatically with the connection address (COM port or IP address)
of any Ossila Source Measure Units connected to the computer.
II. To rescan for connected units, click the blue refresh button next to the drop-down box.
III. This box is disabled whilst connected to a Source Measure Unit.
(II) Connect
• Connects to the Source Measure Unit currently selected in the “Connected Systems” drop-down box.
• Once connected, all other elements of the software will be enabled.
I. This box is disabled whilst connected to a Source Measure Unit.
(III) Reset
• Remotely resets the connected Source Measure Unit and reconnects to it.
I. This resets all settings to their default values.

20
(IV) Disconnect
• Safely disconnects from the connected Source Measure Unit.
I. SMU 1, SMU 2, Vsense 1, and Vsense 2 will also be disabled.
(I) Fan
• Toggles the fan of the connected Source Measure Unit on and o.
(II) SMU Lights
• Toggles whether the status LEDs of the SMUs turn on when the channels are enabled.
(III) Shutter
• Toggles the shutter output on and o.
I. The shutter outputs 5 V DC when switched on.
(IV) Log Data
• Records the values of all channels in the logged data table, along with the current date and time.
I. Records 0.0 for channels that are switched o.
(V) Save Live Data
• Toggles whether data will be continuously saved while a channel is switched on.
I. The data will be saved to the comma separated value (.csv) or text (.txt) le set in the “Save Data
Path” eld.
(VI) Save Data Path
• Sets the directory and le name for saving live data.
I. If the selected le does not exist, it will be created.
9.2 Utility Controls
Figure 9.2. Utility controls.
