Oster FPSTFP4600 User manual

10 CUP PROFESSIONAL FOOD PROCESSOR
PROCESADORA DE ALIMENTOS CON CAPACIDAD PARA 10 TAZAS
User Guide/ Guía del Usuario:
FPSTFP4600
www.oster.com
Safety
Seguridad
How to use
Cómo usar
Cleaning
Cuidado y Limpieza
Recipes
Recetas
Warranty
Garantía

www.oster.com
2
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed
including the following:
1. Read all instructions before use.
2. To protect against risk of electrical shock, do not put food processor in water or any other liquid.This
may cause personal injury or damage to the product.
3. Close supervision is necessary when using this appliance near children.
4. Unplug from outlet when not in use, before putting on or taking o parts and before cleaning.
5. Do not contact moving parts.
6. Do not operate food processor with a damaged cord or plug or after the appliance malfunctions, or
is dropped or damaged in any manner. Return appliance to the nearest authorized service center for
examination, repair or mechanical adjustment.
7. The use of attachments not recommended or sold by the manufacturer may cause re,
electrical shock or injury.
8. Do not let cord touch hot surfaces or hang over table edges or counters.
9. Do not use your food processor if any part is broken.
10. Do not use outdoors or for commercial purposes.
11. Keep hands and utensils away from moving blades or discs while processing food to reduce the risk of
severe injury to persons or damage to the food processor. A scraper may be used but must be used only
when the food processor is not running.
12. Blade and processing disc are sharp. Handle carefully.
13. To reduce the risk of injury to persons, never place cutting blade on motor base without rst putting
container properly in place.
14. Be certain container cover is securely locked in place while operating appliance.
15. Never feed food into food chute by hand, always use the food pusher.
16. Be sure to turn o the food processor after each use.
17. Do not use this appliance for other than its intended use.
18. Do not attempt to defeat the cover interlock mechanism.
19. The small pusher should only be used in combination with the large pusher.
Do not use this piece by itself.
SAVE THESE INSTRUCTIONS

www.oster.com 3
THIS UNIT IS INTENDED FOR HOUSEHOLD USE ONLY.
This appliance has a polarized alternating current plug (one blade is
wider than the other). To reduce the risk of electric shock, as a safety
feature, this plug will t in a polarized outlet only one way. If the plug
does not insert fully in the outlet, reverse the plug. If it still fails to t,
contact a qualied electrician. Do not modify the plug in any way.
DO NOT ATTEMPT TO DEFEAT THIS SAFETY FEATURE.
EXTENSION CORD USE
A short power-supply cord is provided to reduce the risk resulting from
becoming entangled in or tripping over a longer cord. An extension cord
may be used if care is exercised in its use. If an extension cord is used, the
electrical rating of the cord must be at least as great as the electrical rating
of the appliance. The extension cord should be arranged so that it will
not drape over the countertop or tabletop where it can be pulled on by
children or tripped over unintentionally.
Thank you for purchasing the OSTER® 10 Cup Professional Food
Processor. Before you use this product for the rst time, please take a few
moments to read these instructions and keep it for reference. Pay particular
attention to the Safety Instructions provided. Please review the product
service and warranty statements. Please do not return to the place of
purchase. To learn more about Oster® products, please visit us
at www.oster.com or call us at 1-800-334-0759.

www.oster.com
4
LEARNING ABOUT YOUR
10 CUP FOOD PROCESSOR
a
b
e
g
h
k
i
l
j
c
d
Small Food Pusher
Large Food Pusher
Food Chute Lid
Slice Disc
Shred Disc
Disc Stem
Dough Blade
Accessory Storage Bowl
Multi-purpose Blade
Bowl
Spatula
Base
Control panel
f
j
d
g
f
h
c
a
b
e
i
l
m
m
k

www.oster.com 5
BEFORE USING YOUR OSTER®
FOOD PROCESSOR
•When unpacking the product and removing packing material, handle
the chopping blade and slice/shred discs carefully: they are very sharp.
•Wash all parts except the Base in hot, soapy water. Rinse them dry.
These parts can also be placed in the dishwasher. Be sure to read the
Care & Cleaning Section of this manual to learn the correct methods
for taking the unit apart and cleaning.
HOW TO:
Using Your Food Processor
NOTE: Do not attempt to chop ice in this food processor; it will damage the
bowl and dull the Chopping Blade. This unit will not whip cream, beat egg
whites, grind coee beans, spices or other items with high oil content, or slice
or shred hard-cooked eggs, marshmallows, or soft cheeses.
Important: For your protection, this unit has an interlock system. The
processor will not operate unless the bowl is properly locked onto the
base and cover is properly locked onto the bowl. Do not attempt to operate
the unit without the bowl lid, bowl and food chute lid correctly in place. Be
sure base is on a at, dry and clean surface before you begin processing.
NOTE: Before you begin, PLEASE BE SURE THAT THE ELECTRIC CORD IS
UNPLUGGED.
1Using the PULSE control: You can control the texture of processed foods
better by using the PULSE button on your food processor. Simply press
and release to quickly turn the food processor on and o. This allows you
to check processed results and control the
consistency. For longer processing, continue
pressing the PULSE button.
2Using the ON (Continuous) control: Add
ingredients through the feed tube; remove
the pusher and ll the feed tube as directed
(see How to Slice or Shred). Engage the pusher and press the ON button.
The LED will turn on and the motor will start. Press the Pusher rmly down
until all ingredients have passed into the work bowl. Remove the Pusher
and rell ingredients as needed. Press the OFF button when nished.
3O Setting- Processor should always be in the OFF position when not in use.
Figure 1

www.oster.com
6
How To Assemble The Bowl
Be sure the unit is unplugged. Put the bowl on top of
the food processor base, with the work bowl handle
just to the right of center. Turn the bowl clockwise until
the bowl clicks into place. The handle should now be
aligned with the center of the control panel. (Figure 2)
Select the appropriate attachment and assemble onto
food processor as directed in the chopping, kneading or
slicing/shredding sections. Place food or dough in bowl
if using multipurpose blade or dough blade.
NOTE: There is only one position for the bowl to lock
onto the base. The unit will not operate if the bowl does not lock
onto the base.
How to Lock the Cover
Place the lid on the bowl. Turn clockwise until the lid
clicks into place; the arrow on the lid will line up with
the arrow on the handle (the food pusher should be
positioned in the front). Your food processor features a
safety interlock system. The unit will not operate unless
the bowl and bowl cover are properly aligned and
locked into place. (Figure 3)
NOTE: When the cover is locked into position, the
safety mechanism on the cover and bowl will align. The
unit will not operate if the cover is not locked onto the
bowl.
NOTE: BOWL MUST BE LOCKED INTO BASE BEFORE COVER CAN BE LOCKED
INTO POSITION.
Plug unit into outlet. Turn the unit on by pressing the on button or pulse
button. Use the food pusher when using
the slicing or shredding discs. Press the food down slowly
and steadily with the pusher.
To stop your food processor, press the o button. Wait until the blade or disc
comes to a complete stop before removing the lid or bowl.
Figure 2
Figure 3

www.oster.com 7
How to Chop
NOTE: Make sure the unit is turned OFF and unplugged before use. Never use
hand to push food into processor. Do not use the processor continuously for
more than 3 minutes at a time.
Multipurpose Blade: Use multi purpose
blade for chopping, mixing, blending,
pureeing and preparing pu pastry,
crumbs and short crust pastry.
1 Lock the bowl onto base.
(See “How to assemble the bowl”)
2 Take the disc stem and slide it onto
the center post. Then grasp the
multi purpose blade by its stem and
slide over the disc stem. (Figure 4)
3 Place food into bowl.
4 Lock cover onto bowl.
(See “How to Lock the cover”)
5 Place the food pusher into the feed tube.
6 Plug the cord into an electric outlet. Use the Food Guide to prepare food
for chopping.
7 Press the ON button for continuous
processing or the PULSE button for short
processing tasks. When using the PULSE
setting, hold down the PULSE button for
about 2–3 seconds at a time, check results
and repeat if desired.
8 When nished processing, press the OFF button and allow the chopping
blade to stop rotating.
9 Twist the cover counter-clockwise to remove lid.
10 Hold the disc stem with multi purpose blade attached by its stem and
remove. Unlock the bowl by turning it counter- clockwise towards the
UNLOCK mark, and lift o. Empty the processed food.
NOTE: The 10 Cup Food Processor comes with a spatula to easily empty
contents inside the bowl.
NOTE: Chopping Blade is very sharp, use caution when handling.
Figure 4

www.oster.com
8
How to Knead Dough
NOTE: NEVER TRY TO PROCESS DOUGH THAT IS TOO STIFF TO KNEAD
COMFORTABLY BY HAND.
NOTE: Make sure the unit is turned OFF and unplugged before use. Never use
hand to push food into processor. Do not use the processor continuously for
more than 3 minutes at a time.
Dough Blade: Use the dough blade for kneading bread dough and for mixing
batters and cake mixtures.
1 Lock the bowl onto base.
(See “How to assemble the bowl”)
2 Take the disc stem and slide it onto the
center post. Then grasp the dough blade
by its stem and slide over the disc stem
(Figure 5).
3 Place all the dry ingredients into
the bowl.
4 Lock cover onto bowl.
(See “How to Lock the cover”)
5 Place the food pusher into the feed tube.
6 Plug the cord into an electric outlet.
7 Press the ON button for continuous processing or the PULSE button for short
processing tasks. When using the PULSE setting, hold down the PULSE button
for about 2-3 seconds at a time, check results and repeat if desired.
NOTE: All liquid ingredients should be added through the food chute while
unit is processing. Add liquid in a slow, steady stream for even distribution. It
is important to add enough liquid to make the dough soft enough to knead.
Kneading dough that is too sti ca n strain the machine.
8 When nished processing, press the OFF button and allow the dough blade
to stop rotating.
9 Twist the cover counter-clockwise to remove lid.
10 Hold the disc stem with dough blade attached by its stem and remove.
Unlock the bowl by turning it counter- clockwise towards the UNLOCK
mark, and lift o. Empty the processed food.
NOTE: The 10 Cup Food Processor comes with a spatula to easily empty
contents inside the bowl.
Figure 5

www.oster.com 9
How to Slice or Shred
NOTE: Make sure the unit is turned OFF and unplugged before use. Never use
hand to push food into processor. Do not use the processor continuously for
more than 3 minutes at a time.
Slicing and Shredding Discs: Use these discs for slicing and shredding meats,
fruits, vegetables, cheeses and more.
1Lock the bowl onto base.
(See “How to assemble the bowl”)
2Slide the Disc Stem onto the center post
of the base. With the desired side facing
up (slicing or shredding), push the slice/
shred disc onto the disc stem (Figure 6). Use
caution when handling disc, blades
are extremely sharp.
3Lock cover onto bowl.
(See “How to Lock the cover”)
4Plug the cord into an electric outlet. Turn
machine on by pressing the ON button.
5Put ingredients in the feed tube and press
the food pusher lightly onto the ingredients
(Figure 7). The small pusher should only be
used in combination with the large pusher.
Do not use this piece by itself.
7When nished processing, press the
OFF button and allow the disc to stop
rotating. Twist the cover counter-clockwise
to remove lid.
8Carefully remove the Shredding Disc. Unlock
the bowl by turning it
counter- clockwise towards the
UNLOCK mark and lift o. Empty the processed food.
NOTE: Shredding Disc is very sharp, use caution when handling.
IMPORTANT: Use GENTLE force to press down on the food pusher. Excessive
force could cause damage to the disc.
•Press the ingredients down slowly and steadily with the pusher.
•Precut large chunks of food to t the size of the feed tube.
•For best results, ll the feed tube evenly.
•When processing large quantities, process small batches at a time and empty
the bowl between batches.
Figure 7
Figure 6
Push

www.oster.com
10
Helpful Hints
•Never attempt to process any food that cannot be cut with a sharp knife.
•When mincing garlic, fresh herbs or small quantities of foods, add to feed
tube with multipurpose blade in place and processor running. Make sure
bowl and all parts are very dry before processing garlic or fresh herbs.
•To chop nuts, use multipurpose blade and the pulse setting. Use short
pulses. Process smaller batches for coarser texture.
•Let hard cheeses, such as Parmesan and Romano, come to room
temperature before processing. Freeze soft cheeses, such as cheddar and
mozzarella, for 10 to 15 minutes before processing.
•Make sure uncooked meats and poultry are very cold before processing.
•Do not overll processing bowl. Fill no more then 1/3 to 1/2 full when
chopping. The bowl can hold up to 10 cups of dry ingredients or 2 cups
liquid.
•Position the slicing and shredding discs so that cutting surfaces are to the
right of the feed tube. This will allow one full rotation of the blade before
contacting food.
•When processing several slices or pieces of food, put as many pieces as will
t in feed tube together to help hold each other in place.
•This food processor is NOT designed to grind coee beans or spices
or crush ice.
•Most foods can be processed in 10 to 30 seconds, depending on the
quantity. For large quantities, process in several batches. Let the processor
rest about 1 minute between batches.
•If the food processor suddenly stops running, turn the unit OFF and unplug.
Let the unit cool down for 15 minutes and restart.
•A food processor is not recommended for making Italian meringue
(a meringue made by using hot sugar syrup)
Food Processing Tips/Liquids
1Hot liquids (less than 176˚F) and hot foods can be processed in the bowl.
2Be sure to process small amounts of liquids—2 cups or less at a time.
Larger amounts may leak from the bowl.

www.oster.com 11
Care & Cleaning
NOTE: Do not attempt to sharpen the cutting edges of the chopping blade or
the reversible disc. They are permanently sharpened at the factory and will be
ruined by attempted sharpening.
Cleaning
1Before cleaning, be sure the unit is switched o and the cord is unplugged.
2Whenever possible, rinse parts immediately after processing for easy cleanup.
3Wipe the base, control panel, and feet with a damp cloth and dry thoroughly.
Stubborn spots can be removed by rubbing with a damp cloth and a mild,
non-abrasive cleaner. Do not immerse the base in liquid.
4All removable parts can be washed by hand or in a dishwasher, top rack.
•If washing by hand, wash in hot sudsy water, rinse, and dry thoroughly. If
necessary, use a small nylon bristle brush to thoroughly clean the bowl and
food chute/cover, this type of brush will also help prevent cutting yourself
on the sharp chopping blade and slice/shred disc.
•If washing in a dishwasher, place removable parts on the top rack
only – not in or near the utensil basket.
5Do not use rough scouring pads or cleansers on any plastic or metal parts.
6 Do not ll the bowl with boiling water or place any of the parts in boiling
water. Some foods, such as carrots, may temporarily stain the bowl. To remove
stains, make a paste of
2 tablespoons (30ml)
baking soda and 1
tablespoon (15ml) warm
water. Apply the paste to
the stains and rub with
a cloth. Rinse with sudsy
water and dry.
Storing
The 10 cup food processor
comes with a unique in-bowl
storage rack that conveniently
stores all your food processor
accessories inside the bowl
and out of the way. See the
following diagram.
Accessory
Storage Bowl
Slice Disc
Shred Disc
Disc Stem
Dough
Blade

www.oster.com
12
Chopping Guide
Food Amount Directions
Baby Food Up to 4 cups
(1000ml)
Add up to 4 cups (1000ml) cooked vegetables and/
or meat in a bowl, along with ¼ cup (60ml) liquid
per cup of solid food, process continuously to
desired neness.
Bread Crumbs Up to 5 slices Cut either fresh or dry bread slices into 1½–2 inch
(3.75–5cm) pieces. Add to bowl and process to
ne crumbs.
Cookie/Cracker
Crumbs
Up to 5 cups
(1250ml)
Use for crumbing Graham Crackers, Chocolate or
Vanilla Wafers. Break larger crackers into 1½–2 inch
(3.75–5cm) pieces. Add to bowl and process
until ne.
Cranberries, minced 3 cups
(750ml)
Pulse to chop to desired neness. Can also add
sugar to make Cranberry Relish.
Eggs, chopped Up to 12 Peel, dry and halve hard-cooked eggs. Add to bowl,
Pulse to chop, checking neness after 4–5 pulses.
Garlic, minced Up to 12 Be sure bowl is dry. Drop clove(s) down Food Chute
while unit is running.
Meat, chopped
(raw or cooked)
Up to 2.5 cups
(600ml)
Cut the meat into 1inch (2.54cm) cubes. Add to
bowl and pulse to chop.
Mushrooms,
chopped
Up to 12 medium Halve large ones and add to bowl.
Pulse to desired neness.
Nuts, chopped 2 cups (300ml) Add to bowl and pulse to chop.
Onions, chopped Up to 2 large Quarter, add to bowl. Pulse 1 or 2 times to coarsely
chop. For green onions, up to 2 cups (500ml) cut
into 1 inch (2.45cm) pieces.
Parmesan or Romano
Cheese, grated
Up to 1½cups
(375ml)
Allow cheese to reach room temperature. Cut into
1 inch (2.54cm) cubes. Add to bowl and pulse to
coarse chop. Process continuously to nely grate.
Parsley, chopped Up to 2 cups (500ml) Add to bowl and pulse to chop to desired neness,
about 10–15 seconds. Process other herbs in the
same manner (Basil, Cilantro, Mint, etc.)
Pepper, Green, Red,
Yellow, chopped
Up to 1 Pepper Cut into 1 inch (2.54cm) pieces. Add to bowl and
pulse to chop.
Soups, pureed
or creamed
2 cups (500ml) Add up to 2 cups hot (less than 176°)
vegetable soup for pureeing or creaming.
Process to desired smoothness.
Squash (Butternut),
Pumpkin or Sweet
Potatoes, pureed
Up to 5 cups (1250ml)
of 1 inch (2.54cm)
cubes
Add ¼ (60ml) cup of cooking liquid per cup of food.
Pulse to nely chop then process continuously
to puree.
Strawberries, pureed 2 cups (500ml) Hull and halve large berries. Add to bowl and pulse
to chop. Process continuously to puree.
Tomatoes, chopped 4 medium Quarter tomatoes. Add up to 4 and pulse to
desired size.

www.oster.com 13
Shredding Guide
Food Directions
Cabbage Use Shredding Disc for very ne cabbage or slaw. Cut into pieces to t
Chute. Shred using light pressure. Empty bowl as cabbage reaches Disc.
Carrots Position in Chute and shred.
Cheese, cheddar Cheese must be well chilled. Cut to t Chute, use light pressure.
Cheese, Mozzarella Cut to t Chute. Cheese must be chilled in freezer for 30 minutes prior to
shredding. Use light pressure.
Potatoes Cut to t Chute.
Zucchini Slice o ends, cut to t Chute, either lengthwise or horizontally.
Slicing Guide
Food Directions
Apple Halve and stack horizontally in Chute. Use rm pressure.
Cabbage/Lettuce Halve head, cut to t Chute
Carrots Cut to t Chute.
Celery Remove string, pack Chute for best results.
Cucumber Cut to t Chute if necessary.
Mushrooms Stack Chute with mushrooms on their sides for lengthwise slices.
Onions Halve and ll Chute, positioning onions upright for coarsely
chopped results.
Peaches/Pears Halve and core. Position upright in Chute and slice using light pressure.
Peppers, Green, Yellow,
Red, etc.
Halve and seed. Fit pepper up bottom of Chute squeezing slightly to t
if necessary. Cut large ones into quarters or strips, depending on desired
results. Slice using moderate pressure.
Pepperoni Cut into 3 inch (8cm) lengths. Remove inedible casing.
Potatoes Peel if desired, cut large potatoes in halves, position in Chute.
Strawberries Hull. Arrange berries on their sides for lengthwise slices.
Tomatoes Use small tomatoes for whole slices, halve if necessary. Use gentle but
rm pressure.
Turnips Peel, cut turnips to t Chute.
Zucchini Slice o ends. Use small squash for whole slices; halve larger ones
to t Chute.

www.oster.com
14
1 Year Limited Warranty
Sunbeam Products, Inc. doing business as Jarden Consumer Solutions or if in Canada, Sunbeam
Corporation (Canada) Limited doing business as Jarden Consumer Solutions (collectively“JCS”) warrants
that for a period of one year from the date of purchase, this product will be free from defects in material
and workmanship. JCS, at its option, will repair or replace this product or any component of the
product found to be defective during the warranty period. Replacement will be made with a new or
remanufactured product or component. If the product is no longer available, replacement may be made
with a similar product of equal or greater value. This is your exclusive warranty. Do NOT attempt to repair
or adjust any electrical or mechanical functions on this product. Doing so will void this warranty.
This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not
transferable. Keep theoriginal sales receipt.Proof of purchaseis requiredto obtain warranty performance.
JCS dealers, service centers, or retail stores selling JCS products do not have the right to alter, modify or
any way change the terms and conditions of this warranty.
This warranty does not cover normal wear of parts or damage resulting from any of the following:
negligent use or misuse of the product, use on improper voltage or current, use contrary to the operating
instructions, disassembly, repair or alteration by anyone other than JCS or an authorized JCS service
center. Further, the warranty does not cover: Acts of God, such as re, ood, hurricanes and tornadoes.
What are the limits on JCS’s Liability?
JCS shall not be liable for any incidental or consequential damages caused by the breach of any express,
implied or statutory warranty or condition.
Except to the extent prohibited by applicable law, any implied warranty or condition of merchantability
or tness for a particular purpose is limited in duration to the duration of the above warranty.
JCS disclaims all other warranties, conditions or representations, express, implied, statutory or otherwise.
JCS shall not be liable for any damages of any kind resulting from the purchase, use or misuse of, or
inability to use the product including incidental, special, consequential or similar damages or loss
of prots, or for any breach of contract, fundamental or otherwise, or for any claim brought against
purchaser by any other party.
Some provinces, states or jurisdictions do not allow the exclusion or limitation of incidental or
consequential damages or limitations on how long an implied warranty lasts, so the above limitations
or exclusion may not apply to you.
This warranty gives you specic legal rights, and you may also have other rights that vary from province
to province, state to state or jurisdiction to jurisdiction.
How to Obtain Warranty Service
In the U.S.A.
If you have any question regarding this warranty or would like to obtain warranty service, please call
1-800-334-0759 and a convenient service center address will be provided to you.
In Canada
If you have any question regarding this warranty or would like to obtain warranty service, please call
1-800-667-8623 and a convenient service center address will be provided to you.
In the U.S.A., this warranty is oered by Sunbeam Products, Inc. doing business as Jarden Consumer
Solutions located in Boca Raton, Florida 33431. In Canada, this warranty is oered by Sunbeam
Corporation (Canada) Limited doing business as Jarden Consumer Solutions, located at 20 B Hereford
Street, Brampton, Ontario L6Y 0M1. If you have any other problem or claim in connection with this
product, please write our Consumer Service Department
PLEASE DO NOT RETURN THIS PRODUCT TO ANY OF THESE ADDRESSES
OR TO THE PLACE OF PURCHASE

www.oster.com 15
MEDIDAS DE SEGURIDAD IMPORTANTES
Cuando se utilizan aparatos eléctricos, siempre deben tomarse medidas de seguridad básicas,
incluyendo las siguientes:
1. Lea estas instrucciones antes de usar.
2. Para prevenir el riesgo de descargas eléctricas, no sumerja la procesadora de alimentos en
agua u otros líquidos. Ello podría ocasionar lesiones personales o daños al producto.
3. Se requiere supervisión cuando el electrodoméstico se utiliza cerca de niños.
4. Desenchufe el electrodoméstico de la toma de corriente cuando no esté siendo utilizado,
antes de colocar o retirar piezas o antes de limpiarlo.
5. No toque las piezas móviles.
6. No utilice la procesadora de alimentos si el cable de alimentación o el enchufe está dañado,
si el electrodoméstico no funciona correctamente, se ha caído o presenta algún tipo de daño.
Para la inspección, reparación o ajuste mecánico, recurra al centro de mantenimiento
autorizado más cercano.
7. El uso de accesorios no recomendados o no vendidos por el fabricante puede ocasionar incendios,
descargas eléctricas o lesiones.
8. No deje que el cable cuelgue del borde de la mesa o mesada o esté en contacto con
supercies calientes.
9. No utilice la procesadora de alimentos si alguna pieza está dañada.
10. No utilice el electrodoméstico en el exterior o para nes comerciales.
11. Cuando procese alimentos, mantenga las manos y los utensilios alejados de los discos o las
cuchillas móviles para reducir el riesgo de lesiones graves a personas o daños a la procesadora
de alimentos. Puede utilizarse un raspador pero solo cuando la procesadora de alimentos no esté
en funcionamiento.
12. El disco y las cuchillas son losas. Manipule con cuidado.
13. Para reducir el riesgo de lesiones a personas, nunca coloque la cuchilla o la base del motor sin haber
colocado previamente el recipiente correctamente en su lugar.
14. segúrese de que la tapa del recipiente esté trabada de modo seguro cuando utilice el electrodoméstico.
15. Nunca coloque alimentos en el vertedor de alimentos manualmente; siempre utilice el
empujador de alimentos.
16. Asegúrese de que el interruptor esté en la posición OFF (APAGADO) después de cada uso.
17. Solo utilice este electrodoméstico con el n para el cual ha sido diseñado.
18. No intente modicar el mecanismo de seguro de la cubierta
19. El empujador pequeño debe usarse sólo en combinación con el empujador largo.
No use esta pieza por sí sola.
GUARDE ESTAS INSTRUCCIONES

www.oster.com
16
ESTA UNIDAD HA SIDO DISEÑADA SOLO
PARA USO DOMÉSTICO.
Este electrodoméstico tiene un enchufe de corriente alternativo polarizado (una
paleta es más ancha que la otra). Para reducir el riesgo de descargas eléctricas,
como una función de seguridad, este enchufe encaja en la toma polarizada solo
de una forma. Si el enchufe no se inserta completamente en la toma de corriente,
invierta el enchufe. Si aun no encaja, contacte a un electricista calicado. No
modique el enchufe de ninguna manera.
NO INTENTE IGNORAR ESTA MEDIDA DE SEGURIDAD
USO DE CABLE DE EXTENSIÓN
Se proporciona un cable de alimentación corto para reducir el riesgo de enredarse
o tropezar con un cable más extenso. Si se utiliza con cuidado, puede emplearse
un cable de extensión. En caso de utilizar un cable de extensión, la capacidad
eléctrica del cable debe ser al menos igual que la capacidad eléctrica nominal
del electrodoméstico. El cable de extensión debe instalarse de modo que
no cuelgue de la mesada o mesa donde pueda ser jalado por niños o pueda
ocasionar tropiezos.
Gracias por adquirir la Procesadora de Aliwmentos con 11 Elementos
OSTER®. Antes de utilizar este producto por primera vez, por favor lea
estas instrucciones y consérvelas para referencia futura. Preste especial
atención a las Instrucciones de Seguridad. Por favor lea las declaraciones
de garantía y mantenimiento del producto. Por favor, no volver al lugar de
compra. Para obtener más información sobre los productos OSTER®, por
favor visite www.oster.com o llámenos al 1-800-334-0759.

www.oster.com 17
INFORMACIÓN SOBRE SU
PROCESADORA DE ALIMENTOS
CON CAPACIDAD PARA 10 TAZAS
a
b
e
g
h
k
i
l
j
c
d
Empujador de alimentos chico
Empujador de alimentos grande
Tapa con entrada para alimentos
Disco rebanador
Disco rallador
Vástago del disco
Hoja doble para amasar
Tazón para almacenamiento
de accesorios
Hoja multipropósito
Tazón
Spatula
Base
Panel de control
f
j
d
g
f
h
c
a
b
e
i
l
m
k
m

www.oster.com
18
ANTES DE UTILIZAR SU PROCESADORA
DE ALIMENTOS OSTER®
•Cuando desempaque el producto y retire el material de embalaje, maneje
con cuidado las hojas del disco rebanador y el disco rallador, pues son muy
losas.
•Lave todas las piezas con agua jabonosa caliente, excepto la Base. Enjuague
y seque. Estas piezas también pueden lavarse en el lavavajillas. Asegúrese
de leer la Sección Cuidado & Lavado de este manual para conocer los
métodos correctos para desarmar la unidad y limpiarla.
CÓMO:
Usar su procesadora de alimentos
NOTA: No intente moler hielo en esta procesadora de alimentos, pues se dañará
el tazón y se desalarán las hojas de corte. Esta unidad no está diseñada para
batir crema o huevos, moler granos de café, especias ni otros ingredientes con
alto contenido de aceite, tampoco para rebanar o rallar huevos duros, bombones
ni quesos suaves.
Importante: Para su protección, esta unidad tiene un sistema de bloqueo. La
procesadora no funcionará a menos que el tazón esté bien colocado en la
base y la tapa esté bien ajustada en el tazón. No intente operar la unidad si
la tapa del tazón, la tapa con entrada para alimentos o el tazón no están bien
colocados. Compruebe que la base esté en una supercie plana, seca y limpia
antes de empezar a procesar los alimentos.
NOTA: Antes de empezar, COMPRUEBE QUE EL CABLE ELÉCTRICO ESTÁ
DESCONECTADO.
1Uso del control PULSE (PULSO): Usted puede
controlar mejor la textura de los alimentos
procesados mediante el botón PULSE de su
procesadora de alimentos. Sólo presione
y suelte para cambiar con rapidez la
procesadora de encendido a apagado. Esto
le permite revisar el resultado del proceso
y controlar la consistencia. Para un procesamiento más largo, mantenga
presionado el botón PULSE.
Figura 1

www.oster.com 19
2Uso del control ON (Continuo): Para agregar ingredientes por el tubo de
entrada; quite el empujador y llene el tubo de entrada como se indica
(consulte Cómo rebanar o rallar). Coloque el empujador y presione el botón
ON. El LED se encenderá y el motor arrancará. Presione el empujador con
rmeza hacia abajo hasta que todos los ingredientes hayan pasado al tazón.
Quite el empujador y ponga más ingredientes según sea necesario. Presione
el botón OFF cuando termine.
3Posición OFF - La procesadora siempre deberá estar en la posición OFF
cuando no esté en uso.
Cómo ensamblar el tazón
Compruebe que la unidad esté desconectada. Ponga el
tazón en la parte superior de la base de la procesadora
de alimentos, con el mango del tazón de trabajo
exactamente a la derecha del centro. Gire el tazón en
el sentido de las manecillas del reloj hasta que el tazón
se enganche en su sitio. Ahora el mango deberá estar
alineado con el centro del panel de control. (Figura 2)
Seleccione el dispositivo apropiado y ensámblelo en
la procesadora de alimentos como se indica en las
secciones picar, amasar o rebanar/rallar. Coloque los
alimentos o la masa en el tazón si se está usando la
hoja multipropósito o la hoja para amasar.
NOTA: El tazón solo se puede ajustar en una posición sobre la base. La unidad no
funcionará si el tazón no está bien colocado en la base.
Cómo bloquear la tapa
Coloque la tapa en el tazón. Gire en el sentido de las
manecillas del reloj hasta que la tapa se enganche
en su sitio; la echa de la tapa deberá estar alineada
con la echa del mango (el empujador de alimentos
deberá estar colocado hacia el frente). Su procesadora
de alimentos cuenta con un sistema de bloqueo de
seguridad. La unidad no funcionará a menos que el
tazón y su tapa estén bien alineados y asegurados en
su sitio. (Figura 3)
NOTA: Cuando la tapa está asegurada en su posición,
el mecanismo de seguridad de la tapa y el tazón
estarán alineados. La unidad no funcionará si la tapa no está
asegurada en el tazón.
NOTA: EL TAZÓN DEBERÁ ESTAR ENGANCHADO A LA BASE ANTES DE QUE LA
TAPA SE PUEDA ASEGURAR EN SU SITIO.
Figura 2
Figura 3

www.oster.com
20
Enchufe la unidad. Encienda la unidad presionando el botón ON o el botón PULSE.
Use el empujador de alimentos cuando utilice los discos para rebanador o rallador.
Presione la comida hacia abajo lenta y continuamente con el empujador.
Para detener su procesadora de alimentos, presione el botón OFF. Espere hasta que
la hoja o el disco se detengan completamente antes de quitar la tapa o el tazón.
Cómo picar
NOTA: Compruebe que la unidad esté APAGADA y desconectada antes de usarla.
Nunca use las manos para empujar los alimentos en la procesadora. No use la
procesadora por más de 3 minutos continuos a la vez.
Hoja multipropósito: Use la hoja multipropósito para picar, mezclar, licuar, hacer
puré o preparar pasta de hojaldre, migas y pasta quebrada.
1 Enganche el tazón a la base (consulte“Cómo ensamblar el tazón”).
2Tome el vástago del disco y deslícelo en el poste
central. Luego tome la hoja multipropósito por su
vástago y deslícelo en el vástago del disco.
(Figura 4)
3 Ponga la comida en el tazón.
4 Coloque la tapa en el tazón. (Consulte“Cómo
colocar la tapa”)
5 Ponga el empujador de alimentos en el tubo de
entrada.
6 Enchufe el cable en un tomacorriente. Use la guía
de alimentos para preparar la comida para picarla.
7 Presione el botón ON (ENCENDIDO) para un
procesamiento continuo o el botón PULSE (PULSO) para procesamientos
cortos. Cuando use la función PULSE, sostenga el botón PULSE durante 2 o 3
segundos a la vez, revise los resultados y repita si es necesario.
8 Cuando termine el procesamiento, presione el botón OFF y permita que la
hoja de corte deje de girar.
9 Gire la tapa en sentido contrario a las
manecillas del reloj para quitarla.
10 Sostenga el vástago del disco con la hoja
multipropósito unida por su vástago y
quítelos. Desbloquee el tazón girándolo en sentido contrario a las manecillas
del reloj hacia la marca UNLOCK (DESBLOQUEAR) y levántelo. Vacíe los
alimentos procesados.
NOTA: La procesadora de alimentos para 10 tazas se vende junto con una
espátula para vaciar con facilidad el contenido del tazón.
NOTA: La hoja de corte es muy losa, tenga cuidado cuando la manipule.
Figura 4
