Ovente HE24B Series User manual

Before use, please read this manual thoroughly and save for future reference.
ovente.com
he24b series
portable fan
heater

portable FAN HEATER
he24b series
TABLE OF CONTENTS
3
5
6
7
..........
..........
..........
..........
Important safeguards
parts & features
using your fan heater
care & maintenance

3ovente.com
IMPORTANT SAFEGUARDS
Toreducetheriskofburns,fire,electricshock,orinjury,basicsafetyprecautionsshouldalwaysbefollowed,including:
This fan heater is for household use only.
Connect the unit to a single phase AC supply of the voltage specified on the rating plate.
In order to avoid overheating,do not cover the fan heater.
Never leave unattended while in use.Always turn the function switch to 0(off)and unplug it when not in use.
Do not run the cable under carpeting,rugs,runners or the like.Arrange the cable away from high-traffic areas, where it will not
be tripped over.
Do not operate the fan heater with a damaged cable or plug,or if it malfunctions,or has been dropped or damaged in any
manner.
Avoid using an extension cable as it may overheat and cause a fire.
Always use the fan heater on a dry,flat,heat-resistant surface.Do not place the cable near the hot surface of the fan heater.
Use the fan heater in a well-ventilated area.Do not insert objects or block air outlets in any manner.

4ovente.com
IMPORTANT SAFEGUARDS
Toreducetheriskofburns,fire,electricshock,orinjury,basicsafetyprecautionsshouldalwaysbefollowed,including:
Do not place this fan heater near flammable materials,such as furniture or curtains,as this may cause a fire.
Do not use the fan heater in any area where gasoline,paint or other flammable liquids are stored,e.g., garages or workshops.
Do not use this fan heater near a bath,shower or swimming pool.Never place it where it could fall into water.
This fan heater should not be used by people (including children)with reduced physical,sensory or mental capabilities or lack
of experience and knowledge,unless they are supervised or have been given instructions concerning use of the fan heater by
someone responsible for their safety.
Caution –some parts of this fan heater can become very hot and cause burns.Pay careful attention when children are present.
Do not use this fan heater with a programmer,timer,separate remote control system or any other device that switches the fan
heater on automatically,since a fire risk exists if the heater is covered or positioned incorrectly.
Always use this heater in an upright position.
Do not use the fan heater outdoors.
Please note that the fan heater may give off a slight odor due to manufacturing residue.This should stop after one to three uses.

5ovente.com
parts & features
5) FUNCTION SWITCH
Off, fan, 750W heat,
1500W heat
3) POWER INDICATOR LIGHT
Lets you know at a glance
that the unit is on
2) AIR OUTLETS
Circulate hot or cold air according
to the selected setting
4) ADJUSTABLE THERMOSTAT
Select your desired
temperature
1) INTEGRATED CARRY HANDLE
Safely move the unit
between rooms
1
2
3
5
4
6) TIP-OVER SAFETY SWITCH
Place the unit on a flat
surface to ensure that
the switch is pushed in
6

6ovente.com
USING YOUR fan heater
Remove fan heater from its carton and unwind the cord to its full length.
Place on a firm,level desk or table in a stable,upright position.
Make sure the function switch is turned to 0 (off).
Plug the cable into a 110-120V (60Hz) AC power outlet.To avoid an
electrical circuit overload,be sure that no other appliances are plugged
into the same circuit.
FAN
For fan-only operation,without any heat output,turn the function switch to
and rotate the thermostat to your preferred position.The power
indicator light will go on to let you know the fan is operating.
HEATING
Turn the function switch to “I”for the 750W heat setting and “II”for the
1500W heat setting.
To conserve energy use the 750W heat setting initially and then switch to
the 1500W heat setting.
1
2
3
4
THERMOSTAT CONTROL
Before setting the thermostat,allow the heater to operate and
warm up the room.Then set heater to High (the thickest block on
the right of the thermostat).
Once the desired temperature is reached,lower the thermostat
setting until the fan heater stops operating.
The fan heater will cycle on and off to maintain the temperature
you set.

7ovente.com
CARE & MAINTENANCE
Always remove the plug from the outlet and allow the fan
heater to cool completely before cleaning it.
Wipe the fan heater with a soft,damp (not wet)cloth.
WARNING
Do not immerse the fan heater in water.
Do not use any cleaning chemicals such as detergents
or abrasives.
Do not allow the interior to get wet as this could create a
fire hazard.
When not in use,store heater in a cool,dry location with
the power cord properly secured.
TECHNICAL SPECIFICATIONS
Rated Voltage: 120V~60Hz
Wattage: 1500W
Thermal Overload Protector
This heater is fitted with a thermal overload protector,
which will switch off the device if it overheats or is
picked up.To reset,disconnect the plug from the
outlet for a few minutes,remove the cause of the
overheating and plug in the appliance again.

OVENTE WARRANTY
ovente.com
LIMITED ONE (1) YEAR WARRANTY
At Ovente,we aim to make your life easier by producing top-quality housewares,designed with you in mind.We have
pledged to uphold all our offerings to the highest standards,and we back all our fan heaters with a one-(1) year warranty
from the date of purchase from an authorized retailer.This warranty covers defects in workmanship and materials.It does
not include damage due to abuse,misuse,commercial use,accidents or natural wear and tear.In case of replacement,
ship- ping and handling fees may apply.
LIMITATIONS
The warranty stated above is the only warranty applicable to this product.Other expressed or implied warranties are
hereby disclaimed.No verbal or written information given by the Manufacturer,its agents or employees shall create a
guarantee or in any way increase the scope and duration of this warranty.Repair or replacement as provided under this
warranty is the exclusive remedy of the consumer.The manufacturer shall not be liable for incidental or consequential
damages resulting from the use of this product.Any implied warranty of merchantability or fitness for a particular purpose
on this product is limited to the applicable warranty period set forth above except to the extent prohibited by law.Proof
of purchase may be required to validate the order.Promotional items may not be covered under any warranty.Consumer
rights may vary from state to state.
For product support email [e-mail] or call 1-855-926-2626.
Visit us at ovente.com
Facebook.com/ovente @oventeTweets youtube.com/ovente@Ovente
