Oxy Heli OXY3 SPEED User manual

SP-OXY3-200 OXY3 Speed Fuselage, Yellow
SP-OXY3-227 OXY3 Speed Fuselage, Orange
SP-OXY3-228 OXY3 Speed Fuselage, Green
NOTE: OXY3 SPEED FUSELAGE COMPATIBLE
WITH 285MM MAIN BLADE CLASS ONLY
OXY3 SPEED INSTRUCTION MANUAL
page 1

OXY0307-OXY3-
BOTTOM PLATE TE
TBES2X6-M2X6
SELF TAPPING SCREW
OXY0562-OXY3-CF LOW
PROFILE LANDING GEAR
TBES2X6-M2X6
SELF TAPPING SCREW

REMOVE TAIL BLOCK
REMOVE BREAK AWAY CANOPY
& BOOM CLAMP STIFFENER
page 3

OXY0381
OXY0505
TCEM2X5-M2X5
HEX CAP SCREW
OXY3 TAIL BOOM FUSELAGE
3X TCEM2X5-M2X5
HEX CAP SCREW
(ADD LOCTITE 243)
SLIDE TAIL BOOM IN CASE OF NEED
TO FIND THE VERTIAL FIN AND
SIDE CASE HOES
page 4

8 X TCEM2X8-M2X8
HEX CAP SCREW
( ADD LOCTITE )
DON'T FULLY TIGHTEN IN THIS STEP
PULL BACK TAIL ROTOR BLOCK AND
FULLY TIGHTEN 8 SCREW M2X8 IN BOOM CLAMP
M2X8
page 5
OXY0506-OXY3
Speed Boom Stiffener
OXY0504-OXY3 Speed
Canopy Mount Female

OXY0502 - OXY3
Speed Canopy Pusher
BREAK AWAY CANOPY
TCEM2X5-M2X5
HEX CAP SCREW
TBES2X6-M2X6
SELF TAPPING SCREW

page 7
