OxyNov FreeO2 User manual

Quickstart Guide
A B
ED
C
A
Connect the FreeO2on the power ouitlet
1
B2 Connect the oxygen hose before starting
the FreeO2
C3 Press the switch in order to start
the FreeO2
D4 Connect the SpO2sensor
E5 Connect the patient interface 3Conrm your choice
4Select the FreeO2 mode
5Adjust the SpO2target according
to the prescription
6Possibility of limiting the
maximum O2flow rate
2
Select the type of patient
Pediatric: maximum O2 flow rate limited at 10L/min
Adult: maximum O2 flow rate limited at 20L/min
1
Select New patient
To start a new treatment which will record their data
Be careful not to push «Continue» when dealing with a new patient.
Possibility to adjust the alarms.
By default, the O2flow rate alarm
triggers at 80% of initiated
maximum O2flow rate
7
DEVICE START-UP SETTINGS

2
3
4
5
2
3
4
5
1
Delivered O2flow rate
SpO2 target
Actual measured SpO2
SpO2 signal quality
Heart rate
Respiratory rate
Plugged in or battery mode
1Ensure the quality of
the SpO2 signal
Inform the patient of the importance of
good SpO2 measurement
Monitor the bar graph below the value of
the SpO2and the shape of the
plethysmography curve
Differences in the SpO2measurements might be noticable
between the FreeO2and the bedside monitor. This is due to the
difference in calibration of the systems and
averaging of the SpO2measurement
In the event of signal loss or malfunction, FreeO2
switches to safety mode and delivers a constant flow rate
calculated on the average flow rate during the last 15 minutes.
Favor standard oxygen mask
Do not use high concentration oxygen mask
Except during transfert or exercise, always
leave the FreeO2 plugged in, even
when not in use on a patient
Wait for the display on the screen of the
plethysmography curve and the O2flow rate before
positioning the interface
Be careful not to unplug
the oxygen supply while in treatment
To stop the FreeO2,
Return to the Treatment screen and select
«Suspend the treatment»
START TREATMENT MONITORING
MAIN SCREEN
