Outbound 076-5441-0 User manual

CTC1611078POP 05/15
OWNER’S MANUAL
4-Person Pop-Up Tent
CTC Model: 076-5441-0
CTC1611078POP
NOTICE!
Do Not Return to Retail Store
For Warranty consideration
or for replacement parts call
8 8 8 – 2 8 0 – 7 8 7 6
1-YEAR REPLACEMENT PARTS WARRANTY
This product carries a replacement parts warranty against defects
in materials and workmanship for a period of 12 months from
date of purchase. At its discretion, the manufacturer may provide
replacement parts. Original purchaser will be required to provide
proof of purchase. The consumer will be responsible for shipping
costs incurred outside of the U.S. or Canada.
Warranties DO NOT cover normal wear and tear, misuse, abuse,
inclement weather conditions (i.e. wind, rain, hail, lightning,
tornadoes or hurricanes) or other acts of God, mildew and
rotting,damage or fading caused by prolonged exposure to UV
rays. This warranty gives you specific legal rights. You may also
have other rights which vary depending on locale.
Under no circumstances shall the manufacturer be liable for
any incidental or consequential damages.
The tent is water-repellent. It is not waterproof. During heavy or
continuous rain, some leakage may occur. Avoid contact between
objects and the inside of the tent, as this may result in leakage at
points of contact. In the event of seam leakage, apply
a seam-sealer compound.
Although our products are manufactured according to rigorous
specifications, periods of wind or rain may loosen the stakes and
cause the frame to sink into the ground.This will weaken the
structure’s overall rigidity.Puddles may also form on the roof if
the unit has not been assembled tightly. If pooling should occur,
it is advisable to drain the fly to avoid possible damage to frame
and fabric. Adjustment of guy lines may be necessary. In case of
inclement weather, remove valuables and seek appropriate
shelter. Intended for recreational use only.
CLEANING:
Allow dirt to dry on the fabric after a rainfall before lightly
sweeping it off with a brush. For tougher stains, spray the area
with water and lightly wipe it off with a few strokes.Do not use
washer or dryer. DO NOT SCRUB THE FABRIC. ALWAYS MAKE
SURE IT IS COMPLETELY DRY BEFORE REPACKING.
DANGER!
Stoves, lanterns, candles, grills, heaters and other fuel-burning
devices produce carbon monoxide and will consume the
available oxygen in a tent. Use of such devices in a tent may
cause asphyxiation, carbon monoxide poisoning,and death or
serious and permanent injuries. For this reason:
- DO NOT use fuel-burning devices inside or near this product.
- Your failure to follow this warning may cause death or serious
and permanent injury to you or others.
WARNING!
- KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS
FABRIC. This product is made with flame-resistant fabric,
which meets CPAI-84 specifications. IT IS NOT FIREPROOF!
The fabric will burn if left in continuous contact with any
flame source. The application of any foreign substance to the
fabric may render the flame-resistant properties ineffective.
- Anchor properly at all times and carefully consider campsite
choice. Be aware of possible falling rocks or tree limbs,
lightning strikes, flash floods, strong winds and other hazards
which may cause harm to this product or its occupants.
- Have a minimum of two adults for assembly. During assembly
poles are under tension. If not held firmly in place during
assembly, poles could break or flip up, possibly causing
serious injury.
- Safety glasses may be worn throughout the assembly
process as an additional precaution.
- Exercise care when using electric devices in and near tents.
CTC 7-DAY REPLACEMENT WARRANTY
Unpack and inspect all contents for defects in workmanship and
materials within 7 days of purchase. If any defects are found,
return the product to the place of purchase,along with the proof
of purchase, and it will be replaced free of charge.
For your tent, screen house or canopy DO NOT...
- Pitch near an open fire.
- Use candles or open flames of any kind inside or near it.
- Leave children unattended inside.
- Use fuel-burning,oxygen-consuming devices (heaters, lanterns,
cooking stoves or other flame sources) inside.
- Refuel lamps, heaters or stoves inside.
- Smoke inside.
- Store flammable liquids inside.
- Use water-repellent compounds other than those recommended
for use on outdoor equipment.
- Spray with insecticide.
- Store on concrete floor.
For your tent, screen house or canopy DO...
- Always extinguish campfire before sleeping or leaving the area.
- Exercise care when using electricity and lighting.
- Make certain it is properly ventilated in all weather conditions.
In extreme weather conditions, snow could obstruct airflow and
cause asphyxiation. Clear frequently.
- Anchor securely to provide additional security in changing
climatic conditions. Snow pegs, skis and/or heavy rocks may be
necessary to supplement stakes and guy lines.
- Take down and store properly after camping.
CAMPERS’TIPS
The key to an enjoyable camping experience is planning and
preparation.
Before you go …
Research the area where you intend to camp. Prepare for any
possible weather condition. Be aware of hazards and emergency
protocol. Know the rules and regulations.
Check out your equipment before your trip. Be sure your cook
stove, lanterns, flashlights, air mattress, etc., are in good working
order. Erect your tent to become familiar with setup. Once
you’ve assembled your tent in a dry, well-ventilated area, apply
seam-sealing compound to the stitching of the inside seams
following manufacturer’s directions. Allow to dry thoroughly
before storage. Reapply annually.
Checklists are great planning tools. Here are some areas to
consider.
Camp setup: Tent, chairs, table, ground cloth, entrance mat, tarp,
poles, rope, stakes, bungee cords, duct tape, zip ties,
hammer/tools, bedding.
Kitchen setup, food and beverages: Plan for transport,
preparation, storage and disposal. Remember to pack
fire-starting devices in waterproof containers,and bring pots,
dishes, utensils, can opener,heavy-duty garbage bags and
biodegradable soap. Store your food in lockers or out of sight in
vehicles.
Clothing: Be prepared for all your activities. Include a hat,
sunglasses and quality socks. Dress in layers.
Hygiene: Personal toiletries, rubber gloves, basic first aid items.
Don’t forget your medications.
Miscellaneous: Extra batteries, sewing kit, clothespins, dust
pan/brush and insect-repellant.
Be considerate of others, humans and wildlife.
Remember to clean up and dispose of waste properly.
“Leave no trace behind.”

IMPORTANT NOTES:
* Assemble your tent before camping to become
familiar with the assembly.
* Select a clean, level area for the campsite free
of debris and sharp objects, away from a
natural watercourse.
* Use of a ground cloth is recommended to
prolong the life of the tent floor and provide
additional insulation and moisture protection.
* To prevent damage to the zippers, unzip the
doors and windows of the tent prior to
disassembly allowing air to move freely.
* Seam seal the inside stitched seams of the tent.
This will improve weather resistance. Available
in sporting goods departments. Discolouration
may occur if applied to outside seams.
CTC1611078POP (076-5441-0)
ASSEMBLY INSTRUCTIONS
CAUTION
THIS TENT EXPANDS RAPIDLY !
HOLD TENT FIRMLY
THROUGHOUT PROCESS
Step 4: Stake tent
1) Stake down the tent by inserting a stake through the stake loops, located along the
perimeter of the tent.
2) Hammer the stakes into the ground at a 450angle using a hammer or mallet.
Stakes : 8 each
The fiberglass poles used in this tent are under
constant tension and require an adult to carefully
assemble and fold for storage.
Do not attempt to expand tent unless you are in
a large open area, away from people, flames or
fragile items to avoid injury or property damage.
NOTE: USE CAUTION when removing pop-up tent
from carry bag! It will automatically and very
rapidly expand when the elastic safety strap is
released.
Step 1: Read instructions, remove from
bag, verify contents
1) Read all instructions and cautions carefully
before proceeding.
2) Remove tent from bag.
3) Verify that contents include 1 tent and
8 stakes.
Step 2: Remove strap
1) Carefully remove strap.
Keep a firm grip on the tent poles until you
are in an appropriate open area that is
large enough to expand this tent.
Step 3: Hold the tent at arms length as you release your grip of the tensioned poles to avoid any possible injury or property damage.
Step 6: Secure guy lines
1) Secure tent using all guy lines and stakes.
Tent must be secured for proper function.
Step 5: Fasten the fly
1) Position the fly over the roof.Fasten s-hooks
at the edges of the fly to the tent.
CTC1611078POP 05/15

B
1
7
8 9 10
12 13 14
2 3 4 5
B
11
over
elastic
strap
starting
position
goes down
and back
side view of step 4 side view of step 5
side view of step 7
under
6
side view of step 6
A
B
A
A
BB
Keep stakes in stake bag provided.
Tent must be clean and dry before storage.
Do not store tent on concrete floor.
Step 6: Disassembly - 1) Unfasten the s-hooks. 2) Remove the stakes with a hammer or stake puller. DO NOT pull on tent. 3) Follow the images step by step to fold the tent.
NOTE: DURING STEPS 7-9 TENT POLE TENSION WILL FEEL STRONG. POLES WILL BEND AS PER INSTRUCTIONS.
CTC1611078POP 05/15

SPECIFICATIONS: Floor size: 9’2” x 6’6“(2.80 x 1.98 m)
Centre height: 3’4”(1.04m)
Weight : 6.19lbs(2.81kg)
KEY
NO.
MODEL NO. CTC1611078POP(076-5441-0) QTY.
REQ.
DESCRIPTION
8
HMS4-7
Tent Stakes
PART NO.
REPLACEMENT PARTS
TROUBLESHOOTING GUIDE
PROBLEM
1. CONDENSATION
2. SEAM LEAKAGE
3. MILDEW
4. REPAIRING A TEAR
5. FAULTY ZIPPER
6. FADING FABRIC
7. FLOOR CONDENSATION
Condensation occurs when warm moist air inside tent comes in contact with cooler outside air.Avoid touching walls to reduce contact leakage.Venting doors and
windows will reduce condensation.Store wet clothing outside of tent. A battery powered fan may be helpful.Not applicable to screen houses.
Apply a generous amount of seam sealer on inside seams.Seam sealer may be purchased at any local sporting goods store.
To avoid mildew, store tent/screen house ONLY when thoroughly dry. However, if mildew occurs, use a soft bristle brush or sponge with mild dishwashing soap or Fels
Naptha soap to clean. Let dry thoroughly, and a tent approved water repellent compound may be applied.
For small tears, use a self-adhesive patch kit. We recommend a canvas or awning repair shop for larger tears.
Zippers are self-repairing.If the zipper separates, you can move the slider to the beginning of the zipper tape and rework the zipper.
Do not leave up in direct sunlight longer than necessary. If left in sunlight for prolonged periods of time, fabric will fade and weaken.
8. USE OF STAKES Stakes should be installed at a 45° angle using a hammer or mallet. Stake loops should be kept taut without over-stretching fabric or webbing.This could cause tears or
leakage.To remove safely, use a hammer or stake puller. Do not remove by pulling on the fabric.
SOLUTION
A ground cloth under the floor helps prolong its life, provides additional insulation and moisture protection.The cloth should be smaller than the floor to prevent rain
from running under the tent. Not applicable to screen houses.
