Owon XDM1000 Series User manual

XDM1000 Series
Digital Multimeter
User Manual
XDM1041
For product support, visit:www.owon.com.hk download

General Warranty
We warrant that the product will be free from defects in materials and
workmanship for a period of 3 years (1 year for accessories) from the date of
purchase of the product by the original purchaser from our company. This
warranty only applies to the original purchaser and is not transferable to a
third party.
If the product proves defective during the warranty period we will either repair
the defective product without charge for parts and labour or will provide a
replacement in exchange for the defective product. Parts modules and
replacement products used by our company for warranty work may be new or
reconditioned like new. All replaced parts modules and products become the
property of our company.
In order to obtain service under this warranty the customer must notify our
company of the defect before the expiration of the warranty period. Customer
shall be responsible for packaging and shipping the defective product to the
designated service centre a copy of the customers proof of purchase is also
required.
This warranty shall not apply to any defect failure or damage caused by
improper use or improper or inadequate maintenance and care. We shall not
be obligated to furnish service under this warranty a) to repair damage
resulting from attempts by personnel other than our company representatives
to install repair or service the product; b) to repair damage resulting from
improper use or connection to incompatible equipment; c) to repair any
damage or malfunction caused by the use of not our supplies; or d) to service
a product that has been modied or integrated with other products when the
eect of such modication or integration increases the time or diculty of
servicing the product.
Please contact the nearest Sales and Service Oces for services.
Excepting the after-sales services provided in this summary or the
applica le warranty statements, we will not oer any guarantee for
maintenance declared or hinted, including ut not limited to the implied
guarantee for marketa ility and special-purpose accepta ility. We
should not take any responsi ilities for any indirect, special, or
consequent damages.

Table of Contents
1............................................................................................................Safety Information
1
Safety Terms and Sym ols.........................................................................................1
General Safety Requirements.....................................................................................2
Measurement Limits....................................................................................................3
Main Input Terminals Measurement Limits...............................................................................3
Current Input Terminal Measurement Limits.............................................................................3
Measurement Category................................................................................................3
2.Quick Start...........................................................................................................5
General Inspection.......................................................................................................5
Dimensions...................................................................................................................5
Front Panel Overview...................................................................................................6
Rear Panel Overview....................................................................................................7
User Interface...............................................................................................................8
Power On......................................................................................................................8
Measurement Connections.........................................................................................9
3.Functions and Operations................................................................................11
To Set the Range........................................................................................................11
Measurement Speed..................................................................................................12
Basic Measurement Functions..................................................................................12
Measuring DC Voltage............................................................................................................ 12
Measuring AC Voltage............................................................................................................ 13
Measuring DC Current............................................................................................................ 14
Measuring AC Current............................................................................................................ 15
Measuring Resistance............................................................................................................ 16
Continuity Test........................................................................................................................ 17
Diode Test.............................................................................................................................. 18
Measuring Capacitance..........................................................................................................19
Measuring Frequency and Period...........................................................................................20
Measuring Temperature.......................................................................................................... 21
Dual Display................................................................................................................23
Data Hold....................................................................................................................24
Math.............................................................................................................................24
Max/Min.................................................................................................................................. 24
dB/dBm................................................................................................................................... 24
Relative Value......................................................................................................................... 25
i

Data Record Function................................................................................................26
Manual Record........................................................................................................................26
Auto Record............................................................................................................................ 26
Utility Menu.................................................................................................................28
Language................................................................................................................................ 28
Backlight................................................................................................................................. 28
Clock....................................................................................................................................... 28
Default.................................................................................................................................... 28
Serial...........................................................................................................................................
4.Measurement Tutorial.......................................................................................3
Loading Errors (DC Voltage).....................................................................................30
True RMS AC Measurements....................................................................................31
5.Troubleshooting................................................................................................32
6.Technical Specications..................................................................................33
7.Appendix............................................................................................................35
Appendix A: Enclosure..............................................................................................35
Appendix B: General Care and Cleaning..................................................................35
Appendix C: Line Fuse Replacement...........................................................................35
ii

1.Safety Information
1. Safety Information
Safety Terms and Sym ols
Safety Terms
Terms in this Manual. The following terms may appear in this manual:
Warning: Warning indicates the conditions or practices that could result in
injury or loss of life.
Caution: Caution indicates the conditions or practices that could result in
damage to this product or other property.
Terms on the Product. The following terms may appear on this product:
Danger: It indicates an injury or hazard may immediately happen.
Warning: It indicates an injury or hazard may be accessible potentially.
Caution: It indicates a potential damage to the instrument or other property might
occur.
Safety Sym ols
Sym ols on the Product. The following symbol may appear on the product:
Direct current (DC) Warning risk of electric shock
Alternating current (AC)
Caution risk of danger (refer to this
manual for specic Warning or Caution
information)
Both direct and alternating
current Conforms to European Union directives
Ground terminal Chassis Ground
IEC Measurement Category I. The maximum measurable voltage is
1000 Vpk in the HI -LO terminal.
IEC Measurement Category II. Inputs may be connected to AC mains
power (up to 600 VAC) under Category II overvoltage conditions.
1

1.Safety Information
This product complies with the WEEE Directive (2012/19/EC) marking
equipment. The axed product label indicates that you must not
discard this electrical/electronic product in
domestic household waste.
2

1.Safety Information
General Safety Requirements
Before any operations, please read the following safety precautions to avoid
any possi le odily injury and prevent this product or any other products
connected from damage. In order to avoid any contingent danger, this
product is only used within the range specied.
Use Proper Power Cord. Use only the power cord supplied with the product
and certied to use in your country.
Product Grounded. This instrument is grounded through the power cord
grounding conductor. To avoid electric shock the grounding conductor must
be grounded. The product must be grounded properly before any connection
with its input or output terminal.
Limit operation to the specied measurement category, voltage, or
amperage ratings.
Check all Terminal Ratings. To avoid instrument damage and the risk of
electric shock check all the Measurement Limits and markers of this product.
Refer to the user's manual for the Measurement Limits before connecting to
the instrument. Do not exceed any of the Measurement Limits dened in the
following section.
Do not operate without covers. Do not operate the instrument with covers or
panels removed.
Use Proper Fuse. Use only the specied type and rating fuse for this
instrument.
Avoid exposed circuit. Do not touch exposed junctions and components
when the instrument is powered.
Do not operate if in any dou t. If you suspect damage occurs to the
instrument have it inspected by qualied service personnel before further
operations.
Use your instrument in a well-ventilated area. Inadequate ventilation may
cause increasing of temperature or damages to the device. Please keep well
ventilated and inspect the intake regularly.
Do not operate in wet conditions. In order to avoid short circuiting to the
interior of the device or electric shock please do not operate in a humid
environment.
Do not operate in an explosive atmosphere.
Keep product surfaces clean and dry.
Only the qualied technicians can implement the maintenance.
3

1.Safety Information
Measurement Limits
The protection circuitry of the multimeter can prevent damage to the instrument
and protect against the danger of electric shock when the Measurement Limits
are not exceeded. To ensure safe operation of the instrument do not exceed the
Measurement Limits shown on the front panel it is dened as follows:
Main Input Terminals Measurement Limits
The Input and COM Input terminals are used for voltage resistance
continuity frequency (period) capacitance diode and temperature test
measurements. The Measurement Limit is dened for these terminals:
Input to COM Input Measurement Limit
The measurement limit from Input to COM Input is 1000 VDC or
750 VAC which is also the maximum voltage measurement. This limit can
also be expressed as 1000 Vpk maximum.
Current Input Terminal Measurement Limits
The measurement limit from 10A input terminal to COM Input terminal is 10A
(DC or AC).
The measurement limit from μA mA input terminal to COM Input terminal is
600mA (DC or AC).
Note that the current input terminals will always be at approximately the same
voltage as the COM Input terminal.
Measurement Category
The safety rating of the multimeter:
1000 V, CAT I
IEC Measurement Category I. The maximum measurable voltage is 1000 Vpk in
the HI -LO terminal.
600 V, CAT II
IEC Measurement Category II. Inputs may be connected to AC mains power (up
to 600 VAC) under Category II overvoltage conditions.
Measurement category denition
4

1.Safety Information
Measurement CAT I applies to measurements performed on circuits not directly
connected to the AC mains. Examples are measurements on circuits not derived
from the AC mains and specially protected (internal) mains- derived circuits.
Measurement CAT II applies to protect against transients from energy-
consuming equipment supplied from the xed installation such as TVs PCs
portable tools and other household circuits.
Measurement CAT III applies to protect against transients in equipment in xed
equipment installations such as distribution panels feeders and short branch
circuits and lighting systems in large buildings.
Measurement CAT IV applies to measurements performed at the source of the
low- voltage installation. Examples are electricity meters and measurements on
primary over current protection devices and ripple control units.
5

1.Safety Information
2. Quick Start
General Inspection
After you get a new multimeter it is recommended that you should make a check
on the instrument according to the following steps:
1. Check whether there is any damage caused y transportation.
If it is found that the packaging carton or the foamed plastic protection cushion
has suered serious damage do not throw it away rst till the complete device
and its accessories succeed in the electrical and mechanical property tests.
2. Check the Accessories
The supplied accessories have been already described in the Appendix A:
Enclosure of this Manual. You can check whether there is any loss of
accessories with reference to this description. If it is found that there is any
accessory lost or damaged please get in touch with our distributor
responsible for this service or our local oces.
3. Check the Complete Instrument
If it is found that there is damage to the appearance of the instrument or the
instrument cannot work normally or fails in the performance test please get
in touch with our distributor responsible for this business or our local oces. If
there is damage to the instrument caused by the transportation please keep
the package. With the transportation department or our distributor responsible
for this business informed about it a repairing or replacement of the
instrument will be arranged by us.
Dimensions
200 mm
6

1.Safety Information
86.5 mm
64 mm
Front Panel Overview
2
4
5
1
7
3
6
Figure 2-1 Front panel overview
Ite
m
Name Description
1LCD Display the user interface
2Menu selection
Keys Activate the corresponding menu
7

1.Safety Information
3Measurement
Function Keys
DC or AC voltage measurements
DC or AC current measurements
Resistance continuity and diode
measurements
Capacitance measurements
Frequency/Period measurements
Temperature measurements
4Power utton Turn on/o the multimeter.
5Range/Direction
Keys
When the Range softkey is shown on the right menu
you can press the key to switch between auto
and manual range. Press or keys to enable
manual range and increase or decrease the
measurement range.
When setting a parameter press to move the
cursor press or keys to increase or
decrease the value.
6Operation Keys
Run/Stop Start or stop auto trigger. When the trigger is stopped
the displayed data will be held.
Record Access menus of manual record and auto record.
See page 30 Data Record Function.
Utility Set the auxiliary system function including Language
Backlight Clock Default and Serial port.
Math Perform math operations (Max/Min dB/dBm) on the
measurement results.
Dual Press this key to display the function list on the right
menu select a function if the function is supported
the reading will be displayed in the Vice Display.
7Input Terminals Signal input terminals used for AC/DC current
voltage resistance continuity frequency (period)
capacitance diode and temperature test
measurements.
8

1.Safety Information
Rear Panel Overview
Figure 2-2 Rear panel overview （Take the -U model or instance ）
Ite
m
Name Description
1Communication
interface
-Rmodelscanbeconnectedtoacomputerthroughaserialp
ort;
-UmodelcanbeconnectedtothecomputerviaUSBDevice.
2Line Fuse The fuse rating is 250 V F1AL. To replace the fuse see
page 41 Appendix C: Line Fuse Replacement.
3AC Mains Input AC mains input connector.
User Interface
Trigger Mode
Reading
Range Function
Operation Menus
Unit
Status Icon
Trigger Mode Status Icon
9

1.Safety Information
Figure 2-3 User inter ace (Single display)
Secondary unction
Primary unction reading
Primary unction
Figure 2-4 User inter ace (Dual display)
Power On
(1) Connect the instrument to the AC supply using the supplied power cord.
Warning:
To avoid electric shock the instrument must be grounded
properly.
(2) Press down the power utton at the front panel the screen shows the boot
screen.
Icon Description
Auto record function is running
Manual record
10
Display Description
Trigger Auto trigger

1.Safety Information
Measurement Connections
After selecting the desired measurement function please connect the signal
(device) under test to the multimeter according to the method below. To avoid
instrument damage do not discretionarily switch the measurement function when
measuring.
DC Voltage Measurement
DC Voltage
AC Voltage Measurement
AC Voltage
DC Current Measurement
DC Current
DC Current
AC Current Measurement
AC Current
AC Current
11

1.Safety Information
Resistance Measurement
Resistance
I
Continuity Test
Open or
Closed Circuit
I
Diode Measurement
I
Forward Bias
Capacitance Measurement
Capacitance
Frequency Period Measurement
AC Signal
Temperature Measurement
I
Temp
Transd cer
12

1.Safety Information
3. Functions and Operations
To Set the Range
The instrument provides auto and manual range. In auto range the multimeter
selects a proper range automatically according to the input signal; in manual
range you can use the front panel key or menu softkey to set the range. The auto
range can bring a lot of convenience for users while the manual range provides
higher reading precision.
1st Method: Use the front panel key to set the range.
When the Range softkey is shown on the right menu you can press the
key to switch between auto and manual range. Press or keys to enable
manual range and increase or decrease the measurement range.
2nd Method: Select the range in the measurement function menu.
Select auto range: In the measurement function menu press the Range softkey
select Auto.
Select manual range: In the measurement function menu press the Range
softkey select a range except Auto.
Note:
 When the input signal exceeds the current range "overload” will be displayed.
 By default the range is set to Auto at power-on or after a reset.
 Auto range is recommended if you are not sure about the measurement range
in order to protect the instrument and obtain accurate data.
13

1.Safety Information
Measurement Speed
The instrument provides three types of measurement speed:
"Low" speed is 4 reading/s; "Mid" speed is 16 reading/s; "High" speed is 65
reading/s.
In DCV ACV DCI ACI and resistance measurements the measurement speed is
selectable.
Basic Measurement Functions
Measuring DC Voltage
This section describes how to congure DC voltage measurements.
Operating Steps:
1. Ena le the DCV measurement.
Press on the front panel to enter DCV measurement mode.
2. Connect the test lead.
DC Voltage
3. Set the function.
Press the Function softkey to switch between V and mV.
4. Set the range.
Press the Range softkey to set the range. Auto range automatically selects the
range for the measurement based on the input.
14

1.Safety Information
Note:
 1000 V input protection is available in all ranges.
 10% over range for all ranges except 1000 V range.
 If the reading exceeds 1050 V in 1000 V range "overload" will be displayed.
5. Set the measurement speed.
Press the Speed softkey to switch between Low Mid and High. See page 15 ”
Measurement Speed”.
6. Set the relative value.
Press the Rel softkey to turn on or o the relative operation. For relative
operation the multimeter subtracts the pre-specied value of REL operation
from the actual measurement result and displays the result. See page 29
Relative Value.
Measuring AC Voltage
This section describes how to congure AC voltage measurements.
Operating Steps:
1. Ena le the ACV measurement.
Press on the front panel press it again to enter ACV measurement
mode.
2. Connect the test lead.
AC Voltage
3. Set the function.
Press the Function softkey to switch between V and mV.
15

1.Safety Information
4. Set the range.
Press the Range softkey to set the range. Auto range automatically selects the
range for the measurement based on the input.
Note:
 750 V input protection is available in all ranges.
 10% over range for all ranges except 750 V range.
If the reading exceeds 787.5 V in 750 V range "overload" will be displayed.
5. Set the measurement speed.
Press the Speed softkey to switch between Low Mid or High. See page 14
“Measurement Speed “.
6. Set the relative value.
Press the Rel softkey to turn on or o the relative operation. For relative
operation the multimeter subtracts the pre-specied value of REL operation
from the actual measurement result and displays the result. See page 29
Relative Value.
Measuring DC Current
This section describes how to congure DC current measurements.
Operating Steps:
1. Ena le the DCI measurement.
Press on the front panel to enter DCI measurement mode.
2. Set the function.
Press the Function softkey to switch between A and mA.
3. When the Function is set as A connect the test lead as below.
DC Current
When the Function is set as mA connect the test lead as below.
16
