Oursson AM6240/GA User manual
Automatic coffee machine
Автоматическая кофемашина
Автоматична кавомашина
AM6240/RD AM6240/GA AM6240/DC AM6240/OR
Operation manual with the warranty card
Руководство по эксплуатации с гарантийным талоном
Інструкція для експлуатації з гарантійним талоном усередині
We congratulate on acquisition of the full-automatic Oursson coffee machine!
Поздравляем c приобретением автоматической кофемашины Oursson!
Поздоровляємо з придбанням автоматичної кофемашини Oursson!
CONTENTS
Safety instructions
Precautions
Prohibitions
Cautions
Safety tips
Standard configuration
Instructions of coffe machine parts
Coffee machine operation interface instructions
Testing and setting water hardness
Fill beans
Fill water tank
Insert the water filter
Grinding wheel
First-time use
Power on
Power off
Recognizing
Preparing coffee by touch icon
Single time setting of coffee parameters
Setting up beverage parameters and range
Coffee menu
Making beverages
Beverage setting
Water filter
Adjusting the water hardness setting
Energy-saving setting
Automatic switch-off
Information
Language
Reset
Exit
Cleaning the coffee machine before operation
Cleaning the brewing unit
Descaling the coffee machine
Cleaning the coffee grounds container and the drip tray
Cleaning the water tank
Cleaning the bean container
Disassembling and cleaning the milk frother
Cleaning the coffee machine
Display information
Failures handling
Transport
Technical data
Service maintenance
ENG
4
INTRODUCTION
• Please do not contact with heat parts of coffee machine to avoid
scalding.
• To avoid operator’s injury caused by burn, electric shock or other
unexpected reasons, please do not contact the power cord, plug, and
main body with water.
• Children shall operate the machine under the supervision of adults.
• Please keep various packages, cartons, plastic bags and Styrofoam
away from children’s reach.
• Unplug from outlet when stop using and before cleaning. Allow to cool
before disassembling and cleaning the coffee machine.
• Stop using the machine once power cord or plug is damaged. Take the
machine to authorized after-sale service center for testing and repairing.
• Use of parts that are not explicitly recommended by would result in a fire
of coffee machine, electric shock, or injury to persons.
• Please do not use the machine outdoor.
• Please do not hang up the power cord to the edges of the table, for it
might be abased to an electric leakage, and cause injury to operators.
• Please place the machine in a fixed and stable workbench, and keep far
away from high temperature (e.g. gas stoves, electric cookers, induction
cookers, etc).
• Power off the machine, until the cleaning program finished and no
indication on screen, and then unplug the power.
• When using espresso, long coffee and hot water, liquid in high
temperature will flow from coffee spout and hot water spout. Please do
not touch it to avoid scalding.
• When using cappuccino, coffee latte, hot milk/cream, please confirm that
the milk pipe has been connected from the milk frother to milk before
making cappuccino, coffee latte, and hot milk/cream. Otherwise, high
temperature steam may cause personal injury.
• Place the coffee machine on a stable workbench that is not close to
water.
• Keep the coffee machine far away from high temperature heat source.
• Be sure to use power supply that is in accord with regulation.
• Put the power cable at a suitable place to avoid people tripping over.
Non-compliance with the operation, may cause electric shock, and threat
to life.
Non-compliance with the operation may cause Coffee machine damaged,
or personal injury.
Non-compliance with the operation, may cause scalded or burn injury.
This symbol, if prompted, please carefully read it.
5
INTRODUCTION
Except cleaning and daily maintenance for coffee machine, if it failures,
please send it to after-sale service center authorized by Oursson for repair-
ing, or contact with Oursson customer service for after-sale services.
• Never immerse the machine into water, and do not put the machine near
the water tap or water tank.
• Never disassemble coffee machine without authorization, for any mainte-
nance, please return it to Service Centre or contact after-sales service of
Oursson.
• Never use a unmatched voltage to the electric specification of the ma-
chine; otherwise, the machine would be burnt.
• Only purified water in room temperature is allowed to be filled into the
water tank. Never put warm water, hot water, milk or other liquid into it.
• Never carry or move the coffee machine while working. For moving or
carrying the coffee machine, please switch it off and unplug the power
cord first.
• The machine may release heat. Therefore, when placing the machine in
the workbench, at least 3cm must be left against its surface, sides and
wall side; at least 15cm must be left against its top. Prohibit placing the
machine into a narrow space. As for dimension of the machine, please
look up the Technical Data of User Manual (Page 40).
• Never use non-family usage detergent to wipe the machine, otherwise
it may cause corrosion of coffee machine, and result in a risk of electric
shock.
• Never use wet rag to wipe coffee machine, may result in a risk of electric
shock.
• Never use hard edged tool or rough rag to clean the stain on the machine,
it will damage the machine. To wipe the coffee machine with a rag provid-
ed by Oursson is recommended.
• Never put instant coffee powder or cocoa powder and other mixture into
the bean container or powder container. It would cause coffee machine
damaged.
• Never fill specially treated coffee bean (e.g. cocoa, sugar coated) into the
bean container, it would cause coffee machine damaged.
• Only roasted coffee bean is allowed to put into the bean container. Rice,
soybean, chocolate bean, nut, sugar, spice etc are prohibited.Otherwise it
would cause coffee machine damaged.
• Never wash bean container or powder container with water, it will damage
the machine.
• Never use coffee machine in the environment temperature below 0°C. Wa-
ter inside the machine will freeze and cause the coffee machine damaged.
• Never expose the machine in rainy, snowy, frosty environment. It would
cause coffee machine damaged.
Never disassemble and repair the machine without
authorization. If there is any errors, please sent it to service
center authorized for repairing.
ENG
6
INTRODUCTION
If the coffee machine is damaged because of the situation that
has been warned above, it is not covered in the warranty!
Please keep this manual properly for looking up at any time.
To guarantee the coffee taste, make sure that temperature of the water filled
into the water tank is at 25°C or so.
Coffee machine can only be used for preparing coffee, hot milk, milk foam,
and hot water. Do not use it for any other intended use. Oursson will not in
charge of any responsibility for the consequences of improper use. Please
carefully read all the contents of this manual, so that you can know the cof-
fee machine sufficiently.
• The usage of the device is to be performed in strict accordance with the
instruction manual.
• Strictly forbidden to use the device in areas where the air can contain
vapors of flammable substances.
• Use only the tools that come with the device.
• To prevent the risk of fire or electrical shock, avoid contact of water with
the device and do not use the device in high humidity. If for some reason
the water gets inside the unit, contact your Authorized Service Center
(ASC) OURSSON AG.
• Do not attempt to open the the device yourself under any circumstances –
it may cause an electrical shock, lead to failure of the device and will void
the warranty of the manufacturer.
• For repair and maintenance contact only an authorized service center for
repair of products under the OURSSON trademark.
• Use circuits with appropriate characteristics as the main power supply.
• The device should not be exposed to direct sunlight, high and low tem-
peratures and high humidity. Avoid sudden changes in temperature and
humidity.
• When moving the device from a cold to a warm location, and vice versa,
unpack it before use, and wait 1-2 hours, without turning it ON.
• The device should be installed on a stable surface.
• Do not lift or move the coffee machine while it is operating.
• Do not mount any other items on top of the device.
• Protect the device from bumps, drops, vibrations and other mechanical
influences.
7
Please notice the following tips to avoid personal injury from electric shock.
• Do not operate the coffee machine if the appliance or the power cord is
damaged.
• When encountering breakdowns of the machine (if any burning smell or
smoke), unplug the power cord immediately and contact with Oursson
service center.
• If the power cord of coffee machine is damaged, please contact with
Oursson service center.
• Place the coffee machine and the power cord far away from heat
sources.
• Please don’t contact power cord with sharp tools.
• Do not repair the coffee machine without authorization or operate it in
the way that was not mentioned in this manual, to avoid personal injury.
• Place the coffee machine out of the reach of children.
• When Coffee machine is unused for long periods, unplug the power
cord and put it away, so that not to trip up people or damage to the
power cord.
• Please don’t use non-Oursson original parts, otherwise, it may cause
the machine damaged.
1. Full-automatic coffee machine............................................................. 1 pc.
2. Operation manual with the warranty card ............................................ 1 pc.
3. Accessory bag..................................................................................... 1 pc.
• Wiping cloth ................................................................................... 1 pc.
• Water hardness test paper ............................................................. 1 pc.
• Descaling powder .......................................................................... 1 pc.
• Coffee powder spoon...................................................................... 1 pc.
• Milk pipe ......................................................................................... 1 pc.
Do not discard all the boxes of the coffee machine, in case to
use them again to prevent the coffee machine damaging during
transportation.
INTRODUCTION
ENG
8
INTRODUCTION
Bean container cover
Water tank lid
Water tank
Coffee grounds container
Drip tray
Drip tray grid
Powder container cover
Grinding wheel
Bean container
Coffee spout
Handle
Milk pipe
Milk frother
Hot water spout
Milk and cream spout
Power cord
Support for heating of cups,
removable
9
INTRODUCTION
Espresso icon
Long Coffee icon
Hot water icon
Power switch
Screen
Cappuccino icon
Coffee Latte icon
Hot milk/cream icon
Cleaning button
Rotary button ENG
10
FOR FIRST-TIME USE
1. Take out the water hardness test paper from the accessory bag.
2. Put the testing part in the water for 5 seconds.
3. Take out the paper from water, and observe the color. Then set the
water hardness number according to the contrast card. Please refer to
page 29 for water hardness setting.
• The harder the water is, the higher frequency the coffee ma-
chine need descaling.
• You need to re-test the hardness of water once you change
the water resource. If the water hardness setting on the coffee
machine does not match the actual water hardness, it will not
give a good taste of coffee, or even damage the machine.
1. Take off the bean container cover.
2. Add beans to the bean container.
3. Put on the bean container cover.
1. Open the water tank lid.
2. Take out the water tank.
3. Fill the water tank with purified water at room temperature, and insert the
tank back to the machine.
4. Cover the water tank lid.
• Never put the coffee beans that have been specially treated
(e.g. sugar, cocoa) into the bean container.
• Only roasted coffee beans can be put into the bean container,
never put others like rice, soybeans, chocolate beans, nuts,
sugar, and spices.
• Never put hard objects into the bean container, otherwise it
will damage the grinder.
• The bean container cover playing a role as seal. It keeps the
aroma of coffee bean maximally. Please do not lose the cover.
• The maximum capacity of bean container is 250g.
• Only purified water at room temperature is allowed to fill in
the water tank, never fill any other liquid (e.g. warm water, hot
water, milk). It will damage coffee machine. In order to ensure
the taste of coffee, it is recommended to use water at 25°C or
so. Low temperature water will not make a good taste.
• To ensure healthy and the taste of coffee, please change the
water in the tank every day.
• The amount of water in the water tank cannot exceed the
height of the MAX mark.
11
FOR FIRST-TIME USE
• Do not stop water filter cleaning process, thus ensuring the
water filter is well cleaned and pre-brewing, and reaching the
best effect of filtering.
• After 2 months use, the water filter will lose efficacy. There is
a month indicator on the water filter. Please adjust the rotary
button to the month when you insert the water filter.
• Please use the original model of water filters. If you need to
buy one, please contact Oursson Service Center or login
Oursson website.
• Water filters can effectively filter impurities in the water and
reduce the degree of water hardness. If you use a water filter,
your appliance needs no descaling.
1. Adjust the date rotary button at the top of water filter to the
current month.
2. Insert the water filter into the water tank.
• Please adjust the fineness of coffee bean powder according to
the coffee beans.
• Please do not adjust the grinding wheel when the grinder is
running, or the grinder will be damaged.
• If your coffee beans are in dark color, it is recommended to
set to rough mode.
• If your coffee beans are in light color, it is recommended to set
to the fine mode.
• During making coffee, if the coffee outflows very slow or com-
pletely does not outflow, please set it to the rough mode.
• If the coffee outflows very quickly and the color of crema on
the top is very light, please set it to the fine mode.
The fineness adjustment will come into effect after making at
least 2 cups of coffee.
ENG
12
FOR FIRST-TIME USE
• Every time powering on the coffee machine, it will automatical-
ly complete heating and cleaning for one time, and the process
cannot be stopped. The coffee machine can only be used after
finished the above cycle process.
• During the cleaning process, some hot water may flow out of
the coffee spout into the drip tray. Please avoid contacting the
spilling hot water.
Welcomes.
Welcomes.
Self-testing of the coffee machine.
The coffee machine begins to heat up. Heating system will automatically
stop when it reaches the proper temperature to make coffee or steam.
The coffee machine begins to heat up. Heating system will automatically
stop when it reaches the proper temperature to make coffee or steam.
Coffee machine automatically cleans the brewing unit and both coffee
spouts after heating (аutomatic-clean process is to make coffee fresh
enough).
Coffee machine automatically cleans the brewing unit and both coffee
spouts after heating (automatic-clean process is to make coffee fresh
enough).
The coffee machine is ready to makecoffee after cleaning.
The machine is ready. Please begin to make coffee.
Please ensure the power is connected, and then press the power button.
Please ensure the power is connected, and then press the power button.
• As the machine has been tested at factory, there may be a little
coffee powder left over. We promise the machine is brand new.
• The coffee machine will start self-testing and cleaning at the
first-time use, this helps the coffee machine to achieve the best
working condition, and this process cannot be skiped.
• During the cleaning process, some hot water will outflow from
the coffee spout into the drip tray. Please pay attention to avoid
contacting with the spilling hot water, not to be scalded.
1
1
1
1
2
2
2
3
3
3
2
4
4
4
3
5
5
4
13
FOR FIRST-TIME USE
• Every time when powering off the coffee machine, it will
automatically complete cleaning process for one time, and the
process cannot be stopped. This operation is to clean up the
coffee pipelines and remove the coffee grounds.
• During the cleaning process, some hot water will flow out of
the coffee spout into the drip tray. Avoid touching spilt hot
water, so as not to be burned.
Cleaning coffee machine.
When «GOODBYE» is displayed, it means cleaning process has been
completed, and the coffee machine is being switched off.
Please ensure the power is connected, and then press the power button.
1
2
2
1
ENG
14
OPERATION
• Making coffee by touch icon.
• Single time setting of coffee parameters.
• Default parameters of beverage can be set.
Owning the coffee machine, you need just one touch to get a cup of perfect
coffee instantly. Moreover, you can also set the fineness of coffee, the volume
of coffee, the volume of milk, the volume of milk foam, the temperature and
the volume of hot water according to your preference.
You can make any kinds of coffee by touch icons, when the screen shows
«READY».
Take espresso and cappuccino for example to explain how to make coffee
by touch icons.
Press the rotary button to stop making of beverage.
8 items as bellow can be set at single time:
• Set the amount of coffee beans during grinding process
• Set the volume of coffee when making coffee.
• Set the making time of milk foam when making cappuccino.
• Set the making time of milk when making latte.
• Set the temperature of hot water before making hot water.
When screen indicates «ESPRESSO», touch the cappuccino icon.
The screen will change to the content of picture on the left.
When screen shows «CAPPUCCINO», touch the cappuccino icon
again. It will display the content of picture on the left.
No operation in 10 seconds after touching any beverage icon, the
screen will change to the content of picture on left.
Touch espresso icon, when the screen indicates as the left picture.
Press the rotary button, when the screen indicates as the left picture.
1
2
33
4
4
5
5
1
2
15
OPERATION
• Set the hot water volume when making hot water.
• Set the making time of hot milk when making hot milk.
• Set the making time of hot cream when making hot cream.
You can set the fineness of coffee and the volume of beverage before or
during making the beverage at single time, the setting will not be saved.
Change default setting, please refers to the parameter settings.
When grinding the coffee beans, you can rotate the rotary button to
adjust the amount of coffee beans, to left is mild , and to right
is strong . The default value is normal .
When making espresso, cappuccino, coffee long and coffee latte,
the coffeevolume can be adjusted by rotating the rotary button. For
example, the current volume is 40ML, 2 cells to left to reduce to 35ML,
and 2 cells to right to increase to 45ML.
When making cappuccino, milk foam making time can be adjusted by
rotating the rotary button while milk foam outflows. For example, the
current time is 20SEC, 2 cells to left to reduce to 19SEC, and 2 cells to
right to increase to 21SEC.
When making coffee latte, milk making time can be adjusted by rotating
the rotary button. For example, the current value of milk making time is
20SEC, 2 cells to left to reduce to 19SEC, and 2 cells to right to increase
to 21SEC.
Before making hot water, the temperature can be adjusted by rotating
the rotary button. To left is low, to right is high.The default temperature is
normal.
When making hot water, the hot water volume can be adjusted by rotat-
ing the rotary button. For example, the current volume is 150ML, 2 cells
to left to reduce to 145ML, and 2 cells to right to increase to 155ML.
When making hot milk, hot milk making time can be adjusted by rotating
the rotary button. For example, the current time is 20SEC, 2 cells to left
to reduce to 19SEC, and 2 cells to right to increase to 21SEC.
When making milk foam, milk foam making time can be adjusted by ro-
tating the rotary button. For example, the current time is 20SEC, 2 cells
to left to reduce to 19SEC, and 2 cells to right to increase to 21SEC.
1
3
3
4
4
5
5
6
6
7
7
8
8
1
2
2
ENG
16
OPERATION
When making hot water, the hot water volume can be adjusted by rotating
the rotary button. For example, the current volume is 150ML, 2 cells to left to
reduce to 145ML, and 2 cells to right to increase to 155ML.
• The strength and volume of espresso can be set.
• The strength and volume of long coffee can be set.
• The strength and volume of coffee part in cappuccino can be set. Milk
foam making time can be set.
• The strength and volume of coffee part in latte can be set. Milk and milk
foam making time can be set.
• The temperature and the volume of hot water can be set.
• Hot milk making time can be set.
• Hot cream making out can be set.
Please read the following table for the detail setting parameters and adjust-
ment range.
If you want to change the default parameters for detailed method, please
refer to the parameter settings in program settings.
Espresso Around 80°C Mild:
Normal:
Strong:
Volume: 25-120ML
Long Coffee
Cappuccino Around 70°C Mild:
Normal:
Strong:
Volume: 25-240ML
Milk time: 3-120SEC
Cream tiem: 3-120SECCoffee Latte
Hot water Low: around 60°C
Normal: around 70°C
High: around 80°C
Volume: 25-450ML
Hot milk Around 40°C Milk time: 3-120SEC
Hot cream Around 50°C Cream time: 3-120SEC
17
OPERATION
Coffee bean: Moderate roasting
Cup temperature: 55°C
Amount of ground powder: Strong
Brewing temperature: 93°C
Volume of coffee: 50ML
Coffee bean: Moderate roasting
Cup temperature: 55°C
Amount of ground powder: Mild
Milk temperature: 10°C
Milk time: 15S
Volume of coffee: 100ML
Coffee bean: Moderate roasting
Cup temperature: 55°C
Amount of ground powder: Mild
Milk temperature: 10°C
Milk time: 15S
Milk foam time: 15S
Volume of coffee: 100ML
Coffee bean: Moderate roasting
Cup temperature: 55°C
Amount of ground powder: Normal
Brewing temperature: 93°C
Volume of coffee: 100ML
High temperature: To make black tea/green tea
Normal temperature: To drink directly
Low temperature: To make juice or milk powder.
The milk can be heated up to the perfect tempera-
ture for drinking without destroying the nutrition.
ENG
18
OPERATION
The volume of espresso is suggested between 30 to 50ml. Because of the
small volume of espresso, please warm the coffee cup before making coffee.
Press the rotary button, the grinder will begin to grind. At this time, you
can adjust the amount of coffee beans by rotating the rotary button.
Default amount of coffee beans for espresso:
During making coffee, you can adjust the volume of coffee by rotating the
rotary button.
Default volume of espresso: 50ML
When the screen shows as the left picture, it means the espresso is ready,
please enjoy it.
The taste of long coffee is much lighter than espresso. ц
Press the rotary button, the grinder will begin to grind. At this time, you
can adjust the amount of coffee beans by rotating the rotary button.
Default amount of coffee beans for espresso:
This chapter instructs you making various kinds of coffee, hot
water, hot milk and milk foam by this coffee machine. Please
read the following instructions carefully to help you make
high-quality beverages.
The temperature of the hot water is high, please do not touch it
to avoid being scalded.
Before we make all kinds of coffee, please ensure «READY» is
indicated on the display.
• Never use dark roasted coffee beans.
• The coffee beans should be put at dry place and avoid sunlight.
• Only purified water at normal temperature can be used. To make the cof-
fee taste better, it is recommended to use water around 25°C.
• To ensure the quality of coffee, please change the water in water tank
every day.
• Please warm the coffee cup before making coffee for better taste.
• Please adjust the height of the coffee spout according to the height of the
cup in order to avoid coffee splashing.
• Adjustable height of coffee spout: 80-140mm.
Touch Espresso icon for espresso function.
Touch the Long Coffee icon for long coffee function.
1
1
1
1
2
2
2
2
33
44
LONG COFFEE
19
OPERATION
During making coffee, you can adjust the volume of coffee by rotating the
rotary button.
Default volume of espresso: 150ML
When the screen indicates as the top picture, it means the long coffee is
ready, please enjoy it.
1
1
4
2
2
3
3
33
44
4
Hot water can be adjusted to three temperature level, which are
high temperature, medium temperature and low temperature.
Touch the Hot water icon for hot water function.
Default temperature level of the hot water: normal temperature.
When the hot water is at the medium grade, you can adjust the hot water to
high temperature by rotating the rotary button to the right side.
When the hot water is at the normal level, you can adjust the hot water to
low temperature by rotating the rotary button to the left side.
During making hot water, you can adjust the volume of hot water by rotating
the rotary button.
Default volume of hot water: 200ML
• When making cappuccino, steam will erupt from the spout,
please be careful to avoid being scalded.
• When making cappuccino, coffee latte, hot milk and milk foam,
please ensure the milk frother has been set up in the machine
and connected to the milk pipe; please insert the milk pipe into
the milk before making.
• It will achieve the best foam quality if the milk temperature is
below 10°C.
• One electric rapid heater controls the steam separately, and
it needs to be heated under energy saving mode, and this
process cannot be skipped.
1
5
2
3
4
Touch the Cappuccino icon for cappuccino function.
Produce the temperature is not high enough to produce steam, the elec-
tric rapid heater will begin to heat.
Press the rotary button, the grinder will begin to grind. At this time, you
can adjust the amount of coffee beans by rotating the rotary button.
Default amount of coffee beans for cappuccino:
When the screen indicates as the top picture, it means the heating
process is completed.
When the screen indicates as the left picture, it begins to make hot milk
foam.
1
5
2
3
4
ENG
20
OPERATION
• Please use a bigger cup to make coffee latte.
• When making coffee latte, steam will erupt from the spout,
please be careful to avoid being scalded.
If the temperature is not high enough to make steam, the electric rapid
heater begins to heat.
When the screen indicates as the left picture, it means the heating of
coffee latte is completed.
Touch the Coffee Latte icon for coffee latte function.
Press the rotary button, the grinder will begin to grind. At this time, you
can adjust the amount of coffee beans by rotating the rotary button.
Default amount of coffee beans for coffee latte:
When the screen indicates as the left picture, it begins to make hot milk.
When the screen indicates as the left picture, it begins to make hot milk
foam.
During making hot milk, you can adjust the volume of hot milk by rotat-
ing the rotary button.
Default time for making hot milk: 15S
During making milk foam, you can adjust the volume of milk foam by
rotating the rotary button.
Default time for making milk foam: 15S
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
7
7
8
8
9
9
When the screen indicates as the left picture, it begins to make coffee.
During making coffee, you can adjust the volume of coffee by rotating
the rotary button.
Default volume of coffee: 100ML
When the screen indicates as the left picture, it means the cappuccino is
ready, please enjoy it.
6
6During making milk foam, you can adjust the volume of milk foam by
rotating the rotary button.
Default time for making hot milk foam: 20s.
This manual suits for next models
3
Table of contents
Other Oursson Coffee Maker manuals
