Owon HDS1022M-I User manual

HDS-N Dual Channel Series
Handheld Digital Storage
Oscilloscope & Multimeter
User Manual
HDS1022M-I
HDS1022M-N
HDS2062M-N
HDS3102M-N
HDS4202M-N
Note: "I" indicates that the two channels are isolated electrically.
www.owon.com.cn

Feb. 2018 edition Ver1.6.4
Copyright © LILLIPUT Company. All rights reserved.
The LILLIPUT's products are under the protection of the patent rights, including ones which have
already obtained the patent rights and those which are applied for. The information in this manual will
replace all materials published.
The information in this manual was correct at the time of printing. However, LILLIPUT will continue to
improve products and reserves the rights to change specification at any time without notice.
is the registered trademark of the LILLIPUT Company.
Fujian LILLIPUT Optoelectronics Technology Co., Ltd.
No. 19, Heming Road
Lantian Industrial Zone, Zhangzhou 363005 P.R. China
Tel: [phone] Fax: [phone]
Web: www.owon.com.cn E-mail: [email protected]

General Warranty
OWON warrants that the product will be free from defects in materials and
workmanship for a period of 3 years from the date of purchase of the product by the
original purchaser from the OWON Company. The warranty period of accessories
such as probe, battery, adapter is 12 months. This warranty only applies to the
original purchaser and is not transferable to the third party.
If the product proves defective during the warranty period, OWON either will repair
the defective product without charge for parts and labor, or will provide a
replacement in exchange for the defective product. Parts, modules and replacement
products used by OWON for warranty work may be new or reconditioned like new
performance. All replaced parts, modules and products become the property of
OWON.
In order to obtain service under this warranty, Customer must notify OWON of the
defect before the expiration of the warranty period. Customer shall be responsible
for packaging and shipping the defective product to the service center designated by
OWON, and with a copy of customer proof of purchase.
This warranty shall not apply to any defect, failure or damage caused by improper
use or improper or inadequate maintenance and care. OWON shall not be obligated
to furnish service under this warranty a) to repair damage resulting from attempts
by personnel other than OWON representatives to install, repair or service the
product; b) to repair damage resulting from improper use or connection to
incompatible equipment; c) to repair any damage or malfunction caused by the use
of non-OWON supplies; or d) to service a product that has been modified or
integrated with other products when the effect of such modification or integration
increases the time or difficulty of servicing the product.
Please contact the nearest OWON's Sales and Service Offices for services or a
complete copy of the warranty statement.
For better after-sales service, please visit www.owon.com.cn and register the
purchased product online.
Excepting the after-sales services provided in this summary or the applicable warranty
statements, OWON will not offer any guarantee for maintenance definitely declared or hinted,
including but not limited to the implied guarantee for marketability and special-purpose
acceptability. OWON should not take any responsibilities for any indirect, special or
consequent damages.

OWON HDS-N Series Handheld DSO & DMM Contents
Table of Contents
1. DECLARATION OF CONFORMITY ···································1
1.1 Declaration of Conformity··············································································1
1.2 Package Contents························································································· 2
2. SAFETY INFORMATION··················································3
2.1 Safety Symbols and Terms··············································································3
2.1.1 Safety Symbols·····················································································3
2.1.2 Safety Terms·························································································3
2.2 General Safety Information ············································································3
3. GENERAL CHARACTERISTICS·······································6
4. PERFORMING THE GENERAL INSPECTION ·····················7
4.1 Performing the General Inspection···································································7
4.1.1 Check whether there is any Damage on it Due to Transportation·····················7
4.1.2 Make a Check on Accessories··································································7
4.1.3 Make a Check on the Complete Instrument·················································7
5. INPUT CONNECTIONS ···················································8
5.1 Input Connections ························································································8
5.1.1 Input connections ·····················································································8
5.1.2 The connection of 1 kHz/5 V Square-wave test signal ··········································9
5.2 Front Panel and Keys Overview·······································································9
6. USING THE OSCILLOSCOPE········································ 12
6.1 About this Chapter ······················································································12
6.2 Powering Up the Oscilloscope·········································································12
6.3 Oscilloscope Operation Window······································································12
6.4 Menu Description························································································14
6.5 Manually Setting the Vertical System, Horizontal System and Trigger Position ··········15
6.5.1 Setting the Vertical System·········································································15
6.5.2 Setting the Horizontal System and Trigger Position············································15
6.6 Recall factory settings···················································································19
6.7 Input Connections ·······················································································19
6.8 Displaying an Unknown Signal with Auto Set·····················································20
6.9 Automatic Zero-returning of Trigger Horizontal Position and Trigger Level Position ··20
6.10 Automatic Measurements ············································································20
6.11 Freezing the Screen ····················································································21
i

OWON HDS-N Series Handheld DSO & DMM Contents
6.12 Using Average for Smoothing Waveforms························································22
6.13 Using Persistence to Display Waveforms··························································22
6.14 Using Peak Detection to Display Glitches·························································23
6.15 Selecting AC-coupling·················································································24
6.16 Reversing the Polarity of the Displayed Waveform·············································25
6.17 Using Waveform Mathematics Functions·························································26
6.18 Use USB mass storage device to save waveform data··················································27
7. USING THE MULTIMETER ············································ 32
7.1 About this Chapter ······················································································32
7.2 Making Meter Connections············································································32
7.3 Multimeter Operation Window·······································································32
7.4 Making Multimeter Measurements··································································33
7.4.1 Measuring Resistance Values ·································································33
7.4.2 Measuring Diode ··················································································34
7.4.3 On-off Test ··························································································35
7.4.4 Measuring Capacitance ·········································································35
7.4.5 Measuring DC Voltage···········································································36
7.4.6 MeasuringAC Voltage ···········································································37
7.4.7 Measuring DC Current···········································································38
7.4.8 MeasuringAC Current ···········································································39
7.5 Freezing the Readings···················································································40
7.6 Taking a Relative Measurement ······································································41
7.7 SelectingAutomatic/ManualRange Adjustment ··················································42
8. ADVANCED FUNCTION OF OSCILLOSCOPE ·················· 43
8.1 About this Chapter ······················································································43
8.2 Setting the Vertical CH1 and CH2 ···································································43
8.2.1 Setting the Channel Coupling··································································44
8.2.2 Open and Close Settings on Channel ·······················································45
8.2.3 Setting the probe attenuation ··································································45
8.2.4 Setting of Inverted Waveform··································································46
8.3 Make the Math Function Menu Setting·····························································46
8.4 Setting the Trigger System·············································································47
8.5 Triggering Control·······················································································48
8.5.1 Edge Trigger························································································48
8.5.2 Video Trigger ·······················································································49
8.5.3 Alternate Trigger ····················································································51
8.6 Setting the Acquiring Mode············································································53
8.7 Display Setting····························································································54
8.7.1 Display Style························································································54
8.7.2 Persistence ·························································································55
8.7.3 XY Mode·····························································································55
ii

OWON HDS-N Series Handheld DSO & DMM Contents
8.7.4 Cymometer··························································································56
8.8 Waveform Saving Setups···············································································56
8.8.1 Waveform Saving Setups in normal mode ·······················································56
8.8.2 Waveform Saving Setups in FFT mode···························································58
8.9 Function Setting Menu ·················································································59
8.10 Making Automatic Measurements··································································59
8.11 Setting the Cursor Measurements ··································································61
8.11.1 Setting the cursor measurement in normal mode ··············································61
8.11.2 Setting the cursor measurement in FFT mode··················································64
8.12Autoscale ·································································································65
8.13 Record ····································································································67
8.14 Using FFT································································································70
8.15 System State Menu·····················································································76
8.15.1 Real time clock···················································································77
8.16 Setting of Time Base Mode···········································································77
8.17 Data Transmission······················································································79
9. TROUBLE SHOOTING·················································· 80
10. APPENDIX ································································ 81
10.1AppendixA: Specifications···········································································81
10.1.1 Oscilloscope ······················································································81
10.1.2 Meter································································································84
10.1.3 General Specifications ·········································································86
10.2Appendix B: Maintenance and Cleaning··························································87
10.2.1 Maintenance······················································································87
10.2.2 Storage of Oscilloscope········································································87
10.2.3 Replacing the Lithium Battery Unit··························································87
iii

OWON HDS-N Series Handheld DSO & DMM 1-Declaration of Conformity
1. Declaration of Conformity
1.1 Declaration of Conformity
HDS-N Series Handheld Digital Storage Oscilloscope & Multimeter
Manufacturer: Fujian LILLIPUT Optoelectronic Technology Co., Ltd.
Statement of Conformity
Base on the result using appropriate standards, the product is in conformity with
Electromagnetic Compatibility Directive 2004/108/EC
Low Voltage Directive 2006/95/EC
Sample tests
Standards used:
EN61010-1：2001（2nd edition）
Safety Requirements for Electrical Equipment for Measurement, Control, and
Laboratory use-part 1: General Requirements
EN61326-1：2006
Electrical Equipment for Measurement, Control and Laboratory use-EMC
Requirements-part 1: General Requirements
EN61000-3-2：2000+A2：2005
Electromagnetic Compatibility (EMC)-part 3: Limits-Section 2: Limits for Harmonic
Current Emissions (Equipment Input Current less than/equal to 16A per phase)
EN61000-3-3：1995+A1：2001
Electromagnetic Compatibility (EMC)-part 3: Limits-Section 3 Limitation of Voltage
Fluctuations and Flicker in Low-Voltage Supply systems for Equipment with Rated
Current less than or equal to 16A
The tests have been performed in typical configuration.
This conformity is indicated by the symbol CE, i.e. "Conformite Europeenne".
1

OWON HDS-N Series Handheld DSO & DMM 1-Declaration of Conformity
1.2 Package Contents
See the picture below. This picture is only for your reference. If any discrepancy
found between certain picture and product, please look the actual product.
# Description Standard Optional
1 Oscilloscope and Battery ●
2 AC-DC adapter ●
3 Oscilloscope Probe ×2 (grey) ●
4 Multimeter test lead ×2 (black and red) ●
5
USB Mass Storage connect cable
●
6
Extension module for capacitance measurement
●
7
Probe adjustment tools
●
8
USB communication cable or RS-232C communication cable
●
9
Quick Guide
●
10 CD-ROM (software) ●
11 Metal carrying case ●
12 Soft carrying case ●
13 The output terminal of 1 kHz 5 V square-wave test signal ●
Figure 1: Digital Oscilloscope Parts
2

OWON HDS-N Series Handheld DSO & DMM 2-Safety information
2. Safety Information
In order to ensure the correct using and the best efficient service, please carefully read this user's
manual.
2.1 Safety Symbols and Terms
2.1.1 Safety Symbols
These symbols may appear in this manual or on the instrument.
Warning: "Warning" identifies conditions and actions that pose hazards to the users.
Caution: "Caution" identifies conditions and actions that may damage the product or
other properties.
2.1.2 Safety Terms
The following terms may appear on the instrument:
Danger: The term "Danger" is used in this manual to indicate that when you read this
mark, personal injury may be caused to you immediately.
Warning: The term "Warning" is used in this manual to indicate that when you read this
mark, personal injury may not be caused to you immediately, but you need to
be cautionary.
Notice: The term "Notice" is used in this manual to indicate that damages may be
caused on this product or other properties.
2.2 General Safety Information
Carefully read the following safety information in order to avoid any personal injury and damage
on this product or any products connected with it. This product can only be used in the specified
DANGER:
High Voltage
Refer to the
Manual
Protective
Conductor
Terminal
Chassis
Ground
Earth (ground)
Terminal
3

OWON HDS-N Series Handheld DSO & DMM 2-Safety information
applications to prevent any possible dangers.
Warning:
To avoid fire or electrical shock, please use proper power adapter. Use only the power
adapter appointed by the manufacturer and subject to approval of being used in the user's
country.
Warning:
The two channels of the oscilloscope are non-isolated electrically. The channels should adopt
common basis during measuring. To prevent short circuits, the 2 probe ground must not be
connected to 2 different non-isolated DC level.
Warning:
The channels should adopt common basis during measuring. To prevent short circuits, the 2
probe ground must not be connected to 2 different non-isolated DC level.
The diagram of the oscilloscope ground wire connection:
Ground Clip
Signal Input
Electrical Outlet
Probe Oscilloscope AC Adapter
The diagram of the ground wire connection when the battery-powered oscilloscope is
connected to theAC-powered PC through the ports:
Ground Clip
Signal Input
Oscilloscope
(Battery-power) PC Electrical Outlet
Probe
USB/COM Cable
It is not allowed to measure AC power when the oscilloscope is AC powered through the
adapter, or when the battery-powered oscilloscope is connected to the AC-powered PC
through the ports.
Warning:
To avoid fire or electrical shock if a test tool input is connected to more 42V peak (30Vrms)
or on circuits of more than 4800VA:
●Use only insulated voltage probes, test leads and adapter supplied with the test tool, or
indicated by OWON as suitable for the Oscilloscope & Multimeter.
●Before use, inspect voltage probes, test leads and accessories for mechanical damage and
replace when damaged.
●Remove all probes, test leads and accessories that are not in use.
4
