OV303R2M Bridge Modem
（TR069）
User Manual
Ver: 1.10

Contents
Chapter 1 Introduction.....................................................1
1.1 Features.........................................................................1
1.2 Encapsulation support...................................................1
1.3 System requirements.....................................................1
1.4 LED status description..................................................2
1.5 Rear panel layout..........................................................2
Chapter 2 Hardware Installation......................................4
Chapter 3 Parameters Setting...........................................5
3.1 Network adaptor TCP/IP configuration........................5
3.2 RFC 1483 Bridge dial-up..............................................9
Chapter 4 Questions & Answers....................................14

Usermanual
1
Chapter 1 Introduction
The device is the ADSL CPE (Customer Premise Equipment) with ATU-R
module, which complies with various ADSL standards, and excellent
interoperation.
1.1 Features
zFull rate ADSL modem
zProvide up to 24Mbps downstream and up to 1.2Mbps
upstream.
zSupport TR069
zComplies with full rate ADSL standards:
ANSI T1.413 ISSUE 2
ITU-T G.992.1 (G.dmt)
ITU-T G.992.2 (G.Lite)
ITU G.992.3 (ADSL2)
ITU G.992.5 (ADSL2+)
1.2 Encapsulation support
RFC 1483 bridge
1.3 System requirements
Recommended system requirements are:
zPentium 233MHz or above
zMemory: 64MB or above
z10M Base-T Ethernet or above
zWin9X, Win2000, WinXP, WinME, WinNT

Usermanual
1.4 LED status description
Indicator Status Description
Off No power
Power On Power on
Blink Ethernet data transferring
LAN On Connected to the network card or
HUB
Blink DSL line is training
ADSL ON DSL line is connected
DATA Blink
DSL data transferring
1.5 Rear panel layout
2

Usermanual
3
Interface Description
Switch Power on/off switch
Power Plug in for power adaptor
Reset
Modem Reset button, switch off then press
“reset” button and switch on 4s to reset the
hardware. The modem will auto restart. This
action will recover the modem’s default
configuration.
LAN LAN interface for connecting to computer or
Switch
Line ADSL connector for connecting to ADSL
telephone line

Usermanual
Chapter 2 Hardware Installation
Please connect your device to computer as following description:
zIf connecting to the splitter, connect the “Line” splitter to wall jack
using one telephone cable
zUse the other telephone cable to connect “MODEM” port of the
splitter and “LINE” port of the modem. The “phone” port of the
splitter can be use to connect the telephone and the splitter by a
telephone cable.
zUse Ethernet cable to connect “LAN” port of the modem and “LAN”
port of your computer.
If do not need to connect to the splitter,
zConnect the modem to wall jack using one telephone cable
zUse Ethernet cable to connect “LAN” port of the modem and “LAN”
port of your compute
4

Usermanual
5
Chapter 3 Parameters Setting
This section will be the guideline for connecting the device to the Internet.
There are two ways to visit Internet via the device.
3.1 Network adaptor TCP/IP configuration
Note: Please collect the necessary information including IP address
/Gateway/DNS server from your ADSL service provider before you
start to configure TCP/IP properties
You can connect the device to Internet without dial-up (It depends on
service your ISP provided).
3.1.1 Dynamical IP configuration
Fallow below steps and your can let your computer get an IP address from a
DHCP server automatically.
Open the “Internet Protocol (TCP/IP) Properties” window, select Obtain
an IP address automatically and Obtain DNS service automatically, click
OK to confirm and save the changes of “Internet protocol (TCP/IP)
properties”.

Usermanual
3.1.2 Static IPconfiguration
Take Windows 2000 as an example, the setting procedures in other
operating systems are similar with the following description. In static
IP address mode, if you have the information of the IP and DNS
address, please follow below steps to configure the TCP/IP
properties
Step 1:
Select Start-Settings-Network and Dial-up connection, Select the icon of
“Local Area Connection” and open it.
6

Usermanual
Step 2:
Select Local Area Connections and open “Local Area connections
Properties” window. Then double click Internet Protocol (TCP/IP).
7

Usermanual
Step 3:
The “Internet Protocol TCP/IP Properties” window will pop up.
Select Use the following IP address and type the IP address, Subnet mask
and default gateway.
Then select Use the following DNS service address and type the DNS server
address.
Step 4:
Click OK to confirm and save the changes of “Internet protocol (TCP/IP)
properties”.
Then you can enjoy the high-speed Internet visiting with your Internet
explorer.
8

Usermanual
9
3.2 RFC 1483 Bridge dial-up
For Windows 95/98/Me, you need to install third party dial up software that
can be obtained from ISP. You can dial up with RFC1483 Bridge protocol
support as follow:
Step 1:
Check your hardware connection followed Chapter 2 Then power on
the modem and wait for the ADSL connection established by the LINK
LED is solid on
Step 2:
Install third-party dial-up program such as Enternet300/500. Please
contact your ADSL service provider if you don’t have the PPPoE dialer.
Step 3:
Dial up by the PPPoE dialer with your correct username/password.
For Windows 2000/XP, use built in PPPoE component as follow:
1) Select Start-All Programs-Accessories-Communications-
Network connections.

Usermanual
2) Select Connect to the Internet, and then click Next.
3) In “New Connection Wizard” window, please select Set up my
connection manually, and then click Next.
10

Usermanual
4) Select Connect using a broadband connection that requires a user
name and password, then click Next.
5) Enter the name of your ISP, and then click Next.
11

Usermanual
6) Enter user name and password, and then click Next.
7) The following window will be shown. Select Add a shortcut to this
12

Usermanual
connection to my desktop, then click Finish. A shortcut of dial-up
connection will be created on the desktop.
8) Double click the icon of dial-up connection, and a message window
will pop up. You can click Connect, just wait for a few seconds; you are
ready to visit the Internet.
13

Usermanual
14
Chapter 4 Questions & Answers
1. Question: Why are all led indicators off?
Answer:
Check the connection between the power adaptor and the power
socket, and then check the power switch is on or not.
2. Question: Why doesn’t the LAN led light?
Answer:
Check the connection between the ADSL modem and your computer,
Hub or Switch.
Check your PC, Hub or Switch running status and make sure that they
are working normally.
3. Question: Why doesn’t the ADSLled light?
Answer:
Check the connection between the ADSL “line” port and the wall jack.
4. Question: Why doesn’t it connect to Internet?
Answer:
Check ADSL Modem setting is right or not.
Press “reset” button, reset hardware into default status.
