Overland Tandberg RDX QuikStation 4 User manual

Quick Start Guide
RDX®QuikStation®4
1U Storage Appliance
Step 1
Register the Unit
It is essential to activate your warranty. Technical and warranty
support are not available until the warranty is active:
1. Go to https://www.overlandtandberg.com/service-support/customer-
product-registration/.
2. Click Register.
3. Fill in the information (including serial number) and click Submit.
Your warranty certificate will be emailed to you. Follow the email
instructions to complete the registration process.
Step 2
Unpack the Unit
Place the unit and any supplied RDX cartridges on a secure surface.
WARNING: To reduce the risk of electric shock or damage to
equipment, always remove any power cords while working with the
unit.
WARNUNG: Um das Risiko eines elektrischen Schlags oder Schäden
am Gerät zu vermeiden, ziehen Sie stets den Netzstecker, bevor Sie an
der Einheit arbeiten.
AVERTISSEMENT: Pour réduire le risque de choc électrique ou
endommagement de l'équipement, retirez toujours les cordons
électriques en travaillant avec l'appareil.
Save the packaging materials in case the unit is returned or shipped for
any reason.
Step 3
Install Rails in Rack
The rack version of the RDX QuikStation 4 is designed for use in a
19-inch rack using 1U of rack space.
Rack-mount
Desktop
NOTE: The length of the power cord and the Ethernet cables may restrict
placement.
Ensure that the airflow around
the front and back of the unit is
not obstructed, dust is kept to a
minimum, and there is at least
12cm (4.75 in.) free space in front
of the unit to allow the operators
to safely remove the RDX
cartridges.
1. Determine the 1U area where the QuikStation 4 is to be mounted
and mark the first and third set of holes (left and right sides) on the
front.
2. At the rear, mark the same first and third holes on both sides.
3. Measure the space between the
front and rear rack rails.
•If the measurement is less
than the length of the
QuikStation 4, secure the first
and third mounting rail holes
with M4x12 screws, washers,
and nuts.
•If the measurement is greater
than or equal to the length
of the QuikStation 4, secure
the second and fourth mounting rail holes with M4x12 screws,
washers, and nuts.
4. Align the left-front flange with the two marked holes on the front
rack rail and loosely attach the left-side mounting rail with two
screws.
5. Ensure the mounting rail is level and attach it loosely to the rack
rear with two screws.
6. Repeat Steps 4–5 for the right-side rail.
7. Verify both rails are level and then securely tighten all screws.
Install the Unit in the Rack
1. Lift and position the unit onto the
rails and push it in until the front
brackets are touching the rails.
2. Using the two provided screws,
attach the QuikStation 4 brackets to
the bottom holes in the rack and
tighten them just enough to support
the appliance.
3. Verify that the appliance is level,
and tighten the screws evenly.
WARNING: Do not place anything on top of the rack-mounted unit
when it is extended from the rack.
WARNUNG: Stellen Sie nichts auf die Rack-Einheit, wenn diese aus
dem Rack herausragt.
AVERTISSEMENT: Ne rien poser sur l’unité installée dans le rack
lorsqu’elle est étendue du rack.
QuikStation 4
Mark
Mark
(Front) 1U
Use these holes if the
rack rail’s gap < unit length
Use these holes if the
rack rail’s gap ≥unit length
Front
Step 4
Connect Network Cables and Power Cords
All power connections, cable ports, and cooling vents are located on the
rear panel of the QuikStation 4.
1. Connect one or more of the 1 Gb Ethernet ports to the network
ports of a switch, hub, or router on the same LAN as the host system
being used to manage the QuikStation.
NOTE: For failover protection and maximum performance, connect all four
1GbEnetworkports.
2. Connect the appropriate power cord to the QuikStation 4, and plug
the power cord into either a UPS appliance or properly grounded
AC power source.
3. Turn the power on by pressing the power button/LED on the front
center of the unit.
Install Cartridges
1. Position an RDX cartridge at an empty QuikStation 4 RDX dock
opening.
2. Slide the cartridge in until it locks in place.
3. Repeat Steps 1–2 for each remaining cartridge.
Step 5
Obtain the IP Address
The default QuikStation 4 network configuration is set for dynamic IP
addresses (DHCP), but static IP addresses are also supported. To
determine an IP address:
1. With the appliance off, attach a monitor to the VGA display port.
2. Attach a keyboard as appropriate.
3. Power on the unit by pressing the power button/LED.
After the unit initializes, the IP addresses are displayed.
The IP address may also be obtained using a USB stick with a single
MBR partition formatted with either FAT32 or NTFS.
1. Create an empty
network.info
file on a USB stick.
2. Insert the stick in the USB port on the front of the unit and wait at
least 30 seconds for the network configuration to download to the
network.info
file.
3. Move the USB stick to a host computer and scan the updated
network.info
file to determine the available IP addresses.
1 - AC Power Plug
2 - 1 Gb IPMI Port
3 - USB 2.0 Port (USB1)
4 - USB 2.0 Port (USB0)
5 - 1 Gb Ethernet Ports (eth2)
6 - 1 Gb Ethernet Ports (eth0)
7 - 1 Gb Ethernet Ports (eth3)
8 - 1 Gb Ethernet Ports (eth1)
9 - VGA/Display Port
129567 843
*10401049003*
10401049-003
https://www.overlandtandberg.com
©2022 Overland-Tandberg
10401049-003 RMN-A-01-14
Assign a Static IP Address
If DHCP support is not enabled, set a static IP address for the unit:
CAUTION: Make sure the USB stick file name
network.conf
is all
lowercase letters.
1. Create a file on a USB stick named “
network.conf
” with these
entries:
BOND0_IP4_CONFIG=static
BOND0_IP4_ADDR=nnn.nnn.nnn.nnn
BOND0_IP4_GW=nnn.nnn.nnn.nnn
BOND0_IP4_PREFIX=nn
Replace the variables (“n”) with your desired IP address, gateway,
and prefix as required. For example:
BOND0_IP4_CONFIG=static
BOND0_IP4_ADDR=192.168.10.111
BOND0_IP4_GW=192.168.10.1
BOND0_IP4_PREFIX=24
2. Insert the stick in the USB port on the front of the unit and wait at
least two minutes for the
network.conf
file to update.
3. Remove the USB stick from the front port.
The unit will restart with the updated network settings.
NOTE: If the unit does not reboot automatically, recheck network.conf
filename to ensure it is all lowercase letters.
You may need to use a Linux or MacOS host system to check a filename as
Windows OS can change the filename to uppercase but cannot display it.
The Remote Management Console should now be available at the
static IP address selected. For more information on how to configure
IP addresses, refer to the RDX QuikStation 4 & 8 Product Manual.
Connect to the Remote Management Console
Use a web browser to connect to the Remote Management Console
(RMC) of the RDX QuikStation 4 from any computer on the same
network. Supported operating systems include Microsoft Windows,
Linux, and Apple MacOS.
To connect to the RMC:
1. Obtain the unit’s IP address.
2. On a network host, type the RDX QuikStation IP address in a web
browser’s URL field (for example, “
192.168.10.111
”).
3. Using the default username and password, sign in to the Console.
The default username/password is “
Admin/Admin!
”.
NOTE: Passwords are case-sensitive and should be changed regularly.
Step 6
Configure the RDX QuikStation 4
You can configure your RDX QuikStation 4 as RDX Disks (default) or
RDX Logical Volume (see the RDX QuikStation 4 & 8 Product Manual).
1. Using the RMC, select the device type from the dialog window.
2. Click
OK
.
The system restarts. When done, your selected device configuration
is shown.
NOTE: If you have any RDX cartridges loaded into the RDX QuikStation, the
system will eject the cartridges when it restarts.
Step 7
Connect to iSCSI Targets
In iSCSI terminology, a host computer is referred to as an initiator and
the storage device it connects to as the target.
NOTE: The RDX QuikStation and the host computers must reside on the same
network.
To establish an iSCSI connection in Windows Server:
1. Open the Microsoft iSCSI Initiator and click the
Discovery
tab.
2. Click
Discover Portal
to enter the IP address for the QuikStation 4.
3. Click
OK
.
4. Click the
Targets
tab.
5. Select the target you want to connect to and click
Connect
.
For more information on how to connect to targets, refer to the RDX
QuikStation 4 & 8 Product Manual and your OS documentation.
Prepare for and Perform a Backup
1. If needed, install an approved backup application. Check the
Software Compatibility Matrix using the link available at the top of
the Overview page on Overland-Tandberg Knowledge Base.
2. Launch and configure the backup application software.
For questions regarding software installation, configuration, and
operation, refer to your backup software product documentation or
contact your software provider.
Step 8
For product information, support, and documentation, visit our website:
www.overlandtandberg.com
Additional RDX Cartridges
To purchase RDX media cartridges, contact your Overland-Tandberg
Partner or go to our website listed above.
Warranty and Technical Support
For warranty and technical support information, use the Support tab
on our website listed above.
User Guides and Articles
For detailed information on configuring your RDX QuikStation 4, refer
to the RDX QuikStation 4 and 8 Product Manual. The product manual,
quick start guide, and other knowledge base articles are available at:
https://www.overlandtandberg.com/knowledgebase
Product Information
Product name: RDX QuikStation 4
Model/Type Reference: RMN-A-01-14
Manufacturer: Tandberg Data
European Regulatory Address:
Tandberg Data GmbH, Nikolaus-Groß-Straße 13, 44329
Dortmund, Germany
Power Ratings
Safety Precautions
CAUTION: Be aware of the location of the power ON/OFF switch on
the front of the RDX QuikStation 4 chassis as well as the room’s
emergency power-off switch, disconnection switch, or electrical outlet
used. If an electrical accident occurs, you can then quickly remove power from
the system.
The rack version of the RDX QuikStation 4 is intended for use when mounted
in a standard rack. It may be used on a shelf or table top as long as the area
is free of clutter to ensure proper ventilation.
The unit is intended for indoor use only. Use an appropriate power supply cord
with a grounded plug and a grounded electrical outlet. The outlet must be
near the equipment and easily accessible.
FCC Compliance Notice
This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
Environment Friendly Disposal
You can help protect the environment!
Please remember to respect the local regulations and
hand in the non-working electrical equipments to an
appropriate waste disposal center. The packaging
material is recyclable. Dispose of the packaging in an
environmentally friendly manner and make it available
for the recyclable material collection-service.
Input Voltage 100 - 240 VAC
Input Rated Current 2.0-1.0 A
Rated Input Frequency 50-60 Hz

Other manuals for RDX QuikStation 4

6

This manual suits for next models

1

Other Overland Tandberg Disk Array System manuals

Overland Tandberg RDX QuikStation 4 Guide

Overland Tandberg

Overland Tandberg RDX QuikStation 4 Guide

Overland Tandberg SnapServer DX1 User manual

Overland Tandberg

Overland Tandberg SnapServer DX1 User manual

Overland Tandberg RDX QuikStation 8 User manual

Overland Tandberg

Overland Tandberg RDX QuikStation 8 User manual

Popular Disk Array System manuals by other brands

ATTO Technology Diamond Storage Array S-Class Installation and operating manual

ATTO Technology

ATTO Technology Diamond Storage Array S-Class Installation and operating manual

SE Audiotechnik M-F3 user manual

SE Audiotechnik

SE Audiotechnik M-F3 user manual

HP XP20000/XP24000 Configuration guide

HP

HP XP20000/XP24000 Configuration guide

HP STORAGEWORKS XP24000 user guide

HP

HP STORAGEWORKS XP24000 user guide

HP P2000 G3 reference guide

HP

HP P2000 G3 reference guide

Fujitsu Eternus DX200F Configuration guide

Fujitsu

Fujitsu Eternus DX200F Configuration guide

NetApp E2760 quick start guide

NetApp

NetApp E2760 quick start guide

HP StorageWorks XP12000 Configuration guide

HP

HP StorageWorks XP12000 Configuration guide

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
