OWT Project 342 User manual

Project 342 Patio Pergola
V1.00 - Installation Instructions effective May 1, 2015 and reflects information that available as of April 10, 2014. This information is
updated periodically and should not be relied upon after May 1, 2015. Please visit www.OZCOBP.com to get current information
Project 342 Patio Pergola
1

4876.80
192.00
=
(
304.80
12.00
)
4118.01
162.13
2059.01
81.06
2205.10
86.82
2652.71
104.44
=
(
304.80
12.00
)
Overview-Front
V1.00 - Installation Instructions effective May 1, 2015 and reflects information that available as of April 10, 2014. This information is
updated periodically and should not be relied upon after May 1, 2015. Please visit www.OZCOBP.com to get current information
Project 342 Patio Pergola
2

4876.80
192.00
3657.60
144.00
355.58
14.00
typ
152.40
6.00
152.40
6.00
typ
C
L
Overview-Top
V1.00 - Installation Instructions effective May 1, 2015 and reflects information that available as of April 10, 2014. This information is
updated periodically and should not be relied upon after May 1, 2015. Please visit www.OZCOBP.com to get current information
Project 342 Patio Pergola
3

3657.60
144.00
504.83
19.88
260.35
10.25
2743.20
108.00
Overview-Right
V1.00 - Installation Instructions effective May 1, 2015 and reflects information that available as of April 10, 2014. This information is
updated periodically and should not be relied upon after May 1, 2015. Please visit www.OZCOBP.com to get current information
Project 342 Patio Pergola
4

10 5 8 2 3 9 7416
ITEM
NO.
QTY.
PART
NUMBER
DESCRIPTION
1 5 56608 56608
2 5 56637
Post to
Beam Bolt
Inline
3 3 56617
Assembly, 2"
Rafter Clip
4 6 56651
Assembly,
OWT Timber
Bolt 8-10"
5 1 56677
8” Post to
Beam
Coupler
Laredo
Sunset (P2B-
SB-8)
6 5
6x6
Cedar
Post
8 feet
7 2
2x10
Cedar
Board
2x10x16
8 13
2x6
Cedar
Board
2x6x144.00
9 23
2x2
Cedar
Board
2x2x192.00
10 4
2x10
Cedar
Board
2x10x8
Bill of Material
V1.00 - Installation Instructions effective May 1, 2015 and reflects information that available as of April 10, 2014. This information is
updated periodically and should not be relied upon after May 1, 2015. Please visit www.OZCOBP.com to get current information
Project 342 Patio Pergola
5

V1.00 - Installation Instructions effective May 1, 2015 and reflects information that available as of April 10, 2014. This information is
updated periodically and should not be relied upon after May 1, 2015. Please visit www.OZCOBP.com to get current information
Project 342 Patio Pergola
Suggested Tools
(others may be required)
6

56608
56617
10 pack
56637
2 pack
56651
2 pack
56677
2 pack
OZCO
V1.00 - Installation Instructions effective May 1, 2015 and reflects information that available as of April 10, 2014. This information is
updated periodically and should not be relied upon after May 1, 2015. Please visit www.OZCOBP.com to get current information
Project 342 Patio Pergola
7

see template 1
2x10 Cedar Board
16 with Decora cut both ends
2x2 Cedar Board
16 with chamfer on both ends
see template 2
2x6 Cedar Board
12 with Decora cut both ends
12.70
.50
X 45°
both ends
see template 1 2x10 Cedar Board
8 with Decora cut
Cutlist
V1.00 - Installation Instructions effective May 1, 2015 and reflects information that available as of April 10, 2014. This information is
updated periodically and should not be relied upon after May 1, 2015. Please visit www.OZCOBP.com to get current information
Project 342 Patio Pergola
8

63.50
2.50
63.50
R2.50
114.30
R4.50
177.80
7.00
34.93
1.38
12.70
.50
SCALE 1 : 2
Template 1
V1.00 - Installation Instructions effective May 1, 2015 and reflects information that available as of April 10, 2014. This information is
updated periodically and should not be relied upon after May 1, 2015. Please visit www.OZCOBP.com to get current information
Project 342 Patio Pergola
9

138.03
5.43
76.20
R3.00
63.50
R2.50
63.50
2.50
15.88
.63
SCALE 1 : 2
Template 2
V1.00 - Installation Instructions effective May 1, 2015 and reflects information that available as of April 10, 2014. This information is
updated periodically and should not be relied upon after May 1, 2015. Please visit www.OZCOBP.com to get current information
Project 342 Patio Pergola
10

4948.05
194.81
4118.01
162.13
2743.20
108.00
2059.01
81.06
Locate desired
center of structure
if site is not level,
see Ozco Site Leveling instruction
site plan
V1.00 - Installation Instructions effective May 1, 2015 and reflects information that available as of April 10, 2014. This information is
updated periodically and should not be relied upon after May 1, 2015. Please visit www.OZCOBP.com to get current information
Project 342 Patio Pergola
11

Tool Required
3/8" Driver
(Hex Cap Nut)
provided
(OWT Screw)
provided
step 1
V1.00 - Installation Instructions effective May 1, 2015 and reflects information that available as of April 10, 2014. This information is
updated periodically and should not be relied upon after May 1, 2015. Please visit www.OZCOBP.com to get current information
Project 342 Patio Pergola
12

see "Overview-
Front" page for
Beam spacing
2x10x16
Beams
2x10x8
Beams
Tool Required
3/8" Driver
(Hex Cap Nut)
provided
(OWT Screw)
provided
step 2
V1.00 - Installation Instructions effective May 1, 2015 and reflects information that available as of April 10, 2014. This information is
updated periodically and should not be relied upon after May 1, 2015. Please visit www.OZCOBP.com to get current information
Project 342 Patio Pergola
13

see "Overview-
Right" page for
Rafter spacing
Rafter
step 3
V1.00 - Installation Instructions effective May 1, 2015 and reflects information that available as of April 10, 2014. This information is
updated periodically and should not be relied upon after May 1, 2015. Please visit www.OZCOBP.com to get current information
Project 342 Patio Pergola
14

see "Overview-
Top" page for
Purlin spacing
Purlin
chamfer
facing
down
secure with
nails or screws
step 4
V1.00 - Installation Instructions effective May 1, 2015 and reflects information that available as of April 10, 2014. This information is
updated periodically and should not be relied upon after May 1, 2015. Please visit www.OZCOBP.com to get current information
Project 342 Patio Pergola
