OYPLA DIY 4713 User manual

Page 1
Manual Version: V1.0
Model Code: 4713
Oypla.com LLP / www.oypla.com
User Manual
Model Code: 4713
3kW Industrial
Heater
Contents
1 Front Cover
2 Safety
Instructions
4 Operating
Instructions
5 Cleaning
Instructions
5 Trouble
Shooting
6 Back Cover

Page 2
Manual Version: V1.0
Model Code: 4713
Oypla.com LLP / www.oypla.com
Safety Instructions
Notice: Ensure you read and fully understand instructions before use
While every attempt is made to ensure the highest degree of protection in all equipment, we cannot
guarantee freedom from injury. The user assumes all risk of injury due to use. All merchandise is sold
on this condition, which no representative of the company can waive or change.
-Make sure all fastenings are tightly in place and that everything is in order before using
the product. This should be checked periodically by an adult.
-Never carry out any alterations or modifications to this product.
-This product is not a toy, and is only to be used for its designated purpose.
-Never leave the product unattended whilst it is switched on. If you have to leave the
product unattended, even for a short while, always switch it off.
-Keep the product out of children’s reach, and do not allow children to operate it.
-Do not place the mains cable on or near any hot surface.
-Do not touch the product if your hands are moist or wet.
-Do not attempt to move the product by pulling on the power cord.
-Do not place the heater next to, or above, an electrical socket.
-Do not cover the heater in any way.
-Do not place the heater close to flammable materials or explosive gases/liquids.
-Only place the heater in a position that will allow for the flow of hot air to not be
blocked.
-Always unplug the heater when it is not in use. Even at the lowest setting, the heater is
still operating, making it a potential fire hazard.
-Clean only with a damp cloth. Do not use strong industrial cleaning substances or
abrasive materials as these may damage the product. Make sure the product is
switched off, unplugged from the socket and been left for an hour before cleaning, to
remove the risk of electrical shock.
-This appliance should only be used by persons aged 8 or above.
-This appliance is not intended for use by children or other persons without assistance
or supervision if their physical, sensory or mental capabilities prevent them from using
it safely.
-If the power cable is damaged, it must be replaced by the manufacturer or its service
agent, or similarly qualified person in order to avoid a hazard.
-Some parts of this product can become very hot and cause burns. Particular attention
must be given where children and/or vulnerable people are present.
-When using the heater for the first time, you may notice a slight emission of smoke.
This is quite normal and it will stop after a short time. The heating element is made
from stainless steel and coated in protection oil during production. The smoke is
caused by the oil when heated.
-This appliance is not suitable for use outdoors in damp weather, in bathrooms or in
other wet or damp environments.
-The appliance can become very hot and therefore should be placed a safe distance
away from any flammable objects or furniture.
Contents
1 Front Cover
2 Safety
Instructions
4 Operating
Instructions
5 Cleaning
Instructions
5 Trouble
Shooting
6 Back Cover

Page 3
Manual Version: V1.0
Model Code: 4713
Oypla.com LLP / www.oypla.com
Contents
1 Front Cover
2 Safety
Instructions
4 Operating
Instructions
5 Cleaning
Instructions
5 Trouble
Shooting
6 Back Cover
-The appliance must not be placed directly below a socket outlet.
-Do not connect the appliance using an on/off timer or other equipment which can
automatically switch the device on.
-The appliance must not be used in rooms where flammable liquids or gases are used or
stored.
-If an extension cord is used, it must be as short as possible and always be fully
extended.
-Do not use the appliance in the immediate surroundings of a bath, a shower or a
swimming pool.
-Make sure the appliance is always under surveillance to keep children and animals
away from it.
-Do not place the appliance on moving vehicles or somewhere easy to be tipped over.
-Never remove the plug by pulling on the cord.
-Keep the heater far away from objects such as curtains where the air inlet can easily be
blocked.
-The power coupler is waterproof when not in use. In order to prevent possible electric
shock or leakage current, never use the appliance with wet or damp hands, or operate
the appliance when there is water, or any liquid, on the power cord.
-Always keep your work area clean and well lit. Cluttered or dark areas invite accidents.
-Appliance plug must match the outlet. Never modify the plug in any way. Do not use
any adapter plugs with the appliance.
-If operating a heater in a damp location is unavoidable, use a residual current device
(RCD) protected supply.
-Avoid unintentional starting. Ensure the switch is in the off position before connecting
the appliance to the power source.
-Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from
moving parts and the air intake.
-Do not move the appliance when it is in operation or when plugged into the mains
supply. Only move the appliance once it has cooled and it has been unplugged.
-Never point the appliance directly at persons nearby.
-Operate only on a stable, level surface.
-Warning –failure to comply with the precautions and instructions provided with this
heater can result in death, serious bodily injury and property loss/damage from
hazards of fire, explosions, burns, asphyxiation, carbon monoxide poisoning and/or
electrical shock.
-Check the heater thoroughly for damage. Do NOT operate a damaged heater.
-Do not insert any objects through the air intake or outlet.
-Only install the heater in a normal, upright position.
-If the product is damaged or defective, please contact cservic[email protected].

Page 4
Manual Version: V1.0
Model Code: 4713
Oypla.com LLP / www.oypla.com
Operating Instructions
Contents
1 Front Cover
2 Safety
Instructions
4 Operating
Instructions
5 Cleaning
Instructions
5 Trouble
Shooting
6 Back Cover
-Dial Operation
0 / Off
Fan
Half Heat
Full Heat
Thermostat

Page 5
Manual Version: V1.0
Model Code: 4713
Oypla.com LLP / www.oypla.com
Cleaning &
Maintenance
Instructions
This heater is intended for use in outdoor open areas or in indoor well-ventilated areas. For indoor use, provide
permanent ventilation openings of at least 25cm²/kW, equally distributed between floor and high level, with a
minimum of 250cm².
Contents
1 Front Cover
2 Safety
Instructions
4 Operating
Instructions
5 Cleaning
Instructions
5 Trouble
Shooting
6 Back Cover
-Before cleaning the appliance, disconnect it from the socket and let it cool down.
-The enclosure can become dirty. Wipe it often with a slightly damp (not wet) sponge or
cloth using water and soft detergents only. Never use harsh cleaning chemicals or
detergents, as these may cause damage to the product.
-After cleaning, dry the appliance with a dry, clean cloth.
-Be very careful not to let the water enter the appliance at any entrance.
-Be careful not to splash water when cleaning the appliance.
-Before putting the heater away for storage, let it cool down sufficiently. Store in a
plastic bag back inside its packaging box, in a well-ventilated, dry place.
Troubleshooting
Problem
Possible cause
Treatment
The heater does not
operate, even when it is
plugged in and the
switch, thermostat are
switched on .
The plug is loose, bad connection
Pull out the plug, check the connection of the
plug and socket. Then connect again.
No power in socket outlet
Insert the plug in a proper socket
The heating element
glowing
The input voltage is too high or too
low
Use power supply according to the rating on the
label
The air inlet grill is blocked
Keep the heater far way from articles like curtain,
plastic bag, paper and other things which can
cover the inlet or can be easily cover on the air
inlet
The appliance didn’t
heat up, or only
ventilator worked
The switch was not put at heating
setting
Turn the switch to heat setting
The thermostat operated
Turn the thermostat and listen if there is
open/close voice. If there is no click and the
thermostat is not damaged, the heater will
automatic switch on when the appliance cooled
down
The self-resetting cut-out operated
Turn the heater off and inspect the blockage of
inlet or outlet. Disconnect the plug and wait at
least 10 minutes for the protection system to
reset before attempting to restart the heater.
Abnormal noise
The appliance is not stands upright
Put the heater on a level surface

Page 6
Manual Version: V1.0
Model Code: 4713
Oypla.com LLP / www.oypla.com
Environmental Protection
Products bearing the symbol shown below means that used electrical and electronic equipment (WEEE)
should not be mixed with general household waste. For proper treatment, recovery and recycling, please take
this product(s) to designated collection points where it will be accepted free of charge. Disposing of this
product correctly will help save valuable resources and prevent any potential negative effects on human
health and the environment, which could otherwise arise from inappropriate waste handling. Please contact
your local authority for further details of your nearest designated collection point. Penalties may be applicable
for incorrect disposal of this waste, in accordance with your national legislation.
Imported by Oypla.com LLP, Uxbridge, UB8 2FX
