Oxygen X-Air C200 User manual

Rev 1.6 2019.06
INSTALLATION AND OPERATION MANUAL
Heat Recovery Unit OXYGEN X-Air C200

1

2
CONTENTS
1. TRANSPORTATION AND STORAGE OF EQUIPEMENT .......................................................................................3
2. UNIT PACKAGE ..................................................................................................................................................4
3. SAFETY REQUIREMENTS ...................................................................................................................................5
4. EU DECLARATION OF CONFORMITY .................................................................................................................6
5. TECHNICAL DATA ..............................................................................................................................................7
5.1. Performance characteristics .................................................................................................................8
5.2. Performance and power consumption .................................................................................................8
5.3. Sound characteristics ............................................................................................................................9
5.4. Dimensions and weight ..................................................................................................................... 10
6. FUNCTIONALITY ............................................................................................................................................. 11
7. INSTALLATION OF THE UNIT .......................................................................................................................... 12
7.1. Selecting the mounting location ........................................................................................................ 12
7.2. Installation incline ............................................................................................................................. 12
7.3. Connecting ducts ............................................................................................................................... 13
7.4. Installing the maintenance and servicing hatch ................................................................................ 14
7.5. Connecting the condensate drain ..................................................................................................... 15
8. CONNECTION OF THE UNIT ........................................................................................................................... 16
8.1. Connecting electric circuit ................................................................................................................. 16
8.2. Connecting the control panel ............................................................................................................ 17
8.3. Connector of comfort functions ........................................................................................................ 18
8.4. Control board electrical wiring diagram ............................................................................................ 19
8.5. Description of control board contacts ............................................................................................... 20
9. OPERATION OF THE UNIT .............................................................................................................................. 21
9.1. Control panel with a knob ................................................................................................................. 21
9.1.1. Operating state indicator .............................................................................................................. 21
9.1.2. Air filter replacing / anti-frost protection indicator ...................................................................... 21
9.1.3. Failure indicator ............................................................................................................................. 22
9.1.4. Additional system settings............................................................................................................. 23
9.2. Control panel with touchscreen display ............................................................................................ 25
9.2.1. Standby mode ................................................................................................................................ 25
9.2.2. Main screen ................................................................................................................................... 26
9.2.3. Settings menu ................................................................................................................................ 27
9.2.4. Setting up weekly operation program ........................................................................................... 27
9.2.5. Failure indication ........................................................................................................................... 28
9.3. Replacing of air filters ........................................................................................................................ 29
10. MAINTEINANCE AND WARRANTY ................................................................................................................. 31
11. CONTACTS ...................................................................................................................................................... 32

3
1. TRANSPORTATION AND STORAGE OF EQUIPEMENT
Heat Recovery Unit (hereinafter – the Unit) is prepared for transportation and storage. Packaging
materials ensure protection against exposure to environment, dust and humidity. The Unit must be
properly secured during transportation to protect it against possible housing deformation or other
mechanical damage.
Transportation conditions: -20oC - +40oC.
Long-term storage conditions: +5oC - +40oC, relative air humidity <= 60%.
IMPORTANT! Sender does not assume any obligations towards damage or loss of the Unit or its part, if
there is no a corresponding record in the consignment document!
CONSIGNMENT ACCEPTANCE:
 Carefully check the received consignment – make sure that the number of packages matches with
the consignment documentation. Upon noticing any non-conformity or damage of the package
(tears, dents or compressed box, detached or reattached packaging tape), inform the courier
immediately and indicate the disrepancies or damages in the consignment document.
 Verify if the right product was delivered. Upon noticing any non-conformity, inform the Sender
immediately.
 Verify if all the supplementary parts listed were delivered. In case of any doubt, contact the Sender
immediately.
 Do not attempt to repair the Unit, damaged during the transportation by yourself!

4
2. UNIT PACKAGE
Heat Recovery Unit Oxygen X-Air C200 1 pc.
Control panel 1 pc.
Contol panel connection cable, 10m 1 pc.
Fastening elements:
L-shaped horizontal installation bracket 4 pcs.
Bolt (type M5), 8 mm 8 pcs.
Spring washer (type M5) 8 pcs.
Condensate drain nozzle, Ø32 1 pc.
Condensate drain gasket, Ø20 1 pc.
Installation manual 1 pc.

5
3. SAFETY REQUIREMENTS
Carefully read and follow safety requirements provided below before installing and while operating the
Unit:
 Do not discard the Installation and operation manual, keep it for future reference.
 The Unit should be installed and operated in compliance with this Installation and operation
manual, following the requirements of effective legislation and standards.
 When connecting the Unit to mains supply, grounding must be installed in compliance with
requirements of effective legislation and standards.
 To prevent accidents and potential damage to the Unit, it should be installed, connected,
maintained and repaired only by qualified technician. Never attempt to do this by yourself!
 Turn off the Unit by using Control panel and wait for fans to stop completely before replacing air
filters.
 Turn off the Unit by using Control panel, wait for fans to stop completely and disconnect the Unit
from mains supply before performing any maintenance.
 Before connecting the Unit make sure that no items will get sucked into the its air intake openings!
 Children may only use the Unit under adult supervision.
 The Unit is not intended to be used by persons (including children) with reduced physical, sensory
or mental capabilities, unless they have been instructed to use of the Unit and under constant
supervision of person held responsible for their safety.
 Only original supplementary parts and consumables, certified by manufacturer should be used.
 The Unit package (cardboard, plastic, foam polystyrene) can pose hazard to children. Dispose of
or recycle the package elements!
 Disused Unit should be disposed of in accordance with requirements of legislation on handling
of waste electrical and electronic equipment.
 IT IS PROHIBITED to operate the Unit with damaged mains supply cable! Switch off the power
circuit-breaker to disconnect mains supply and contact a qualified technician or manufacturer
service centre immediately upon noticing such damage.
 IT IS PROHIBITED to attempt the repair of the damaged Unit or its part, to open its cover! Contact
a qualified technician or manufacturer service centre.

6
4. EU DECLARATION OF CONFORMITY
We, undersigned below, representing the manufacturer of ventilation equipment:
Sviezias oras, JSC
Birzelio 23-osios g. 23G
50220 Kaunas
LITHUANIA
confirm, that heat recovery ventilation device Oxygen X-Air C200 conforms to Europe Union standarts,
directives and regulations:
2009/125/EC – eco-design requirements for energy-related products
ES 1253/2014
2010/30/EU – labelling and standard product information of the consumption of energy and other
resources by energy-related products
ES 1254/2014
2011/65/EU – restriction of the use of certain hazardous substances in electrical and electronic
equipment (RoHS)
EN 50581(2012)
2014/35/EU – harmonization of the laws of the Member States relating to the making available on the
market of electrical equipment designed for use within certain voltage limits
LST EN 60335-1:2012 (EN 60335-1:2012)
LST EN 60335-1:2012/A11:2014
CEO Zilvinas Salialionis
10.05.2018, Vilnius

7
5. TECHNICAL DATA
a) Supplier's name or trade mark OXYGEN
b) Model identifier X-Air C200
c) Specific energy consumption (SEC), SEC class A
Warm climate kWh/m2.a -15.7
Average climate kWh/m2.a -40.0
Cold climate kWh/m2.a -77.7
d) Declared typology Bi-directional,
residential ventilation
e) Type of drive installed or intended to be installed Variable speed drive
f) Type of heat recovery system Recuperative
g) Thermal efficiency of heat recovery % 81
h) Maximum flow rate m3/h 191
i) Electric power input of the fan drive, including
any motor control equipment, at maximum flow
rate
W 106
j) Sound power level (LWA) 49
k) Reference flow rate m3/s 0.0378
l) Reference pressure difference Pa 50
m) Specific power input (SPI) W/(m3/h) 0.353
n) Control factor 0.65
Control typology Local demand control
o) Declared maximum leakage rate:
internal % 2.31
external % 1.16
q) Position and description of visual filter warning See user’s manual
s) Internet address for pre-/dis-assembly
instructions
www.oxygen.lt
v) The annual electricity consumption (AEC)
Warm climate kWh/m2.a 1.9
Average climate kWh/m2.a 2.3
Cold climate kWh/m2.a 7.7
w) The annual heating saved (AHS)
Warm climate kWh/a 20.4
Average climate kWh/a 45.0
Cold climate kWh/a 88.0
According to commission delegated regulation (EU) No. 1254/2014

8
5.1. Performance characteristics
Graph. 1. Ventilation power dependence on the resistance of the installed ventilation system
5.2. Performance and power consumption
Power setting Resistance, Pa Air flow, m3/h El. outlay, W
100%
100 191 101
150 189 99
200 184 98
250 172 100
300 154 98
350 136 96
400 110 97
450 91 97
490 75 98
70%
50 140 46
100 130 46
150 114 44
200 85 44
250 61 41
50%
25 100 24
75 80 24
115 50 22
According to EN13141-7, with G4 class filters installed.
0
100
200
300
400
500
600
40 65 90 115 140 165 190
Pasipriešinimas, Pa
Air flow, m3/h
Performance curves
50%
70%
100%

9
5.3. Sound characteristics
Power
setting
Air duct
Sound power level (LWA)
Octave band, Hz Total
125 250 500 1000 2000 4000 8000
50%
Suppply 34.1 42.8 42.2 41.7 40.9 30.6 17.5 48.2
Extract 13.3 35.6 35 26.8 22.4 14.8 12.6 38.8
Outside 15.1 36.7 32.1 26.9 21.8 14.4 12.6 38.5
Exhaust 28.9 39.7 42 40.7 38.5 28.6 16 46.6
70%
Suppply 39 51.1 51.8 51.2 49.9 43.8 30.4 57.3
Extract 21.5 45.2 44.5 36.6 33.2 22.5 14.2 48.4
Outside 22 44.6 42.8 36.1 33.1 21.7 13.7 47.3
Exhaust 35.4 51.1 51.6 50.4 48.4 41.8 28.7 56.8
100%
Suppply 43 56.1 63.3 58.5 58.7 53.6 41.3 66.3
Extract 30.1 47.7 55.3 46.5 42.4 32.1 21.6 56.7
Outside 29.7 48.1 54.3 45.7 42.4 30.7 20.7 55.9
Exhaust 41.2 53.3 62 58.4 57.6 52.7 40 65.2
According to LST EN13141-7.

10
5.4. Dimensions and weight
Figure 1. Unit dimensions
Body dimensions and weight Length, mm Width, mm Height, mm Weight, kg
OXYGEN X-Air C200 1010 500 254 23
OXYGEN X
-
Air C200
–
left
-
side version
OXYGEN
X
-
Air C200
–
right
-
side version

11
6. FUNCTIONALITY
Function Control
panel with
a rotary
switch
Control
panel with
a LCD
Ventilation
Silent and efficient EC fans 
Stepless power setting adjustment 30-100%  
Power setting at 5% steps within 30-100% range  
Weekly operation program, up to 4 different modes for every week day  
Ventilation boost activation by control panel button  
System balancing by adjusting power of each fan 
Constant air pressure maintenance   *
Display of outdoor, supply, extract and exhaust air temperatures  
Display of relative air humidity indoors  
Display of date and time  
Stepless increase of preheater power 
„WC boost″ activation by turning the light switch on 
„Away″ - reduced ventilation power, when the security system is active 
Adjustment of ventilation power according to CO2 level indoors  *
Adjustment of ventilation power according to humidity level indoors  *
Summer time ventilation – heat exchanger bypass device 
Filtration
G4 class filter (average deposition of synthetic dust <90%) 
M5 class filter (efficiency to filter 0.4 µm diameter particles 40-60%) 
F7 class filter (efficiency to filter 0.4 µm diameter particles 80-90%) 
Visual warning of the necessity to replace the filters 
Filter lifetime metering 
Filter fouling metering  *
Protection functions
Overheat protection 
Anti-frost protection 
Ventilation shutdown function upon activation of fire alarm 
Visual warning of the Unit failure 
Additional functions / features
Possibility to install according to the layout of outdoor ventilation openings
(right / left versions)

* sensors for pressure maintenance and determination of indoor air quality are optional.

12
7. INSTALLATION OF THE UNIT
7.1. Selecting the mounting location
It is recommended to install the Unit in a heated room such as bath, storage room, boiler room or an
attic. Make sure, that there is sufficient space to install not only the Unit itself, but also auxiliary ventilation
system components – noise silencers or air distribution boxes. Make sure that there is a possibility to
connect the condensate drain pipe of the Unit to the internal or external sewerage system.
Operating conditions: +10oC - +30oC, relative air humidity <= 60%.
The Unit should be installed horizontally, with servicing cover looking downwards. 4 L-shape fastening
brackets (provided) should be used to fasten Unit to the ceiling. Use ceiling pins or locking sleeves (not
included), depending on installation surface. It is essential to use vibroinsulation gaskets (not included)
to ensure that Unit vibration will not be transferred to the mounting surface.
7.2. Installation incline
IMPORTANT! After Unit installation, make sure that the condensate drain corner is positioned lower than
remaining Unit corners (refer to Figure 2). This will ensure smooth removal of accumulated condensate.
Corresponding distances must be maintained from ceiling plane, when installing the Unit:
No. Distance from horizontal plane
1 20 mm
2 10 mm
3 0 mm
4 10 mm

13
Figure 2. Horizontal installation diagram
7.3. Connecting ducts
It is recommended to install outside air supply and exhaust ducts as far as possible from each other to
prevent the ingress of contaminated air back to premises. Please refer to local construction regulations.
Make sure that outdoor humidity or precipitation will not get into the Unit, when connecting outside air
supply and exhaust ducts. Make sure that openings in the outside wall are installed lower than the Unit
itself. The air intake opening in the outside wall should be protected against precipitation ingress to
ventilation duct by grille or roof, with mesh to prevent ingress of insects and other small objects.
Figure 3. Air intake duct connection diagram
IMPORTANT! At least 1° ventilation duct incline should be ensured to prevent ingress of outdoor
humidity or precipitation into the Unit.
OXYGEN X
-
Air C200
–
left
-
side version
„
OXYGEN X
-
Air C200
–
right
-
side version

14
IMPORTANT! Both outside air intake and exhaust ducts should be covered with a layer of thermal
insulation of sufficient thickness to prevent condensation of humidity on their walls due to different
outdoor and indoor air temperatures.
7.4. Installing the maintenance and servicing hatch
When installing the Unit ensure enough space for its maintenance. Suspended ceiling in the room should
be installed at least 40 mm from the lowest point of the Unit housing (refer to section 8.2. Installation
incline).
Maintenance and servicing hatch installed in the ceiling should be of suitable size to allow convenient
access to all Unit components. At least 100 mm distance should be ensured from every edge of the Unit.
Figure 4. Installation of maintenance and servicing hatch
IMPORTANT! Owner of the Unit shall ensure the possibility to perform Unit maintenance. If there is not
enough space for Unit maintenance, the manufacturer’s representative is entitled to refuse to perform
maintenance or repairs.

15
7.5. Connecting the condensate drain
The Unit condensate drain should be connected to indoor or outdoor wastewater network. If condensate
drain is installed in non-heated premises or directed outdoors, it must be thermally insulated or equipped
with electric heater.
Install a round rubber gasket into the condensate drain socket, then firmly screw the condensate drain
nozzle in by hand.
Figure 5. Installing the condensate drain
IMPORTANT! Do not use pliers or other similar tools, as excess power applied may damage the unit.
The necessary incline of the condensate drain should be ensured during the installation: at least 2° incline
should be ensured in the horizontal part of the system.
Siphon is the obligatory part of the condensate drain system. It is recommended to use HL138 or similar
type, internally or externally mounted siphon with mechanical odor control damper. Siphon should be
installed according to the diagram “Connecting the condensate drain″, ensuring that the manufacturer
instructions on the incline, distances, necessary inspection hatch for the selected siphon model are
observed.
Figure 6. Connecting the condensate drain

16
8. CONNECTION OF THE UNIT
Mains supply, control panel cable and, if necessary, comfort function connector should be connected to
the Unit, according to the following diagram:
Figure 7. Unit connection
IT IS PROHIBITED to connect any cables or devices to the connectors of the control panel and comfort
functions, despite similarity to any standard connectors. External similarity of connectors does not
guarantee compatibility – the connected devices may fail or damage the Unit. The failure of the Unit due
to incompatible supplementary parts connection will void the warranty!
8.1. Connecting electric circuit
WARNING!!!
 To prevent accidents and potential damage to the Unit, it can only be connected by a qualified
technician. Do not attempt to do that by yourself!
 Mains supply power rating shall comply with the rating indicated in the Unit manual.
 Mains supply should be disconnected when connecting the Unit.
 The Unit should be connected according to diagram provided in the User Manual.
 Only power cable provided with the Unit should be used to connect it to power source.
 Grounding should be installed in compliance with the requirements of effective legislation and
standards when connecting the Unit to mains supply.
 Electric circuit must be equipped with suitable power circuit-breaker.
- Control panel connector (USB)
-
Comfort
f
unctions
c
onnector
(RJ
-
45)
-
Mains c
able
(
230V, 3x1.5mm
2
L+N+PE
)

17
Power supply 230V, 50Hz, 5A
Maximum electric power consumption – fans 106W
Maximum electric power consumption – preheater 500W
IP protection class 20
8.2. Connecting the control panel
It is recommended to install the control panel in residential premises (e.g., corridor or lounge) for
convenient access. It is recommended to install the control panel at 1.5 – 1.6 m height from the floor.
Figure 8. Control panel installation
IT IS PROHIBITED to install control panel in a premises, where relative air humidity exceeds 90%.

18
8.3. Connector of comfort functions
The Oxygen X-Air C200 device supports the following external functionality:
 Fire alarm – emergency shutdown of the Unit upon activation of fire alarm;
 WC boost – ventilation boost activation upon switching on the light in the bathroom;
 CO2 sensor – ventilation power increase based on readings of auxiliary CO2 or humidity
sensors connected;
 Away – reduction of ventilation power when no one is at home. Requires security system to
be installed in the premises.
Functions can be activated by short circuiting the respective digital contacts of RJ45 function connector.
Conn. contact No. Function of ventilation system
1-2 Fire alarm
3-4 WC boost
5-6 CO2 / humidity sensors
7-8 Away
Figure 9. Contacts of functions connector
IMPORTANT! Only passive jumpers or electric relays should be used to activate the function!
IT IS PROHIBITED to connect the functions connector directly to electrical wiring network!
The optional RJ45 adapter can be used for more convenient connection:
Figure 10. Comfort functions RJ45 connector adapter

19
8.4. Control board electrical wiring diagram
Figure 11. Control board electrical wiring diagram
IMPORTANT! Make sure that the Unit is disconnected from mains supply before connecting or
disconnecting system components.
