Outform OF2021 Instruction manual
Appearance Page 2
6
Audio
7
HDMI
11
ODC
12
ODC
CONTROL CENTER
0F2021
DC IN
12V
MIN 5A
5
4
TF Card
1
RJ45
8
USB 3.0
9
USB 2.0
10
USB 2.0
3
USB C
2
GPIO
Pwr Error
Pwr On
ODC Pwr Error
ODC Comm
SVC
Reset
WiFi
6
Audio
7
HDMI
11
ODC
12
ODC
CONTROL CENTER
0F2021
DC IN
12V
MIN 5A
5
4
TF Card
1
RJ45
8
USB 3.0
9
USB 2.0
10
USB 2.0
3
USB C
2
GPIO
Pwr Error
Pwr On
ODC Pwr Error
ODC Comm
SVC
Reset
WiFi
2021 All Rights Reserved
6
Audio
7
HDMI
11
ODC
12
ODC
CONTROL CENTER
0F2021
DC IN
12V
MIN 5A
5
4
TF Card
1
RJ45
8
USB 3.0
9
USB 2.0
10
USB 2.0
3
USB C
2
GPIO
Pwr Error
Pwr On
ODC Pwr Error
ODC Comm
SVC
Reset
WiFi
1
11 12 13 14 16 17 18 1915
2 3 4 5 6 7 8 9 10
Appearance Page 3
2021 All Rights Reserved
Appearance Page 4
2021 All Rights Reserved
No. Input and Output Description
1 Antenna Transmission gain for WiFi
2 RJ45 Network Interface RJ45 Network no POE
3 GPIO Interface 6 Pin Phoenix Connector for Signal input and output
4 USB-C Interface For Android System Debug
5 TF-Card Jack SD Card Slot
6 Reset Button Hard Reset OF2021
7 SVC Button For Factory Reset
8 DC Input Outform Standard Power Port – 12V input
9 Power On LED Power Indicator
10 Power Error LED Power Error Indicator
11 3.5mm Audio Jack Analog Audio Out Interface
12 HDMI Interface HDMI Signal Transmission
13 USB 3.0 Interface USB Type A, Powered 5V 2A
14 USB 2.0 Interface 1 USB Type A, Powered 5V 1A
15 USB 2.0 Interface 2 USB Type A, Powered 5V 1A
16 ODC 1 Interface RJ25 Interface, support Power input and output, Audio and
Data transmit
17 ODC 2 Interface RJ25 Interface, support Power input and output, Audio and
Data transmit
18 ODC Communication LED ODC Data transmission Indicator
19 ODC Error LED ODC Data Transmission Error Indicator
Accessories Page 5
2021 All Rights Reserved
HDMI Cable
USB Mini Mouse
Wifi Antenna
AC Cable- 1.5m
ODC RJ25 Cables
OSM Stub-A
12V 5A Power Supply (PSU)
Page 6
2021 All Rights Reserved
Note: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy, and if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
•
The device is slaver device.
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit dierent from that to which
the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
Statement
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
Radiation Exposure Statement
To comply with FCC RF exposure compliance requirements, this grant is applicable to only
mobile configurations. The antennas used for this transmitter must be installed to provide a
separation distance of at least 20cm from all persons and must not be co-located or operating
in conjunction with any other antenna or transmitter.
Note: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy, and if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• The device is slaver device.
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Note: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy, and if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• The device is slaver device.
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Wi-Fi Connection Page 7
2021 All Rights Reserved
If you want to use Wi-Fi to gain access to the internet, you need to establish a
connection to a Wi-Fi network. Follow these easy instructions.
Step 1. Open Wi-Fi Connection.
Step 2. Select Wi-Fi Network.
Wi-Fi Connection Page 8
2021 All Rights Reserved
Step 3. Input Wi-Fi password to connect to the Wi-Fi network.
Connect to Bluetooth device Page 9
2021 All Rights Reserved
Step 1. Open Bluetooth in System configuration menu.
Step 2. Pair a new device by select the corresponding Bluetooth device.
For additional assistance, TBD
