Ovente PF1007 Series User manual

Before use, please read this manual thoroughly and save for future reference.
ovente.com
OVENTE
PF1007 Series
Mini Food
Processor

2ovente.com
PF1007 Series
Mini Food
Processor

Mini Food Processor
HA015 Series
TABLE OF CONTENTS
4
5
7
8
9
..........
..........
..........
..........
..........
Important safety
Parts and features
Using food processor
Care & maintainance
Electrical requirements

IMPORTANT SAFEGUARDS
Whenusingyourminifoodprocessor,basicsafetyprecautionsshouldalwaysbefollowed,includingthefollowing
：
Read all instructions.
To protect against risk of electric shock,do not put base,cord or plug
into water or any other liquids.
Close supervision is necessary when any appliance is being used by
children.
Turn the unit “OFF”and unplug from the outlet when not in use,when
putting on or taking the parts off and before cleaning.To disconnect,turn
the unit “OFF”, grasp plug and pull from wall outlet.
Never yank on cord.
Avoid making contact with moving parts.
Do not operate any appliance with a damaged cord/plug or after the
appliance malfunctions or damaged in any manner.Contact service
provider immediately.
The use of attachments not recommended or sold by the appliance
manufacturer may cause fire,electric shock or injury.
Do not use outdoors.
Do not let cord hang over the edge of a table or counter and don’t let it
touch hot surfaces.
Keep hands and utensils away from moving blades or discs while
processing food to prevent the possibility of severe injuries or damage
to the food processor.A spatula (not included)can be used,but it must
only be used when the food processor is not running.
Blades are sharp.Please handle with care.
Be sure to insert or remove chopping blade and slice/shred disc by
using hubs to avoid injury.
To avoid injury,never place chopping blade or slice/shred disc on base
without putting the bowl properly in place.Make sure that the motor,disc
and chopping blade have stopped completely before removing the
cover.
Be certain that the cover is securely locked in place before operating
the appliance.
When cleaning the food processor,do not put the main body into water
or any other liquids.Wet cloth can be used to wipe the main body.
Water temperature for washing the container or other parts is not
allowed to be over 140°F.Otherwise,they may be deformed.
This appliance is not intended to be used by people (including children)
with reduced physical,sensory and mental capabilities.This appliance
is not for people with lack of experience and knowledge,unless they
have been given supervision or instructions concerning the use of the
appliance by a person responsible for their safety.
Normal operating time:2-minute intervals.
Remove bones,skins or seeds before processing meat,fish or fruits,
etc.
This appliance is intended for household use only and not for
commercial or industrial use.
POLARIZED PLUG
This appliance has a polarized plug,which means that the plug has a
small blade for the hot wire and a wide blade for the neutral wire.To
reduce the risk of electric shock,only insert the plug into the outlet slots
in one direction –wide blade to wide slot and narrow blade to narrow
slot.If the plug does not fit fully in the outlet,reverse the plug.If it still
doesn’t fit,contact a qualified electrician.Do not modify the plug in any
way.
4ovente.com

5ovente.com
PARTS & FEATURES
FOOD
PUSHER
COVER
PULSE
CONTROL
CONTINUOUS FLOW
FOOD CHUTE
CHOPPING BLADE
MIXER
BOWL
FLAT LID
STAINLESS STEEL
SHREDDING DISC
50-Watt Motor –Handles dense slicing,shredding,
chopping and mixing.
Pulse Control –Large pulse control for instant food
processing.
Mixer –effective for mixing and blending ingredients.
Stainless Steel Chopping Blade –The standard blade
that’s best for average jobs like churning out pesto and
hummus.
Stainless Steel Shredding Disc –Sharp shredder for
shredding food before falling into the bowl.
1.5L Large-Capacity BPA-Free Bowl –durable and sturdy
bowl that is perfect for everyday use.
Food Pusher –can be used to push food down the mill
or chute of the mini food processor.
Food Chute –allows the continuous flow of food right
out and into your container.

6ovente.com
Mini Food Processor
PF1007 Series
MINCED GARLIC
Garlic Supplementation is known for
boosting the immune system and reducing
highblood pressure or hypertension.
SALSA
Create delicious party starters with
homemade salsa and tortilla chips!
FRESH TOMATO SAUCE
Homemade tomato sauce is mouthwatering,
satisfying and surprisingly easy to make!
NUTS
Toss whole nuts into the processor,
then add them to your favorite yugort, ice cream,
cookies, salad or to any food taht you love.

7ovente.com
How to Use the Stainless Steel Chopping Blade
The stainless steel chopping blade speeds up everyday kitchen tasks
and is designed to chop,crumb,grind,mince and mix quickly.
Place the bowl over the center post in the base,then turn the bowl
clockwise until you hear it click into place.
Hold the stainless steel chopping blade by its center shaft and slide it
down onto the center post.
Cut the food into 0.8in-10in blocks
Put the food into the bowl;the bowl can accommodate up to 0.44lbs of
food.
Place the lid onto the bowl so that it’s facing the base.Twist the lid
towards the base until you hear it lock into place.
Plug the cord to an electrical outlet.
Press down the food pusher lightly but firmly while
pushing the pulse control for 30-20 seconds.
After processing food,release the pulse control.
1
2
3
4
5
6
7
8
Cut the food into 0.8in-10in block
Put the food into the bowl;the
bowl can accommodate up to
0.44lbs of food.
Place the food chute or the cover onto the bowl so that its tab is facing
How to Use the Stainless Steel Shredding Disc
The stainless steel shredding disc is capable of slicing and shredding
food in a fast and effective way.
Place the bowl over the center post in the base,then turn the bowl
clockwise until you hear it click into place.
To process food into the serving bowl using the food chute,place the
disc stem onto the center post in the bowl.Hold the shredding disc by
the hub or by its edge with the desired side (slide or shred)on top and
push it down on the discharge disc.
Plug the cord to an electric outlet.
Press down the pusher lightly
but firmly while pushing the
pulse control for 30-20 seconds.
After processing the food,release the pulse control.
Cover
Continuous Flow Food
Chute
1
2
3
4
5
6
7
8
USING THE mini FOOD PROCESSOR

8ovente.com
NOTE:Do not attempt to sharpen the cutting edges of the chopping
blade and shredding disc.They are permanently sharpened at the
factory and will be ruined by attempted sharpening.
Be sure that the unit is “OFF”and the cord is unplugged before cleaning.
Whenever possible,rinse parts immediately after processing for easy
cleanup.
Wipe the base and feet with a damp cloth and dry thoroughly.Stubborn
spots can be removed by rubbing with a damp cloth and mild,
non-abrasive cleaner.Do not immerse the base in liquid.
All removable parts can be washed by hand.
Some staining of parts may occur.Use 2tablespoons of baking soda
and 1tablespoon of water,then apply to stains and let it stand overnight.
Rinse and dry.
Do not use rough scouring pads or cleansers on any plastic or metal
parts.
Blades are sharp.Handle carefully.
Be sure to insert or remove chopping blade and shredding disc by using
hubs to avoid injury.
Never place chopping blade or shredding disc on base without putting
the bowl properly in place to avoid injury.Make sure that the motor,
shredding disc,and chopping blade have stopped completely before
removing the cover.
Be certain that the cover is securely locked in place before operating
appliance.
When cleaning the food processor,do not put the main body into water
and any other liquids.A wet cloth can be used to wipe the main body.
Water temperature for washing the container or other parts is not
allowed to be over 140°F.Otherwise,they may be deformed.
Remove bones,skins or seeds before processing meat,fish or fruits,etc.
Normal operating time:2-minute intervals.
Care & maintainance

9ovente.com
ELECTRICAL REQUIREMENTS
Model
PF1007
Turning
speed
2300-
2800r/min
Rated
Voltage
120V
Electric
shock
protection
回
Rated
Frequency
60Hz
Rated
working
time
≤2min
Rated
Power
50W
Rest
period
≥2min
PROTECT THE ENVIRONMENT
This product must not be disposed together with the
domestic waste.This product has to be disposed at
an authorized place for recycling of electrical and
electronic appliances.By collecting and recycling
waste,you help save natural resources,and make
sure the product is disposed in an environmental
friendly and healthy way.

PF1007 Series
MINI Food
ProcessoR

OVENTE WARRANTY
ovente.com
Register your product within 30 days of purchase to activate its one-year limited manufacturer’s warrant at
ovente.com/register
NOTE:WARRANTY IS ONLY VALID IF YOU REGISTERED WITHIN 30 DAYS AFTER PURCHASE.
LIMITED ONE (1) YEAR WARRANTY:
Your product has a one (1) year warranty period from the date of purchase from an authorized retailer.In the event
that the product is defective,feel free to contact us to arrange for a replacement.This warranty only covers defects in
workmanship and materials.The warranty does not include damage due to abuse or misuse,any commercial use or
accidents.
LIMITATIONS
The warranty stated above is the only warranty applicable to this product.Other expressed or implied warranties are
hereby disclaimed.No verbal or written information given by the Manufacturer,its agents or employees shall create a
guarantee or in any way increase the scope and duration of this warranty.Repair or replacement as provided under
this warranty is the exclusive remedy of the consumer.The manufacturer shall not be liable for incidental or conse�
quential damages resulting from the use of this product.Any implied warranty of merchantability or fitness for a
particular purpose on this product is limited to the applicable warranty period set forth above except to the extent
prohibited by law.Consumer rights may vary from state to state.
Customer Support: ovente.com/support
Visit us at ovente.com
Facebook.com/ovente @oventeTweets @Ovente
