Outback Excel 100T User manual

Excel 100T
Assembly and Operating Instructions for
Excel 100T, Excel 200T, and Excel 300T Gas Barbecues
Gas Barbecues
Photographs are not to scale.
Specifications subject to change
without prior notice.
WARNING
• For outdoor use only. Not for commercial use.
• Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
• Warning: accessible parts may be very hot. Keep young children away.
• Do not move the appliance during use.
• Turn off the gas supply at the gas bottle after use.
• Any modification of the appliance, misuse, or failure to follow the instructions may
be dangerous and will invalidate your warranty. This does not affect your statutory
rights.
• Retain these instructions for future reference.
• Leak test your barbecue annually. Check the hose connections are tight and leak
test them each time you reconnect the gas bottle.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open barbecue lid or hood.
4. If odour continues, discontinue use and
contact your local dealer.
FOR YOUR SAFETY
1. Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2. A gas bottle not connected for use shall not be
stored in the vicinity of this or any other
appliance.
0359
Excel 200T Excel 300T

2
 Pre-Assembled
 Quantity and specification varies according to model purchased.
A. Parts List
Quantities vary according to model purchased. Specifications subject to change without prior notice. For more
details on hardware, please see the corresponding Hardware Reference Diagram for your barbecue model.
OUTBACK® EXCEL RANGE
CODE PART QTY EXCEL 100T EXCEL 200T EXEL 300T
Body
Assembly
A1 Lava Rock Rack 1 √√√
A2 Burner 1 √√√
A3 Hood Lower Handle 1 √√√
A4 Hood 1 √* √* √*
A5 Body 1 √* √* √*
A6 Grease Cup Holder 1 √√√
A7 Grease Cup 1 √√√
A8 Cooking Grill 1 √√√
A9 Lava Rock (Shrink Packed) 1 √* √* √*
A10 Hood Upper Handle 1 √* √* √*
A11 Hinge Bracket 2 √* √* √*
A12 Main Electrode & Gas Collector Box 1 √√√
A13 Heat Shield 1 √√√
A14 Warming Rack 1 √√√
A15 Sillcon Bumpers 2 √√√
A16 Body Support 2 √√√
Upper
Trolley
B1 Control Panel 1 √√√
B2 Igniter Button 1 √* √* √*
B3 Main Burner Knob 2 √* √* √*
B4 Trolley Handle 1 √
B5 Main Hose / Regulator Assembly 1 √*√*√*
B6 Side Shelf ▲2 1
B7 Side Burner Knob 1 √
B8 Side Burner Rack 1 √
B9 Side Burner Shelf 1 √
B10 Side Burner 1 √
B11 Side Burner Electrode 1 √
B12 Side Burner Valve/Hose Assembly 1 √*
Lower
Trolley
C1 Short Leg Front 1 √√√
C2 Short Leg Rear 1 √√√
C3 Gas Cylinder Holder 1 √√√
C4 Wheel 2 √√√
C5 Axle 1
√√√
C6 Leg End Loop 1 √√√
C7 Long Leg Front 1 √√√
C8 Long Leg Rear 1 √√√
C9 Bottom Shelf 1 √√√
C10 Gas Bottle Strap 1 √*√*√*
C11 Hose Tidy 1 √√√
C12 Wheel Spacer 2 √√√
Hardware
D1 M6x15 Bolt ▲24 28 28
D2 M5x10 Bolt 4 √√√
D3 M4x10 Bolt 1 √
D4 ST4.0x10 Screw 2 √√√
D5 ST4.8x15 Screw 2 √√√
D6 M8 Locknut 2 √√√
D7 M5 Keps Nut 2 √√√
D8 Shelf Spacer ▲8 4

3
B1. Parts Diagram: Excel 100T
Quantities vary according to model purchased. Specifications subject to change without prior notice. For more
details on hardware, please see ‘Hardware Reference Diagram: Excel 100.’
A8
A1
A9
A2
A13
A6
A7
A12
A3
A14
B1
B2
B3
B4
B5
C1
C3
C4 C6
C7
C9
C5
C2
C8
C10
A4 A5 A10
A11 A15
Pre-assembled body unit
includes the following
individual parts:
A16
C11
C12

4
B2. Hardware Reference Diagram: Excel 100T
Specifications subject to change without prior notice.
D1
D1 D4 D2
D5
D6D7

5
C1. Parts Diagram: Excel 200T
Quantities vary according to model purchased. Specifications subject to change without prior notice. For more
details on hardware, please see ‘Hardware Reference Diagram: Excel 200.’
A8
A1
A9
A6
A7
A3
A2
A13
A12
A14
B1
B2
B3
B5
B6
C1
C3
C4 C6
C7
C9
C5
C2
C8
C10
Pre-assembled body unit
includes the following
individual parts:
A4 A5 A10
A11 A15
A16
C11
C12

6
C2. Hardware Reference Diagram: Excel 200T
Specifications subject to change without prior notice.
D1
D2
D4
D7 D8 D6
D1
D5

7
D1. Parts Diagram: Excel 300T
Quantities vary according to model purchased. Specifications subject to change without prior notice. For more
details on hardware, please see ‘Hardware Reference Diagram: Excel 300.’
A8
A1
A9
A2
A13
A6
A12
A3
A14
B1
B2
B3
B5
B8
B11
B10
B9
B7
B6
A7
C1
C3
C4 C6
C7
C9
C5
C2 C8
C10
Pre-assembled body unit
includes the following
individual parts:
A4 A5 A10
A11 A15
B12
A16
C11
C12

8
D2. Hardware Reference Diagram: Excel 300T
Specifications subject to change without prior notice.
D1
D1 D5 D4 D3
D7 D8 D2 D6

9
E. Assembly
TOOLS NEEDED FOR ASSEMBLY:
Medium size flat blade or Philips/cross-point screwdriver, adjustable spanner or metric spanner set
This barbecue requires two people for assembly. Please remove all packaging materials from all
individual parts before assembling. Please lay out all nuts and bolts and check lengths before
assembling. Whilst every care is taken during the manufacture of this product, care must be taken
during the assembly in case sharp edges are present.
2
C6
C7
Attach the Long Leg Front
(C7) and Long Leg Rear
(C8) to the Leg End Loop
(C6). The legs are a push
fit onto the Leg End Loop.
In case of difficulty, they
may need tapping with a
soft faced mallet. Take
care not to damage the
parts.
C1
C2
C3
Excel 100T  Excel 200T  Excel 300T
1
Attach the Short Leg
Front (C1) and Short Leg
Rear (C2) to the Gas
Bottle Holder (C3). The
legs are a push fit onto
the Gas Bottle Holder. In
case of difficulty; they
may need tapping with a
soft faced mallet. Take
care not to damage the
parts.
Excel 100T  Excel 200T  Excel 300T

10
Attach the Bottom Shelf (C9) to the Gas Bottle
Holder (C3) using the screws (D5). Taking care
not to over tighten.
C9
C3
D1
Attach the leg assembly to the Bottom
Shelf assembly using the screws (D1).
4
3
D5
Excel 100T  Excel 200T  Excel 300T
Excel 100T  Excel 200T  Excel 300T
