Otto BT3968 User manual

INSTRUCTION MANUAL
Model: BT3968
WIRELESS SPEAKER
M

Product Specications
Pack Contents
Functions
1
Do not connect this cable to products
other than BT3968 Bluetooth
. Connecting this cable to
other devices might cause damage
to both cable and the device.
Model: BT3968
Officeworks Product Code: OTWLSPPK / OTWLSPPE /
OTWLSPGN / OTWLSPBE
Bluetooth version: 5.0
Power supply: USB, DC 5V, 1A
Battery capacity: 300mAh
Battery charge time: 2-3hours
S/N: ＞85dB
O
Output Power: 3W
peration Distance: Up to 10m
1. Wireless Speaker
2.
Instruction Manual3.
Micro USB Charging
Cable (50cm)
4. Quick-start Guide
M
1 2 3 4
1
2
3
4
Mode button (Bluetooth / Radio Mode)
Previous Track (Long press)/ Volume down (Short press)
Next Track (Long press) / Volume up (Short press)
Play / Pause / Pick up / Handsfree (Short press)
speaker

Ensure the battery has been fully charged on the first three
initial uses to ensure the battery’s best performance.
Upon completion of charging, please unplug the charging
cable from the wireless speaker. Do not leave the wireless
speaker charging after it’s fully charged. It may shorten
the lifetime of the battery.
Charging the Speaker
Powering the Speaker
Before using the speaker for the first time, charge it for at
least two hours. Insert the included USB charging cable into
the micro USB charging port. Connect the other end of the
USB cable to a working USB power source.
1. Once fully charged, slide the ON/OFF switch to turn on the
speaker.
2. BT3968 is in pairing mode after power-on.
3. To manually turn off the speaker, slide ON/OFF switch again.
2
TF ON OFF USB
5
6
78
6
5
7
8
USB Port (for music playing)
MicroSD (TF) card slot (for music playing)
ON/OFF switch
Micro USB Charging port (for charging & working as
antenna under Radio mode)

Pairing the Speaker
Playing Through MicroSD (TF) Card or USB
1. When the speaker is powered on,insert USB to USB slot or
insert MicroSD (TF) card to MicroSD (TF) card slot, the speaker
would play the music in USB or MicroSD (TF) card automatically,
these two media types have priority over Bluetooth playback.
Picking up Calls
Before using the Bluetooth Speaker, you must pair it with a
Bluetooth enabled device.
1. When the speaker is powered on, it will enter Bluetooth
mode, the LED lights will flash quickly.
2. From the Bluetooth menu of your device, search for new
devices and select “BT3968” to pair with your device.
3. Once they are paired successfully, you will hear a
confirmation sound.
Remarks:
* When you turn on the wireless speaker, it will automatically
connect to the last connected device if it is still in range.
* To pair a different device, you must turn off the wireless
capability of the paired device or take it out of range.
1.Press the PLAY/PAUSE button to answer an incoming
phone call.
2.Press the PLAY/PAUSE button to end call.
3.Use the volume buttons to change the volume of the call.
4.Note: Some calls need to be answered on device.
3

No Sound:
Power on the speaker and charge the battery
Increase the volume on your speaker and Bluetooth device
Make sure you are using the correct paired device
Move your Bluetooth device closer to the speaker and away
from any interference or obstructions
Use a different music source
Check the play mode to select the attached media storage
device
1.Press mode button to switch to FM Radio Mode, insert the
micro USB cable into the Micro USB port to work as antenna
automatically, short press PLAY/PAUSE button to start
scanning radio channels, and it will automatically save the
FM channels searched.
2.Once finished searching, long press “-”/ “+” button to play the
previous or next saved FM channel. Press mode button to
change mode.
2.
3.
4
Switch play mode in between Bluetooth, USB and
MicroSD (TF) by the pressing the mode button.Prompt
message will beplayed to confirm the success of switching of
each mode.
Speaker will play media file from attached USB storage and
MicroSD (TF) card when the power is turned on (If storage
device is attached).
4.Note: Ensure the speaker is powered ON before you insert
the USB drive. Otherwise the speaker may not play media as
expected.
Radio Mode
Troubleshooting

Officeworks Ltd warrants that this product will be free from
defects and work as intended for 3 years from the date of
purchase by the original customer.
If the product has any defects or does not work as specified
during the Warranty Period, Officeworks will, at its election and
at its expense, repair or replace the product.
This warranty does not apply:
• to cosmetic damage;
• to damage caused by consumables used in connection with
the product ;
• where the product has not been used in accordance with all
provided instructions;
Product Warranty
– Valid for Australian Customers Only
5
1. Do not subject the device to liquid or attempt to
disassemble the device.
2. Do not use this product in an aircraft.
3. Do not expose the device to direct sunlight, heat or flame.
4. Device may be warm while charging. It is normal.
Safety and General Information
Product Warranty
Note: Hands free conversation feature allows user to remotely
accept avoice call from direct number dial in and certain instant
messaging Apps by pressing the Play/Pause button on the
speaker. Some instant messaging Apps require user to confirm
the acceptance of voice call within the App only.
Distorted sound:
Decrease the volume on your speaker and Bluetooth device
Check attached media storage for proper insertion

This warranty is provided in addition to any rights you may be
entitled to under the Competition & Consumer Act 2010. Our
goods come withguarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement
or refund for a major failure and compensation for any other
reasonably foreseeable loss or damage. You are also entitled
to have the goods repaired or replaced if the goods fail to be
of acceptable quality and the failure does not amount to a
major failure.
• where the product has been intentionally or negligently
damaged; and/or
• if the customer has attempted to repair the product.
To make a claim under this warranty, please return your
product with your receipt or proof of purchase to your nearest
Officeworks store or contact 1300 633 423.
6
• to damage arising from fair wear and tear;
• where the product has not been subject to reasonable use;
