Ozito AMC-3000 User manual

AIR
COMPRESSOR
12V
INSTRUCTION MANUAL
SPECIFICATIONS
Voltage: 12V
Max Current: 14Amp
Max Pressure: 150psi
Flow Rate: 35 L/min
Hose Length: 1.5m
Weight: 1.8kg
AMC-3000
STANDARD EQUIPMENT
IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from
the original date of purchase and is intended for DIY (Do It
Yourself) use only. If a product is defective it will be replaced in
accordance with the terms of this warranty.
Warranty excludes consumable parts, for example: valve adaptors.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other
than that specified on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
ozito.com.au
0120
Mini Compressor
Accessories x 3

ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
1. SWITCHING ON & OFF
Connecting to a 12V outlet
Switching On and O󰀨
1 To start the air compressor
press the on/o󰀨 switch to the
on position “I”.
1 Connect the 12V socket to 12V DC outlet which can be found in
your vehicle.
2 Press the on/o󰀨
switch into the o󰀨
position “0” to stop the
compressor.
0
I I
I
0
I I
I
WARNING! COMPRESSED AIR CAN BE DANGEROUS.
NEVER POINT THE OUTLET NOZZLE TOWARDS ANY
PART OF YOUR BODY OR ANOTHER PERSON.
1 Air Hose
2 Carry Handle
3 Pressure Gauge
4 On/O󰀨 Switch
AIR COMPRESSOR
ACCESSORIES
KNOW YOUR PRODUCT OPERATION
5 General Purpose Adaptors
6 Needle Inator
1 2 3 4
56
Note: Check car outlet for su󰀩cent power up to 168W.

2. PRESSURE GAUGE
Using the Pressure Guage
1 Identify the required pressure
for the item to be inated.
3 Once the compressor is
switched on and the item is
being inated, the pressure
reading will increase on the
pressure gauge.
The pressure gauge has dual readings for reading pressures in PSI or
BAR to help match the units of the items required pressure.
2 Once the air hose
is connected, the
pressure guage will
display the current
pressure.
2
0
5
/
5
0
R
1
7
-
3
2
P
S
I
Bar
Psi
2
46
8
10
0
75
50
25
0
150
125
100
Bar
Psi
2
46
8
10
0
75
50
25
0
150
125
100
3. INFLATING TYRES
2 Attach the air hose
by screwing the
end of the hose in a
clockwise direction.
4 Once the pressure
gauge reads the
required pressure,
switch the
compressor o󰀨.
5 Uncrew the air hose
and tighten plastic
cap onto the tyre air
valve.
1 Unscrew the cap on the
tyre air valve.
3 Press the on/o󰀨 switch
into the on position “I”.
0
I I
I
0
I I
I
Note: The required pressure should be labeled on the surface of the
item.

5. REPLACING FUSE
AMC-3000
4. INFLATING SPORTING EQUIPMENT
5 Switch the
compressor o󰀨 and
remove the adaptor
from the inated
item.
2 Connect the 12V
socket to a power
supply.
3 Insert the connected
adaptor into the
inatable item.
1 Screw the required adator
clockwise into the end of
the air hose.
3 valve adaptors are supplied with the automotive mini compressor for
inating sporting equipment.
4 Press the on/o󰀨 switch
into the on position “I”
to inate the item to the
required pressure.
NOTE: The same proccess can be used to inate balloons or inatable
toys using the general purpose adaptors instead of the ball
adaptor.
0
I I
I
WARNING! BEFORE CONNECTING OR DISCONNECTING
ACCESSORIES, ALWAYS MAKE SURE THAT THE
COMPRESSOR IS OFF.
1 Unscrew the top of the 12V socket to expose the fuse.
The 12V socket is tted with a 15A fuse to protect the air compressor.
If the compressor has stopped working, the fuse may need to be
replaced.
2 Replace the 15A fuse and screw the top back onto the 12V socket.
WARNING! ENSURE THE TOOL IS SWITCHED OFF AND
DISCONNECTED FROM THE POWER SUPPLY BEFORE
PERFORMING ANY OF THE FOLLOWING STEPS.

DESCRIPTION OF SYMBOLS
CARING FOR THE ENVIRONMENT
Power tools that are no longer usable should not be disposed of
with household waste but in an environmentally friendly way. Please
recycle where facilities exist. Check with your local council authority
for recycling advice.
Recycling packaging reduces the need for landll and raw materials.
Reuse of recycled material decreases pollution in the environment.
Please recycle packaging where facilities exist. Check with your
local council authority for recycling advice.
TROUBLESHOOTING
Cleaning
• Keep the ventilation vents of the Compressor clean at all times, if
possible, prevent foreign matter from entering the vents.
• After each use, blow air through the Compressor housing to ensure
it is free from all dust particles which may build up. Build up of dust
particles may cause the Compressor to overheat and fail.
• If the enclosure of the Compressor requires cleaning do not use
solvents but a moist soft cloth only. Never let any liquid get inside the
Compressor; never immerse any part of the Compressor into a liquid.
Note: Ozito Industries will not be responsible for any damage or
injuries caused by the repair of the Compressor by an unauthorised
person or by mishandling of the Compressor.
Problem Cause Solution
The compressor
does not start
Compressor not
connected to the power
Connect the 12V
socket to a 12V DC
outlet
Insu󰀩cient supply
voltage
Try another 12V
outlet
Fuse needs replacing Replace Fuse
The compressor
starts but there is no
pressure
Loose hose
connections
Check the
compressed air
hose and adaptor
and replace if
necessary
The seals are damaged Check the seals
and have any
damaged seals
replaced by a
service centre
MAINTENANCE
WARNING! BEFORE CLEANING YOUR COMPRESSOR
OR CARRYING OUT ANY MAINTENANCE
PROCEDURE, ENSURE THE COMPRESSOR IS
SWITCHED OFF AND DISCONNECTED FROM THE
POWER SUPPLY.
WARNING! STORE THE COMPRESSOR ONLY IN A
DRY LOCATION WHICH IS NOT ACCESSIBLE TO
UNAUTHORISED PERSONS.
WARNING! WAIT UNTIL THE COMPRESSOR HAS
COMPLETELY COOLED DOWN TO PREVENT BURNS.
Warning
Read instruction manual
VVolts WWatts
dc Direct current mA Milliamperes
Indoor use only
Electrical Emissions
Conformity (EMC)
SPARE PARTS
Spare parts can be ordered from the Special Orders Desk
at your local Bunnings Warehouse.
For further information, or any parts not listed here, visit
www.ozito.com.au or contact Ozito Customer Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]

This appliance is not intended for use by young or inrm persons unless
supervised by a responsible person to ensure that they can use the appliance
safely. Young children should be supervision to ensure that they do not play with
play with the appliance.
• When using the compressor, ensure you are parked in a safe, well lit location, o󰀨
the road and with the hand brake engaged.
• Ensure your personal safety is not at risk and never use the Automotive
MiniCompressor while the car is in motion.
• Do not place the hose end against any part of your body when turned on, as this
may infuse air into your blood stream putting your health at serious risk.
• Do not make any alterations to this Compressor. Only use the adaptors supplied
with this product.
• Use this product only in accordance with operation instructions included in this
manual.
• If the vehicle fuse is blown, only replace with identical rated fuse.
• Inspect each part before use. Do not use if bent, broken, melted, burnt or if the unit
appears to be damaged.
• Check the tyre pressure before inating. Never exceed the suggested pressure of
the item being inated. If suggested pressure is exceeded, the item being inated
may burst.
• Do not bend or pinch the air hose while the Compressor is in use.
• It is not suggested that the Compressor work continuously for more than 30
minutes. If 30 minutes of use has been reached, turn it o󰀨 and let it cool for 8
minutes before using again.
• If the Compressor is making abnormal sounds or its temperature if quite high, turn
o󰀨 the power straight away and let it cool for at least 10 minutes before trying again.
Improper use may result in damage of the Compressor.
• Do not leave unattended and operating. Keep out of reach of children.
• Put the Compressor in a dry place if it is not in use for an extended period of time.
• Keep the Compressor away from ammable liquid or gas. Do not allow the
Compressor to become wet.
• Never put the connector and adaptors into your mouth, ear or eye. They are not
toys.
AIR COMPRESSOR SAFETY WARNINGS
GENERAL POWER TOOL SAFETY WARNINGS-PERSONAL SAFETY
ELECTRICAL SAFETY
WARNING! When using mains-powered tools, basic safety precautions, including the
following, should always be followed to reduce risk of re, electric shock, personal injury
and material damage.
Read the whole manual carefully and make sure you know how to switch the tool o󰀨 in an emergency, before
operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
The electric motor has been designed for 12V only. Always check that the power supply corresponds to the
voltage on the rating plate.
If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid
a hazard.
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the warnings refers
to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to
lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will
reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the
risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase
the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the o󰀨-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your
nger on the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct power tool
will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and o󰀨. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands
of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and
any other condition that may a󰀨ect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operations di󰀨erent from those intended could result in a hazardous situation.
5. Service
a. Have your power tool serviced by a qualied repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
